LN166R-TRMDS (1997)
Toyota Hilux
(8308- )RN5#,6#,YN5#,6#..MTM
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| Common parts | ||||
| 90119-08026 | ||||
| 90159-60261 | ||||
| 90170-08197 | ||||
| 94512-00800 | ||||
(8308- )LN5#,6#..MTM
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| Common parts | ||||
| 90119-08026 | ||||
| 90159-60139 | ||||
| 90159-60261 | ||||
| 90170-08197 | ||||
| 94512-00800 | ||||
(9908-0504)KDN151,16#,KZN165,190..MTM
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 31126 - BOOT, CLUTCH RELEASE FORK | ||||
| 31126-20070 |
LN192;LN150..SR;LN167..DSL;LN145..DCB..GEN;LN152..DEFI..IV3;LN145..LHD..DLX..TH;LN152,167..MTM..DEFI..TH;LN167..DCB..DLX..DEFI..ARL;LN167..(SCB,THDCB,THSCB)..DLX..DEFI;LN145,152..(SCB,THXTR,XTR)..MTM..DSL;LN140,141,146,147,155,157,166,17#,191..DLX..(ARL,GCC,GEN,SA,TH) |
1 | ||
| 31126-26020 |
RZN154..GEN;RZN148,149..MTM..(CO,GCC);RZN149..(THDCB,THSCB)..MTM;RZN142,144,147,16#,174,193;RZN148,154..(DCB,SCB,THXTR)..MTM..(ARL,GEN)..CBU |
1 | ||
| 31126-60081 |
KZN165,190..SR;KDN145,15#,16#..MTM;KZN165..(THDCB,THSCB)..DLX |
1 | ||
| 31126-20070 |
LN145..LHD..IV3;LN167..THDCB..SR;LN167..THSCB..CBU;LN145..(GEN,SA)..CBU;LN140,141,146,16#,17#,19#..(DCB,SCB,XTR)..(ARL,GCC,GEN,MA,SA) |
1 | ||
| 31204 - FORK SUB-ASSY, CLUTCH RELEASE | ||||
| 31204-35050 |
LN192;LN150..SR;LN167..DSL;LN145..DCB..GEN;LN152..DEFI..IV3;LN145..LHD..DLX..TH;LN152,167..MTM..DEFI..TH;LN167..DCB..DLX..DEFI..ARL;LN167..(SCB,THDCB,THSCB)..DLX..DEFI;LN145,152..(SCB,THXTR,XTR)..MTM..DSL;LN140,141,146,147,155,157,166,17#,191..DLX..(ARL,GCC,GEN,SA,TH) |
1 | ||
| 31204-35050 |
LN147..THDCB;LN145..DCB..TH;LN145..LHD..IV3;LN147..THSCB..IV3;LN16#..ARL,GCC,GEN,MA,SA;LN140,141,146,150,155,17#,19#..DLX;LN145,152..(DCB,SCB,THXTR)..(ARL,GEN,SA)..CBU |
1 | ||
| 31204-20071 |
RZN154..GEN;RZN148,149..MTM..(CO,GCC);RZN149..(THDCB,THSCB)..MTM;RZN142,144,147,16#,174,193;RZN148,154..(DCB,SCB,THXTR)..MTM..(ARL,GEN)..CBU |
1 | ||
| 31210 - COVER ASSY, CLUTCH | ||||
| 31210-35100 |
LN141,146,166,171,191,RZN142,147..CBR,DSL |
1 | ||
| 31210-35101 |
RZN147..DCB..SA;LN141,146,166,171,191,RZN142,147..DLX..(GCC,GEN) |
1 | ||
| 31210-35260 |
KZN190..SR;KDN151,166,KZN165..MTM |
1 | ||
| 31210-35101 |
