HDJ100L-GCMEZ (2002)

Toyota Land Cruiser 100

Production Aug 2002 - Aug 2007
Engine 1HDFTE
Transmission 5F MTM
Displacement 2500cc
Power 168 HP (125 kW)

(9801- )HDJ100..SOB ; (9801- )FZJ10#,UZJ100..5F..ARL,GCC,GEN

Click highlighted areas on diagram

BENCH SEAT TYPE

diagram 33504F 33505B 33506A 33506F 33530F 33548F 33555 5851
Part # Description Qty Price
33504F - KNOB SUB-ASSY, SHIFT LEVER
33504-60121C0

HDJ100..SOB;UZJ100..5F..GCC;FZJ10#,HZJ105..5F..GX

URETHANE,BLACK,TRIM1#,4#

 1
33504-60130C0

HDJ100..SOB;FZJ105..5F..GX..ARL

LEATHER,BLACK,TRIM1#,4#

 1
33504-60121C0

HDJ100..LHD..5F;FZJ10#,HZJ105..5F..GX..(ARL,GCC,GEN)

URETHANE,BLACK,TRIM0#,1#

 1
33504-60121C0

HDJ100..LHD..5F;FZJ10#,HDJ100,HZJ105,UZJ100..5F..GX..(ARL,GCC,GEN)

URETHANE,BLACK,TRIM0#,1#

 1
33504-60130C0

HDJ100,UZJ100..5F

LEATHER,BLACK,TRIM0#,1#

 1
33504-60130C0

HDJ100,UZJ100..5F..(ARL,GCC,GEN)

LEATHER,BLACK,TRIM0#,1#

 1
33505B - SEAT SUB-ASSY, SHIFT LEVER
33505-60011

FZJ10#,HDJ100,UZJ100..5F..(ARL,GCC,GEN)

 1
33505-60011

HDJ100..SOB;FZJ10#,UZJ100..LHD..5F

 1
33505-60011

FZJ10#,HDJ100,UZJ100..5F..(ARL,GCC,GEN)

 1
33506A - BOLT (FOR CONTROL SHIFT LEVER RETAINER)
90119-08332

HDJ100..SOB

 6
90119-08332

FZJ100..5F;FZJ105..LHD..LUB;FZJ105,HDJ100..SOB

BENCH SEAT TYPE

 6
90119-08332

HDJ100..SOB;FZJ10#..LHD..5F..(GCC,GEN)

BENCH SEAT TYPE

 6
33506F - RETAINER SUB-ASSY, CONTROL SHIFT LEVER (FOR FLOOR SHIFT
33506-60090

FZJ100..5F;FZJ105..LHD..LUB;FZJ105,HDJ100..SOB

BENCH SEAT TYPE

 1
33506-60090

HDJ100..SOB

 1
33506-60090

HDJ100..SOB;FZJ10#..LHD..5F..(GCC,GEN)

BENCH SEAT TYPE

 1
33530F - LEVER ASSY, SHIFT (FOR FLOOR SHIFT)
33530-60360

HDJ100..SOB;FZJ10#..LHD..5F

BENCH SEAT TYPE

 1
33530-60360

HDJ100..SOB

 1
33530-60360

HDJ100..SOB;FZJ10#..LHD..5F..(GCC,GEN)

BENCH SEAT TYPE

 1
33548F - BUSH, NO.1, SHIFT LEVER (FOR FLOOR SHIFT)
33548-31010

FZJ10#,HDJ100,HZJ105,UZJ100..5F

 1
33548-22020

FZJ10#,HDJ100,UZJ100..5F..(ARL,GCC,GEN)

 1
33548-22020

FZJ10#,HDJ100,UZJ100..5F..(ARL,GCC,GEN)

 1
33555 - BOOT, SHIFT LEVER
33555-60090

FZJ100..5F;FZJ105..LHD..LUB;FZJ105,HDJ100..SOB

BENCH SEAT TYPE

 1
33555-60090

HDJ100..SOB

 1
33555-60090

HDJ100..SOB;FZJ10#..LHD..5F..(GCC,GEN)

BENCH SEAT TYPE

 1
Linked diagrams
5851
