RN46L-KRP (1980)
Toyota Hilux
(7808-8312)18R
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 16261 - HOSE, WATER BY-PASS | ||||
| 90910-05106 |
18R..RN31,36,41;18R..RN46..ARL..IV3;18R..RN46..EUR,GEN,ME,SA |
1 | ||
| 16261A - CLAMP OR CLIP, HOSE(FOR WATER BY-PASS HOSE) | ||||
| 96112-10160 |
18R..RN31,36,41;18R..RN46..ARL..IV3;18R..RN46..EUR,GEN,ME,SA |
2 | ||
| 16261A - CLAMP OR CLIP, HOSE(FOR WATER BY-PASS HOSE) | ||||
| 96112-10160 |
18R..RN31,36,41;18R..RN46..ARL..IV3;18R..RN46..EUR,GEN,ME,SA |
2 | ||
| 16261B - UNION(FOR WATER BY-PASS HOSE) | ||||
| 90404-17005 |
18R..RN31,36,41;18R..RN46..ARL..IV3;18R..RN46..EUR,GEN,ME,SA |
1 | ||
| 16331 - OUTLET, WATER | ||||
| 16331-36012 |
18R..RN31,36,41,46..EUR,GEN,ME,SA |
1 | ||
| 16331 - OUTLET, WATER | ||||
| 16331-36012 |
18R..RN31,36,41,46..EUR,GEN,ME,SA |
1 | ||
| 16331A - THERMOSTAT | ||||
| 90916-03036 |
18R..RN31,36,41,46..EUR,GEN,ME,SA *WAX 88-100,FUJI-THOMSON |
1 | ||
| 90916-03040 |
18R..RN31,36,41,46..EUR,GEN,ME,SA *WAX 88-100,KUZEH |
1 | ||
| 16341 - GASKET, WATER OUTLET | ||||
| 16341-38010 |
18R..RN46..ARL..IV3;12R#,18R..RN3#,40,41;18R..RN46..EUR,GEN,ME,SA |
1 | ||
| 16341-38010 |
18R..RN46..EUR,GEN;18R..RN46..ARL..IV3;12R#,18R..RN3#,40,41 |
1 | ||
| 16361 - FAN | ||||
| 16361-38010 |
18R..RN36,46 7 BLADES |
1 | ||
| 16361-38010 |
18R..RN31,36,41,46 7 BLADES |
1 | ||
| 16361-38010 |
18R..RN46..ARL..IV3;18R..RN46..GEN,ME,SA;18R..RN36..ARL,GEN,ME 7 BLADES |
1 | ||
| 16361A - BELT, V(FOR FAN & ALTERNATOR) | ||||
| 90916-02048 |
18R..RN31,36,41,46 L=839 |
1 | ||
| 16381 - BAR, FAN BELT ADJUSTING | ||||
| 16381-34030 |
18R..RN31,36,41;18R..RN46..ARL..IV3;18R..RN46..EUR,GEN,ME,SA |
1 | ||
| 16381B - SPACER, FAN BELT ADJUSTING BAR | ||||
| 90560-10005 |
18R..RN31,36,41;18R..RN46..ARL..IV3;18R..RN46..EUR,GEN,ME,SA |
1 | ||
| 16400 - RADIATOR ASSY | ||||
| 16400-34290 |
18R..RN31,36,41,46 FIN PITCH=4.0 |
1 | ||
| 16400B - PLUG, RADIATOR DRAIN COCK | ||||
| 90910-09054 |
L..LN3#,4# |
1 | ||
| 90910-09054 |
12R#,18R..RN3#,4# |
1 | ||
| 16400F - PACKING(FOR RADIATOR DRAIN COCK) | ||||
| 96710-01007 |
L..LN3#,4# |
1 | ||
| 96710-01007 |
12R#,18R..RN3#,4# |
1 | ||
| 16401 - CAP SUB-ASSY, RADIATOR | ||||
| 16401-36010 |
12R#,18R..RN3#,4# |
1 | ||
| 16470 - TANK ASSY, RADIATOR RESERVE | ||||
| 16470-34120 |
12R#,18R..RN3#,4#..ARL,EUR,GEN,PHL PAPER ELEMENT AIR CLEANER |
1 | ||
| 16470B - CLAMP OR CLIP(FOR RADIATOR RESERVE TANK HOSE) | ||||
| 90467-11085 |
12R#,18R..RN3#,4# |
2 | ||
| 90467-11085 |
L..LN3#,4# |
2 | ||
| 16470G - BRACKET, RESERVE TANK MOUNTING, NO.1 | ||||
| 53261-89101 |
18R..RN46..ARL..IV3;18R..RN46..GEN,ME,SA;18R..RN36..ARL,GEN,ME CYCLONE AIR CLEANER |
1 | ||
| 16470H - BRACKET, RESERVE TANK MOUNTING, NO.2 | ||||
| 53262-89102 |
