HDJ80R-GNMNWQ (1995)

Toyota Land Cruiser

Production Jan 1995 - Jan 1998
Engine 1HDFT
Transmission 5F MTM
Displacement 2500cc
Power 168 HP (125 kW)

(9501- )

Click highlighted areas on diagram

4-SPOKE

diagram 45100 45130 45186 45187 45188 45201P 9356054012
Part # Description Qty Price
45100 - WHEEL ASSY, STEERING
45100-60200B0

HDJ80..GX;HZJ80..ARL,GCC;FZJ80..4FC..GX..ARL;FZJ80..5F..(GX,STD)..(ARL,GCC)

4-SPOKE,URETHANE,W(*80),BLUEISH GRAY,TRIM1#

 1
45100-60200E0

HDJ80..GX;HZJ80..ARL,GCC;FZJ80..4FC..GX..ARL;FZJ80..5F..(GX,STD)..(ARL,GCC)

4-SPOKE,URETHANE,W(*80),OAK,TRIM4#

 1
45100-60210B0

HDJ80..GX;FZJ80..4FC..GX..ARL

4-SPOKE,URETHANE,W(*80 & *CRC),BLUEISH GRAY,TRIM1#

 1
45100-60210E0

HDJ80..GX;FZJ80..4FC..GX..ARL

4-SPOKE,URETHANE,W(*80 & *CRC),OAK,TRIM4#

 1
45130 - BUTTON ASSY, HORN
45130-6016001

FJ80,FZJ80,HDJ80,HZJ80..GX,VX

BLACK,TRIM1#,4#

 1
45130-50110E0

HDJ80..GX;HZJ80..ARL,GCC;FZJ80..4FC..GX..ARL;FZJ80..5F..(GX,STD)..(ARL,GCC)

W(*80),OAK,TRIM4#

 1
45130-50110B1

HDJ80..GX;HZJ80..ARL,GCC;FZJ80..4FC..GX..ARL;FZJ80..5F..(GX,STD)..(ARL,GCC)

W(*80),BLUEISH GRAY,TRIM1#

 1
45186 - COVER, STEERING WHEEL, LOWER NO.2
45186-60030E0

HDJ80..GX;FZJ80..4FC..GX..ARL

W(*80 & *CRC),OAK,TRIM4#

 1
45186-60020B0

HDJ80..GX;HZJ80..VX..GCC;FZJ80..4FC..GX..ARL

W(*80),BLUEISHGRAY,TRIM1#

 1
45186-60020E0

HDJ80..GX;HZJ80..VX..GCC;FZJ80..4FC..GX..ARL

W(*80),OAK,TRIM4#

 1
45186-60030B0

HDJ80..GX;FZJ80..4FC..GX..ARL

W(*80 & *CRC),BLUEISHGRAY,TRIM1#

 1
45201P - NUT, STEERING WHEEL SET
90179-12086

FJ80,FZJ80,HDJ80,HZJ80

 1
Common parts
93560-54012
