RZJ95R-GKPNKQ (1996)
Toyota Land Cruiser 90
(9604- )RZJ95,VZJ95..ATM
A343F
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 32000 - CONVERTER ASSY, TORQUE | ||||
| 32000-35160 |
RZJ95..ATM |
1 | ||
| 32000-35160 |
RZJ95..ATM..ARL |
1 | ||
| 32101 - GEAR SUB-ASSY, DRIVE PLATE & RING | ||||
| 32101-26010 |
RZJ95..ATM |
1 | ||
| 32101-26010 |
RZJ95..ATM..ARL |
1 | ||
| 32101A - BOLT(FOR DRIVE PLATE & TORQUE CONVERTER SETTING) | ||||
| 90119-09009 |
VZJ95..ATM;RZJ95..ATM..ARL *9-1.25PX12.8-8.8,YELLOW |
5 | ||
| 90119-09010 |
VZJ95..ATM;RZJ95..ATM..ARL *9-1.25PX12.8-9,GREEN |
1 | ||
| 90119-09010 |
RZJ95,VZJ95..ATM..(ARL,GCC) *9-1.25PX12.8-9,GREEN |
1 | ||
| 90119-09010 |
KZJ95..MA;RZJ95,VZJ95..ATM *9-1.25PX12.8-9,GREEN |
1 | ||
| 90119-09009 |
RZJ95..ATM..ARL *9-1.25PX12.8-8.8,YELLOW |
5 | ||
| 90119-09010 |
RZJ95..ATM..ARL *9-1.25PX12.8-9,GREEN |
1 | ||
| 90119-09009 |
KZJ95..MA;RZJ95,VZJ95..ATM *9-1.25PX12.8-8.8,YELLOW |
5 | ||
| 90119-09010 |
RZJ95,VZJ95..ATM *9-1.25PX12.8-9,GREEN |
1 | ||
| 90119-09009 |
RZJ95,VZJ95..ATM..(ARL,GCC) *9-1.25PX12.8-8.8,YELLOW |
5 | ||
| 90119-09009 |
RZJ95,VZJ95..ATM *9-1.25PX12.8-8.8,YELLOW |
5 | ||
| 32101A - BOLT(FOR DRIVE PLATE & TORQUE CONVERTER SETTING) | ||||
| 90119-09009 |
VZJ95..ATM;RZJ95..ATM..ARL *9-1.25PX12.8-8.8,YELLOW |
5 | ||
| 90119-09010 |
VZJ95..ATM;RZJ95..ATM..ARL *9-1.25PX12.8-9,GREEN |
1 | ||
| 90119-09010 |
RZJ95,VZJ95..ATM..(ARL,GCC) *9-1.25PX12.8-9,GREEN |
1 | ||
| 90119-09010 |
KZJ95..MA;RZJ95,VZJ95..ATM *9-1.25PX12.8-9,GREEN |
1 | ||
| 90119-09009 |
RZJ95..ATM..ARL *9-1.25PX12.8-8.8,YELLOW |
5 | ||
| 90119-09010 |
RZJ95..ATM..ARL *9-1.25PX12.8-9,GREEN |
1 | ||
| 90119-09009 |
KZJ95..MA;RZJ95,VZJ95..ATM *9-1.25PX12.8-8.8,YELLOW |
5 | ||
| 90119-09010 |
RZJ95,VZJ95..ATM *9-1.25PX12.8-9,GREEN |
1 | ||
| 90119-09009 |
RZJ95,VZJ95..ATM..(ARL,GCC) *9-1.25PX12.8-8.8,YELLOW |
5 | ||
| 90119-09009 |
RZJ95,VZJ95..ATM *9-1.25PX12.8-8.8,YELLOW |
5 | ||
| 32101C - BOLT, HEXAGON(FOR DRIVE PLATE SETTING) | ||||
| 90105-10276 |
RZJ95..ATM *10-1.25PX30-17.5 |
10 | ||
| 90105-10276 |
RZJ95..ATM..ARL *10-1.25PX30-17.5 |
10 | ||
