GUN143L-MDMMYV (2017)
Toyota Innova
(1511- )
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 48231A - SPRING, COIL, REAR RH | ||||
| 48231-0K320 |
GUN142..GEN,IDN;TGN141..5F..27..LA;GUN143,TGN141..6FC..(GCC,LA);GUN143,TGN140..IDNP..(IDN,PHL,TH) |
1 | ||
| 48231-0K320 |
TGN140..20..GEN;GUN143,TGN141..5F..(GCC,GEN);GUN143,TGN140..PHLP..(20E,20G,28E,28G,28V,N);GUN142,TGN141..(24,24G,24V,27SR,28V)..(GCC,LA,SA,TH) |
1 | ||
| 48231B - SPRING, COIL, REAR LH | ||||
| 48231-0K320 |
GUN142..GEN,IDN;TGN141..5F..27..LA;GUN143,TGN141..6FC..(GCC,LA);GUN143,TGN140..IDNP..(IDN,PHL,TH) |
1 | ||
| 48231-0K320 |
TGN140..20..GEN;GUN143,TGN141..5F..(GCC,GEN);GUN143,TGN140..PHLP..(20E,20G,28E,28G,28V,N);GUN142,TGN141..(24,24G,24V,27SR,28V)..(GCC,LA,SA,TH) |
1 | ||
| 48257C - INSULATOR, REAR COIL SPRING, UPPER RH | ||||
| 48257-0K010 |
GUN142..GEN,IDN;TGN141..5F..27..LA;GUN143,TGN141..6FC..(GCC,LA);GUN143,TGN140..IDNP..(IDN,PHL,TH) |
1 | ||
| 48257-0K010 |
TGN140..(MAP,PHLP)..5F;TGN14#..(20,27SR)..(GEN,LA);GUN142..(GCC,IND,SA,TH)..DCR;GUN143,TGN141..5F..(GCC,GEN);TGN140..PHLP..6FC..(20E,20G);GUN143..(INDP,PHLP)..(28E,28G,28V,28Z,N) |
1 | ||
| 48259A - INSULATOR, REAR COIL SPRING, UPPER LH | ||||
| 48257-0K010 |
GUN142..GEN,IDN;TGN141..5F..27..LA;GUN143,TGN141..6FC..(GCC,LA);GUN143,TGN140..IDNP..(IDN,PHL,TH) |
1 | ||
| 48257-0K010 |
TGN140..(MAP,PHLP)..5F;TGN14#..(20,27SR)..(GEN,LA);GUN142..(GCC,IND,SA,TH)..DCR;GUN143,TGN141..5F..(GCC,GEN);TGN140..PHLP..6FC..(20E,20G);GUN143..(INDP,PHLP)..(28E,28G,28V,28Z,N) |
1 | ||
| 48341A - BUMPER, REAR SPRING, NO.1 RH | ||||
| 48341-0K150 |
GUN142..GEN,IDN;TGN141..5F..27..LA;GUN143,TGN141..6FC..(GCC,LA);GUN143,TGN140..IDNP..(IDN,PHL,TH) |
1 | ||
| 48341-0K150 |
TGN140..20..GEN;TGN140..(MAP,PHLP)..5F;GUN143,TGN141..5F..(GCC,GEN);TGN140..PHLP..6FC..(20E,20G);GUN143..PHLP..(28E,28G,28V,N);GUN142,TGN141..(24,24G,24V,27SR,28V)..(GCC,LA,SA,TH) |
1 | ||
| 48341B - BUMPER, REAR SPRING, NO.1 LH | ||||
| 48341-0K150 |
GUN142..GEN,IDN;TGN141..5F..27..LA;GUN143,TGN141..6FC..(GCC,LA);GUN143,TGN140..IDNP..(IDN,PHL,TH) |
1 | ||
| 48341-0K150 |
TGN140..20..GEN;TGN140..(MAP,PHLP)..5F;GUN143,TGN141..5F..(GCC,GEN);TGN140..PHLP..6FC..(20E,20G);GUN143..PHLP..(28E,28G,28V,N);GUN142,TGN141..(24,24G,24V,27SR,28V)..(GCC,LA,SA,TH) |
1 | ||
| 48516 - BRACKET, REAR SHOCK ABSORBER, UPPER RH | ||||
| 48516-0K030 |
TGN140..(MAP,PHLP)..5F;TGN14#..(20,27SR)..(GEN,LA);GUN142..(GCC,IND,SA,TH)..DCR;GUN143,TGN141..5F..(GCC,GEN);TGN140..PHLP..6FC..(20E,20G);GUN143..(INDP,PHLP)..(28E,28G,28V,28Z,N) |
1 | ||
| 48516-0K030 |
