8715 - HEATING & AIR CONDITIONING - CONTROL & AIR DUCT

HZJ80L-GNMNS (1990)

Toyota Land Cruiser

Production Jan 1990 - Jan 1998

Engine 1HZ

Transmission 5F MTM

Displacement 2500cc

Power 168 HP (125 kW)

ILLUST NO. 2 OF 3(9001- )LHD

Click highlighted areas on diagram

AIR DUCT

Part #	Description	Period	Qty	Price
Common parts
90119-08879
90159-60198
90164-50008
90168-50027
93560-55016
93568-55012

ILLUST NO. 1 OF 3(9001- )LHD

Click highlighted areas on diagram

CONTROL PANEL

Part #	Description	Period	Qty	Price
Common parts
90170-11206
90206-11012
93568-55016
Linked diagrams
8302
8401

ILLUST NO. 1 OF 5(9001- )

Click highlighted areas on diagram

FRONT CONTROL---W(HEATER)

Part #	Description	Period	Qty
55519 - PLATE, HEATER CONTROL NAME
55519-60060	HZJ80..LHD..GX..GEN;FJ80..LHD..(GX,STD)..GEN W(HEATER & MANUAL AIR CONDITIONER)	01/1990 - 08/1991	1
55519-60040	FJ80..STD..GCC;FJ80,HZJ80..LHD..(GX,STD)..GEN W(HEATER)	01/1990 - 01/1992	1
55519-60080	FJ80..STD..GCC;FJ80,HZJ80..LHD..(GX,STD)..GEN	01/1990 - 01/1992	1
55519-60060	FJ80,HZJ80..LHD..GX..GEN W(HEATER & MANUAL AIR CONDITIONER)	08/1991 - 01/1992	1
55519-60100	FJ80,HZJ80..LHD..GX..GEN W(MANUAL AIR CONDITIONER)	01/1990 - 01/1992	1
55519-60041	FZJ80..LHD..GX..GEN;FZJ80..LHD..SOB..STD..GEN;HZJ80..LHD..(GX,STD)..GEN W(HEATER)	01/1992 - 08/1992	1
55519-60081	FZJ80..LHD..GX..GEN..CBR;FZJ80..LHD..SOB..STD..GEN;HZJ80..LHD..(GX,STD)..GEN	08/1992 - 01/1998	1
55519-60081	FZJ80..LHD..GX..GEN;FZJ80..LHD..SOB..STD..GEN;HZJ80..LHD..(GX,STD)..GEN	01/1992 - 08/1992	1
55905A - KNOB, HEATER CONTROL
55905-89115	FJ80..STD..GCC;FZJ80..GX..GEN;FZJ80..RHD..STD;FJ80,HZJ80..(GX,STD)..GEN W(HEATER)	01/1990 - 08/1992	4
55905-89115	FZJ80..GX..GEN;FZJ80..SOB..STD..GEN;HZJ80..(GX,STD)..GEN W(HEATER)	08/1992 - 05/1993	4
55905-89115	FJ80..STD..GCC;FZJ80..GX..GEN;FZJ80..SOB..STD..GEN;FJ80,HZJ80..(GX,STD)..GEN	01/1990 - 08/1992	3
55905-89115	FZJ80..GX..GEN..CBR;FZJ80..SOB..STD..GEN;HZJ80..(GX,STD)..GEN W(HEATER)	05/1993 - 10/1995	4
55905-89115	FZJ80..GX..GEN;FZJ80..SOB..STD..GEN;HZJ80..(GX,STD)..GEN	08/1992 - 05/1993	3
55905-89115	FZJ80,HDJ80,HZJ80..GX,STD	05/1993 - 01/1998	4
55905A - KNOB, HEATER CONTROL
55905-89115	FJ80..STD..GCC;FZJ80..GX..GEN;FZJ80..RHD..STD;FJ80,HZJ80..(GX,STD)..GEN W(HEATER)	01/1990 - 08/1992	4
55905-89115	FZJ80..GX..GEN;FZJ80..SOB..STD..GEN;HZJ80..(GX,STD)..GEN W(HEATER)	08/1992 - 05/1993	4
55905-89115	FJ80..STD..GCC;FZJ80..GX..GEN;FZJ80..SOB..STD..GEN;FJ80,HZJ80..(GX,STD)..GEN	01/1990 - 08/1992	3
55905-89115	FZJ80..GX..GEN..CBR;FZJ80..SOB..STD..GEN;HZJ80..(GX,STD)..GEN W(HEATER)	05/1993 - 10/1995	4
55905-89115	FZJ80..GX..GEN;FZJ80..SOB..STD..GEN;HZJ80..(GX,STD)..GEN	08/1992 - 05/1993	3
55905-89115	FZJ80,HDJ80,HZJ80..GX,STD	05/1993 - 01/1998	4
55905A - KNOB, HEATER CONTROL
55905-89115	FJ80..STD..GCC;FZJ80..GX..GEN;FZJ80..RHD..STD;FJ80,HZJ80..(GX,STD)..GEN W(HEATER)	01/1990 - 08/1992	4
55905-89115	FZJ80..GX..GEN;FZJ80..SOB..STD..GEN;HZJ80..(GX,STD)..GEN W(HEATER)	08/1992 - 05/1993	4
55905-89115	FJ80..STD..GCC;FZJ80..GX..GEN;FZJ80..SOB..STD..GEN;FJ80,HZJ80..(GX,STD)..GEN	01/1990 - 08/1992	3
55905-89115	FZJ80..GX..GEN..CBR;FZJ80..SOB..STD..GEN;HZJ80..(GX,STD)..GEN W(HEATER)	05/1993 - 10/1995	4
55905-89115	FZJ80..GX..GEN;FZJ80..SOB..STD..GEN;HZJ80..(GX,STD)..GEN	08/1992 - 05/1993	3
55905-89115	FZJ80,HDJ80,HZJ80..GX,STD	05/1993 - 01/1998	4
55905A - KNOB, HEATER CONTROL
55905-89115	FJ80..STD..GCC;FZJ80..GX..GEN;FZJ80..RHD..STD;FJ80,HZJ80..(GX,STD)..GEN W(HEATER)	01/1990 - 08/1992	4
55905-89115	FZJ80..GX..GEN;FZJ80..SOB..STD..GEN;HZJ80..(GX,STD)..GEN W(HEATER)	08/1992 - 05/1993	4
55905-89115	FJ80..STD..GCC;FZJ80..GX..GEN;FZJ80..SOB..STD..GEN;FJ80,HZJ80..(GX,STD)..GEN	01/1990 - 08/1992	3
