LN166R-TRMDS (1997)
Toyota Hilux
(8308- )MTM
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| Common parts | ||||
| 93381-15012 | ||||
(9708- )LN166,171..GEN,MA
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 33357B - SPRING, SUB GEAR THRUST | ||||
| 33357-35010 |
LN166,171..DSL..GEN NO.1 |
1 | ||
| 33357-35010 |
LN166,171..GEN,MA NO.1 |
1 | ||
| 33357-35021 |
LN166,171..GEN,MA NO.2 |
1 | ||
| 33357-35021 |
LN166,171..DSL..GEN NO.2 |
1 | ||
| 33357B - SPRING, SUB GEAR THRUST | ||||
| 33357-35010 |
LN166,171..DSL..GEN NO.1 |
1 | ||
| 33357-35010 |
LN166,171..GEN,MA NO.1 |
1 | ||
| 33357-35021 |
LN166,171..GEN,MA NO.2 |
1 | ||
| 33357-35021 |
LN166,171..DSL..GEN NO.2 |
1 | ||
| 33481P - GEAR, SPEEDOMETER DRIVE (FOR TRANSFER) | ||||
| 33481-22010 |
LN166,171..DSL..GEN N=6,MARK 6X18-20 |
1 | ||
| 33481-22010 |
LN166,171..GEN,MA N=6,MARK 6X18-20 |
1 | ||
| 33481Q - KEY OR BALL, SPEEDOMETER DRIVE GEAR (FOR TRANSFER) | ||||
| 90360-06004 |
LN166,171..DSL..GEN |
1 | ||
| 90360-06004 |
LN166,171..GEN,MA |
1 | ||
| 36163 - STOPPER, TRANSFER FRONT BEARING | ||||
| 36163-35010 |
LN166,171..GEN,MA |
1 | ||
| 36163-35010 |
LN166,171..DSL..GEN |
1 | ||
| 36187 - PIPE, TRANSFER OIL SUPPLY, RH | ||||
| 36187-35010 |
LN166,171..GEN,MA |
1 | ||
| 36187-35010 |
LN166,171..DSL..GEN |
1 | ||
| 36188 - PIPE, TRANSFER OIL SUPPLY, LH | ||||
| 36188-35010 |
LN166,171..GEN,MA |
1 | ||
| 36188-35010 |
LN166,171..DSL..GEN |
1 | ||
| 36189 - SCREW, TRANSFER OIL PUMP | ||||
| 36189-35010 |
LN166,171..GEN,MA |
1 | ||
| 36189-35010 |
LN166,171..DSL..GEN |
1 | ||
| 36189A - RING, O (FOR TRANSFER OIL PUMP SCREW) | ||||
| 96711-24028 |
LN166,171..DSL..GEN |
1 | ||
| 96711-24028 |
LN166,171..GEN,MA |
1 | ||
| 36212 - GEAR, TRANSFER INPUT | ||||
| 36212-35012 |
LN166,171..DSL..GEN |
1 | ||
| 36212-35012 |
LN166,171..GEN,MA |
1 | ||
| 36212A - BEARING, RADIAL BALL (FOR TRANSFER INPUT GEAR) | ||||
| 90363-35009 |
LN166,171..DSL..GEN |
1 | ||
| 90363-35009 |
LN166,171..GEN,MA |
1 | ||
| 36212B - BEARING, NEEDLE ROLLER (FOR TRANSFER INPUT GEAR) | ||||
| 90364-19006 |
LN166,171..DSL..GEN |
1 | ||
| 90364-19006 |
LN166,171..GEN,MA |
1 | ||
| 36212C - RING, SHAFT SNAP (FOR TRANSFER INPUT GEAR) | ||||
| 90520-33172 |
LN166,171..GEN,MA T=2.25,MARK 5 |
1 | ||
| 90520-33172 |
LN166,171..DSL..GEN T=2.25,MARK 5 |
1 | ||
