HJ61RG-PEZXQ (1987)
Toyota Land Cruiser
(8708- )12HT,2H
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 11011 - WASHER SET, CRANKSHAFT THRUST | ||||
| 11011-68020 |
12HT,2H..HJ6# STD |
1 | ||
| 11012-68020 |
12HT,2H..HJ6# O/S 0.125 |
1 | ||
| 11013-68020 |
12HT,2H..HJ6# O/S 0.250 |
1 | ||
| 11702 - BEARING SET, CRANKSHAFT | ||||
| 11706-68021 |
12HT,2H..HJ6# U/S 0.75 |
1 | ||
| 11704-68021 |
12HT,2H..HJ6# U/S 0.25 |
1 | ||
| 11707-68021 |
12HT,2H..HJ6# U/S 1.00 |
1 | ||
| 11705-68021 |
12HT,2H..HJ6# U/S 0.50 |
1 | ||
| 11711 - BEARING, CRANKSHAFT | ||||
| 11071-6802001 |
12HT,2H..HJ6# NO.2,MARK 1 |
1 | ||
| 11071-6802003 |
12HT,2H..HJ6# NO.2,MARK 3,MARK 3 |
1 | ||
| 11071-6802002 |
12HT,2H..HJ6# NO.2,MARK 2,MARK 2 |
1 | ||
| 11701-6802003 |
12HT,2H..HJ6# NO.1,MARK 3,MARK 3 |
6 | ||
| 11701-6802002 |
12HT,2H..HJ6# NO.1,MARK 2,MARK 2 |
6 | ||
| 11701-6802001 |
12HT,2H..HJ6# NO.1,MARK 1,MARK 1 |
6 | ||
| 11711 - BEARING, CRANKSHAFT | ||||
| 11071-6802001 |
12HT,2H..HJ6# NO.2,MARK 1 |
1 | ||
| 11071-6802003 |
12HT,2H..HJ6# NO.2,MARK 3,MARK 3 |
1 | ||
| 11071-6802002 |
12HT,2H..HJ6# NO.2,MARK 2,MARK 2 |
1 | ||
| 11701-6802003 |
12HT,2H..HJ6# NO.1,MARK 3,MARK 3 |
6 | ||
| 11701-6802002 |
12HT,2H..HJ6# NO.1,MARK 2,MARK 2 |
6 | ||
| 11701-6802001 |
12HT,2H..HJ6# NO.1,MARK 1,MARK 1 |
6 | ||
| 11711 - BEARING, CRANKSHAFT | ||||
| 11071-6802001 |
12HT,2H..HJ6# NO.2,MARK 1 |
1 | ||
| 11071-6802003 |
12HT,2H..HJ6# NO.2,MARK 3,MARK 3 |
1 | ||
| 11071-6802002 |
12HT,2H..HJ6# NO.2,MARK 2,MARK 2 |
1 | ||
| 11701-6802003 |
12HT,2H..HJ6# NO.1,MARK 3,MARK 3 |
6 | ||
| 11701-6802002 |
12HT,2H..HJ6# NO.1,MARK 2,MARK 2 |
6 | ||
| 11701-6802001 |
12HT,2H..HJ6# NO.1,MARK 1,MARK 1 |
6 | ||
| 11711 - BEARING, CRANKSHAFT | ||||
| 11071-6802001 |
12HT,2H..HJ6# NO.2,MARK 1 |
1 | ||
| 11071-6802003 |
12HT,2H..HJ6# NO.2,MARK 3,MARK 3 |
1 | ||
| 11071-6802002 |
12HT,2H..HJ6# NO.2,MARK 2,MARK 2 |
1 | ||
| 11701-6802003 |
12HT,2H..HJ6# NO.1,MARK 3,MARK 3 |
6 | ||
| 11701-6802002 |
12HT,2H..HJ6# NO.1,MARK 2,MARK 2 |
6 | ||
| 11701-6802001 |
12HT,2H..HJ6# NO.1,MARK 1,MARK 1 |
6 | ||
| 11711 - BEARING, CRANKSHAFT | ||||
| 11071-6802001 |
12HT,2H..HJ6# NO.2,MARK 1 |
1 | ||
| 11071-6802003 |
12HT,2H..HJ6# NO.2,MARK 3,MARK 3 |
1 | ||
| 11071-6802002 |
12HT,2H..HJ6# NO.2,MARK 2,MARK 2 |
1 | ||
| 11701-6802003 |
12HT,2H..HJ6# NO.1,MARK 3,MARK 3 |
6 | ||
| 11701-6802002 |
12HT,2H..HJ6# NO.1,MARK 2,MARK 2 |
6 | ||
| 11701-6802001 |
12HT,2H..HJ6# NO.1,MARK 1,MARK 1 |
6 | ||
| 11711 - BEARING, CRANKSHAFT | ||||
| 11071-6802001 |
12HT,2H..HJ6# NO.2,MARK 1 |
