YN51R-JRN (1986)
Toyota Hilux
(8308-9110)LN50,51,RN50,YN50,51,52
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 04371 - SPIDER KIT, UNIVERSAL JOINT(FOR PROPELLER SHAFT) | ||||
| 04371-25010 |
LN50,51,55,56,YN5# |
3 | ||
| 37101A - PIECE, BALANCE, NO.1 (FOR PROPELLER SHAFT) | ||||
| 90937-01003 |
LN5#,YN5# 8G,T=1.2,10G,SPOT |
1 | ||
| 90937-01005 |
LN5#,YN5# 30G,T=1.2,30G,SPOT |
1 | ||
| 90937-01031 |
LN5#,YN5# 25G,SPOT |
1 | ||
| 90937-01004 |
LN5#,YN5# 20G,T=1.2,20G,SPOT |
1 | ||
| 90937-01030 |
LN5#,YN5# 15G,SPOT |
1 | ||
| 90937-01140 |
LN5#,YN5# 30G,L=62.2,30G,PROJECTION |
1 | ||
| 90937-01152 |
RN58..SR5;LN50,51,55,56,60,61,65,RN50,55,6#,YN5#,6# 14G,L=29.0,14G,PROJECTION |
1 | ||
| 90937-01147 |
RN58..SR5;LN50,51,55,56,60,61,65,RN50,55,6#,YN5#,6# 2G,T=2.0,2G,T=2.0 |
1 | ||
| 90937-01148 |
RN58..SR5;LN50,51,55,56,60,61,65,RN50,55,6#,YN5#,6# 4G,T=2.0,4G,T=2.0 |
1 | ||
| 90937-01151 |
RN58..SR5;LN50,51,55,56,60,61,65,RN50,55,6#,YN5#,6# 12G,L=24.9,12G,PROJECTION |
1 | ||
| 90937-01154 |
LN5#,6#,RN5#,YN5#,6# 18G,L=37.3,18G,PROJECTION |
1 | ||
| 90937-01155 |
LN5#,6#,RN5#,YN5#,6# 22G,L=45.6,22G,PROJECTION |
1 | ||
| 90937-01136 |
LN5#,6#,RN5#,YN5#,6# 20G,L=41.4,20G,PROJECTION |
1 | ||
| 90937-01132 |
RN58..SR5;LN50,51,55,56,60,61,65,RN50,55,6#,YN5#,6# 10G,L=20.7,10G,PROJECTION |
1 | ||
| 90937-01150 |
RN58..SR5;LN50,51,55,56,60,61,65,RN50,55,6#,YN5#,6# 8G,L=16.6,8G,T=2.0 |
1 | ||
| 90937-01157 |
LN5#,6#,RN5#,YN5#,6# 26G,L=53.9,26G,PROJECTION |
1 | ||
| 90937-01149 |
RN58..SR5;LN50,51,55,56,60,61,65,RN50,55,6#,YN5#,6# 6G,L=12.4,6G,T=2.0 |
1 | ||
| 90937-01158 |
LN5#,6#,RN5#,YN5#,6# 28G,L=58.1,28G,PROJECTION |
1 | ||
| 90937-01153 |
LN5#,6#,RN5#,YN5#,6# 16G,L=33.2,16G,PROJECTION |
1 | ||
| 90937-01029 |
LN5#,YN5# 5G,SPOT |
1 | ||
| 90937-01201 |
RN58..SR5;LN50,51,55,56,60,61,65,RN50,55,6#,YN5#,6# 30G,T=4.5,L=27.4,30G |
1 | ||
| 90937-01156 |
LN5#,6#,RN5#,YN5#,6# 24G,L=49.7,24G,PROJECTION |
1 | ||
| 37101A - PIECE, BALANCE, NO.1 (FOR PROPELLER SHAFT) | ||||
| 90937-01003 |
LN5#,YN5# 8G,T=1.2,10G,SPOT |
1 | ||
| 90937-01005 |
LN5#,YN5# 30G,T=1.2,30G,SPOT |
1 | ||
| 90937-01031 |
LN5#,YN5# 25G,SPOT |
1 | ||
| 90937-01004 |
LN5#,YN5# 20G,T=1.2,20G,SPOT |
1 | ||
| 90937-01030 |
LN5#,YN5# 15G,SPOT |
1 | ||
| 90937-01140 |
LN5#,YN5# 30G,L=62.2,30G,PROJECTION |
1 | ||
| 90937-01152 |
RN58..SR5;LN50,51,55,56,60,61,65,RN50,55,6#,YN5#,6# 14G,L=29.0,14G,PROJECTION |
1 | ||
| 90937-01147 |
RN58..SR5;LN50,51,55,56,60,61,65,RN50,55,6#,YN5#,6# 2G,T=2.0,2G,T=2.0 |
1 | ||
| 90937-01148 |
RN58..SR5;LN50,51,55,56,60,61,65,RN50,55,6#,YN5#,6# 4G,T=2.0,4G,T=2.0 |
1 | ||
| 90937-01151 |
RN58..SR5;LN50,51,55,56,60,61,65,RN50,55,6#,YN5#,6# 12G,L=24.9,12G,PROJECTION |
1 | ||
| 90937-01154 |