| 90520-33168 |
LN166,171..DSL..GEN T=2.05,MARK 1 |
1 | ||
| 90520-33170 |
LN166,171..GEN,MA T=2.15,MARK 3 |
1 | ||
| 90520-33170 |
LN166,171..DSL..GEN T=2.15,MARK 3 |
1 | ||
| 90520-33168 |
LN166,171..GEN,MA T=2.05,MARK 1 |
1 | ||
| 36212D - RING, SHAFT SNAP (FOR TRANSFER INPUT BEARING) | ||||
| 90520-76001 |
LN166,171..DSL..GEN T=1.65 |
1 | ||
| 90520-76001 |
LN166,171..GEN,MA T=1.65 |
1 | ||
| 36221 - GEAR, TRANSFER IDLER | ||||
| 36221-35010 |
LN166,171..GEN,MA |
1 | ||
| 36221-35010 |
LN166,171..DSL..GEN |
1 | ||
| 36221B - BEARING (FOR TRANSFER IDLER GEAR) | ||||
| 90365-38001 |
LN166,171..GEN,MA |
1 | ||
| 90365-38001 |
LN166,171..DSL..GEN |
1 | ||
| 36221C - RING, SHAFT SNAP (FOR TRANSFER IDLER GEAR) | ||||
| 90520-28242 |
LN166,171..DSL..GEN T=1.50-1.55,MARK A |
1 | ||
| 90520-28243 |
LN166,171..GEN,MA T=1.60-1.65,MARK B |
1 | ||
| 90520-28242 |
LN166,171..GEN,MA T=1.50-1.55,MARK A |
1 | ||
| 90520-28243 |
LN166,171..DSL..GEN T=1.60-1.65,MARK B |
1 | ||
| 36221E - BEARING, RADIAL BALL (FOR TRANSFER IDLER GEAR) | ||||
| 90363-30012 |
LN166,171..DSL..GEN |
1 | ||
| 90363-30012 |
LN166,171..GEN,MA |
1 | ||
| 36221F - RING, SHAFT SNAP (FOR TRANSFER IDLER GEAR BEARING) | ||||
| 90520-68193 |
LN166,171..DSL..GEN |
1 | ||
| 90520-68193 |
LN166,171..GEN,MA |
1 | ||
| 36223 - GEAR, TRANSFER COUNTER | ||||
| 36223-35011 |
LN166,171..GEN,MA |
1 | ||
| 36223-35011 |
LN166,171..DSL..GEN |
1 | ||
| 36223A - RING, SHAFT SNAP (FOR TRANSFER COUNTER GEAR) | ||||
| 90520-30217 |
LN166,171..DSL..GEN T=2.20,MARK 3 |
1 | ||
| 90520-30215 |
LN166,171..GEN,MA T=2.10,MARK 1 |
1 | ||
| 90520-30217 |
LN166,171..GEN,MA T=2.20,MARK 3 |
1 | ||
| 90520-30215 |
LN166,171..DSL..GEN T=2.10,MARK 1 |
1 | ||
| 36223B - BEARING (FOR TRANSFER COUNTER GEAR) | ||||
| 90369-45001 |
LN166,171..DSL..GEN REAR |
1 | ||
| 90363-32006 |
LN166,171..DSL..GEN FRONT |
1 | ||
| 90363-32006 |
LN166,171..GEN,MA FRONT |
1 | ||
| 90369-45001 |
LN166,171..GEN,MA REAR |
1 | ||
| 36223B - BEARING (FOR TRANSFER COUNTER GEAR) | ||||
| 90369-45001 |
LN166,171..DSL..GEN REAR |
1 | ||
| 90363-32006 |
LN166,171..DSL..GEN FRONT |
1 | ||
| 90363-32006 |
LN166,171..GEN,MA FRONT |
1 | ||
| 90369-45001 |
LN166,171..GEN,MA REAR |
1 | ||
| 36223D - RING, SHAFT SNAP (FOR TRANSFER COUNTER GEAR BEARING) | ||||
| 90520-71221 |
LN166,171..DSL..GEN |