GUN142..GEN,IDN;TGN141..5F..27..LA;GUN143,TGN141..6FC..(GCC,LA);GUN143,TGN140..IDNP..(IDN,PHL,TH) |
1 | ||
| 48517 - BRACKET, REAR SHOCK ABSORBER, UPPER LH | ||||
| 48517-0K020 |
GUN142..GEN,IDN;TGN141..5F..27..LA;GUN143,TGN141..6FC..(GCC,LA);GUN143,TGN140..IDNP..(IDN,PHL,TH) |
1 | ||
| 48517-0K020 |
TGN140..(MAP,PHLP)..5F;TGN14#..(20,27SR)..(GEN,LA);GUN142..(GCC,IND,SA,TH)..DCR;GUN143,TGN141..5F..(GCC,GEN);TGN140..PHLP..6FC..(20E,20G);GUN143..(INDP,PHLP)..(28E,28G,28V,28Z,N) |
1 | ||
| 48530 - ABSORBER ASSY, SHOCK, REAR RH | ||||
| 48530-8Z036 |
GUN142..GEN,IDN;TGN141..5F..27..LA;GUN143,TGN141..6FC..(GCC,LA);GUN143,TGN140..IDNP..(IDN,PHL,TH) MARK 48530-0K010 |
1 | ||
| 48530-8Z036 |
TGN140..20..GEN;GUN143,TGN141..5F..(GCC,GEN);GUN143,TGN140..PHLP..(20E,20G,28E,28G,28V,N);GUN142,TGN141..(24,24G,24V,27SR,28V)..(GCC,LA,SA,TH) MARK 48530-0K010 |
1 | ||
| 48530G - CUSHION, REAR SHOCK ABSORBER, NO.1 | ||||
| 90948-T1008 |
TGN140..20..GEN;GUN143,TGN141..5F..(GCC,GEN);GUN143,TGN140..PHLP..(20E,20G,28E,28G,28V,N);GUN142,TGN141..(24,24G,24V,27SR,28V)..(GCC,LA,SA,TH) |
2 | ||
| 90948-T1008 |
GUN142..GEN,IDN;TGN141..5F..27..LA;GUN143,TGN141..6FC..(GCC,LA);GUN143,TGN140..IDNP..(IDN,PHL,TH) |
2 | ||
| 48530J - RETAINER, CUSHION, NO.1(FOR REAR SHOCK ABSORBER) | ||||
| 90948-T2005 |
GUN142..GEN,IDN;TGN141..5F..27..LA;GUN143,TGN141..6FC..(GCC,LA);GUN143,TGN140..IDNP..(IDN,PHL,TH) |
2 | ||
| 90948-T2005 |
TGN140..(MAP,PHLP)..5F;TGN14#..(20,27SR)..(GEN,LA);GUN142..(GCC,IND,SA,TH)..DCR;GUN143,TGN141..5F..(GCC,GEN);TGN140..PHLP..6FC..(20E,20G);GUN143..(INDP,PHLP)..(28E,28G,28V,28Z,N) |
2 | ||
| 48530K - CUSHION, REAR SHOCK ABSORBER, NO.2 | ||||
| 90948-T1011 |
GUN142..GEN,IDN;TGN141..5F..27..LA;GUN143,TGN141..6FC..(GCC,LA);GUN143,TGN140..IDNP..(IDN,PHL,TH) |
2 | ||
| 90948-T1011 |
TGN140..20..GEN;GUN143,TGN141..5F..(GCC,GEN);GUN143,TGN140..PHLP..(20E,20G,28E,28G,28V,N);GUN142,TGN141..(24,24G,24V,27SR,28V)..(GCC,LA,SA,TH) |
2 | ||
| 48530P - RETAINER, CUSHION, NO.2(FOR REAR SHOCK ABSORBER) | ||||
| 90948-T2008 |
GUN142..GEN,IDN;TGN141..5F..27..LA;GUN143,TGN141..6FC..(GCC,LA);GUN143,TGN140..IDNP..(IDN,PHL,TH) |
4 | ||
| 90948-T2008 |
TGN140..(MAP,PHLP)..5F;TGN14#..(20,27SR)..(GEN,LA);GUN142..(GCC,IND,SA,TH)..DCR;GUN143,TGN141..5F..(GCC,GEN);TGN140..PHLP..6FC..(20E,20G);GUN143..(INDP,PHLP)..(28E,28G,28V,28Z,N) |
4 | ||
| 48530P - RETAINER, CUSHION, NO.2(FOR REAR SHOCK ABSORBER) | ||||
| 90948-T2008 |
GUN142..GEN,IDN;TGN141..5F..27..LA;GUN143,TGN141..6FC..(GCC,LA);GUN143,TGN140..IDNP..(IDN,PHL,TH) |
4 | ||
| 90948-T2008 |
