RZN147R-TRMDS (1997)
Toyota Hilux
(9708- )RZN142,147..RHD..CBR
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 78110A - SPRING (FOR ACCELERATOR PEDAL ROD) | ||||
| 90959-03085 |
RZN147,169,194..RHD;KZN165,RZN149,154,174..MTM..ARL |
1 | ||
| 90959-03085 |
RZN169..DCB..SA;RZN169..RHD..CBR;RZN149,169..MTM..DLX..(ARL,SA);RZN142,147,154,174,194..RHD..MTM |
1 | ||
| 90959-03085 |
RZN169..ARL;RZN142,147,149,154,174..RHD..MTM |
1 | ||
| 78110C - BUSH (FOR ACCELERATOR PEDAL ROD) | ||||
| 90386-08063 |
RZN169..DCB..SA;RZN169..RHD..CBR;RZN169..DLX..(ARL,SA);LN145,155..LHD..DLX..TH;RZN142,147,149,154,YN140..RHD..DLX;LN14#,152,16#,17#,19#,RZN174,194..(DSL,EFI)..(ARL,GCC,GEN,SA) |
2 | ||
| 90386-08063 |
LN145,166..RHD..GEN;RZN147..RHD..SCB..GEN |
2 | ||
| 90386-08063 |
RZN169..ARL;LN145..LHD..TH;LN145..GEN..CBU;LN145..LHD..IV3;LN166,RZN174,VZN167,172;RZN142,147,149,154..RHD;LN141,146,155,171,191..LHD |
2 | ||
| 90386-08063 |
LN145,166..RHD..GEN;RZN147..RHD..SCB..GEN |
2 | ||
| 90386-08063 |
LN145..GEN,SA;LN145,155..LHD..TH;LN140,167,192,RZN147,169,194,YN140..RHD..(ARL,GEN,SA);KZN165,LN141,146,147,152,166,17#,191,RZN149,154,174..(DSL,EFI,TDE)..(ARL,GCC,GEN) |
2 | ||
| 78110C - BUSH (FOR ACCELERATOR PEDAL ROD) | ||||
| 90386-08063 |
RZN169..DCB..SA;RZN169..RHD..CBR;RZN169..DLX..(ARL,SA);LN145,155..LHD..DLX..TH;RZN142,147,149,154,YN140..RHD..DLX;LN14#,152,16#,17#,19#,RZN174,194..(DSL,EFI)..(ARL,GCC,GEN,SA) |
2 | ||
| 90386-08063 |
LN145,166..RHD..GEN;RZN147..RHD..SCB..GEN |
2 | ||
| 90386-08063 |
RZN169..ARL;LN145..LHD..TH;LN145..GEN..CBU;LN145..LHD..IV3;LN166,RZN174,VZN167,172;RZN142,147,149,154..RHD;LN141,146,155,171,191..LHD |
2 | ||
| 90386-08063 |
LN145,166..RHD..GEN;RZN147..RHD..SCB..GEN |
2 | ||
| 90386-08063 |
LN145..GEN,SA;LN145,155..LHD..TH;LN140,167,192,RZN147,169,194,YN140..RHD..(ARL,GEN,SA);KZN165,LN141,146,147,152,166,17#,191,RZN149,154,174..(DSL,EFI,TDE)..(ARL,GCC,GEN) |
2 | ||
| 78120G - ROD ASSY, ACCELERATOR PEDAL | ||||
| 78120-35170 |
RZN142,147..RHD..CBR |
1 | ||
| 78120-35170 |
RZN142,147..RHD..CBR |
1 | ||
| 78180P - CABLE ASSY, ACCELERATOR CONTROL | ||||
| 78180-35360 |
RZN142,147..RHD..CBR |
1 | ||
| 78180-35360 |
RZN142,147..RHD..CBR |
1 | ||
| 78184B - BRACKET, ACCELERATOR CONTROL CABLE | ||||
| 78024-26010 |
RZN147..RHD..SCB..GEN |
1 | ||
| 78024-26010 |
RZN147..RHD..SCB..GEN |
1 | ||
| 78024-26010 |
RZN142,147..GEN |
1 | ||
| 78024-26010 |
RZN142,147..CBR |
1 | ||
| 78185A - CLAMP, ACCELERATOR CONTROL CABLE, NO.2 | ||||
| 78185-35080 |
RZN169..EFI;RZN147,194,YN140..RHD;KZN165,RZN149,154,174..ARL |
1 | ||
| 78185-35080 |
RZN169..SA;RZN149,169..DLX..ARL;RZN142,147,154,174,194,YN140..RHD |
1 | ||
| 78185-35080 |
RZN169..SCB..SA;RZN169..RHD..(ARL,GEN);RZN149,154..(DCB,SCB,XTR)..ARL;RZN142,147,174,194,VZN167,172..RHD |
1 | ||
| 78185-35080 |
RZN147..RHD..SCB..GEN |
1 | ||
| 78185-35100 |
LN150..SR;LN152..DEFI..TH;LN145,157..RHD..SCB;LN145..RHD..DCB..GEN;LN140,147,152,155,16#,172,192,RZN169..RHD..(CBR,DSL)..(ARL,GEN,SA,TH) |
1 | ||
| 78188C - CLAMP, ACCELERATOR CONTROL CABLE, NO.5 | ||||
| 78188-35050 |
RZN142,147..RHD..CBR |
1 | ||
| 78188-35050 |
RZN147..RHD..GEN |
1 | ||
| Common parts | ||||
| 90119-06775 | ||||
| 90201-07008 | ||||
| 91511-B0814 | ||||
| 91611-G0612 | ||||
| 91621-60614 | ||||
| 91621-B0616 | ||||