55905-89115	FZJ80..GX..GEN..CBR;FZJ80..SOB..STD..GEN;HZJ80..(GX,STD)..GEN W(HEATER)	05/1993 - 10/1995	4
55905-89115	FZJ80..GX..GEN;FZJ80..SOB..STD..GEN;HZJ80..(GX,STD)..GEN	08/1992 - 05/1993	3
55905-89115	FZJ80,HDJ80,HZJ80..GX,STD	05/1993 - 01/1998	4
55906 - CABLE SUB-ASSY, HEATER CONTROL
55906-60031	FZJ80,HZJ80..LHD..(GX,STD)	01/1992 - 08/1992	1
55906-60030	FJ80,HDJ80,HZJ80..GX,STD	01/1990 - 05/1990	1
55906-60030	FJ80,HZJ80..LHD..(GX,STD)	05/1990 - 01/1992	1
55906-60031	FZJ80,HZJ80..LHD..(GX,STD)	08/1992 - 01/1995	1
55906-60080	FZJ80,HZJ80..LHD..(GX,STD)	01/1995 - 12/2999	1
55907A - CABLE SUB-ASSY, WATER VALVE CONTROL
55907-60031	FZJ80..SOB..GX;FZJ80..STD..GCC;HZJ80..LHD..(GX,STD);FZJ80..LHD..LUB..(GX,STD)	01/1992 - 08/1992	1
55907-60031	FZJ80..LUB..STD;FZJ80..(GX,STD)..GCC;HZJ80..LHD..(GX,STD)	08/1992 - 05/1993	1
55907-60031	FZJ80,HZJ80..LHD..(GX,STD)	05/1993 - 01/1995	1
55907-60110	FZJ80,HZJ80..LHD..(GX,STD)	01/1995 - 10/1995	1
55907-60110	HZJ80..LHD..GX..GEN W(HEATER)	10/1995 - 08/1996	1
55907-60030	FJ80,HZJ80..LHD..(GX,STD)	01/1990 - 01/1992	1
55908A - CABLE SUB-ASSY, AIR INLET DAMPER CONTROL
55908-60030	FJ80,FZJ80,HDJ80,HZJ80..GX,STD	01/1990 - 08/1992	1
55908-60030	FZJ80,HDJ80,HZJ80..GX,STD	08/1992 - 01/1995	1
55908-60060	FZJ80,HDJ80,HZJ80..GX,STD	01/1995 - 01/1998	1
55909A - CABLE SUB-ASSY, AIRMIX DAMPER CONTROL
55909-60031	FJ80,HZJ80..LHD..(GX,STD)	05/1990 - 01/1992	1
55909-60032	FZJ80,HZJ80..LHD..(GX,STD)	05/1993 - 10/1995	1
55909-60030	FJ80,HZJ80..LHD..(GX,STD)	01/1990 - 05/1990	1
55909-60032	FZJ80..SOB..GX;FZJ80..STD..GCC;HZJ80..LHD..(GX,STD);FZJ80..LHD..LUB..(GX,STD)	01/1992 - 08/1992	1
55909-60032	HZJ80..LHD..LUB..GX COLD SPEC & W(HEATER)	10/1995 - 01/1998	1
55909-60032	FZJ80..LUB..STD;FZJ80..(GX,STD)..GCC;HZJ80..LHD..(GX,STD)	08/1992 - 05/1993	1
55910 - CONTROL ASSY, HEATER OR BOOST VENTILATOR
55910-60020	FJ80..STD..GCC;FJ80,HZJ80..LHD..(GX,STD)..GEN W(HEATER)	01/1990 - 05/1990	1
55910-60060	FJ80..STD..GCC;FJ80,HZJ80..LHD..(GX,STD)..GEN W(MANUAL AIR CONDITIONER)	01/1990 - 05/1990	1
55910-60040	FJ80..STD..GCC;FJ80,HZJ80..LHD..(GX,STD)..GEN	01/1990 - 05/1990	1
55910-60041	FJ80..STD..GCC;FJ80,HZJ80..LHD..(GX,STD)..GEN	05/1990 - 01/1992	1
55910-60061	FJ80..STD..GCC;FJ80,HZJ80..LHD..(GX,STD)..GEN W(MANUAL AIR CONDITIONER)	05/1990 - 01/1992	1
55910-60021	FJ80..STD..GCC;FJ80,HZJ80..LHD..(GX,STD)..GEN W(HEATER)	05/1990 - 01/1992	1
55910-60062	FZJ80..LHD..GX..GEN;FZJ80..LHD..SOB..STD..GEN;HZJ80..LHD..(GX,STD)..GEN W(MANUAL AIR CONDITIONER)	08/1992 - 05/1993	1
55910-60042	FZJ80..LHD..GX..GEN;FZJ80..LHD..SOB..STD..GEN;HZJ80..LHD..(GX,STD)..GEN	08/1992 - 05/1993	1
55910-60042	FZJ80..LHD..GX..GEN;FZJ80..LHD..SOB..STD..GEN;HZJ80..LHD..(GX,STD)..GEN	01/1992 - 08/1992	1
55910-60022	FZJ80..LHD..GX..GEN;FZJ80..LHD..SOB..STD..GEN;HZJ80..LHD..(GX,STD)..GEN W(HEATER)	08/1992 - 05/1993	1
55910-60022	FZJ80..LHD..GX..GEN;HZJ80..LHD..(GX,STD)..GEN W(HEATER)	01/1992 - 08/1992	1
55910-60022	FZJ80..LHD..GX..GEN..CBR;FZJ80..LHD..SOB..STD..GEN;HZJ80..LHD..(GX,STD)..GEN W(HEATER)	05/1993 - 09/1994	1
55910-60100	FZJ80..LHD..GX..GEN..CBR;FZJ80..LHD..SOB..STD..GEN;HZJ80..LHD..(GX,STD)..GEN W(HEATER)	09/1994 - 08/1996	1
55910-60042	FZJ80..LHD..GX..GEN..CBR;FZJ80..LHD..SOB..STD..GEN;HZJ80..LHD..(GX,STD)..GEN	05/1993 - 09/1994	1
55910-60062	FZJ80..LHD..GX..GEN;FZJ80..LHD..SOB..STD..GEN;HZJ80..LHD..(GX,STD)..GEN W(MANUAL AIR CONDITIONER)	01/1992 - 08/1992	1
55910-60100	HZJ80..LHD..LUB..GX COLD SPEC & W(HEATER & *AIC)	08/1996 - 01/1998	1
55910-60062	FZJ80..LHD..GX..GEN..CBR;FZJ80..LHD..SOB..STD..GEN;HZJ80..LHD..(GX,STD)..GEN W(MANUAL AIR CONDITIONER)	05/1993 - 09/1994	1
55910-60120	FZJ80..LHD..GX..GEN..CBR;FZJ80..LHD..SOB..STD..GEN;HZJ80..LHD..(GX,STD)..GEN	09/1994 - 01/1998	1
Common parts
93566-15516
Linked diagrams
8401