| 32116 - SPACER, DRIVE PLATE, FRONT | ||||
| 32116-26010 |
RZJ95..ATM |
1 | ||
| 32116-26010 |
RZJ95..ATM..ARL |
1 | ||
| 32117 - SPACER, DRIVE PLATE, REAR | ||||
| 32117-26010 |
RZJ95..ATM..ARL |
1 | ||
| 32117-26010 |
RZJ95..ATM |
1 | ||
| 35301 - BODY SUB-ASSY, FRONT OIL PUMP | ||||
| 35301-30040 |
VZJ95..ATM;RZJ95..ATM..ARL |
1 | ||
| 35301-30040 |
RZJ95,VZJ95..ATM..(ARL,GCC) |
1 | ||
| 35301-30040 |
KZJ95,RZJ95..ATM |
1 | ||
| 35301-30040 |
VZJ95..ATM..CO;RZJ95..ATM..ARL |
1 | ||
| 35301-30040 |
RZJ95..ATM |
1 | ||
| 35301-30040 |
KZJ95,RZJ95..ATM |
1 | ||
| 35301-30040 |
RZJ95..ATM..ARL |
1 | ||
| 35301A - SEAL, OIL (FOR FRONT OIL PUMP) | ||||
| 90311-38029 |
VZJ95..ATM;RZJ95..ATM..ARL |
1 | ||
| 90311-38029 |
KZJ95,RZJ95,VZJ95..ATM..(ARL,GCC) |
1 | ||
| 35301B - RING, O (FOR FRONT OIL PUMP BODY) | ||||
| 90301-99033 |
KZJ95,RZJ95,VZJ95..ATM |
1 | ||
| 90301-99033 |
VZJ95..ATM;RZJ95..ATM..ARL |
1 | ||
| 35301F - BOLT (FOR FRONT OIL PUMP SETTING) | ||||
| 90105-08091 |
VZJ95..ATM;RZJ95..ATM..ARL *8-1.25PX35-35 |
7 | ||
| 90105-08091 |
KZJ95,RZJ95,VZJ95..ATM *8-1.25PX35-35 |
7 | ||
| 90105-08091 |
KZJ95,RZJ95,VZJ95..ATM..(ARL,GCC) *8-1.25PX35-35 |
7 | ||
| 35307C - RACE, THRUST BEARING (FOR STATOR SHAFT) | ||||
| 35789-30020 |
RZJ95,VZJ95..ATM T=3.7 |
1 | ||
| 35789-30340 |
KZJ95,RZJ95,VZJ95..ATM..(ARL,GCC) T=3.7 |
1 | ||
| 35789-30340 |
KZJ95,RZJ95,VZJ95..ATM T=3.7 |
1 | ||
| 35789-30340 |
VZJ95..ATM..CO;RZJ95..ATM..ARL T=3.7 |
1 | ||
| 35321 - GEAR, FRONT OIL PUMP DRIVE | ||||
| 35321-12080 |
VZJ95..ATM;RZJ95..ATM..ARL T=9.450-9.459 |
1 | ||
| 35321-12100 |
VZJ95..ATM;RZJ95..ATM..ARL T=9.471-9.480 |
1 | ||
| 35321-12090 |
VZJ95..ATM;RZJ95..ATM..ARL T=9.460-9.470 |
1 | ||
| 35321-12110 |
VZJ95..ATM;RZJ95..ATM..ARL T=9.481-9.490 |
1 | ||
| 35321-12070 |
VZJ95..ATM..CO;RZJ95..ATM..ARL T=9.440-9.449 |
1 | ||
| 35321-12080 |
VZJ95..ATM..CO;RZJ95..ATM..ARL T=9.450-9.459 |
1 | ||
| 35321-12070 |
RZJ95..ATM..ARL T=9.440-9.449 |
1 | ||
| 35321-12070 |
VZJ95..ATM;RZJ95..ATM..ARL T=9.440-9.449 |
1 | ||
| 35321-12090 |
RZJ95..ATM..ARL T=9.460-9.470 |
1 | ||
| 35321-12110 |
VZJ95..ATM..CO;RZJ95..ATM..ARL T=9.481-9.490 |