1 | ||
| 11071-6802003 |
12HT,2H..HJ6# NO.2,MARK 3,MARK 3 |
1 | ||
| 11071-6802002 |
12HT,2H..HJ6# NO.2,MARK 2,MARK 2 |
1 | ||
| 11701-6802003 |
12HT,2H..HJ6# NO.1,MARK 3,MARK 3 |
6 | ||
| 11701-6802002 |
12HT,2H..HJ6# NO.1,MARK 2,MARK 2 |
6 | ||
| 11701-6802001 |
12HT,2H..HJ6# NO.1,MARK 1,MARK 1 |
6 | ||
| 11711 - BEARING, CRANKSHAFT | ||||
| 11071-6802001 |
12HT,2H..HJ6# NO.2,MARK 1 |
1 | ||
| 11071-6802003 |
12HT,2H..HJ6# NO.2,MARK 3,MARK 3 |
1 | ||
| 11071-6802002 |
12HT,2H..HJ6# NO.2,MARK 2,MARK 2 |
1 | ||
| 11701-6802003 |
12HT,2H..HJ6# NO.1,MARK 3,MARK 3 |
6 | ||
| 11701-6802002 |
12HT,2H..HJ6# NO.1,MARK 2,MARK 2 |
6 | ||
| 11701-6802001 |
12HT,2H..HJ6# NO.1,MARK 1,MARK 1 |
6 | ||
| 13011 - RING SET, PISTON | ||||
| 13011-68030 |
12HT..HJ61 STD |
2 | ||
| 13013-68030 |
12HT..HJ61 O/S 0.50 |
1 | ||
| 13041 - BEARING, CONNECTING ROD | ||||
| 13041-6804001 |
12HT..HJ61..VX MARK 1 |
6 | ||
| 13041-6805002 |
12HT..HJ61 MARK 2 |
6 | ||
| 13041-6804002 |
12HT,2H..HJ6# MARK 2 |
6 | ||
| 13041-6805001 |
12HT..HJ61 MARK 1 |
6 | ||
| 13041 - BEARING, CONNECTING ROD | ||||
| 13041-6804001 |
12HT..HJ61..VX MARK 1 |
6 | ||
| 13041-6805002 |
12HT..HJ61 MARK 2 |
6 | ||
| 13041-6804002 |
12HT,2H..HJ6# MARK 2 |
6 | ||
| 13041-6805001 |
12HT..HJ61 MARK 1 |
6 | ||
| 13041 - BEARING, CONNECTING ROD | ||||
| 13041-6804001 |
12HT..HJ61..VX MARK 1 |
6 | ||
| 13041-6805002 |
12HT..HJ61 MARK 2 |
6 | ||
| 13041-6804002 |
12HT,2H..HJ6# MARK 2 |
6 | ||
| 13041-6805001 |
12HT..HJ61 MARK 1 |
6 | ||
| 13041 - BEARING, CONNECTING ROD | ||||
| 13041-6804001 |
12HT..HJ61..VX MARK 1 |
6 | ||
| 13041-6805002 |
12HT..HJ61 MARK 2 |
6 | ||
| 13041-6804002 |
12HT,2H..HJ6# MARK 2 |
6 | ||
| 13041-6805001 |
12HT..HJ61 MARK 1 |
6 | ||
| 13041 - BEARING, CONNECTING ROD | ||||
| 13041-6804001 |
12HT..HJ61..VX MARK 1 |
6 | ||
| 13041-6805002 |
12HT..HJ61 MARK 2 |
6 | ||
| 13041-6804002 |
12HT,2H..HJ6# MARK 2 |
6 | ||
| 13041-6805001 |
12HT..HJ61 MARK 1 |
6 | ||
| 13041 - BEARING, CONNECTING ROD | ||||
| 13041-6804001 |
12HT..HJ61..VX MARK 1 |
6 | ||
| 13041-6805002 |
12HT..HJ61 MARK 2 |
6 | ||
| 13041-6804002 |
12HT,2H..HJ6# MARK 2 |
6 | ||
| 13041-6805001 |
12HT..HJ61 MARK 1 |
6 | ||
| 13041 - BEARING, CONNECTING ROD | ||||
| 13041-6804001 |
12HT..HJ61..VX MARK 1 |
6 | ||
| 13041-6805002 |
12HT..HJ61 MARK 2 |
6 | ||
| 13041-6804002 |
12HT,2H..HJ6# MARK 2 |
6 | ||
| 13041-6805001 |
12HT..HJ61 MARK 1 |
6 | ||
| 13101 - PISTON SUB-ASSY, W/PIN | ||||
| 13101-68020 |
12HT..HJ61 STD |
6 | ||
| 13101-68020 |
12HT..HJ61 STD |
6 | ||
| 13101-6802001 |
