RZN169R-TRMDU (1997)
Toyota Hilux
(9708- )RZN16#,174
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 33124E - PIPE, OIL RECEIVER(FOR TRANSFER) | ||||
| 33106-35020 |
RZN169..CBR |
1 | ||
| 33124K - CLAMP OIL RECEIVER(FOR TRANSFER) | ||||
| 90463-08260 |
RZN169..CBR |
1 | ||
| 33309B - FLANGE SUB-ASSY, OUTPUT SHAFT COMPANION | ||||
| 33309-35061 |
KZN165..XTR;KZN165..SCB..DLX;RZN168..DLX..GEN;KZN165..SR..(ARL,SA);LN167,RZN169..CBR,DSL;RZN169..DLX..(ARL,SA);LN166,172,RZN174..ARL,GCC;LN167..(SCB,THDCB,THSCB)..DLX..DEFI;KZN165,LN167..DCB..DLX..(DEFI,TDE)..ARL..CBU;LN167,RZN169..(DCB,XTR)..SR..(DEFI,EFI)..(SA,TH) |
1 | ||
| 33309C - FLANGE SUB-ASSY, OUTPUT SHAFT COMPANION | ||||
| 33309-35100 |
KZN165..XTR;KZN165..SCB..DLX;RZN168..DLX..GEN;KZN165..SR..(ARL,SA);LN167,RZN169..CBR,DSL;RZN169..DLX..(ARL,SA);LN166,172,RZN174..ARL,GCC;LN167..(SCB,THDCB,THSCB)..DLX..DEFI;KZN165,LN167..DCB..DLX..(DEFI,TDE)..ARL..CBU;LN167,RZN169..(DCB,XTR)..SR..(DEFI,EFI)..(SA,TH) |
1 | ||
| 33309D - SEAL, OIL(FOR TRANSFER OUTPUT SHAFT COMPANION FLANGE) | ||||
| 90312-23001 |
KZN165..XTR;KZN165..SCB..DLX;RZN168..DLX..GEN;KZN165..SR..(ARL,SA);LN167,RZN169..CBR,DSL;RZN169..DLX..(ARL,SA);LN166,172,RZN174..ARL,GCC;LN167..(SCB,THDCB,THSCB)..DLX..DEFI;KZN165,LN167..DCB..DLX..(DEFI,TDE)..ARL..CBU;LN167,RZN169..(DCB,XTR)..SR..(DEFI,EFI)..(SA,TH) |
2 | ||
| 33309D - SEAL, OIL(FOR TRANSFER OUTPUT SHAFT COMPANION FLANGE) | ||||
| 90312-23001 |
KZN165..XTR;KZN165..SCB..DLX;RZN168..DLX..GEN;KZN165..SR..(ARL,SA);LN167,RZN169..CBR,DSL;RZN169..DLX..(ARL,SA);LN166,172,RZN174..ARL,GCC;LN167..(SCB,THDCB,THSCB)..DLX..DEFI;KZN165,LN167..DCB..DLX..(DEFI,TDE)..ARL..CBU;LN167,RZN169..(DCB,XTR)..SR..(DEFI,EFI)..(SA,TH) |
2 | ||
| 33449D - MAGNET (FOR TRANSFER CASE) | ||||
| 33449-32020 |
KZN165..XTR;KZN165..SCB..DLX;RZN168..DLX..GEN;KZN165..SR..(ARL,SA);LN167,RZN169..CBR,DSL;RZN169..DLX..(ARL,SA);LN166,172,RZN174..ARL,GCC;LN167..(SCB,THDCB,THSCB)..DLX..DEFI;KZN165,LN167..DCB..DLX..(DEFI,TDE)..ARL..CBU;LN167,RZN169..(DCB,XTR)..SR..(DEFI,EFI)..(SA,TH) |
1 | ||
| 36101 - CASE SUB-ASSY, TRANSFER | ||||
| 36101-35120 |
LN167..DSL;KZN165..XTR;KZN165..SCB..DLX;RZN168..DLX..GEN;RZN169..DLX..(ARL,SA);LN166,172,RZN174..ARL,GCC;LN167..(SCB,THDCB,THSCB)..DLX..DEFI;KZN165,RZN169..(CBR,TDE)..(GCC,GEN,SA);KZN165,LN167..DCB..DLX..(DEFI,TDE)..ARL..CBU;LN167,RZN169..(DCB,XTR)..SR..(DEFI,EFI)..(SA,TH) |
1 | ||