1 | ||
| 35321-12090 |
VZJ95..ATM..CO;RZJ95..ATM..ARL T=9.460-9.470 |
1 | ||
| 35321-12070 |
RZJ95,VZJ95..ATM..(ARL,GCC) T=9.440-9.449 |
1 | ||
| 35321-12100 |
VZJ95..ATM..CO;RZJ95..ATM..ARL T=9.471-9.480 |
1 | ||
| 35321-12080 |
RZJ95..ATM..ARL T=9.450-9.459 |
1 | ||
| 35321-12090 |
RZJ95,VZJ95..ATM..(ARL,GCC) T=9.460-9.470 |
1 | ||
| 35321-12080 |
RZJ95,VZJ95..ATM..(ARL,GCC) T=9.450-9.459 |
1 | ||
| 35321-12110 |
RZJ95,VZJ95..ATM..(ARL,GCC) T=9.481-9.490 |
1 | ||
| 35321-12110 |
RZJ95..ATM..ARL T=9.481-9.490 |
1 | ||
| 35321-12100 |
RZJ95,VZJ95..ATM..(ARL,GCC) T=9.471-9.480 |
1 | ||
| 35321-12090 |
KZJ95,RZJ95..ATM T=9.460-9.470 |
1 | ||
| 35321-12080 |
KZJ95,RZJ95..ATM T=9.450-9.459 |
1 | ||
| 35321-12100 |
KZJ95,RZJ95..ATM T=9.471-9.480 |
1 | ||
| 35321-12110 |
KZJ95,RZJ95..ATM T=9.481-9.490 |
1 | ||
| 35321-12070 |
KZJ95,RZJ95..ATM T=9.440-9.449 |
1 | ||
| 35321-12080 |
KZJ95,RZJ95..ATM T=9.450-9.459 |
1 | ||
| 35321-12100 |
RZJ95..ATM..ARL T=9.471-9.480 |
1 | ||
| 35321-12100 |
KZJ95,RZJ95..ATM T=9.471-9.480 |
1 | ||
| 35321-12090 |
KZJ95,RZJ95..ATM T=9.460-9.470 |
1 | ||
| 35321-12110 |
KZJ95,RZJ95..ATM T=9.481-9.490 |
1 | ||
| 35321-12110 |
RZJ95..ATM T=9.481-9.490 |
1 | ||
| 35321-12090 |
RZJ95..ATM T=9.460-9.470 |
1 | ||
| 35321-12080 |
RZJ95..ATM T=9.450-9.459 |
1 | ||
| 35321-12100 |
RZJ95..ATM T=9.471-9.480 |
1 | ||
| 35321-12070 |
RZJ95..ATM T=9.440-9.449 |
1 | ||
| 35321-12070 |
KZJ95,RZJ95..ATM T=9.440-9.449 |
1 | ||
| 35322 - GEAR, FRONT OIL PUMP DRIVEN | ||||
| 35322-12080 |
VZJ95..ATM;RZJ95..ATM..ARL T=9.460-9.470 |
1 | ||
| 35322-12070 |
VZJ95..ATM;RZJ95..ATM..ARL T=9.450-9.459 |
1 | ||
| 35322-12060 |
VZJ95..ATM;RZJ95..ATM..ARL T=9.440-9.449 |
1 | ||
| 35322-12090 |
VZJ95..ATM;RZJ95..ATM..ARL T=9.471-9.480 |
1 | ||
| 35322-12100 |
VZJ95..ATM..CO;RZJ95..ATM..ARL T=9.481-9.490 |
1 | ||
| 35322-12070 |
VZJ95..ATM..CO;RZJ95..ATM..ARL T=9.450-9.459 |
1 | ||
| 35322-12090 |
VZJ95..ATM..CO;RZJ95..ATM..ARL T=9.471-9.480 |
1 | ||
| 35322-12060 |
VZJ95..ATM..CO;RZJ95..ATM..ARL T=9.440-9.449 |
1 | ||
| 35322-12060 |
RZJ95..ATM..ARL T=9.440-9.449 |
1 | ||
| 35322-12090 |
