LN85R-PRMDSQ (1988)
Toyota Hilux 2wd
(8808- )RN90..V ; (8808- )LN85..ARL..CBU
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 65414 - STOPPER, GUARD FRAME | ||||
| 65414-89102 |
LN8#,RN8#,YN8#..(ARL,GEN,V)..CBU |
2 | ||
| 65470 - BOARD ASSY, HEADER | ||||
| 65470-89143 |
LN85,86,RN85..DLX..ARL |
1 | ||
| 65470-89142 |
LN85,86,RN85..DLX..ARL W(GUARD FRAME) |
1 | ||
| 65470 - BOARD ASSY, HEADER | ||||
| 65470-89143 |
LN85,86,RN85..DLX..ARL |
1 | ||
| 65470-89142 |
LN85,86,RN85..DLX..ARL W(GUARD FRAME) |
1 | ||
| 65700 - GATE ASSY, REAR BODY TAIL | ||||
| 65700-89146 |
RN85..LHD..GEN..CBU;LN85,86,RN85,YN85..ARL..CBU |
1 | ||
| 65737 - STOP, TAIL GATE | ||||
| 65737-89105 |
LN85,YN85..ARL..CBU;LN90,RN85,90,YN92..(ARL,GEN)..CBU |
2 | ||
| 65759 - COVER, TAIL GATE SERVICE HOLE | ||||
| 65759-89102 |
LN90..TH;LN8#,RN8#,YN8#..CBU |
1 | ||
| 65759-89102 |
YN87..CBU;LN8#,RN8#,YN80,81,85,86..(ARL,GEN,V)..CBU |
1 | ||
| 65768A - STRIKER, TAIL GATE LOCK | ||||
| 65768-89102 |
RN85..LHD..GEN..CBU;LN85,RN85,YN85..ARL..CBU;LN86,90,RN90,YN92..(ARL,GEN)..CBU |
2 | ||
| 65770A - STAY ASSY, TAIL GATE | ||||
| 65770-89103 |
LN85,YN85..ARL..CBU;LN90,RN85,90,YN92..(ARL,GEN)..CBU |
2 | ||
| 65778 - STOPPER, TAIL GATE STAY | ||||
| 65778-89104 |
LN85,YN85..ARL..CBU;LN90,RN85,90,YN92..(ARL,GEN)..CBU |
4 | ||
| 65778-89105 |
LN85,YN85..ARL..CBU;LN90,RN85,90,YN92..(ARL,GEN)..CBU |
4 | ||
| 65780A - LOCK ASSY, TAIL GATE, RH | ||||
| 65780-89105 |
RN85..LHD..GEN..CBU;LN85,RN85,YN85..ARL..CBU;LN86,90,RN90,YN92..(ARL,GEN)..CBU |
1 | ||
| 65790A - LOCK ASSY, TAIL GATE, LH | ||||
| 65790-89106 |
RN85..LHD..GEN..CBU;LN85,86,RN85,YN85..ARL..CBU |
1 | ||
| 66110 - HINGE ASSY, TAIL GATE | ||||
| 66120-89101 |
LN8#,90,RN8#,90,YN8#,92..CBU LH |
1 | ||
| 66110-89107 |
LN8#,90,RN8#,90,YN8#,92..CBU RH |
1 | ||
| 66110 - HINGE ASSY, TAIL GATE | ||||
| 66120-89101 |
LN8#,90,RN8#,90,YN8#,92..CBU LH |
1 | ||
| 66110-89107 |
LN8#,90,RN8#,90,YN8#,92..CBU RH |
1 | ||
| 66311D - HOOK, ROPE | ||||
| 66311-89109 |
LN8#,RN8#,YN8#..(ARL,GEN,V)..CBU |
2 | ||
| 66321A - BUMPER, GATE RUBBER | ||||
| 66321-89109 |
LN85,YN85..ARL..CBU;LN90,RN85,90,YN92..(ARL,GEN)..CBU |