LN5#,6#,RN5#,YN5#,6# 18G,L=37.3,18G,PROJECTION |
1 | ||
| 90937-01155 |
LN5#,6#,RN5#,YN5#,6# 22G,L=45.6,22G,PROJECTION |
1 | ||
| 90937-01136 |
LN5#,6#,RN5#,YN5#,6# 20G,L=41.4,20G,PROJECTION |
1 | ||
| 90937-01132 |
RN58..SR5;LN50,51,55,56,60,61,65,RN50,55,6#,YN5#,6# 10G,L=20.7,10G,PROJECTION |
1 | ||
| 90937-01150 |
RN58..SR5;LN50,51,55,56,60,61,65,RN50,55,6#,YN5#,6# 8G,L=16.6,8G,T=2.0 |
1 | ||
| 90937-01157 |
LN5#,6#,RN5#,YN5#,6# 26G,L=53.9,26G,PROJECTION |
1 | ||
| 90937-01149 |
RN58..SR5;LN50,51,55,56,60,61,65,RN50,55,6#,YN5#,6# 6G,L=12.4,6G,T=2.0 |
1 | ||
| 90937-01158 |
LN5#,6#,RN5#,YN5#,6# 28G,L=58.1,28G,PROJECTION |
1 | ||
| 90937-01153 |
LN5#,6#,RN5#,YN5#,6# 16G,L=33.2,16G,PROJECTION |
1 | ||
| 90937-01029 |
LN5#,YN5# 5G,SPOT |
1 | ||
| 90937-01201 |
RN58..SR5;LN50,51,55,56,60,61,65,RN50,55,6#,YN5#,6# 30G,T=4.5,L=27.4,30G |
1 | ||
| 90937-01156 |
LN5#,6#,RN5#,YN5#,6# 24G,L=49.7,24G,PROJECTION |
1 | ||
| 37110 - SHAFT ASSY, PROPELLER | ||||
| 37110-35210 |
LN50,51,YN50,51,52..4F,4H,5F |
1 | ||
| 37110A - BOLT (FOR PROPELLER SHAFT) | ||||
| 90105-10085 |
RN58..SR5;LN50,51,55,56,RN50,55,YN5# *10-1.00PX27-13 |
8 | ||
| 37302 - YOKE SUB-ASSY, UNIVERSAL JOINT SLEEVE | ||||
| 37302-35010 |
LN50,51,55,56,YN5# |
1 | ||
| 37315 - YOKE, UNIVERSAL JOINT FLANGE | ||||
| 37315-35050 |
LN5#,YN5# |
2 | ||
| 37331 - COVER, SLIDING SHAFT DUST | ||||
| 37331-30010 |
YN58..4F;YN58..SR5,STD;LN50,51,55,56,RN50,55,YN50,51,52,55,56,57..4F,4FC,4H,5F |
1 | ||
| 37401A - RING, HOLE SNAP (FOR SPIDER BEARING) | ||||
| 90521-29070 |
LN50,51,55,56,YN5# T=2.375-2.425,T=2.4 |
12 | ||
| 90521-29072 |
LN50,51,55,56,YN5# T=2.475-2.525,T=2.5 |
12 | ||
| 90521-29071 |
LN50,51,55,56,YN5# T=2.425-2.475,T=2.45 |
12 | ||
| 37401A - RING, HOLE SNAP (FOR SPIDER BEARING) | ||||
| 90521-29070 |
LN50,51,55,56,YN5# T=2.375-2.425,T=2.4 |
12 | ||
| 90521-29072 |
LN50,51,55,56,YN5# T=2.475-2.525,T=2.5 |
12 | ||
| 90521-29071 |
LN50,51,55,56,YN5# T=2.425-2.475,T=2.45 |
12 | ||
| 37402 - BEARING SUB-ASSY, UNIVERSAL JOINT SPIDER | ||||
| 37402-25020 |
RN5#,YN5# |
12 | ||
| 37402 - BEARING SUB-ASSY, UNIVERSAL JOINT SPIDER | ||||
| 37402-25020 |
RN5#,YN5# |
12 | ||
| Common parts | ||||
| 90179-10059 | ||||
| 90204-10002 | ||||
(8308-9110)LN55,56,RN55,YN55,56,57,58 ; (9110-)LN5#,RN58,YN5#
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 04371 - SPIDER KIT, UNIVERSAL JOINT(FOR PROPELLER SHAFT) | ||||
| 04371-25010 |
LN50,51,55,56,YN5# |
3 | ||
| 37101A - PIECE, BALANCE, NO.1 (FOR PROPELLER SHAFT) | ||||
| 90937-01003 |
LN5#,YN5# 8G,T=1.2,10G,SPOT |
1 | ||
| 90937-01005 |
LN5#,YN5# 30G,T=1.2,30G,SPOT |
1 | ||
| 90937-01031 |
LN5#,YN5# 25G,SPOT |
1 | ||
| 90937-01004 |
LN5#,YN5# 20G,T=1.2,20G,SPOT |
1 | ||
