LN46L-MRW (1981)
Toyota Hilux
(8108-8307)LN36,46..EUR
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 33311A - BEARING (FOR INPUT SHAFT FRONT) | ||||
| 90363-32005 |
LN36,46,RN31,41..5F |
1 | ||
| 90365-32011 |
LN46..TW;LN30,40..5F,5H;LN46..ARL..IV3;RN46..ARL..CBU;LN36,46..T1..(EUR,GEN) |
1 | ||
| 33311B - RING, SHAFT SNAP (FOR FRONT BEARING) | ||||
| 90520-30218 |
LN46..TW;LN46..ARL..IV3;RN46..ARL..CBU;LN36,46..T1..(EUR,GEN);LN30,40,RN31,41..5F,5H T=2.25,MARK 4,T=2.25-2.30 |
1 | ||
| 90520-30214 |
LN46..TW;LN46..ARL..IV3;RN46..ARL..CBU;LN36,46..T1..(EUR,GEN);LN30,40,RN31,41..5F,5H T=2.05,MARK 0,T=2.05-2.10 |
1 | ||
| 90520-30216 |
LN46..TW;LN46..ARL..IV3;RN46..ARL..CBU;LN36,46..T1..(EUR,GEN);LN30,40,RN31,41..5F,5H T=2.15,MARK 2,T=2.15-2.20 |
1 | ||
| 90520-30219 |
LN46..TW;LN46..ARL..IV3;RN46..ARL..CBU;LN36,46..T1..(EUR,GEN);LN30,40,RN31,41..5F,5H T=2.30,MARK 5,T=2.30-2.35 |
1 | ||
| 90520-30215 |
LN46..TW;LN46..ARL..IV3;RN46..ARL..CBU;LN36,46..T1..(EUR,GEN);LN30,40,RN31,41..5F,5H T=2.10,MARK 1,T=2.10-2.15 |
1 | ||
| 90520-30217 |
LN46..TW;LN46..ARL..IV3;RN46..ARL..CBU;LN36,46..T1..(EUR,GEN);LN30,40,RN31,41..5F,5H T=2.20,MARK 3,T=2.20-2.25 |
1 | ||
| 33311G - RING, SHAFT SNAP (FOR FRONT BEARING) | ||||
| 90520-71221 |
LN46..TW;LN46..ARL..IV3;RN46..ARL..CBU;LN36,46..T1..(EUR,GEN);LN30,40,RN31,41..5F,5H |
1 | ||
| 33321 - SHAFT, OUTPUT | ||||
| 33321-35070 |
RN3#,4#..DLX,STD |
1 | ||
| 33336 - GEAR, 5TH | ||||
| 33336-30010 |
LN36,46..EUR N=24 |
1 | ||
| 33355A - KEY OR BALL, 1ST GEAR BEARING INNER RACE LOCK | ||||
| 90360-06004 |
LN46..TW;LN46..ARL..IV3;RN46..ARL..CBU;LN36,46..T1..(EUR,GEN);LN30,40,RN31,41..5F,5H |
1 | ||
| 33359A - BALL, 5TH GEAR BEARING INNER RACE LOCK | ||||
| 90360-06004 |
LN3#,4#,RN31,41..5F,5H |
1 | ||
| 33367 - RING, SYNCHRONIZER, NO.1 | ||||
| 33368-20012 |
LN46..TW;LN46..ARL..IV3;RN46..ARL..CBU;LN36,46..T1..(EUR,GEN);LN30,40,RN31,41..5F,5H |
2 | ||
| 33367 - RING, SYNCHRONIZER, NO.1 | ||||
| 33368-20012 |
LN46..TW;LN46..ARL..IV3;RN46..ARL..CBU;LN36,46..T1..(EUR,GEN);LN30,40,RN31,41..5F,5H |
2 | ||
| 33376 - SPRING, SYNCHROMESH SHIFTING KEY (FOR NO.3 CLUTCH HUB) | ||||
| 33371-14010 |
LN3#,4#,RN31,41..5F,5H |
2 | ||
| 33376 - SPRING, SYNCHROMESH SHIFTING KEY (FOR NO.3 CLUTCH HUB) | ||||
| 33371-14010 |
LN3#,4#,RN31,41..5F,5H |
2 | ||
| 33395 - SLEEVE, TRANSMISSION HUB, NO.3 | ||||
| 33395-14013 |
LN36,46..EUR |
1 | ||
| 33399A - RING, SHAFT SNAP (FOR TRANSMISSION SLEEVE YOKE) | ||||
| 90520-25005 |
LN46..TW;LN46..ARL..IV3;RN46..ARL..CBU;LN36,46..T1..(EUR,GEN) |
1 | ||
| 33411D - RING, COUNTER GEAR FRONT BEARING SNAP, NO.1 | ||||
| 90520-49222 |
LN46..TW;LN46..ARL..IV3;RN46..ARL..CBU;LN36,46..T1..(EUR,GEN);LN30,40,RN31,41..5F,5H T=1.07,OD=55.6 |
1 | ||
| 33428 - GEAR, COUNTERSHAFT 5TH | ||||
| 33046-30020 |
LN36,46..EUR N=47 |
1 | ||
| Common parts | ||||
| 91611-60820 | ||||
(8308-8508)LN5#,6#,YN56,6#..5F ; (8508- )LN5#,6#,RN5#,67,YN51,52,56,57,58,6#..5F
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| Common parts | ||||
| 91611-60820 | ||||