| 36102 - COVER SUB-ASSY, TRANSFER CASE | ||||
| 36102-35051 |
RZN168..DLX..GEN;RZN169..DLX..(ARL,SA);KZN165..(SCB,XTR)..(IV1,IV3);KZN165..(THDCB,XTR)..SR..CBU;LN167..(SCB,THDCB,THSCB)..DLX;LN167,RZN169..(DCB,XTR)..SR..(SA,TH);LN16#,172,RZN174..(DCB,THXTR,XTR)..DLX..(ARL,GCC);KZN165,RZN169..(DCB,SCB)..(CBR,TDE)..(ARL,GCC,GEN,SA)..CBU |
1 | ||
| 36102-35050 |
RZN16#;KZN165,LN16#,172,RZN174..ARL,GCC,SA,TH |
1 | ||
| 36102J - SEAL, TYPE T OIL (FOR TRANSFER COVER) | ||||
| 90311-40021 |
KZN165..XTR;KZN165..SCB..DLX;RZN168..DLX..GEN;KZN165..SR..(ARL,SA);LN167,RZN169..CBR,DSL;RZN169..DLX..(ARL,SA);LN166,172,RZN174..ARL,GCC;LN167..(SCB,THDCB,THSCB)..DLX..DEFI;KZN165,LN167..DCB..DLX..(DEFI,TDE)..ARL..CBU;LN167,RZN169..(DCB,XTR)..SR..(DEFI,EFI)..(SA,TH) |
1 | ||
| 36103A - BOLT (FOR TRANSFER CASE) | ||||
| 90119-08A28 |
KZN165..XTR;KZN165..SCB..DLX;RZN168..DLX..GEN;KZN165..SR..(ARL,SA);LN167,RZN169..CBR,DSL;RZN169..DLX..(ARL,SA);LN166,172,RZN174..ARL,GCC;LN167..(SCB,THDCB,THSCB)..DLX..DEFI;KZN165,LN167..DCB..DLX..(DEFI,TDE)..ARL..CBU;LN167,RZN169..(DCB,XTR)..SR..(DEFI,EFI)..(SA,TH) *8-1.25PX55-30 |
12 | ||
| 36104D - NUT (FOR TRANSFER OUTPUT SHAFT) | ||||
| 90179-22016 |
KZN165..XTR;KZN165..SCB..DLX;RZN168..DLX..GEN;KZN165..SR..(ARL,SA);LN167,RZN169..CBR,DSL;RZN169..DLX..(ARL,SA);LN166,172,RZN174..ARL,GCC;LN167..(SCB,THDCB,THSCB)..DLX..DEFI;KZN165,LN167..DCB..DLX..(DEFI,TDE)..ARL..CBU;LN167,RZN169..(DCB,XTR)..SR..(DEFI,EFI)..(SA,TH) |
2 | ||
| 36104D - NUT (FOR TRANSFER OUTPUT SHAFT) | ||||
| 90179-22016 |
KZN165..XTR;KZN165..SCB..DLX;RZN168..DLX..GEN;KZN165..SR..(ARL,SA);LN167,RZN169..CBR,DSL;RZN169..DLX..(ARL,SA);LN166,172,RZN174..ARL,GCC;LN167..(SCB,THDCB,THSCB)..DLX..DEFI;KZN165,LN167..DCB..DLX..(DEFI,TDE)..ARL..CBU;LN167,RZN169..(DCB,XTR)..SR..(DEFI,EFI)..(SA,TH) |
2 | ||
| 36108A - DEFLECTOR SUB-ASSY, BREATHER OIL | ||||
| 36108-35030 |
RZN16#;LN16#,172,RZN174..ARL,GCC |
1 | ||
| 36111B - SEAL, OIL (FOR TRANSFER CASE) | ||||
| 90311-41008 |
RZN168..DLX..GEN;LN167,RZN169..CBR,DSL;RZN169..DLX..(ARL,SA);LN167..DCB..DLX..DEFI..ARL;KZN165..(THDCB,THSCB,XTR)..SR;LN167..(SCB,THDCB,THSCB)..DLX..DEFI;LN167,RZN169..(DCB,XTR)..SR..(DEFI,EFI)..(SA,TH);KZN165,LN166,172,RZN174..(DCB,SCB,THXTR,XTR)..(ARL,GCC,SA) FRONT OUTPUT SIDE |
1 | ||
| 90311-15008 |