LN141,146,166,171,191,RZN142,147..GCC,GEN |
1 | ||
| 31230 - BEARING ASSY, CLUTCH RELEASE | ||||
| 31230-60170 |
KZN165,190..SR;KDN151,16#..MTM;KZN165..(THDCB,THSCB)..DLX |
1 | ||
| 31230-35061 |
LN192;LN152..DEFI..IV3;LN152,167..MTM..DSL;LN152,167..MTM..DEFI..TH;LN167..DCB..DLX..DEFI..ARL;LN167..(SCB,THDCB,THSCB)..DLX..DEFI;LN141,146,147,157,166,17#,191..DLX..(ARL,GCC,GEN,TH) |
1 | ||
| 31230-35060 |
LN147..THSCB..IV3;LN147,152..(THDCB,THXTR)..CBU;LN141,146,16#,17#,19#..ARL,GCC,GEN,MA,SA |
1 | ||
| 31232A - CLIP, RELEASE BEARING HUB | ||||
| 31232-35020 |
LN145..DCB..GEN;LN150,RZN194..SR;LN152..DEFI..IV3;LN145..LHD..DLX..TH;LN167..DCB..DLX..DEFI..ARL;RZN149,169..MTM..DLX..(ARL,SA);LN167,RZN154..RHD..MTM..(DSL,EFI);LN167..(SCB,THDCB,THSCB)..DLX..DEFI;LN145,152..(SCB,THXTR,XTR)..MTM..DSL;LN192,RZN144,149,154,169..CBR,DEFI,DSL;LN152,167,RZN169..(DCB,XTR)..MTM..SR..(DEFI,EFI)..(SA,TH);LN140,141,146,147,155,157,166,17#,191,RZN142,147,148,168,174,193,YN140..DLX..(ARL,GCC,GEN,SA,TH) TYPE A:REFER ILLUST. |
1 | ||
| 31232-60030 |
KZN165,190..SR;KDN151,16#..MTM;KZN165..(THDCB,THSCB)..DLX TYPE B:REFER ILLUST. |
1 | ||
| 31232-35030 |
LN147,17#..THDCB,THSCB,THXTR,XTR;LN141,146,152,16#,191..(DCB,SCB,THDCB,THSCB,THXTR)..(ARL,GCC,GEN,MA) TYPE B:REFER ILLUST. |
1 | ||
| 31232-35030 |
LN166..RHD..GEN TYPE B:REFER ILLUST. |
1 | ||
| 31232-36030 |
KZN165,190..SR;KDN151,16#..MTM;KZN165..(THDCB,THSCB)..DLX TYPE A:REFER ILLUST. |
1 | ||
| 31232-35040 |
RZN154..GEN;RZN148,149..MTM..(CO,GCC);RZN149..(THDCB,THSCB)..MTM;RZN142,144,147,16#,174,193;RZN148,154..(DCB,SCB,THXTR)..MTM..(ARL,GEN)..CBU TYPE C:REFER ILLUST. |
1 | ||
| 31232-35020 |
RZN154..GEN;LN147..THDCB;LN145..DCB..TH;LN145..LHD..IV3;LN147..THSCB..IV3;RZN148,149..MTM..(CO,GCC);RZN149..(THDCB,THSCB)..MTM;LN145,152,RZN148..(DCB,SCB,THXTR)..(ARL,GEN,SA)..CBU;LN140,141,146,150,155,17#,19#,RZN142,147,174,193..DLX;LN16#,RZN144,154,16#..(DCB,SCB,THDCB,THSCB,THXTR)..MTM..(ARL,CO,GCC,GEN,MA,SA) TYPE A:REFER ILLUST. |
1 | ||
| 31232A - CLIP, RELEASE BEARING HUB | ||||
| 31232-35020 |
