FJ80L-GCKRS (1990)

Toyota Land Cruiser

Production Jan 1990 - Jan 1992
Engine 3F
Transmission 4F MTM
Displacement 2500cc
Power 168 HP (125 kW)

(9001- )

Click highlighted areas on diagram

diagram 11278 11283 11284 11289 11291 11291 11293 11296A 11296A 11296B 11297B 11298 1356410010 15369 17700C 17700C 17700C 17700D 17791 17792 19869 23923
Part # Description Qty Price
Common parts
13564-10010

ILLUST NO. 2 OF 2(9001- )

Click highlighted areas on diagram

diagram 11291 11296A 11296A 11296A 11296B 1356410010 17792
Part # Description Qty Price
Common parts
13564-10010

ILLUST NO. 1 OF 2(9001- )

Click highlighted areas on diagram

diagram 11278 11283 11284 11292 11293 11296A 11298 15369 16793 17700C 17700D 17791 17792 23923
Part # Description Qty Price
11293 - PLATE, ENGINE CAUTION & ENGINE NAME
11293-61040

3F..FJ80

 1
15369 - PLATE, ENGINE OIL CAUTION
15369-61010

3F..FJ80..LHD..STD..GEN;3F..FJ80..LHD..MTM..LUB..GX..GEN

CHINA SPEC

 1
17700C - PLATE, AIR CLEANER CAUTION (FOR ENGINE MODEL)
90917-07108

1FZF,3F#..FJ80,FZJ80

 1
17700D - PLATE, ENGINE CAUTION
90917-07109

1FZF,3F#,1H#..FJ80,FZJ80,HDJ80,HZJ80

 1