12HT..HJ61 STD,MARK 1 |
6 | ||
| 13101-6802003 |
12HT..HJ61 STD,MARK 3 |
6 | ||
| 13103-68020 |
12HT..HJ61 O/S 0.50 |
6 | ||
| 13101-6802002 |
12HT..HJ61 STD,MARK 2 |
6 | ||
| 13101A - RING, HOLE SNAP(FOR PISTON PIN) | ||||
| 90521-34004 |
12HT..HJ61 |
8 | ||
| 13201 - ROD SUB-ASSY, CONNECTING | ||||
| 13201-68020 |
12HT..HJ61 |
6 | ||
| 13201-69095 |
12HT..HJ61 |
6 | ||
| 13201 - ROD SUB-ASSY, CONNECTING | ||||
| 13201-68020 |
12HT..HJ61 |
6 | ||
| 13201-69095 |
12HT..HJ61 |
6 | ||
| 13201A - BUSH(FOR CONNECTING ROD SMALL END) | ||||
| 90999-73108 |
12HT..HJ61 |
6 | ||
| 13202 - BEARING SET, CONNECTING ROD | ||||
| 13204-68040 |
12HT..HJ61..VX U/S 0.25 |
1 | ||
| 13206-68040 |
12HT,2H..HJ6# U/S 0.75 |
1 | ||
| 13205-68040 |
12HT,2H..HJ6# U/S 0.50 |
1 | ||
| 13207-68040 |
12HT,2H..HJ6# U/S 1.00 |
1 | ||
| 13207-68050 |
12HT..HJ61 U/S 1.00 |
1 | ||
| 13204-68050 |
12HT..HJ61 U/S 0.25 |
1 | ||
| 13205-68050 |
12HT..HJ61 U/S 0.50 |
1 | ||
| 13206-68050 |
12HT..HJ61 U/S 0.75 |
1 | ||
| 13265 - BOLT, CONNECTING ROD | ||||
| 13265-68010 |
12HT,2H..HJ6# |
8 | ||
| 13265A - NUT, HEXAGON(FOR CONNECTING ROD BOLT) | ||||
| 90179-12015 |
12HT,2H..HJ6# |
8 | ||
| 13411 - CRANKSHAFT | ||||
| 13401-68020 |
12HT..HJ61 |
1 | ||
| 13434 - SPLINE, OIL PUMP DRIVE | ||||
| 13519-68010 |
12HT,2H..HJ6# |
1 | ||
| 13471 - PULLEY, CRANKSHAFT | ||||
| 13470-68020 |
12HT,2H..HJ6#..ARL |
1 | ||
| 13471 - PULLEY, CRANKSHAFT | ||||
| 13470-68020 |
12HT,2H..HJ6#..ARL |
1 | ||
| 13471A - KEY, CRANKSHAFT(FOR CRANKSHAFT PULLEY SET) | ||||
| 95161-10519 |
12HT,2H..HJ6# |
1 | ||
| 13471E - NUT(FOR CRANKSHAFT PULLEY) | ||||
| 90179-22062 |
12HT,2H..HJ6# |
1 | ||
| 13521 - GEAR OR SPROCKET, CRANKSHAFT TIMING | ||||
| 13521-68010 |
12HT,2H..HJ6# |
1 | ||
| 13521A - KEY(FOR CRANKSHAFT TIMING GEAR) | ||||
| 95161-10519 |
12HT,2H..HJ6# |
1 | ||
| 13525 - GEAR, IDLE, NO.1 | ||||
| 13525-68010 |
12HT,2H..HJ6# |
1 | ||
| 13526 - GEAR, IDLE, NO.2 | ||||
| 13526-68010 |
12HT,2H..HJ6# |
1 | ||
| 13572 - PLATE, IDLE GEAR THRUST | ||||
| 13572-68010 |
12HT,2H..HJ6# |
1 | ||
| 13572 - PLATE, IDLE GEAR THRUST | ||||
| 13572-68010 |
12HT,2H..HJ6# |
1 | ||
| 13577A - BOLT, HEXAGON(FOR IDLE GEAR BOLT LOCK) | ||||
| 90105-10036 |
12HT,2H..HJ6# |
2 | ||
| 13577A - BOLT, HEXAGON(FOR IDLE GEAR BOLT LOCK) | ||||
| 90105-10036 |
12HT,2H..HJ6# |
2 | ||
| 13581 - SHAFT, IDLE GEAR, NO.1 | ||||
| 13581-68010 |
12HT,2H..HJ6# |
1 | ||
| 13582 - SHAFT, IDLE GEAR, NO.2 | ||||
| 13582-68010 |
12HT,2H..HJ6# |
1 | ||
| Common parts | ||||
| 91611-60812 | ||||
| 91611-60820 | ||||