RZJ95..ATM..ARL T=9.471-9.480 |
1 | ||
| 35322-12070 |
RZJ95,VZJ95..ATM..(ARL,GCC) T=9.450-9.459 |
1 | ||
| 35322-12070 |
RZJ95..ATM..ARL T=9.450-9.459 |
1 | ||
| 35322-12100 |
VZJ95..ATM;RZJ95..ATM..ARL T=9.481-9.490 |
1 | ||
| 35322-12100 |
RZJ95,VZJ95..ATM..(ARL,GCC) T=9.481-9.490 |
1 | ||
| 35322-12080 |
VZJ95..ATM..CO;RZJ95..ATM..ARL T=9.460-9.470 |
1 | ||
| 35322-12100 |
RZJ95..ATM..ARL T=9.481-9.490 |
1 | ||
| 35322-12090 |
RZJ95,VZJ95..ATM..(ARL,GCC) T=9.471-9.480 |
1 | ||
| 35322-12080 |
RZJ95,VZJ95..ATM..(ARL,GCC) T=9.460-9.470 |
1 | ||
| 35322-12060 |
RZJ95,VZJ95..ATM..(ARL,GCC) T=9.440-9.449 |
1 | ||
| 35322-12080 |
RZJ95..ATM..ARL T=9.460-9.470 |
1 | ||
| 35322-12070 |
KZJ95,RZJ95..ATM T=9.450-9.459 |
1 | ||
| 35322-12080 |
KZJ95,RZJ95..ATM T=9.460-9.470 |
1 | ||
| 35322-12070 |
KZJ95,RZJ95..ATM T=9.450-9.459 |
1 | ||
| 35322-12090 |
KZJ95,RZJ95..ATM T=9.471-9.480 |
1 | ||
| 35322-12060 |
KZJ95,RZJ95..ATM T=9.440-9.449 |
1 | ||
| 35322-12090 |
RZJ95..ATM T=9.471-9.480 |
1 | ||
| 35322-12100 |
RZJ95..ATM T=9.481-9.490 |
1 | ||
| 35322-12090 |
KZJ95,RZJ95..ATM T=9.471-9.480 |
1 | ||
| 35322-12060 |
RZJ95..ATM T=9.440-9.449 |
1 | ||
| 35322-12080 |
RZJ95..ATM T=9.460-9.470 |
1 | ||
| 35322-12100 |
KZJ95,RZJ95..ATM T=9.481-9.490 |
1 | ||
| 35322-12060 |
KZJ95,RZJ95..ATM T=9.440-9.449 |
1 | ||
| 35322-12080 |
KZJ95,RZJ95..ATM T=9.460-9.470 |
1 | ||
| 35322-12070 |
RZJ95..ATM T=9.450-9.459 |
1 | ||
| 35322-12100 |
KZJ95,RZJ95..ATM T=9.481-9.490 |
1 | ||
| 35370 - SHAFT ASSY, STATOR | ||||
| 35370-30031 |
VZJ95..ATM;RZJ95..ATM..ARL |
1 | ||
| 35370-30031 |
KZJ95,RZJ95,VZJ95..ATM |
1 | ||
| 35370-30031 |
KZJ95,RZJ95,VZJ95..ATM..(ARL,GCC) |
1 | ||
| 35617 - RING, CLUTCH DRUM OIL SEAL | ||||
| 35617-30020 |
VZJ95..ATM;RZJ95..ATM..ARL |
2 | ||
| 35617-30020 |
KZJ95,RZJ95,VZJ95..ATM..(ARL,GCC) |
2 | ||
| 35617-30020 |
KZJ95,RZJ95,VZJ95..ATM |
2 | ||
| 35617 - RING, CLUTCH DRUM OIL SEAL | ||||
| 35617-30020 |
VZJ95..ATM;RZJ95..ATM..ARL |
2 | ||
| 35617-30020 |
KZJ95,RZJ95,VZJ95..ATM..(ARL,GCC) |
2 | ||
| 35617-30020 |
KZJ95,RZJ95,VZJ95..ATM |
2 | ||
| Common parts | ||||
| 90105-06126 | ||||
