FJ80L-GNPES (1990)

Toyota Land Cruiser

Production Jan 1990 - Jan 1992
Engine 3F
Transmission 4FC ATM
Displacement 2500cc
Power 168 HP (125 kW)

(9001- )

Click highlighted areas on diagram

diagram 33621A 35519 36369 41991A 74511F 74529 74535B 74536A 74537A 74538B 74543R 74547B 74552 74559A 74559A 74559A 74567A 74574A 74575C 74582 74582A 86995B
Part # Description Qty Price

(9001- )

Click highlighted areas on diagram

diagram 33621A 35519 36369 41991A 45197A 47939A 69339A 69339B 74515A 74529 74533 74536A 74538B 74544E 74552 74552 74559A 74559A 74559A 74559B 74582 74582A 74582B 74597
Part # Description Qty Price
33621A - PLATE, CONTROL LEVER CAUTION
33621-60310

FJ80,HDJ80,HZJ80..LHD..4FC

 1
35519 - PLATE, AUTOMATIC TRANSMISSION CAUTION
35519-60010

FJ80,HDJ80,HZJ80..LHD..4FC

 1
35519-60040

FJ80,HDJ80,HZJ80..4FC

 1
36369 - LABEL, TRANSFER INFORMATION
36369-60070

FJ80,HDJ80,HZJ80..LHD..4FC

 1
41991A - PLATE, CAUTION
41991-60060

FJ80,HDJ80,HZJ80

 1
69339B - PLATE, CHILD PROTECTOR LOCK CAUTION
69339-91704

FJ80,FZJ80,HDJ80,HZJ80..LUB..(GX,VX)

 1
74529 - PLATE, CHILD PROOF OR CHILD PROTECTOR LOCK CAUTION
69339-12010

FJ80,FZJ80,HDJ80,HZJ80

DOOR ROCK

 2
74536A - LABEL, FUEL TANK CAP INFORMATION
74536-60010

FJ80,FZJ80,HDJ80,HZJ80..GCC,GEN

 1
74536-60010

FJ80,FZJ80,HDJ80,HZJ80..GCC,GEN

W(SUB FUEL TANK)

 2
74544E - LABEL, REAR NO.2 SEAT INFORMATION
74544-60090

FZJ80..LHD..SOB..STD..GEN;FJ80,FZJ80,HDJ80,HZJ80..GX,VX

 1
74552 - PLATE, SAFETY CAUTION
74582-60310

FJ80..LHD..4F;FJ80..LHD..5F..STD..GEN;HZJ80..LHD..MTM..(GX,STD)..GEN

ALGERIA SPEC & W(9.00-15-6 TIRE)

 1
74582-60180

FJ80..SOB..GEN;FJ80..4FC..SOB;HDJ80,HZJ80..GEN;FJ80..LUB..(GCC,GEN)

W(7.50R16-8 TIRE)

 1
74582-60170

FJ80..SOB..GEN;FJ80..4FC..SOB;HDJ80,HZJ80..GEN;FJ80..LUB..(GCC,GEN)

W(9.00-15-6 TIRE)

 1
74582-60320

FJ80..LHD..4F;FZJ80..LHD..SOB..GEN;FJ80..LHD..5F..STD..GEN;HZJ80..LHD..MTM..(GX,STD)..GEN

ALGERIA SPEC & W(7.50R16-8 TIRE)

 1
74552 - PLATE, SAFETY CAUTION
74582-60310

FJ80..LHD..4F;FJ80..LHD..5F..STD..GEN;HZJ80..LHD..MTM..(GX,STD)..GEN

ALGERIA SPEC & W(9.00-15-6 TIRE)

 1
74582-60180

FJ80..SOB..GEN;FJ80..4FC..SOB;HDJ80,HZJ80..GEN;FJ80..LUB..(GCC,GEN)

W(7.50R16-8 TIRE)

 1
74582-60170

FJ80..SOB..GEN;FJ80..4FC..SOB;HDJ80,HZJ80..GEN;FJ80..LUB..(GCC,GEN)

W(9.00-15-6 TIRE)

 1
74582-60320

FJ80..LHD..4F;FZJ80..LHD..SOB..GEN;FJ80..LHD..5F..STD..GEN;HZJ80..LHD..MTM..(GX,STD)..GEN

ALGERIA SPEC & W(7.50R16-8 TIRE)

 1
74559B - LABEL, FUEL INFORMATION
74572-60010

FZJ80..GX,VX;FZJ80..SOB..STD;FJ80,HDJ80,HZJ80..CBR,DSL,TD2

 1