2 | ||
| 69090B - HANDLE ASSY, TAIL GATE | ||||
| 69090-89102 |
RN85..LHD..GEN..CBU;LN85,RN85,YN85..ARL..CBU;LN86,90,RN90,YN92..(ARL,GEN)..CBU |
1 | ||
| 69759D - SILENCER, TAIL GATE LOCK LINK | ||||
| 69759-89108 |
RN85..LHD..GEN..CBU;LN85,RN85,YN85..ARL..CBU;LN86,90,RN90,YN92..(ARL,GEN)..CBU |
2 | ||
| 69759E - SNAP, TAIL GATE LOCK LINK | ||||
| 69759-20110 |
RN85..LHD..GEN..CBU;LN85,RN85,YN85..ARL..CBU;LN86,90,RN90,YN92..(ARL,GEN)..CBU BLACK |
1 | ||
| 69759-20100 |
RN85..LHD..GEN..CBU;LN85,RN85,YN85..ARL..CBU;LN86,90,RN90,YN92..(ARL,GEN)..CBU RED |
1 | ||
| Common parts | ||||
| 90109-06022 | ||||
| 90119-10510 | ||||
| 90149-80020 | ||||
| 90159-60298 | ||||
| 90159-60535 | ||||
| 90179-06016 | ||||
| 90189-06010 | ||||
| 90901-07002 | ||||
| 91511-B0814 | ||||
| 91655-40820 | ||||
| 93260-56010 | ||||
| 93330-18016 | ||||
(8808- )LN90..5F..TH ; (8808- )LN85..GEN,TH..CBU ; (8808- )LN200,80,81,86,
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 65414 - STOPPER, GUARD FRAME | ||||
| 65414-89102 |
LN8#,RN8#,YN8#..(ARL,GEN,V)..CBU |
2 | ||
| 65414 - STOPPER, GUARD FRAME | ||||
| 65414-89102 |
LN8#,RN8#,YN8#..(ARL,GEN,V)..CBU |
2 | ||
| 65470 - BOARD ASSY, HEADER | ||||
| 65470-89143 |
LN85,86,RN85..DLX..ARL |
1 | ||
| 65470-89142 |
LN85,86,RN85..DLX..ARL W(GUARD FRAME) |
1 | ||
| 65470 - BOARD ASSY, HEADER | ||||
| 65470-89143 |
LN85,86,RN85..DLX..ARL |
1 | ||
| 65470-89142 |
LN85,86,RN85..DLX..ARL W(GUARD FRAME) |
1 | ||
| 65470 - BOARD ASSY, HEADER | ||||
| 65470-89143 |
LN85,86,RN85..DLX..ARL |
1 | ||
| 65470-89142 |
LN85,86,RN85..DLX..ARL W(GUARD FRAME) |
1 | ||
| 65470 - BOARD ASSY, HEADER | ||||
| 65470-89143 |
LN85,86,RN85..DLX..ARL |
1 | ||
| 65470-89142 |
LN85,86,RN85..DLX..ARL W(GUARD FRAME) |
1 | ||
| 65700 - GATE ASSY, REAR BODY TAIL | ||||
| 65700-89146 |
RN85..LHD..GEN..CBU;LN85,86,RN85,YN85..ARL..CBU |
1 | ||
| 65737 - STOP, TAIL GATE | ||||
| 65737-89105 |
LN85,YN85..ARL..CBU;LN90,RN85,90,YN92..(ARL,GEN)..CBU |
2 | ||
| 65759 - COVER, TAIL GATE SERVICE HOLE | ||||
| 65759-89102 |
LN90..TH;LN8#,RN8#,YN8#..CBU |
1 | ||
| 65759-89102 |
YN87..CBU;LN8#,RN8#,YN80,81,85,86..(ARL,GEN,V)..CBU |
1 | ||