| 90937-01030 |
LN5#,YN5# 15G,SPOT |
1 | ||
| 90937-01140 |
LN5#,YN5# 30G,L=62.2,30G,PROJECTION |
1 | ||
| 90937-01152 |
RN58..SR5;LN50,51,55,56,60,61,65,RN50,55,6#,YN5#,6# 14G,L=29.0,14G,PROJECTION |
1 | ||
| 90937-01147 |
RN58..SR5;LN50,51,55,56,60,61,65,RN50,55,6#,YN5#,6# 2G,T=2.0,2G,T=2.0 |
1 | ||
| 90937-01148 |
RN58..SR5;LN50,51,55,56,60,61,65,RN50,55,6#,YN5#,6# 4G,T=2.0,4G,T=2.0 |
1 | ||
| 90937-01151 |
RN58..SR5;LN50,51,55,56,60,61,65,RN50,55,6#,YN5#,6# 12G,L=24.9,12G,PROJECTION |
1 | ||
| 90937-01154 |
LN5#,6#,RN5#,YN5#,6# 18G,L=37.3,18G,PROJECTION |
1 | ||
| 90937-01155 |
LN5#,6#,RN5#,YN5#,6# 22G,L=45.6,22G,PROJECTION |
1 | ||
| 90937-01136 |
LN5#,6#,RN5#,YN5#,6# 20G,L=41.4,20G,PROJECTION |
1 | ||
| 90937-01132 |
RN58..SR5;LN50,51,55,56,60,61,65,RN50,55,6#,YN5#,6# 10G,L=20.7,10G,PROJECTION |
1 | ||
| 90937-01150 |
RN58..SR5;LN50,51,55,56,60,61,65,RN50,55,6#,YN5#,6# 8G,L=16.6,8G,T=2.0 |
1 | ||
| 90937-01157 |
LN5#,6#,RN5#,YN5#,6# 26G,L=53.9,26G,PROJECTION |
1 | ||
| 90937-01149 |
RN58..SR5;LN50,51,55,56,60,61,65,RN50,55,6#,YN5#,6# 6G,L=12.4,6G,T=2.0 |
1 | ||
| 90937-01158 |
LN5#,6#,RN5#,YN5#,6# 28G,L=58.1,28G,PROJECTION |
1 | ||
| 90937-01153 |
LN5#,6#,RN5#,YN5#,6# 16G,L=33.2,16G,PROJECTION |
1 | ||
| 90937-01029 |
LN5#,YN5# 5G,SPOT |
1 | ||
| 90937-01201 |
RN58..SR5;LN50,51,55,56,60,61,65,RN50,55,6#,YN5#,6# 30G,T=4.5,L=27.4,30G |
1 | ||
| 90937-01156 |
LN5#,6#,RN5#,YN5#,6# 24G,L=49.7,24G,PROJECTION |
1 | ||
| 37110 - SHAFT ASSY, PROPELLER | ||||
| 37110-35210 |
LN50,51,YN50,51,52..4F,4H,5F |
1 | ||
| 37110A - BOLT (FOR PROPELLER SHAFT) | ||||
| 90105-10085 |
RN58..SR5;LN50,51,55,56,RN50,55,YN5# *10-1.00PX27-13 |
8 | ||
| 37110A - BOLT (FOR PROPELLER SHAFT) | ||||
| 90105-10085 |
RN58..SR5;LN50,51,55,56,RN50,55,YN5# *10-1.00PX27-13 |
8 | ||
| 37230F - BOLT, NO.1 (FOR CENTER SUPPORT BEARING) | ||||
| 90119-10049 |
RN58..SR5;LN50,51,55,56,RN50,55,YN5# |
2 | ||
| 37302 - YOKE SUB-ASSY, UNIVERSAL JOINT SLEEVE | ||||
| 37302-35010 |
LN50,51,55,56,YN5# |
1 | ||
| 37315 - YOKE, UNIVERSAL JOINT FLANGE | ||||
| 37315-35050 |
LN5#,YN5# |
2 | ||
| 37315 - YOKE, UNIVERSAL JOINT FLANGE | ||||
| 37315-35050 |
LN5#,YN5# |
2 | ||
| 37331 - COVER, SLIDING SHAFT DUST | ||||
| 37331-30010 |
YN58..4F;YN58..SR5,STD;LN50,51,55,56,RN50,55,YN50,51,52,55,56,57..4F,4FC,4H,5F |
1 | ||
| 37401A - RING, HOLE SNAP (FOR SPIDER BEARING) | ||||
| 90521-29070 |
LN50,51,55,56,YN5# T=2.375-2.425,T=2.4 |
12 | ||
| 90521-29072 |
LN50,51,55,56,YN5# T=2.475-2.525,T=2.5 |
12 | ||
| 90521-29071 |
LN50,51,55,56,YN5# T=2.425-2.475,T=2.45 |
12 | ||
| 37402 - BEARING SUB-ASSY, UNIVERSAL JOINT SPIDER | ||||
| 37402-25020 |
RN5#,YN5# |
12 | ||
| Common parts | ||||
| 90179-10059 | ||||
| 90204-10002 | ||||
