RZN147R-TRMDS (1997)
Toyota Hilux
(9708- )1RZ#
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 15100B - RING, O(FOR OIL PUMP) | ||||
| 15188-75020 |
1RZ#,2RZFE,3RZ#..RZN14#,154,16#,174,19# |
1 | ||
| 15188-75021 |
2RZFE..RZN148..GEN..CBU;2RZFE,3RZFE..RZN148,149..ARL,CO,GCC;1RZ#,2RZFE,3RZFE..RZN142,144,147,154,16#,174,19# |
1 | ||
| 15188-75021 |
3RZFE..RZN169..SA;3RZFE..RZN154,194..RHD;3RZFE..RZN169..DLX..ARL;2RZFE,3RZFE..RZN148,149,168,174..DLX..(ARL,GEN);1RZ#,2RZFE,3RZF..RZN142,144,147,149,154,169,193 |
1 | ||
| 15188-75021 |
1RZ..RZN147..RHD..SCB..GEN;2RZFE,3RZFE..RZN148,149,168..DLX..GEN |
1 | ||
| 15188-75021 |
1RZ..RZN147..RHD..SCB..GEN;2RZFE,3RZFE..RZN148,149,168..DLX..GEN |
1 | ||
| 15102 - ROTOR SET, OIL PUMP | ||||
| 15103-75010 |
2RZFE..RZN148..CO;2RZFE..RZN148..GEN..CBU;1RZ#,2RZFE..RZN142,147,168,193 |
1 | ||
| 15103-75010 |
2RZFE..RZN148,168..DLX;1RZ..RZN147..RHD..SCB..GEN |
1 | ||
| 15103-75010 |
1RZ#,2RZFE..RZN142,147,148,168,193..DLX |
1 | ||
| 15103-75010 |
1RZ..RZN147..RHD..SCB..GEN;2RZFE..RZN148,168..DLX..GEN |
1 | ||
| 15104 - STRAINER SUB-ASSY, OIL | ||||
| 15104-75090 |
3RZFE..RZN154..ARL;1RZ#,3RZF..RZN142,144,147,149,154;2RZFE,3RZFE..RZN148,149..DLX..(ARL,GEN) |
1 | ||
| 15104-75090 |
1RZ..RZN147..RHD..SCB..GEN;2RZFE,3RZFE..RZN148,149..DLX..GEN |
1 | ||
| 15104-75090 |
1RZ..RZN147..RHD..SCB..GEN;2RZFE,3RZFE..RZN148,149..DLX..GEN |
1 | ||
| 15104-75090 |
1RZ,3RZFE..RZN142,144,147;2RZFE,3RZFE..RZN148,149..CO,GCC |
1 | ||
| 15115 - COVER, OIL PUMP | ||||
| 15115-75051 |
1RZ#,2RZFE..RZN142,147,148,168,193..DLX |
1 | ||
| 15115-75051 |
2RZFE..RZN148,168..DLX;1RZ..RZN147..RHD..SCB..GEN |
1 | ||
| 15115-75051 |
2RZFE..RZN148..CO;2RZFE..RZN148..GEN..CBU;1RZ#,2RZFE..RZN142,147,168,193 |
1 | ||
| 15115-75051 |
1RZ..RZN147..RHD..SCB..GEN;2RZFE..RZN148,168..DLX..GEN |
1 | ||
| 15131 - VALVE, OIL PUMP RELIEF | ||||
| 15131-24010 |
1RZ..RZN147..RHD..SCB..GEN;2RZFE,3RZFE..RZN148,149,168..DLX..GEN |
1 | ||
| 15131-24010 |
3RZFE..RZN169..SA;3RZFE..RZN154,194..RHD;3RZFE..RZN169..DLX..ARL;2RZFE,3RZFE..RZN148,149,168,174..DLX..(ARL,GEN);1RZ#,2RZFE,3RZF..RZN142,144,147,149,154,169,193 |
1 | ||
| 15131-24010 |
1RZ..RZN147..RHD..SCB..GEN;2RZFE,3RZFE..RZN148,149,168..DLX..GEN |
1 | ||
| 15131-24010 |
2RZFE..RZN148..GEN..CBU;2RZFE,3RZFE..RZN148,149..ARL,CO,GCC;1RZ#,2RZFE,3RZFE..RZN142,144,147,154,16#,174,19# |
1 | ||
| 15132 - SPRING, OIL PUMP RELIEF VALVE | ||||
| 15132-75010 |
1RZ#,2RZFE..RZN142,147,148,168,193..DLX |
1 | ||
| 15132-75010 |
2RZFE..RZN148,168..DLX;1RZ..RZN147..RHD..SCB..GEN |
1 | ||
| 15132-75010 |
1RZ..RZN147..RHD..SCB..GEN;2RZFE..RZN148,168..DLX..GEN |
1 | ||
| 15132-75010 |
2RZFE..RZN148..CO;2RZFE..RZN148..GEN..CBU;1RZ#,2RZFE..RZN142,147,168,193 |
1 | ||
| 15135 - RETAINER, OIL PUMP RELIEF VALVE | ||||
| 15135-15010 |
1RZ#,2RZFE..RZN142,147,148,168,193..DLX |
1 | ||
| 15135-15010 |
1RZ..RZN147..RHD..SCB..GEN;2RZFE..RZN148,168..DLX..GEN |
1 | ||
| 15135-15010 |
2RZFE..RZN148,168..DLX;1RZ..RZN147..RHD..SCB..GEN |
1 | ||
| 15135-15010 |
2RZFE..RZN148..CO;2RZFE..RZN148..GEN..CBU;1RZ#,2RZFE..RZN142,147,168,193 |
1 | ||
| 15147 - GASKET, OIL STRAINER | ||||
| 15147-75020 |
1RZ..RZN147..RHD..SCB..GEN;2RZFE,3RZFE..RZN148,149,168..DLX..GEN |
1 | ||
| 15147-75020 |
1RZ..RZN147..RHD..SCB..GEN;2RZFE,3RZFE..RZN148,149,168..DLX..GEN |
1 | ||
| 15147-75020 |
3RZFE..RZN169..SA;3RZFE..RZN154,194..RHD;3RZFE..RZN169..DLX..ARL;2RZFE,3RZFE..RZN148,149,168,174..DLX..(ARL,GEN);1RZ#,2RZFE,3RZF..RZN142,144,147,149,154,169,193 |
1 | ||
| 15147-75020 |
1RZ,3RZFE..RZN142,144,147;2RZFE,3RZFE..RZN148,149,16#..CO,GCC |
1 | ||
| Common parts | ||||
| 90179-08040 | ||||
| 91641-C0814 | ||||
| 93220-16014 | ||||
| 96151-01500 | ||||
