LN30R-KR (1979)
Toyota Hilux
(7909- )L
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 16331A - THERMOSTAT | ||||
| 90916-03042 |
L..LN46..TW;L..LN46..T1..IV3;L..LN46..T1..GEN..CBU;L..LN3#,40..ARL,GEN,SA *WAX 82-95,FUJI-THOMSON |
1 | ||
| 90916-03042 |
L..LN30,40 *WAX 82-95,FUJI-THOMSON |
1 | ||
| 16333 - HOUSING, WATER OUTLET | ||||
| 16333-54010 |
L..LN30,40 |
1 | ||
| 16333 - HOUSING, WATER OUTLET | ||||
| 16333-54010 |
L..LN30,40 |
1 | ||
| 16341 - GASKET, WATER OUTLET | ||||
| 16341-38010 |
L..LN30,40 |
1 | ||
| 16341-41010 |
L..LN3#,40;L..LN46..TW;L..LN46..ARL..IV3;L..LN46..T1..(EUR,GEN) |
1 | ||
| 16341 - GASKET, WATER OUTLET | ||||
| 16341-38010 |
L..LN30,40 |
1 | ||
| 16341-41010 |
L..LN3#,40;L..LN46..TW;L..LN46..ARL..IV3;L..LN46..T1..(EUR,GEN) |
1 | ||
| 16343 - GASKET, WATER OUTLET HOUSING | ||||
| 16343-54010 |
L..LN30,40 |
1 | ||
| 16361A - BELT, V(FOR FAN & ALTERNATOR) | ||||
| 99332-10985 |
L..LN3#,40;L..LN46..TW;L..LN46..ARL..IV3;L..LN46..T1..(EUR,GEN) L=985 |
1 | ||
| 99332-00985 |
L..LN3#,40;L..LN46..TW;L..LN46..ARL..IV3;L..LN46..T1..(EUR,GEN) L=985 |
1 | ||
| 99332-11000 |
L..LN3#,40;L..LN46..TW;L..LN46..ARL..IV3;L..LN46..T1..(EUR,GEN) L=1000 |
1 | ||
| 16400 - RADIATOR ASSY | ||||
| 16400-54080 |
L..LN30,40 |
1 | ||
| 16400B - PLUG, RADIATOR DRAIN COCK | ||||
| 90910-09054 |
L..LN3#,4# |
1 | ||
| 16400F - PACKING(FOR RADIATOR DRAIN COCK) | ||||
| 96710-01007 |
L..LN3#,4# |
1 | ||
| 16470 - TANK ASSY, RADIATOR RESERVE | ||||
| 16470-89105 |
L..LN3#,4#..EUR,GEN PAPER ELEMENT AIR CLEANER |
1 | ||
| 16470A - HOSE OR PIPE(FOR RADIATOR RESERVE TANK) | ||||
| 90445-12030 |
L..LN3#,4#..EUR,GEN PAPER ELEMENT AIR CLEANER |
1 | ||
| 90445-12730 |
L..LN3#,4#..EUR,GEN *H,L=410,PAPER ELEMENT AIR CLEANER |
1 | ||
| 16470B - CLAMP OR CLIP(FOR RADIATOR RESERVE TANK HOSE) | ||||
| 90467-11085 |
L..LN3#,4# |
2 | ||
| 16470B - CLAMP OR CLIP(FOR RADIATOR RESERVE TANK HOSE) | ||||
| 90467-11085 |
L..LN3#,4# |
2 | ||
| 16470C - BRACKET(FOR RADIATOR RESERVE TANK) | ||||
| 16402-31010 |
L..LN30,40..EUR,GEN PAPER ELEMENT AIR CLEANER |
1 | ||
| 16471 - CAP SUB-ASSY, RESERVE TANK | ||||
| 16405-89103 |
L..LN3#,4#..EUR,GEN PAPER ELEMENT AIR CLEANER |
1 | ||
| 16571 - HOSE, RADIATOR, INLET | ||||
| 16571-54050 |
L..LN3#,4# |
1 | ||
| 16571A - CLAMP OR CLIP, HOSE(FOR RADIATOR INLET) | ||||
| 90467-37001 |
L..LN30,40 ENGINE SIDE,ID=37 |
1 | ||
| 96111-10440 |
L..LN30,40 RADIATOR SIDE,ID=44 |
1 | ||
| 90467-37001 |
L..LN30,40 ENGINE SIDE,ID=37 |
1 | ||
| 96111-10440 |
L..LN30,40 RADIATOR SIDE,ID=44 |
1 | ||
| 16571A - CLAMP OR CLIP, HOSE(FOR RADIATOR INLET) | ||||
| 90467-37001 |
L..LN30,40 ENGINE SIDE,ID=37 |
1 | ||
| 96111-10440 |
L..LN30,40 RADIATOR SIDE,ID=44 |
1 | ||
| 90467-37001 |
L..LN30,40 ENGINE SIDE,ID=37 |
1 | ||
| 96111-10440 |
L..LN30,40 RADIATOR SIDE,ID=44 |
1 | ||
| 16571A - CLAMP OR CLIP, HOSE(FOR RADIATOR INLET) | ||||
| 90467-37001 |
L..LN30,40 ENGINE SIDE,ID=37 |
1 | ||
| 96111-10440 |
L..LN30,40 RADIATOR SIDE,ID=44 |
1 | ||
| 90467-37001 |
L..LN30,40 ENGINE SIDE,ID=37 |
1 | ||
| 96111-10440 |
L..LN30,40 RADIATOR SIDE,ID=44 |
1 | ||
| Common parts | ||||
| 88898-89113 | ||||
| 90099-05151 | ||||
| 90119-08108 | ||||
| 90179-06070 | ||||
| 90463-10060 | ||||
| 91611-60820 | ||||
| 91611-60840 | ||||
| 91651-40616 | ||||
| 91655-40618 | ||||
| 91656-40616 | ||||
| 91656-40818 | ||||
| 91659-41222 | ||||
ILLUST NO. 2 OF 2(0408-0908)2KDFTV ; (0908- )2KDFTV..KUN10,15; (0908- )2KDFTV..KUN35..DLX ; (
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| Common parts | ||||
| 90105-T0053 | ||||
| 90105-T0119 | ||||
| 90119-T0067 | ||||
| 90119-T0134 | ||||
| 90178-T0004 | ||||
| 91551-80812 | ||||
| 91551-80818 | ||||
| 91643-80635 | ||||
| 91671-80612 | ||||
| 94151-80600 | ||||
| Linked diagrams | ||||
| 1105 | ||||
| 8716 | ||||
ILLUST NO. 1 OF 2(0408-0808)1KDFTV,2KDFTV ; (0808-0809)1KDFTV,2KDFTV..KUN15,2#,3#..ANCOM,LA,MA,SA ;
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| Common parts | ||||
| 90119-T0346 | ||||
| 90119-T0347 | ||||
| 90179-06293 | ||||