LN167..DSL;KZN165..XTR;KZN165..SCB..DLX;RZN168..DLX..GEN;RZN169..DLX..(ARL,SA);LN166,172,RZN174..ARL,GCC;LN167..(SCB,THDCB,THSCB)..DLX..DEFI;KZN165,RZN169..(CBR,TDE)..(GCC,GEN,SA);KZN165,LN167..DCB..DLX..(DEFI,TDE)..ARL..CBU;LN167,RZN169..(DCB,XTR)..SR..(DEFI,EFI)..(SA,TH) FORK SHAFT SIDE |
2 | ||
| 36111B - SEAL, OIL (FOR TRANSFER CASE) | ||||
| 90311-41008 |
RZN168..DLX..GEN;LN167,RZN169..CBR,DSL;RZN169..DLX..(ARL,SA);LN167..DCB..DLX..DEFI..ARL;KZN165..(THDCB,THSCB,XTR)..SR;LN167..(SCB,THDCB,THSCB)..DLX..DEFI;LN167,RZN169..(DCB,XTR)..SR..(DEFI,EFI)..(SA,TH);KZN165,LN166,172,RZN174..(DCB,SCB,THXTR,XTR)..(ARL,GCC,SA) FRONT OUTPUT SIDE |
1 | ||
| 90311-15008 |
LN167..DSL;KZN165..XTR;KZN165..SCB..DLX;RZN168..DLX..GEN;RZN169..DLX..(ARL,SA);LN166,172,RZN174..ARL,GCC;LN167..(SCB,THDCB,THSCB)..DLX..DEFI;KZN165,RZN169..(CBR,TDE)..(GCC,GEN,SA);KZN165,LN167..DCB..DLX..(DEFI,TDE)..ARL..CBU;LN167,RZN169..(DCB,XTR)..SR..(DEFI,EFI)..(SA,TH) FORK SHAFT SIDE |
2 | ||
| 36111E - GASKET (FOR TRANSFER CASE) | ||||
| 90430-18008 |
RZN16#;LN167..DLX..SA;KZN165,LN16#,172,RZN174..ARL,GCC,TH W/O(NEUTRAL & LOW SWITCH) |
4 | ||
| 36111E - GASKET (FOR TRANSFER CASE) | ||||
| 90430-18008 |
RZN16#;LN167..DLX..SA;KZN165,LN16#,172,RZN174..ARL,GCC,TH W/O(NEUTRAL & LOW SWITCH) |
4 | ||
| 36111E - GASKET (FOR TRANSFER CASE) | ||||
| 90430-18008 |
RZN16#;LN167..DLX..SA;KZN165,LN16#,172,RZN174..ARL,GCC,TH W/O(NEUTRAL & LOW SWITCH) |
4 | ||
| 36111E - GASKET (FOR TRANSFER CASE) | ||||
| 90430-18008 |
RZN16#;LN167..DLX..SA;KZN165,LN16#,172,RZN174..ARL,GCC,TH W/O(NEUTRAL & LOW SWITCH) |
4 | ||
| 36111F - PLUG (FOR TRANSFER CASE) | ||||
| 90341-18006 |
RZN16#;LN167..DLX..SA;KZN165,LN16#,172,RZN174..ARL,GCC,TH W/O(NEUTRAL & LOW SWITCH) |
4 | ||
| 36111F - PLUG (FOR TRANSFER CASE) | ||||
| 90341-18006 |
RZN16#;LN167..DLX..SA;KZN165,LN16#,172,RZN174..ARL,GCC,TH W/O(NEUTRAL & LOW SWITCH) |
4 | ||
| 36111F - PLUG (FOR TRANSFER CASE) | ||||
| 90341-18006 |
RZN16#;LN167..DLX..SA;KZN165,LN16#,172,RZN174..ARL,GCC,TH W/O(NEUTRAL & LOW SWITCH) |
4 | ||
| 36111F - PLUG (FOR TRANSFER CASE) | ||||
| 90341-18006 |
RZN16#;LN167..DLX..SA;KZN165,LN16#,172,RZN174..ARL,GCC,TH W/O(NEUTRAL & LOW SWITCH) |
4 | ||
| 36111G - PIN, STRAIGHT (FOR TRANSFER CASE) | ||||
| 90250-10214 |
KZN165..XTR;KZN165..SCB..DLX;RZN168..DLX..GEN;KZN165..SR..(ARL,SA);LN167,RZN169..CBR,DSL;RZN169..DLX..(ARL,SA);LN166,172,RZN174..ARL,GCC;LN167..(SCB,THDCB,THSCB)..DLX..DEFI;KZN165,LN167..DCB..DLX..(DEFI,TDE)..ARL..CBU;LN167,RZN169..(DCB,XTR)..SR..(DEFI,EFI)..(SA,TH) L=14,OD=10 |