1 | ||
| 90520-71221 |
LN166,171..GEN,MA |
1 | ||
| 36231 - SHAFT, TRANSFER OUTPUT, REAR | ||||
| 36231-35011 |
LN166,171..DSL..GEN |
1 | ||
| 36231-35011 |
LN166,171..GEN,MA |
1 | ||
| 36231F - RING, SHAFT SNAP (FOR TRANSFER OUTPUT SHAFT) | ||||
| 90520-36252 |
LN166,171..DSL..GEN T=2.50-2.55 |
1 | ||
| 90520-36255 |
LN166,171..DSL..GEN T=2.65-2.70 |
1 | ||
| 90520-36251 |
LN166,171..DSL..GEN T=2.45-2.50 |
1 | ||
| 90520-36250 |
LN166,171..DSL..GEN T=2.40-2.45 |
1 | ||
| 90520-36253 |
LN166,171..DSL..GEN T=2.55-2.60 |
1 | ||
| 90520-36252 |
LN166,171..GEN,MA T=2.50-2.55 |
1 | ||
| 90520-36250 |
LN166,171..GEN,MA T=2.40-2.45 |
1 | ||
| 90520-36254 |
LN166,171..DSL..GEN T=2.60-2.65 |
1 | ||
| 90520-36251 |
LN166,171..GEN,MA T=2.45-2.50 |
1 | ||
| 90520-36255 |
LN166,171..GEN,MA T=2.65-2.70 |
1 | ||
| 90520-36254 |
LN166,171..GEN,MA T=2.60-2.65 |
1 | ||
| 90520-36253 |
LN166,171..GEN,MA T=2.55-2.60 |
1 | ||
| 36231H - BEARING, RADIAL BALL (FOR TRANSFER OUTPUT SHAFT FRONT) | ||||
| 90363-40007 |
LN166,171..DSL..GEN |
1 | ||
| 90363-40007 |
LN166,171..GEN,MA |
1 | ||
| 36231J - BEARING, RADIAL BALL (FOR TRANSFER OUTPUT SHAFT REAR) | ||||
| 90363-28004 |
LN166,171..DSL..GEN |
1 | ||
| 90363-28004 |
LN166,171..GEN,MA |
1 | ||
| 36231P - RING, SHAFT SNAP (FOR TRANSFER OUTPUT SHAFT FRONT BEARI | ||||
| 90520-86001 |
LN166,171..GEN,MA |
1 | ||
| 90520-86001 |
LN166,171..DSL..GEN |
1 | ||
| 36232 - GEAR, TRANSFER FRONT DRIVE | ||||
| 36232-35011 |
LN166,171..DSL..GEN |
1 | ||
| 36232-35011 |
LN166,171..GEN,MA |
1 | ||
| 36232A - BEARING (FOR TRANSFER FRONT DRIVE GEAR) | ||||
| 90369-45001 |
LN166,171..DSL..GEN REAR |
1 | ||
| 90369-45001 |
LN166,171..GEN,MA REAR |
1 | ||
| 90363-30014 |
LN166,171..DSL..GEN FRONT |
1 | ||
| 90363-30014 |
LN166,171..GEN,MA FRONT |
1 | ||
| 36232A - BEARING (FOR TRANSFER FRONT DRIVE GEAR) | ||||
| 90369-45001 |
LN166,171..DSL..GEN REAR |
1 | ||
| 90369-45001 |
LN166,171..GEN,MA REAR |
1 | ||
| 90363-30014 |
LN166,171..DSL..GEN FRONT |
1 | ||
| 90363-30014 |
LN166,171..GEN,MA FRONT |
1 | ||
| 36232C - RING, SHAFT SNAP (FOR TRANSFER FRONT DRIVE GEAR BEARING | ||||
| 90520-76001 |
LN166,171..DSL..GEN |
1 | ||
| 90520-76001 |
LN166,171..GEN,MA |
1 | ||
| 36233 - GEAR, TRANSFER DRIVE | ||||
| 36233-35010 |
LN166,171..DSL..GEN |
1 | ||
| 36233-35010 |