ILLUST NO. 1 OF 5(9001- )

Click highlighted areas on diagram

FRONT CONTROL---W(HEATER),PUSH TYPE

Part #	Description	Period	Qty
55519 - PLATE, HEATER CONTROL NAME
55519-60060	HZJ80..LHD..GX..GEN;FJ80..LHD..(GX,STD)..GEN W(HEATER & MANUAL AIR CONDITIONER)	01/1990 - 08/1991	1
55519-60040	FJ80..STD..GCC;FJ80,HZJ80..LHD..(GX,STD)..GEN W(HEATER)	01/1990 - 01/1992	1
55519-60080	FJ80..STD..GCC;FJ80,HZJ80..LHD..(GX,STD)..GEN	01/1990 - 01/1992	1
55519-60060	FJ80,HZJ80..LHD..GX..GEN W(HEATER & MANUAL AIR CONDITIONER)	08/1991 - 01/1992	1
55519-60100	FJ80,HZJ80..LHD..GX..GEN W(MANUAL AIR CONDITIONER)	01/1990 - 01/1992	1
55519-60041	FZJ80..LHD..GX..GEN;FZJ80..LHD..SOB..STD..GEN;HZJ80..LHD..(GX,STD)..GEN W(HEATER)	01/1992 - 08/1992	1
55519-60081	FZJ80..LHD..GX..GEN..CBR;FZJ80..LHD..SOB..STD..GEN;HZJ80..LHD..(GX,STD)..GEN	08/1992 - 01/1998	1
55519-60081	FZJ80..LHD..GX..GEN;FZJ80..LHD..SOB..STD..GEN;HZJ80..LHD..(GX,STD)..GEN	01/1992 - 08/1992	1
Common parts
93568-55014
Linked diagrams
8302

ILLUST NO. 1 OF 5(9001- )FJ80..STD..GCC ; (9001- )FJ80,FZJ80,HZJ80..GEN

Click highlighted areas on diagram

FRONT CONTROL---W(BOOST VENTILATOR)