LN145..DCB..GEN;LN150,RZN194..SR;LN152..DEFI..IV3;LN145..LHD..DLX..TH;LN167..DCB..DLX..DEFI..ARL;RZN149,169..MTM..DLX..(ARL,SA);LN167,RZN154..RHD..MTM..(DSL,EFI);LN167..(SCB,THDCB,THSCB)..DLX..DEFI;LN145,152..(SCB,THXTR,XTR)..MTM..DSL;LN192,RZN144,149,154,169..CBR,DEFI,DSL;LN152,167,RZN169..(DCB,XTR)..MTM..SR..(DEFI,EFI)..(SA,TH);LN140,141,146,147,155,157,166,17#,191,RZN142,147,148,168,174,193,YN140..DLX..(ARL,GCC,GEN,SA,TH) TYPE A:REFER ILLUST. |
1 | ||
| 31232-60030 |
KZN165,190..SR;KDN151,16#..MTM;KZN165..(THDCB,THSCB)..DLX TYPE B:REFER ILLUST. |
1 | ||
| 31232-35030 |
LN147,17#..THDCB,THSCB,THXTR,XTR;LN141,146,152,16#,191..(DCB,SCB,THDCB,THSCB,THXTR)..(ARL,GCC,GEN,MA) TYPE B:REFER ILLUST. |
1 | ||
| 31232-35030 |
LN166..RHD..GEN TYPE B:REFER ILLUST. |
1 | ||
| 31232-36030 |
KZN165,190..SR;KDN151,16#..MTM;KZN165..(THDCB,THSCB)..DLX TYPE A:REFER ILLUST. |
1 | ||
| 31232-35040 |
RZN154..GEN;RZN148,149..MTM..(CO,GCC);RZN149..(THDCB,THSCB)..MTM;RZN142,144,147,16#,174,193;RZN148,154..(DCB,SCB,THXTR)..MTM..(ARL,GEN)..CBU TYPE C:REFER ILLUST. |
1 | ||
| 31232-35020 |
RZN154..GEN;LN147..THDCB;LN145..DCB..TH;LN145..LHD..IV3;LN147..THSCB..IV3;RZN148,149..MTM..(CO,GCC);RZN149..(THDCB,THSCB)..MTM;LN145,152,RZN148..(DCB,SCB,THXTR)..(ARL,GEN,SA)..CBU;LN140,141,146,150,155,17#,19#,RZN142,147,174,193..DLX;LN16#,RZN144,154,16#..(DCB,SCB,THDCB,THSCB,THXTR)..MTM..(ARL,CO,GCC,GEN,MA,SA) TYPE A:REFER ILLUST. |
1 | ||
| 31236B - SUPPORT, RELEASE FORK | ||||
| 31236-30060 |
LN145..DCB..GEN;LN152..DEFI..IV3;LN145..LHD..DLX..TH;LN150,RZN194..(SADCB,XTR)..SR;LN152,167..MTM..DEFI..(SA,TH);LN167,RZN154..RHD..MTM..(DSL,EFI);LN145,152..(SCB,THXTR,XTR)..MTM..DSL;LN192,RZN144,149,154,169..CBR,DEFI,DSL;LN167,RZN149,169..MTM..DLX..(DEFI,EFI)..ARL;LN140,141,146,147,155,157,166,17#,191,RZN142,147,174,193,YN140..DLX TYPE A |
1 | ||
| 31236-30060 |
LN147..IV3;LN145..LHD..IV3;LN16#..ARL,GCC,GEN;LN145,152..(ARL,GEN)..CBU;LN145,147..(DCB,THDCB)..(ARL,TH);LN141,146,150,155,17#,191,RZN142,147..DLX..(ARL,GCC,GEN,TH) TYPE A |
1 | ||
| 31236-26010 |
LN167,RZN147..RHD..SCB..(GEN,SA);LN140,145,166,192,RZN142..RHD..(GEN,SA) TYPE B |
1 | ||
| 31236-30060 |
RZN144,148,149,154,16#,193..MTM..(GCC,GEN)..CBU TYPE A |
1 | ||
| 31236-26010 |
LN145..LHD..IV3;LN145..(GEN,TH)..CBU;LN147,152..THDCB,THSCB,THXTR;LN141,146,150,155,16#,17#,191,RZN142,147..ARL,GCC,GEN,TH TYPE B |
1 | ||
| 31236-26010 |