LN166,171..GEN,MA |
1 | ||
| 36233A - BEARING, NEEDLE ROLLER (FOR TRANSFER DRIVE GEAR) | ||||
| 90364-35001 |
LN166,171..GEN,MA |
2 | ||
| 90364-35001 |
LN166,171..DSL..GEN |
2 | ||
| 36233A - BEARING, NEEDLE ROLLER (FOR TRANSFER DRIVE GEAR) | ||||
| 90364-35001 |
LN166,171..GEN,MA |
2 | ||
| 90364-35001 |
LN166,171..DSL..GEN |
2 | ||
| 36235 - SLEEVE, TRANSFER HIGH & LOW CLUTCH | ||||
| 36235-35010 |
LN166,171..GEN,MA |
2 | ||
| 36235-35010 |
LN166,171..DSL..GEN |
2 | ||
| 36235 - SLEEVE, TRANSFER HIGH & LOW CLUTCH | ||||
| 36235-35010 |
LN166,171..GEN,MA |
2 | ||
| 36235-35010 |
LN166,171..DSL..GEN |
2 | ||
| 36237 - HUB, TRANSFER CLUTCH | ||||
| 36237-35010 |
LN166,171..DSL..GEN |
1 | ||
| 36237-35010 |
LN166,171..GEN,MA |
1 | ||
| 36242 - GEAR, TRANSFER LOW | ||||
| 36242-35011 |
LN166,171..GEN,MA |
1 | ||
| 36242-35011 |
LN166,171..DSL..GEN |
1 | ||
| 36242A - BEARING, NEEDLE ROLLER (FOR TRANSFER LOW GEAR) | ||||
| 90364-45002 |
LN166,171..DSL..GEN |
1 | ||
| 90364-45002 |
LN166,171..GEN,MA |
1 | ||
| 36255 - SPACER, TRANSFER OUTPUT SHAFT, NO.1 | ||||
| 36255-35010 |
LN166,171..DSL..GEN |
1 | ||
| 36255-35010 |
LN166,171..GEN,MA |
1 | ||
| 36255A - BALL (FOR TRANSFER OUTPUT SHAFT SPACER) | ||||
| 90360-06004 |
LN166,171..GEN,MA |
2 | ||
| 90360-06004 |
LN166,171..DSL..GEN |
2 | ||
| 36255A - BALL (FOR TRANSFER OUTPUT SHAFT SPACER) | ||||
| 90360-06004 |
LN166,171..GEN,MA |
2 | ||
| 90360-06004 |
LN166,171..DSL..GEN |
2 | ||
| 36256 - SPACER, TRANSFER OUTPUT SHAFT, NO.2 | ||||
| 36256-35010 |
LN166,171..DSL..GEN |
1 | ||
| 36256-35010 |
LN166,171..GEN,MA |
1 | ||
| 36261A - SUB-GEAR, TRANSFER, NO.1 | ||||
| 36261-35011 |
LN166,171..GEN,MA |
1 | ||
| 36261-35011 |
LN166,171..DSL..GEN |
1 | ||
| 36261B - SPACER (FOR TRANSFER SUB-GEAR NO.1 | ||||
| 90560-38002 |
LN166,171..DSL..GEN |
1 | ||
| 90560-38002 |
LN166,171..GEN,MA |
1 | ||
| 36262 - SUB-GEAR, TRANSFER, NO.2 | ||||
| 36262-35011 |
LN166,171..DSL..GEN |
1 | ||
| 36262-35011 |
LN166,171..GEN,MA |
1 | ||
| 36262A - RING, SNAP (FOR TRANSFER SUB-GEAR NO.2 | ||||
| 90520-59003 |
LN166,171..DSL..GEN |
1 | ||
| 90520-59003 |
LN166,171..GEN,MA |
1 | ||
| 36262B - SPACER (FOR TRANSFER SUB-GEAR NO.2) | ||||
| 90561-63002 |
LN166,171..DSL..GEN |
1 | ||
| 90561-63002 |
LN166,171..GEN,MA |
1 | ||
| Common parts | ||||
| 93381-15012 | ||||