Part #	Description	Period	Qty
55519 - PLATE, HEATER CONTROL NAME
55519-60060	HZJ80..LHD..GX..GEN;FJ80..LHD..(GX,STD)..GEN W(HEATER & MANUAL AIR CONDITIONER)	01/1990 - 08/1991	1
55519-60040	FJ80..STD..GCC;FJ80,HZJ80..LHD..(GX,STD)..GEN W(HEATER)	01/1990 - 01/1992	1
55519-60080	FJ80..STD..GCC;FJ80,HZJ80..LHD..(GX,STD)..GEN	01/1990 - 01/1992	1
55519-60060	FJ80,HZJ80..LHD..GX..GEN W(HEATER & MANUAL AIR CONDITIONER)	08/1991 - 01/1992	1
55519-60100	FJ80,HZJ80..LHD..GX..GEN W(MANUAL AIR CONDITIONER)	01/1990 - 01/1992	1
55519-60041	FZJ80..LHD..GX..GEN;FZJ80..LHD..SOB..STD..GEN;HZJ80..LHD..(GX,STD)..GEN W(HEATER)	01/1992 - 08/1992	1
55519-60081	FZJ80..LHD..GX..GEN..CBR;FZJ80..LHD..SOB..STD..GEN;HZJ80..LHD..(GX,STD)..GEN	08/1992 - 01/1998	1
55519-60081	FZJ80..LHD..GX..GEN;FZJ80..LHD..SOB..STD..GEN;HZJ80..LHD..(GX,STD)..GEN	01/1992 - 08/1992	1
55905A - KNOB, HEATER CONTROL
55905-89115	FJ80..STD..GCC;FZJ80..GX..GEN;FZJ80..RHD..STD;FJ80,HZJ80..(GX,STD)..GEN W(HEATER)	01/1990 - 08/1992	4
55905-89115	FZJ80..GX..GEN;FZJ80..SOB..STD..GEN;HZJ80..(GX,STD)..GEN W(HEATER)	08/1992 - 05/1993	4
55905-89115	FJ80..STD..GCC;FZJ80..GX..GEN;FZJ80..SOB..STD..GEN;FJ80,HZJ80..(GX,STD)..GEN	01/1990 - 08/1992	3
55905-89115	FZJ80..GX..GEN..CBR;FZJ80..SOB..STD..GEN;HZJ80..(GX,STD)..GEN W(HEATER)	05/1993 - 10/1995	4
55905-89115	FZJ80..GX..GEN;FZJ80..SOB..STD..GEN;HZJ80..(GX,STD)..GEN	08/1992 - 05/1993	3
55905-89115	FZJ80,HDJ80,HZJ80..GX,STD	05/1993 - 01/1998	4
55905A - KNOB, HEATER CONTROL
55905-89115	FJ80..STD..GCC;FZJ80..GX..GEN;FZJ80..RHD..STD;FJ80,HZJ80..(GX,STD)..GEN W(HEATER)	01/1990 - 08/1992	4
55905-89115	FZJ80..GX..GEN;FZJ80..SOB..STD..GEN;HZJ80..(GX,STD)..GEN W(HEATER)	08/1992 - 05/1993	4
55905-89115	FJ80..STD..GCC;FZJ80..GX..GEN;FZJ80..SOB..STD..GEN;FJ80,HZJ80..(GX,STD)..GEN	01/1990 - 08/1992	3
55905-89115	FZJ80..GX..GEN..CBR;FZJ80..SOB..STD..GEN;HZJ80..(GX,STD)..GEN W(HEATER)	05/1993 - 10/1995	4
55905-89115	FZJ80..GX..GEN;FZJ80..SOB..STD..GEN;HZJ80..(GX,STD)..GEN	08/1992 - 05/1993	3
55905-89115	FZJ80,HDJ80,HZJ80..GX,STD	05/1993 - 01/1998	4
55905A - KNOB, HEATER CONTROL
55905-89115	FJ80..STD..GCC;FZJ80..GX..GEN;FZJ80..RHD..STD;FJ80,HZJ80..(GX,STD)..GEN W(HEATER)	01/1990 - 08/1992	4
55905-89115	FZJ80..GX..GEN;FZJ80..SOB..STD..GEN;HZJ80..(GX,STD)..GEN W(HEATER)	08/1992 - 05/1993	4
55905-89115	FJ80..STD..GCC;FZJ80..GX..GEN;FZJ80..SOB..STD..GEN;FJ80,HZJ80..(GX,STD)..GEN	01/1990 - 08/1992	3
55905-89115	FZJ80..GX..GEN..CBR;FZJ80..SOB..STD..GEN;HZJ80..(GX,STD)..GEN W(HEATER)	05/1993 - 10/1995	4
55905-89115	FZJ80..GX..GEN;FZJ80..SOB..STD..GEN;HZJ80..(GX,STD)..GEN	08/1992 - 05/1993	3
55905-89115	FZJ80,HDJ80,HZJ80..GX,STD	05/1993 - 01/1998	4
55906 - CABLE SUB-ASSY, HEATER CONTROL
55906-60031	FZJ80,HZJ80..LHD..(GX,STD)	01/1992 - 08/1992	1
55906-60030	FJ80,HDJ80,HZJ80..GX,STD	01/1990 - 05/1990	1