RZN144,16#,174,193;RZN148,149,154..MTM..(GCC,GEN)..CBU;RZN149,154..(THDCB,THSCB,THXTR)..MTM;LN140,145,16#,192,RZN142,147,148..CO,MA,SA TYPE B |
1 | ||
| 31250 - DISC ASSY, CLUTCH | ||||
| 31250-35221 |
LN141,146,166,171,191 |
1 | ||
| 31250-35222 |
LN141,146,166,171,191 |
1 | ||
| 31250-35410 |
LN141,146,166,171,191..DSL..(GCC,GEN) |
1 | ||
| 31250-26171 |
KZN190..SR;KDN151,166,KZN165..MTM |
1 | ||
| 31250-35410 |
LN141,146,166,171,191..GCC,GEN |
1 | ||
| 33311W - BEARING (FOR INPUT SHAFT) | ||||
| 90363-12020 |
RZN14#,154,16#,174,19#..MTM NACHI |
1 | ||
| 90363-12002 |
KZN165,LN14#,15#,16#,17#,19#,RZN14#,154,16#,174,19#,YN140..MTM |
1 | ||
| 90363-12018 |
RZN14#,154,16#,174,19#..MTM NSK |
1 | ||
| 90363-12020 |
RZN142,147,148,154,16#,193..GEN..CBU |
1 | ||
| 90363-12002 |
LN145..LHD..IV3;LN145,166,171,191..GEN..CBU |
1 | ||
| Common parts | ||||
| 90119-08079 | ||||
| 90521-22003 | ||||
(9708- )LN14#,15#,16#,17#,19#,RZN14#,154,16#,174,19#,VZN167,172,YN140..MTM
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 31126 - BOOT, CLUTCH RELEASE FORK | ||||
| 31126-20070 |
LN192;LN150..SR;LN167..DSL;LN145..DCB..GEN;LN152..DEFI..IV3;LN145..LHD..DLX..TH;LN152,167..MTM..DEFI..TH;LN167..DCB..DLX..DEFI..ARL;LN167..(SCB,THDCB,THSCB)..DLX..DEFI;LN145,152..(SCB,THXTR,XTR)..MTM..DSL;LN140,141,146,147,155,157,166,17#,191..DLX..(ARL,GCC,GEN,SA,TH) |
1 | ||
| 31126-26020 |
RZN154..GEN;RZN148,149..MTM..(CO,GCC);RZN149..(THDCB,THSCB)..MTM;RZN142,144,147,16#,174,193;RZN148,154..(DCB,SCB,THXTR)..MTM..(ARL,GEN)..CBU |
1 | ||
| 31126-60081 |
KZN165,190..SR;KDN145,15#,16#..MTM;KZN165..(THDCB,THSCB)..DLX |
1 | ||
| 31126-20070 |
LN145..LHD..IV3;LN167..THDCB..SR;LN167..THSCB..CBU;LN145..(GEN,SA)..CBU;LN140,141,146,16#,17#,19#..(DCB,SCB,XTR)..(ARL,GCC,GEN,MA,SA) |
1 | ||
| 31204 - FORK SUB-ASSY, CLUTCH RELEASE | ||||
| 31204-35050 |
LN192;LN150..SR;LN167..DSL;LN145..DCB..GEN;LN152..DEFI..IV3;LN145..LHD..DLX..TH;LN152,167..MTM..DEFI..TH;LN167..DCB..DLX..DEFI..ARL;LN167..(SCB,THDCB,THSCB)..DLX..DEFI;LN145,152..(SCB,THXTR,XTR)..MTM..DSL;LN140,141,146,147,155,157,166,17#,191..DLX..(ARL,GCC,GEN,SA,TH) |
1 | ||
| 31204-35050 |
LN147..THDCB;LN145..DCB..TH;LN145..LHD..IV3;LN147..THSCB..IV3;LN16#..ARL,GCC,GEN,MA,SA;LN140,141,146,150,155,17#,19#..DLX;LN145,152..(DCB,SCB,THXTR)..(ARL,GEN,SA)..CBU |