TGN140..(MAP,PHLP)..5F;TGN14#..(20,27SR)..(GEN,LA);GUN142..(GCC,IND,SA,TH)..DCR;GUN143,TGN141..5F..(GCC,GEN);TGN140..PHLP..6FC..(20E,20G);GUN143..(INDP,PHLP)..(28E,28G,28V,28Z,N) |
4 | ||
| 48540 - ABSORBER ASSY, SHOCK, REAR LH | ||||
| 48530-8Z036 |
GUN142..GEN,IDN;TGN141..5F..27..LA;GUN143,TGN141..6FC..(GCC,LA);GUN143,TGN140..IDNP..(IDN,PHL,TH) MARK 48530-0K010 |
1 | ||
| 48530-8Z036 |
TGN140..20..GEN;GUN143,TGN141..5F..(GCC,GEN);GUN143,TGN140..PHLP..(20E,20G,28E,28G,28V,N);GUN142,TGN141..(24,24G,24V,27SR,28V)..(GCC,LA,SA,TH) MARK 48530-0K010 |
1 | ||
| 48710 - ARM ASSY, UPPER CONTROL | ||||
| 48710-0K070 |
TGN141..5F..27..LA;GUN142..24G..(GEN,IDN);GUN143,TGN141..6FC..(27,27G,27SRV,28,28G)..(GCC,LA);GUN143,TGN140..IDNP..(20E,20G,28E,28G,N)..(IDN,PHL,TH) |
2 | ||
| 48710-0K070 |
TGN140..20..GEN;TGN140..(MAP,PHLP)..5F;GUN143..PHLP..(28E,28G,N);GUN143,TGN141..5F..(GCC,GEN);TGN140..PHLP..6FC..(20E,20G);GUN142,TGN141..(24,24G,27SR)..(GCC,LA,SA,TH) |
2 | ||
| 48720 - ARM ASSY, LOWER CONTROL, RH | ||||
| 48720-0K010 |
GUN14#,TGN14#..IDNP |
1 | ||
| 48730 - ARM ASSY, LOWER CONTROL, LH | ||||
| 48720-0K010 |
GUN14#,TGN14#..IDNP |
1 | ||
| 48740 - ROD ASSY, REAR LATERAL CONTROL | ||||
| 48740-0K050 |
TGN140..20..GEN;TGN140..(MAP,PHLP)..5F;GUN143,TGN141..5F..(GCC,GEN);TGN140..PHLP..6FC..(20E,20G);GUN143..PHLP..(28E,28G,28V,N);GUN142,TGN141..(24,24G,24V,27SR,28V)..(GCC,LA,SA,TH) |
1 | ||
| 48740-0K050 |
GUN142..GEN,IDN;TGN141..5F..27..LA;GUN143,TGN141..6FC..(GCC,LA);GUN143,TGN140..IDNP..(IDN,PHL,TH) |
1 | ||
| 48745 - BUSH, LATERAL CONTROL ROD | ||||
| 90385-T0012 |
GUN142..GEN,IDN;TGN141..5F..27..LA;GUN143,TGN141..6FC..(GCC,LA);GUN143,TGN140..IDNP..(IDN,PHL,TH) |
2 | ||
| 90385-T0012 |
TGN140..20..GEN;TGN140..(MAP,PHLP)..5F;GUN143,TGN141..5F..(GCC,GEN);TGN140..PHLP..6FC..(20E,20G);GUN143..PHLP..(28E,28G,28V,N);GUN142,TGN141..(24,24G,24V,27SR,28V)..(GCC,LA,SA,TH) |
2 | ||
| 48745 - BUSH, LATERAL CONTROL ROD | ||||
| 90385-T0012 |
GUN142..GEN,IDN;TGN141..5F..27..LA;GUN143,TGN141..6FC..(GCC,LA);GUN143,TGN140..IDNP..(IDN,PHL,TH) |
2 | ||
| 90385-T0012 |
TGN140..20..GEN;TGN140..(MAP,PHLP)..5F;GUN143,TGN141..5F..(GCC,GEN);TGN140..PHLP..6FC..(20E,20G);GUN143..PHLP..(28E,28G,28V,N);GUN142,TGN141..(24,24G,24V,27SR,28V)..(GCC,LA,SA,TH) |
2 | ||
| Common parts | ||||
| 90105-T0135 | ||||
| 90105-T0149 | ||||
| 90119-T0140 | ||||
| 90119-T0243 | ||||
| 90119-T0264 | ||||
| 90119-T0413 | ||||
| 90177-T0009 | ||||
| 90178-T0041 | ||||
| 90178-T0048 | ||||
| 90201-T0015 | ||||
| 90209-T0002 | ||||
| 94188-01601 | ||||