| 65768A - STRIKER, TAIL GATE LOCK | ||||
| 65768-89102 |
RN85..LHD..GEN..CBU;LN85,RN85,YN85..ARL..CBU;LN86,90,RN90,YN92..(ARL,GEN)..CBU |
2 | ||
| 65770A - STAY ASSY, TAIL GATE | ||||
| 65770-89103 |
LN85,YN85..ARL..CBU;LN90,RN85,90,YN92..(ARL,GEN)..CBU |
2 | ||
| 65778 - STOPPER, TAIL GATE STAY | ||||
| 65778-89104 |
LN85,YN85..ARL..CBU;LN90,RN85,90,YN92..(ARL,GEN)..CBU |
4 | ||
| 65778-89105 |
LN85,YN85..ARL..CBU;LN90,RN85,90,YN92..(ARL,GEN)..CBU |
4 | ||
| 65780A - LOCK ASSY, TAIL GATE, RH | ||||
| 65780-89105 |
RN85..LHD..GEN..CBU;LN85,RN85,YN85..ARL..CBU;LN86,90,RN90,YN92..(ARL,GEN)..CBU |
1 | ||
| 65790A - LOCK ASSY, TAIL GATE, LH | ||||
| 65790-89106 |
RN85..LHD..GEN..CBU;LN85,86,RN85,YN85..ARL..CBU |
1 | ||
| 66110 - HINGE ASSY, TAIL GATE | ||||
| 66120-89101 |
LN8#,90,RN8#,90,YN8#,92..CBU LH |
1 | ||
| 66110-89107 |
LN8#,90,RN8#,90,YN8#,92..CBU RH |
1 | ||
| 66110 - HINGE ASSY, TAIL GATE | ||||
| 66120-89101 |
LN8#,90,RN8#,90,YN8#,92..CBU LH |
1 | ||
| 66110-89107 |
LN8#,90,RN8#,90,YN8#,92..CBU RH |
1 | ||
| 66311D - HOOK, ROPE | ||||
| 66311-89109 |
LN8#,RN8#,YN8#..(ARL,GEN,V)..CBU |
2 | ||
| 66321A - BUMPER, GATE RUBBER | ||||
| 66321-89109 |
LN85,YN85..ARL..CBU;LN90,RN85,90,YN92..(ARL,GEN)..CBU |
2 | ||
| 69090B - HANDLE ASSY, TAIL GATE | ||||
| 69090-89102 |
RN85..LHD..GEN..CBU;LN85,RN85,YN85..ARL..CBU;LN86,90,RN90,YN92..(ARL,GEN)..CBU |
1 | ||
| 69759D - SILENCER, TAIL GATE LOCK LINK | ||||
| 69759-89108 |
RN85..LHD..GEN..CBU;LN85,RN85,YN85..ARL..CBU;LN86,90,RN90,YN92..(ARL,GEN)..CBU |
2 | ||
| 69759E - SNAP, TAIL GATE LOCK LINK | ||||
| 69759-20110 |
RN85..LHD..GEN..CBU;LN85,RN85,YN85..ARL..CBU;LN86,90,RN90,YN92..(ARL,GEN)..CBU BLACK |
1 | ||
| 69759-20100 |
RN85..LHD..GEN..CBU;LN85,RN85,YN85..ARL..CBU;LN86,90,RN90,YN92..(ARL,GEN)..CBU RED |
1 | ||
| Common parts | ||||
| 90109-06022 | ||||
| 90109-08030 | ||||
| 90119-08274 | ||||
| 90119-10510 | ||||
| 90149-80020 | ||||
| 90159-60298 | ||||
| 90159-60535 | ||||
| 90159-80038 | ||||
| 90179-06016 | ||||
| 90189-06010 | ||||
| 90201-08018 | ||||
| 90389-10032 | ||||
| 91651-40616 | ||||
| 91655-40820 | ||||
| 93330-18016 | ||||
| 93385-16010 | ||||