1 | ||
| 31204-20071 |
RZN154..GEN;RZN148,149..MTM..(CO,GCC);RZN149..(THDCB,THSCB)..MTM;RZN142,144,147,16#,174,193;RZN148,154..(DCB,SCB,THXTR)..MTM..(ARL,GEN)..CBU |
1 | ||
| 31210 - COVER ASSY, CLUTCH | ||||
| 31210-35100 |
LN141,146,166,171,191,RZN142,147..CBR,DSL |
1 | ||
| 31210-35101 |
RZN147..DCB..SA;LN141,146,166,171,191,RZN142,147..DLX..(GCC,GEN) |
1 | ||
| 31210-35260 |
KZN190..SR;KDN151,166,KZN165..MTM |
1 | ||
| 31210-35101 |
LN141,146,166,171,191,RZN142,147..GCC,GEN |
1 | ||
| 31230 - BEARING ASSY, CLUTCH RELEASE | ||||
| 31230-60170 |
KZN165,190..SR;KDN151,16#..MTM;KZN165..(THDCB,THSCB)..DLX |
1 | ||
| 31230-35061 |
LN192;LN152..DEFI..IV3;LN152,167..MTM..DSL;LN152,167..MTM..DEFI..TH;LN167..DCB..DLX..DEFI..ARL;LN167..(SCB,THDCB,THSCB)..DLX..DEFI;LN141,146,147,157,166,17#,191..DLX..(ARL,GCC,GEN,TH) |
1 | ||
| 31230-35060 |
LN147..THSCB..IV3;LN147,152..(THDCB,THXTR)..CBU;LN141,146,16#,17#,19#..ARL,GCC,GEN,MA,SA |
1 | ||
| 31232A - CLIP, RELEASE BEARING HUB | ||||
| 31232-35020 |
LN145..DCB..GEN;LN150,RZN194..SR;LN152..DEFI..IV3;LN145..LHD..DLX..TH;LN167..DCB..DLX..DEFI..ARL;RZN149,169..MTM..DLX..(ARL,SA);LN167,RZN154..RHD..MTM..(DSL,EFI);LN167..(SCB,THDCB,THSCB)..DLX..DEFI;LN145,152..(SCB,THXTR,XTR)..MTM..DSL;LN192,RZN144,149,154,169..CBR,DEFI,DSL;LN152,167,RZN169..(DCB,XTR)..MTM..SR..(DEFI,EFI)..(SA,TH);LN140,141,146,147,155,157,166,17#,191,RZN142,147,148,168,174,193,YN140..DLX..(ARL,GCC,GEN,SA,TH) TYPE A:REFER ILLUST. |
1 | ||
| 31232-60030 |
KZN165,190..SR;KDN151,16#..MTM;KZN165..(THDCB,THSCB)..DLX TYPE B:REFER ILLUST. |
1 | ||
| 31232-35030 |
LN147,17#..THDCB,THSCB,THXTR,XTR;LN141,146,152,16#,191..(DCB,SCB,THDCB,THSCB,THXTR)..(ARL,GCC,GEN,MA) TYPE B:REFER ILLUST. |
1 | ||
| 31232-35030 |
LN166..RHD..GEN TYPE B:REFER ILLUST. |
1 | ||
| 31232-36030 |
KZN165,190..SR;KDN151,16#..MTM;KZN165..(THDCB,THSCB)..DLX TYPE A:REFER ILLUST. |
1 | ||
| 31232-35040 |
RZN154..GEN;RZN148,149..MTM..(CO,GCC);RZN149..(THDCB,THSCB)..MTM;RZN142,144,147,16#,174,193;RZN148,154..(DCB,SCB,THXTR)..MTM..(ARL,GEN)..CBU TYPE C:REFER ILLUST. |
1 | ||
| 31232-35020 |