18R..RN46..ARL..IV3;18R..RN46..GEN,ME,SA;18R..RN36..ARL,GEN,ME CYCLONE AIR CLEANER |
1 | ||
| 16471 - CAP SUB-ASSY, RESERVE TANK | ||||
| 16471-34120 |
12R#,18R..RN3#,4#..ARL,EUR,GEN,PHL PAPER ELEMENT AIR CLEANER |
1 | ||
| 16405-89106 |
18R..RN46..ARL..IV3;18R..RN46..GEN,ME,SA;18R..RN36..ARL,GEN,ME CYCLONE AIR CLEANER |
1 | ||
| 16405-89105 |
18R..RN36,46..EUR,GEN |
1 | ||
| 16571 - HOSE, RADIATOR, INLET | ||||
| 16571-34090 |
18R..RN31,36,41;18R..RN46..ARL..IV3;18R..RN46..EUR,GEN,ME,SA |
1 | ||
| 16571A - CLAMP OR CLIP, HOSE(FOR RADIATOR INLET) | ||||
| 90467-37001 |
18R..RN46..EUR,GEN;18R..RN46..ARL..IV3;12R#,18R..RN3#,40,41 ENGINE SIDE,ID=37 |
1 | ||
| 90467-37001 |
L..LN36,46 ID=37 |
2 | ||
| 96111-10440 |
18R..RN46..EUR,GEN;18R..RN46..ARL..IV3;12R#,18R..RN3#,40,41 RADIATOR SIDE,ID=44 |
1 | ||
| 96111-10440 |
18R..RN31,36,41;18R..RN46..EUR,GEN;18R..RN46..ARL..IV3 RADIATOR SIDE,ID=44 |
1 | ||
| 90467-37001 |
18R..RN31,36,41;18R..RN46..EUR,GEN;18R..RN46..ARL..IV3 ENGINE SIDE,ID=37 |
1 | ||
| 16571A - CLAMP OR CLIP, HOSE(FOR RADIATOR INLET) | ||||
| 90467-37001 |
18R..RN46..EUR,GEN;18R..RN46..ARL..IV3;12R#,18R..RN3#,40,41 ENGINE SIDE,ID=37 |
1 | ||
| 90467-37001 |
L..LN36,46 ID=37 |
2 | ||
| 96111-10440 |
18R..RN46..EUR,GEN;18R..RN46..ARL..IV3;12R#,18R..RN3#,40,41 RADIATOR SIDE,ID=44 |
1 | ||
| 96111-10440 |
18R..RN31,36,41;18R..RN46..EUR,GEN;18R..RN46..ARL..IV3 RADIATOR SIDE,ID=44 |
1 | ||
| 90467-37001 |
18R..RN31,36,41;18R..RN46..EUR,GEN;18R..RN46..ARL..IV3 ENGINE SIDE,ID=37 |
1 | ||
| 16572A - CLAMP OR CLIP, HOSE(FOR RADIATOR OUTLET NO.1) | ||||
| 96111-10480 |
18R..RN31,36,41,46 ENGINE SIDE,ID=48 |
1 | ||
| 96111-10480 |
18R..RN36;18R..RN46..ARL..IV3;18R..RN46..EUR,GEN,ME,SA ENGINE SIDE,ID=48 |
1 | ||
| 16572A - CLAMP OR CLIP, HOSE(FOR RADIATOR OUTLET NO.1) | ||||
| 96111-10480 |
18R..RN31,36,41,46 ENGINE SIDE,ID=48 |
1 | ||
| 96111-10480 |
18R..RN36;18R..RN46..ARL..IV3;18R..RN46..EUR,GEN,ME,SA ENGINE SIDE,ID=48 |
1 | ||
| Common parts | ||||
| 88898-89113 | ||||
| 90099-05151 | ||||
| 90339-16007 | ||||
| 90463-10012 | ||||
| 90463-10060 | ||||
| 91611-40820 | ||||
| 91611-41032 | ||||
| 91611-60820 | ||||
| 91651-40616 | ||||
| 91655-40618 | ||||
| 91656-40616 | ||||
| 91656-40818 | ||||
| 93385-15014 | ||||
| 94115-40500 | ||||
| 94180-40600 | ||||
| 96112-10250 | ||||
(8308-9508)L,2L
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| Common parts | ||||
| 16473-71030 | ||||
| 90099-04428 | ||||
| 90116-08366 | ||||
| 90119-08108 | ||||
| 90119-08689 | ||||
| 90119-12224 | ||||
| 90179-06100 | ||||
| 90179-08150 | ||||
| 90480-25025 | ||||
| 91611-60840 | ||||
| 91656-40616 | ||||
| 91656-40818 | ||||
| 91666-60618 | ||||
| 93385-18016 | ||||
| 94180-40600 | ||||
| Linked diagrams | ||||
| 1605 | ||||
