RJ70L-KR (1984)
Toyota Land Cruiser
Production
Nov 1984
-
Jan 1990
Engine
22R
Transmission
4F MTM
Displacement
2500cc
Power
168 HP (125 kW)
ILLUST NO. 1 OF 2(8411- )22R
Click highlighted areas on diagram
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 11302 - COVER SUB-ASSY, TIMING CHAIN OR BELT | ||||
| 11302-35010 |
22R..RJ70 |
1 | ||
| 11302A - SEAL, OIL(FOR TIMING CHAIN OR BELT COVER) | ||||
| 90311-45006 |
22R..RJ70 |
1 | ||
| 11324 - PLATE, TIMING CHAIN COVER | ||||
| 11324-38020 |
22R..RJ70..GEN,ME W/O HEATER |
1 | ||
| 11328 - GASKET, TIMING GEAR OR CHAIN COVER | ||||
| 11328-35020 |
22R..RJ70 |
1 | ||
| 11338 - GASKET, TIMING CHAIN COVER, NO.2 | ||||
| 11329-35020 |
22R..RJ70 |
1 | ||
| 11355 - PLATE, REAR END | ||||
| 11355-35010 |
22R..RJ70 |
1 | ||
| 11381 - RETAINER, ENGINE REAR OIL SEAL | ||||
| 11381-38010 |
22R..RJ70 |
1 | ||
| 11381A - SEAL, ENGINE REAR OIL | ||||
| 90311-80004 |
22R..RJ70 |
1 | ||
| 11383 - GASKET, ENGINE REAR OIL SEAL RETAINER | ||||
| 11383-35010 |
22R..RJ70 |
1 | ||
| 11383-35020 |
22R..RJ70 |
1 | ||
| Common parts | ||||
| 90119-08017 | ||||
| 90119-08291 | ||||
| 91611-60825 | ||||
| 91611-G0816 | ||||
| 91651-60822 | ||||
ILLUST NO. 2 OF 2(8411- )22R
Click highlighted areas on diagram
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| Common parts | ||||
| 90119-08106 | ||||
| 90119-08108 | ||||
| 91611-60822 | ||||
| 91611-60840 | ||||
| 91611-60855 | ||||
| 91611-61065 | ||||
| 91611-F0822 | ||||
| 91611-G0840 | ||||
| 91611-G0855 | ||||
| 91611-G1065 | ||||
| 91651-61060 | ||||
| 91651-G1060 | ||||