55906-60030	FJ80,HZJ80..LHD..(GX,STD)	05/1990 - 01/1992	1
55906-60031	FZJ80,HZJ80..LHD..(GX,STD)	08/1992 - 01/1995	1
55906-60080	FZJ80,HZJ80..LHD..(GX,STD)	01/1995 - 12/2999	1
55908A - CABLE SUB-ASSY, AIR INLET DAMPER CONTROL
55908-60030	FJ80,FZJ80,HDJ80,HZJ80..GX,STD	01/1990 - 08/1992	1
55908-60030	FZJ80,HDJ80,HZJ80..GX,STD	08/1992 - 01/1995	1
55908-60060	FZJ80,HDJ80,HZJ80..GX,STD	01/1995 - 01/1998	1
55910 - CONTROL ASSY, HEATER OR BOOST VENTILATOR
55910-60020	FJ80..STD..GCC;FJ80,HZJ80..LHD..(GX,STD)..GEN W(HEATER)	01/1990 - 05/1990	1
55910-60060	FJ80..STD..GCC;FJ80,HZJ80..LHD..(GX,STD)..GEN W(MANUAL AIR CONDITIONER)	01/1990 - 05/1990	1
55910-60040	FJ80..STD..GCC;FJ80,HZJ80..LHD..(GX,STD)..GEN	01/1990 - 05/1990	1
55910-60041	FJ80..STD..GCC;FJ80,HZJ80..LHD..(GX,STD)..GEN	05/1990 - 01/1992	1
55910-60061	FJ80..STD..GCC;FJ80,HZJ80..LHD..(GX,STD)..GEN W(MANUAL AIR CONDITIONER)	05/1990 - 01/1992	1
55910-60021	FJ80..STD..GCC;FJ80,HZJ80..LHD..(GX,STD)..GEN W(HEATER)	05/1990 - 01/1992	1
55910-60062	FZJ80..LHD..GX..GEN;FZJ80..LHD..SOB..STD..GEN;HZJ80..LHD..(GX,STD)..GEN W(MANUAL AIR CONDITIONER)	08/1992 - 05/1993	1
55910-60042	FZJ80..LHD..GX..GEN;FZJ80..LHD..SOB..STD..GEN;HZJ80..LHD..(GX,STD)..GEN	08/1992 - 05/1993	1
55910-60042	FZJ80..LHD..GX..GEN;FZJ80..LHD..SOB..STD..GEN;HZJ80..LHD..(GX,STD)..GEN	01/1992 - 08/1992	1
55910-60022	FZJ80..LHD..GX..GEN;FZJ80..LHD..SOB..STD..GEN;HZJ80..LHD..(GX,STD)..GEN W(HEATER)	08/1992 - 05/1993	1
55910-60022	FZJ80..LHD..GX..GEN;HZJ80..LHD..(GX,STD)..GEN W(HEATER)	01/1992 - 08/1992	1
55910-60022	FZJ80..LHD..GX..GEN..CBR;FZJ80..LHD..SOB..STD..GEN;HZJ80..LHD..(GX,STD)..GEN W(HEATER)	05/1993 - 09/1994	1
55910-60100	FZJ80..LHD..GX..GEN..CBR;FZJ80..LHD..SOB..STD..GEN;HZJ80..LHD..(GX,STD)..GEN W(HEATER)	09/1994 - 08/1996	1
55910-60042	FZJ80..LHD..GX..GEN..CBR;FZJ80..LHD..SOB..STD..GEN;HZJ80..LHD..(GX,STD)..GEN	05/1993 - 09/1994	1
55910-60062	FZJ80..LHD..GX..GEN;FZJ80..LHD..SOB..STD..GEN;HZJ80..LHD..(GX,STD)..GEN W(MANUAL AIR CONDITIONER)	01/1992 - 08/1992	1
55910-60100	HZJ80..LHD..LUB..GX COLD SPEC & W(HEATER & *AIC)	08/1996 - 01/1998	1
55910-60062	FZJ80..LHD..GX..GEN..CBR;FZJ80..LHD..SOB..STD..GEN;HZJ80..LHD..(GX,STD)..GEN W(MANUAL AIR CONDITIONER)	05/1993 - 09/1994	1
55910-60120	FZJ80..LHD..GX..GEN..CBR;FZJ80..LHD..SOB..STD..GEN;HZJ80..LHD..(GX,STD)..GEN	09/1994 - 01/1998	1
87284 - RESISTOR SUB-ASSY, VARIABLE
88032-60020	FZJ80..LHD..GX..GEN..CBR;FZJ80..LHD..SOB..STD..GEN;HZJ80..LHD..(GX,STD)..GEN	05/1993 - 01/1998	1
88032-60020	FJ80..STD..GCC;FZJ80..LHD..GX..GEN;FZJ80..LHD..SOB..STD..GEN;FJ80,HZJ80..LHD..(GX,STD)..GEN	01/1990 - 08/1992	1
88032-60020	FZJ80..LHD..GX..GEN;FZJ80..LHD..SOB..STD..GEN;HZJ80..LHD..(GX,STD)..GEN	08/1992 - 05/1993	1
Common parts
93566-15516
Linked diagrams
8401