RZN154..GEN;LN147..THDCB;LN145..DCB..TH;LN145..LHD..IV3;LN147..THSCB..IV3;RZN148,149..MTM..(CO,GCC);RZN149..(THDCB,THSCB)..MTM;LN145,152,RZN148..(DCB,SCB,THXTR)..(ARL,GEN,SA)..CBU;LN140,141,146,150,155,17#,19#,RZN142,147,174,193..DLX;LN16#,RZN144,154,16#..(DCB,SCB,THDCB,THSCB,THXTR)..MTM..(ARL,CO,GCC,GEN,MA,SA) TYPE A:REFER ILLUST. |
1 | ||
| 31232A - CLIP, RELEASE BEARING HUB | ||||
| 31232-35020 |
LN145..DCB..GEN;LN150,RZN194..SR;LN152..DEFI..IV3;LN145..LHD..DLX..TH;LN167..DCB..DLX..DEFI..ARL;RZN149,169..MTM..DLX..(ARL,SA);LN167,RZN154..RHD..MTM..(DSL,EFI);LN167..(SCB,THDCB,THSCB)..DLX..DEFI;LN145,152..(SCB,THXTR,XTR)..MTM..DSL;LN192,RZN144,149,154,169..CBR,DEFI,DSL;LN152,167,RZN169..(DCB,XTR)..MTM..SR..(DEFI,EFI)..(SA,TH);LN140,141,146,147,155,157,166,17#,191,RZN142,147,148,168,174,193,YN140..DLX..(ARL,GCC,GEN,SA,TH) TYPE A:REFER ILLUST. |
1 | ||
| 31232-60030 |
KZN165,190..SR;KDN151,16#..MTM;KZN165..(THDCB,THSCB)..DLX TYPE B:REFER ILLUST. |
1 | ||
| 31232-35030 |
LN147,17#..THDCB,THSCB,THXTR,XTR;LN141,146,152,16#,191..(DCB,SCB,THDCB,THSCB,THXTR)..(ARL,GCC,GEN,MA) TYPE B:REFER ILLUST. |
1 | ||
| 31232-35030 |
LN166..RHD..GEN TYPE B:REFER ILLUST. |
1 | ||
| 31232-36030 |
KZN165,190..SR;KDN151,16#..MTM;KZN165..(THDCB,THSCB)..DLX TYPE A:REFER ILLUST. |
1 | ||
| 31232-35040 |
RZN154..GEN;RZN148,149..MTM..(CO,GCC);RZN149..(THDCB,THSCB)..MTM;RZN142,144,147,16#,174,193;RZN148,154..(DCB,SCB,THXTR)..MTM..(ARL,GEN)..CBU TYPE C:REFER ILLUST. |
1 | ||
| 31232-35020 |
RZN154..GEN;LN147..THDCB;LN145..DCB..TH;LN145..LHD..IV3;LN147..THSCB..IV3;RZN148,149..MTM..(CO,GCC);RZN149..(THDCB,THSCB)..MTM;LN145,152,RZN148..(DCB,SCB,THXTR)..(ARL,GEN,SA)..CBU;LN140,141,146,150,155,17#,19#,RZN142,147,174,193..DLX;LN16#,RZN144,154,16#..(DCB,SCB,THDCB,THSCB,THXTR)..MTM..(ARL,CO,GCC,GEN,MA,SA) TYPE A:REFER ILLUST. |
1 | ||
| 31236B - SUPPORT, RELEASE FORK | ||||
| 31236-30060 |
LN145..DCB..GEN;LN152..DEFI..IV3;LN145..LHD..DLX..TH;LN150,RZN194..(SADCB,XTR)..SR;LN152,167..MTM..DEFI..(SA,TH);LN167,RZN154..RHD..MTM..(DSL,EFI);LN145,152..(SCB,THXTR,XTR)..MTM..DSL;LN192,RZN144,149,154,169..CBR,DEFI,DSL;LN167,RZN149,169..MTM..DLX..(DEFI,EFI)..ARL;LN140,141,146,147,155,157,166,17#,191,RZN142,147,174,193,YN140..DLX TYPE A |
1 | ||
| 31236-30060 |