2 | ||
| 36112 - CASE, TRANSFER, REAR | ||||
| 36112-35070 |
LN167..DSL;KZN165..XTR;KZN165..SCB..DLX;RZN168..DLX..GEN;RZN169..DLX..(ARL,SA);LN166,172,RZN174..ARL,GCC;LN167..(SCB,THDCB,THSCB)..DLX..DEFI;KZN165,RZN169..(CBR,TDE)..(GCC,GEN,SA);KZN165,LN167..DCB..DLX..(DEFI,TDE)..ARL..CBU;LN167,RZN169..(DCB,XTR)..SR..(DEFI,EFI)..(SA,TH) |
1 | ||
| 36115 - HOUSING, TRANSFER EXTENSION | ||||
| 36105-35020 |
RZN16#;LN16#,172,RZN174..ARL,GCC,SA,TH |
1 | ||
| 36105-35040 |
KZN165..XTR;KZN165..SCB..DLX;RZN168..DLX..GEN;KZN165..SR..(ARL,SA);LN167,RZN169..CBR,DSL;RZN169..DLX..(ARL,SA);LN166,172,RZN174..ARL,GCC;LN167..(SCB,THDCB,THSCB)..DLX..DEFI;KZN165,LN167..DCB..DLX..(DEFI,TDE)..ARL..CBU;LN167,RZN169..(DCB,XTR)..SR..(DEFI,EFI)..(SA,TH) |
1 | ||
| 36115C - SEAL, TYPE T OIL (FOR TRANSFER EXTENSION HOUSING) | ||||
| 90311-41007 |
KZN165..XTR;KZN165..SCB..DLX;RZN168..DLX..GEN;KZN165..SR..(ARL,SA);LN167,RZN169..CBR,DSL;RZN169..DLX..(ARL,SA);LN166,172,RZN174..ARL,GCC;LN167..(SCB,THDCB,THSCB)..DLX..DEFI;KZN165,LN167..DCB..DLX..(DEFI,TDE)..ARL..CBU;LN167,RZN169..(DCB,XTR)..SR..(DEFI,EFI)..(SA,TH) |
1 | ||
| 36117 - ADAPTER, TRANSFER | ||||
| 36107-35220 |
RZN169..CBR |
1 | ||
| 36117A - SEAL, OIL(FOR TRANSFER ADAPTER) | ||||
| 90311-40007 |
RZN169..CBR |
1 | ||
| 36117D - PLUG(FOR TRANSFER ADAPTER) | ||||
| 90930-03114 |
RZN169..CBR |
1 | ||
| 36117G - PLUG, W/HEAD STRAIGHT SCREW(FOR TRANSFER ADAPTER) | ||||
| 90341-20010 |
LN166..GCC;RZN169..CBR |
1 | ||
| 36117L - TUBE(FOR TRANSFER ADAPTER) | ||||
| 90441-05001 |
LN166..GCC;RZN169..CBR |
1 | ||
| 36117N - HOSE(FOR TRANSFER ADAPTER) | ||||
| 90904-45005 |
LN167..SR..SA;RZN16#..GCC,GEN,SA;LN167..SCB,THDCB,THSCB,XTR;RZN169..(SCB,THDCB,THSCB)..ARL;KZN165,LN166,172,RZN174..ARL,GCC,SA |
1 | ||
| 36121 - COVER, TRANSFER CASE, NO.1 | ||||
| 36102-35040 |
KZN165..XTR;KZN165..SCB..DLX;RZN168..DLX..GEN;KZN165..SR..(ARL,SA);LN167,RZN169..CBR,DSL;RZN169..DLX..(ARL,SA);LN166,172,RZN174..ARL,GCC;LN167..(SCB,THDCB,THSCB)..DLX..DEFI;KZN165,LN167..DCB..DLX..(DEFI,TDE)..ARL..CBU;LN167,RZN169..(DCB,XTR)..SR..(DEFI,EFI)..(SA,TH) |
1 | ||
| 36102-35020 |
RZN16#;LN16#,172,RZN174..ARL,GCC,SA,TH |
1 | ||
| Common parts | ||||
| 82711-1E300 | ||||
| 90119-08336 | ||||
| 90119-10019 | ||||
| 90241-07003 | ||||
| 90341-14012 | ||||
| 90462-10128 | ||||
| 90501-20091 | ||||
| 91611-60822 | ||||
| 91612-61045 | ||||