ILLUST NO. 2 OF 5(9001- )

Click highlighted areas on diagram

FRONT DUCT

Part #	Description	Period	Qty
55085 - DUCT SUB-ASSY, HEATER TO REGISTER, NO.2
55085-60010	FJ80..(GX,STD)..GCC;FJ80,HDJ80..LHD..GEN;FZJ80,HZJ80..LHD..VX..GEN;FZJ80,HZJ80..LHD..(GX,STD)	01/1990 - 08/1992	1
55085-60020	FZJ80,HZJ80..LHD..(GX,STD);FZJ80,HDJ80,HZJ80..LHD..VX..GEN W(AIR CONDITIONER)	08/1992 - 05/1993	1
55085-60010	FZJ80,HZJ80..LHD..(GX,STD);FZJ80,HDJ80,HZJ80..LHD..VX..GEN	08/1992 - 01/1995	1
55085-60070	FZJ80..4FC..VX..GEN;FZJ80,HZJ80..LHD..(GX,STD);FZJ80,HDJ80,HZJ80..LHD..VX..GEN..(CBR,DSL,TD2)	01/1995 - 01/1998	1
55085-60020	FJ80..(GX,STD)..GCC;FJ80,HDJ80..LHD..GEN;FZJ80,HZJ80..LHD..VX..GEN;FZJ80,HZJ80..LHD..(GX,STD) W(AIR CONDITIONER)	01/1990 - 08/1992	1
55085-60020	HDJ80,HZJ80..LHD..VX..GEN;FZJ80,HZJ80..LHD..(GX,STD) W(AIR CONDITIONER)	05/1993 - 01/1995	1
55085-60100	FZJ80..LHD..GX..EFI;FZJ80..4FC..VX..GEN;FZJ80,HZJ80..LHD..5F..(GX,STD);FZJ80,HDJ80,HZJ80..LHD..VX..GEN..(CBR,DSL,TD2) W(AIR CONDITIONER)	01/1995 - 12/2999	1
55087 - DUCT SUB-ASSY, HEATER TO REGISTER, NO.4
55087-60010	FJ80,FZJ80,HDJ80,HZJ80..LHD	01/1990 - 08/1992	1
55087-60030	FZJ80,HDJ80,HZJ80..LHD	01/1995 - 12/2999	1
55087-60010	FZJ80,HDJ80,HZJ80..LHD	08/1992 - 01/1995	1
55088 - DUCT SUB-ASSY, HEATER TO REGISTER, NO.5
55088-60010	FZJ80,HDJ80,HZJ80..LHD	08/1992 - 05/1993	1
55088-60050	FZJ80,HDJ80,HZJ80..LHD	01/1995 - 12/2999	1
55088-60010	FZJ80..VX..GCC;HDJ80,HZJ80..LHD;FZJ80..LHD..(GX,STD)	05/1993 - 01/1995	1
55088-60010	FJ80,FZJ80,HDJ80,HZJ80..LHD	01/1990 - 08/1992	1
55843A - DUCT, HEATER TO REGISTER, NO.1
55843-60010	FJ80,FZJ80,HDJ80,HZJ80..LHD	01/1990 - 08/1992	1
55843-60040	FZJ80,HDJ80,HZJ80..LHD	01/1995 - 12/2999	1
55843-60010	FZJ80,HDJ80,HZJ80..LHD	08/1992 - 01/1995	1
55845A - DUCT, HEATER TO REGISTER, NO.3
55845-60010	FJ80,FZJ80,HDJ80,HZJ80..LHD	01/1990 - 08/1992	1
55845-60040	FZJ80,HDJ80,HZJ80..LHD	01/1995 - 12/2999	1
55845-60010	FZJ80,HDJ80,HZJ80..LHD	08/1992 - 01/1995	1
55847B - DUCT, HEATER TO REGISTER, NO.5
55847-60010	FJ80,FZJ80,HDJ80,HZJ80..LHD	01/1990 - 08/1992	1
55847-60010	FZJ80,HDJ80,HZJ80..LHD	08/1992 - 01/1995	1
55847B - DUCT, HEATER TO REGISTER, NO.5
55847-60010	FJ80,FZJ80,HDJ80,HZJ80..LHD	01/1990 - 08/1992	1
55847-60010	FZJ80,HDJ80,HZJ80..LHD	08/1992 - 01/1995	1
87138B - RESISTOR, HEATER BLOWER
87138-60220	FJ80,HDJ80..ARL,GEN;FJ80..(GX,STD)..GCC;FZJ80,HZJ80..GX,STD;FZJ80,HZJ80..VX..GEN	01/1990 - 08/1992	1
87138-60220	HDJ80..ARL;HDJ80..LHD;FZJ80..GX,STD;HDJ80..RHD..5F..GEN;HZJ80..5F..(GX,STD);FZJ80..4FC..VX..(ARL,GEN);FZJ80,HZJ80..VX..GEN..(CBR,DSL)	08/1992 - 01/1998	1
87211 - DUCT, AIR, NO.1
87211-60180	FJ80..(GX,STD)..GCC;FJ80,HDJ80..LHD..GEN;FZJ80,HZJ80..LHD..VX..GEN;FZJ80,HZJ80..LHD..(GX,STD)	01/1990 - 08/1992	1
87211-60180	FZJ80..4FC..VX..GEN;FZJ80,HZJ80..LHD..(GX,STD);FZJ80,HDJ80,HZJ80..LHD..VX..GEN..(CBR,DSL,TD2)	08/1992 - 01/1998	1
Common parts
90159-50068
90159-50138
90159-60198
90183-05094

ILLUST NO. 3 OF 5(9001- )

Click highlighted areas on diagram

REAR HEATER DUCT

Part #	Description	Period	Qty
87212 - DUCT, AIR, REAR NO.1
87212-60110	FJ80,FZJ80,HDJ80,HZJ80..LHD..GEN	01/1990 - 08/1992	1
87212-60110	HDJ80..LHD..LUB;FZJ80,HZJ80..LHD..GEN	08/1992 - 01/1998	1
87213 - DUCT, AIR, REAR NO.2
87213-60010	HZJ80..GEN;FJ80..STD..GEN;HZJ80..GX..ARL;FZJ80,HDJ80..ARL,GEN;FJ80..(GX,VX)..(ARL,GEN)	01/1990 - 08/1992	1
87213-60010	FZJ80..GEN;HZJ80..5F..GEN;HDJ80..LHD..LUB;HDJ80..RHD..5F..GEN;FZJ80,HDJ80,HZJ80..LUB..ARL	08/1992 - 01/1998	1
Common parts
90179-06054
93540-55016

ILLUST NO. 4 OF 5(9001- )GX,VX

Click highlighted areas on diagram

REAR AIR CONDITIONER DUCT

Part #	Description	Period	Qty
88505 - DUCT SUB-ASSY,AIR CONDITIONER
88505-6003003	FJ80,HDJ80,HZJ80..GX LIGHT GRAY,TRIM1#	01/1990 - 01/1992	1
88505-6003006	FJ80,HDJ80,HZJ80..GX LIGHT SABLE,TRIM4#	01/1990 - 01/1992	1
88505-6003042	FZJ80,HDJ80,HZJ80..GX SABLE,TRIM4#	08/1992 - 01/1995	1
88505-6003003	FZJ80..GX;FZJ80..RHD..VX;HZJ80..VX..GCC;FJ80,HDJ80,HZJ80..GX..(DSL,EFI,TD2) LIGHT GRAY,TRIM1#	01/1992 - 08/1992	1
88505-60030B6	FZJ80,HDJ80,HZJ80..GX BLUEISH GRAY,TRIM1#	08/1992 - 01/1995	1
88505-6003006	FZJ80..GX;FZJ80..RHD..VX;HZJ80..VX..GCC;FJ80,HDJ80,HZJ80..GX..(DSL,EFI,TD2) LIGHT SABLE,TRIM4#	01/1992 - 08/1992	1
88505-60060B1	HZJ80..5F..GX;FZJ80,HDJ80..GX;HDJ80..RHD..5F..TD2;FZJ80..4FC..VX..GEN;FZJ80,HDJ80,HZJ80..LHD..VX..GEN..(CBR,DSL,TD2) LIGHT GRAY,TRIM1#,4#	01/1995 - 01/1998	1
88566A - DUCT, COOLER AIR, NO.1
88566-6001003	FJ80,HDJ80,HZJ80..GX LIGHT GRAY,TRIM1#	01/1990 - 01/1992	1
88566-6001003	FZJ80..GX;FZJ80..RHD..VX;HZJ80..VX..GCC;FJ80,HDJ80,HZJ80..GX..(DSL,EFI,TD2) LIGHT GRAY,TRIM1#	01/1992 - 08/1992	1
88566-6001006	FZJ80..GX;FZJ80..RHD..VX;HZJ80..VX..GCC;FJ80,HDJ80,HZJ80..GX..(DSL,EFI,TD2) LIGHT SABLE,TRIM4#	01/1992 - 08/1992	1
88566-6001006	FZJ80,HDJ80,HZJ80..GX LIGHT SABLE,TRIM4#	08/1992 - 01/1995	1
88566-60040B0	HDJ80..LHD;FZJ80..4FC..GEN;HZJ80..5F..(GX,VX);HDJ80..RHD..5F..TD2;FZJ80..(ARL,GCC)..EFI;FZJ80,HDJ80..(GX,VX)..(CBR,TD4) LIGHT GRAY,TRIM1#,4#	01/1995 - 01/1998	1
88566-6001003	FZJ80,HDJ80,HZJ80..GX LIGHT GRAY,TRIM1#	08/1992 - 01/1995	1
88566-6001006	FJ80,HDJ80,HZJ80..GX LIGHT SABLE,TRIM4#	01/1990 - 01/1992	1
88570E - GRILLE ASSY, AIR OUTLET
88570-6005042	FZJ80..GX,VX;FJ80,HDJ80,HZJ80..(GX,VX)..(DSL,EFI,TD2) LIGHT SABLE,TRIM4#	01/1992 - 08/1992	5
88570-6005042	FJ80,HDJ80,HZJ80..GX,VX LIGHT SABLE,TRIM4#	01/1990 - 01/1992	5
88570-60050B6	FZJ80..GX,VX;FJ80,HDJ80,HZJ80..(GX,VX)..(DSL,EFI,TD2) LIGHT GRAY,TRIM1#	01/1992 - 08/1992	5
88570-6005042	FZJ80,HDJ80,HZJ80..GX,VX LIGHT SABLE,TRIM4#	08/1992 - 01/1995	5
88570-60050B6	FZJ80,HDJ80,HZJ80..GX,VX LIGHT GRAY,TRIM1#	08/1992 - 01/1995	5
88570-60050B6	FJ80,HDJ80,HZJ80..GX,VX LIGHT GRAY,TRIM1#	01/1990 - 01/1992	5
88570-60050B6	HDJ80..LHD;FZJ80..4FC..GEN;HDJ80..RHD..5F..TD2;FZJ80..(ARL,GCC)..EFI;FZJ80,HDJ80,HZJ80..(GX,VX)..(CBR,DSL,TD4) LIGHT GRAY,TRIM1#,4#	01/1995 - 01/1998	5
88576C - DUCT, COOLER AIR, NO.1
88576-60010	HDJ80..LHD;FZJ80..4FC..GEN;HDJ80..RHD..5F..GEN;FZJ80,HZJ80..(GX,VX)..(CBR,DSL);FZJ80,HDJ80..(GX,VX)..(ARL,GCC)..(EFI,TD2,TD4)	08/1992 - 01/1998	1
88576-60010	FJ80,HDJ80,HZJ80..GX,VX	01/1990 - 01/1992	1
88576-60010	FZJ80..GX,VX;FJ80,HDJ80,HZJ80..(GX,VX)..(DSL,EFI,TD2)	01/1992 - 08/1992	1
88610C - SWITCH ASSY, COOLER CONTROL
88610-6006006	HDJ80..GEN;HZJ80..GX,VX;FJ80..GX..GCC;FJ80,HDJ80..GX..(EFI,TD2);FJ80..(GX,VX)..(ARL,GEN)..CBR LIGHT SABLE,TRIM4#	01/1990 - 01/1992	1
88610-6006003	HDJ80..GEN;HZJ80..GX,VX;FJ80..GX..GCC;FJ80,HDJ80..GX..(EFI,TD2);FJ80..(GX,VX)..(ARL,GEN)..CBR LIGHT GRAY,TRIM1#	01/1990 - 01/1992	1
88610-6006006	FZJ80..GX;HZJ80..GX,VX;FZJ80,HDJ80..VX..GEN;FJ80,HDJ80..GX..(EFI,TD2) LIGHT SABLE,TRIM4#	01/1992 - 08/1992	1
88610-6006003	FZJ80..GX;HZJ80..GX,VX;FZJ80,HDJ80..VX..GEN;FJ80,HDJ80..GX..(EFI,TD2) LIGHT GRAY,TRIM1#	01/1992 - 08/1992	1
88610-6006006	FZJ80,HDJ80,HZJ80..GX;FZJ80,HDJ80,HZJ80..VX..GEN LIGHT SABLE,TRIM4#	08/1992 - 01/1995	1
88610-6006003	FZJ80..4FC..VX..GEN;HDJ80..RHD..5F..TD2;FZJ80,HDJ80,HZJ80..GX;FZJ80,HDJ80,HZJ80..LHD..VX..GEN..(CBR,DSL,TD2) LIGHT GRAY,TRIM1#,4#	01/1995 - 01/1998	1
88610-6006003	FZJ80,HDJ80,HZJ80..GX;FZJ80,HDJ80,HZJ80..VX..GEN LIGHT GRAY,TRIM1#	08/1992 - 01/1995	1
88688H - BRACKET, COOLER AIR DUCT, NO.1
88688-60250	FJ80,HDJ80..LUB;FJ80..SOB..GX..GEN;HZJ80..(GX,VX)..(ARL,GEN)	01/1990 - 01/1992	1
88688-60560	HDJ80..LHD;FZJ80..4FC..GEN;HZJ80..5F..(GX,VX);HDJ80..RHD..5F..TD2;FZJ80..(ARL,GCC)..EFI;FZJ80,HDJ80..(GX,VX)..(CBR,TD4)	01/1995 - 01/1998	1
88688-60290	HDJ80..LHD;FJ80,FZJ80,HZJ80..LUB..(GX,VX)..GEN W(ROOF RACK)	01/1990 - 08/1992	1
88688-60250	FZJ80..LUB..(GX,VX);FJ80,HDJ80,HZJ80..(GX,VX)..(ARL,GEN)..(DSL,EFI,TD2)	01/1992 - 08/1992	1
Common parts
88688-60250
88688-60290
88688-60300
88688-60340
88688-60560
90119-08501
90159-50068
90159-60019
90164-50047
91651-40616

HZJ80L-GNMNS (1990)

ILLUST NO. 2 OF 3(9001- )LHD

ILLUST NO. 1 OF 3(9001- )LHD

ILLUST NO. 1 OF 5(9001- )

ILLUST NO. 1 OF 5(9001- )

ILLUST NO. 1 OF 5(9001- )FJ80..STD..GCC ; (9001- )FJ80,FZJ80,HZJ80..GEN

ILLUST NO. 2 OF 5(9001- )

ILLUST NO. 3 OF 5(9001- )

ILLUST NO. 4 OF 5(9001- )GX,VX

Part Price Details