LN147..IV3;LN145..LHD..IV3;LN16#..ARL,GCC,GEN;LN145,152..(ARL,GEN)..CBU;LN145,147..(DCB,THDCB)..(ARL,TH);LN141,146,150,155,17#,191,RZN142,147..DLX..(ARL,GCC,GEN,TH) TYPE A |
1 | ||
| 31236-26010 |
LN167,RZN147..RHD..SCB..(GEN,SA);LN140,145,166,192,RZN142..RHD..(GEN,SA) TYPE B |
1 | ||
| 31236-30060 |
RZN144,148,149,154,16#,193..MTM..(GCC,GEN)..CBU TYPE A |
1 | ||
| 31236-26010 |
LN145..LHD..IV3;LN145..(GEN,TH)..CBU;LN147,152..THDCB,THSCB,THXTR;LN141,146,150,155,16#,17#,191,RZN142,147..ARL,GCC,GEN,TH TYPE B |
1 | ||
| 31236-26010 |
RZN144,16#,174,193;RZN148,149,154..MTM..(GCC,GEN)..CBU;RZN149,154..(THDCB,THSCB,THXTR)..MTM;LN140,145,16#,192,RZN142,147,148..CO,MA,SA TYPE B |
1 | ||
| 31236B - SUPPORT, RELEASE FORK | ||||
| 31236-30060 |
LN145..DCB..GEN;LN152..DEFI..IV3;LN145..LHD..DLX..TH;LN150,RZN194..(SADCB,XTR)..SR;LN152,167..MTM..DEFI..(SA,TH);LN167,RZN154..RHD..MTM..(DSL,EFI);LN145,152..(SCB,THXTR,XTR)..MTM..DSL;LN192,RZN144,149,154,169..CBR,DEFI,DSL;LN167,RZN149,169..MTM..DLX..(DEFI,EFI)..ARL;LN140,141,146,147,155,157,166,17#,191,RZN142,147,174,193,YN140..DLX TYPE A |
1 | ||
| 31236-30060 |
LN147..IV3;LN145..LHD..IV3;LN16#..ARL,GCC,GEN;LN145,152..(ARL,GEN)..CBU;LN145,147..(DCB,THDCB)..(ARL,TH);LN141,146,150,155,17#,191,RZN142,147..DLX..(ARL,GCC,GEN,TH) TYPE A |
1 | ||
| 31236-26010 |
LN167,RZN147..RHD..SCB..(GEN,SA);LN140,145,166,192,RZN142..RHD..(GEN,SA) TYPE B |
1 | ||
| 31236-30060 |
RZN144,148,149,154,16#,193..MTM..(GCC,GEN)..CBU TYPE A |
1 | ||
| 31236-26010 |
LN145..LHD..IV3;LN145..(GEN,TH)..CBU;LN147,152..THDCB,THSCB,THXTR;LN141,146,150,155,16#,17#,191,RZN142,147..ARL,GCC,GEN,TH TYPE B |
1 | ||
| 31236-26010 |
RZN144,16#,174,193;RZN148,149,154..MTM..(GCC,GEN)..CBU;RZN149,154..(THDCB,THSCB,THXTR)..MTM;LN140,145,16#,192,RZN142,147,148..CO,MA,SA TYPE B |
1 | ||
| 31250 - DISC ASSY, CLUTCH | ||||
| 31250-35221 |
LN141,146,166,171,191 |
1 | ||
| 31250-35222 |
LN141,146,166,171,191 |
1 | ||
| 31250-35410 |
LN141,146,166,171,191..DSL..(GCC,GEN) |
1 | ||
| 31250-26171 |
KZN190..SR;KDN151,166,KZN165..MTM |
1 | ||
| 31250-35410 |
LN141,146,166,171,191..GCC,GEN |
1 | ||
| 33311W - BEARING (FOR INPUT SHAFT) | ||||
| 90363-12020 |
RZN14#,154,16#,174,19#..MTM NACHI |
1 | ||
| 90363-12002 |
KZN165,LN14#,15#,16#,17#,19#,RZN14#,154,16#,174,19#,YN140..MTM |
1 | ||
| 90363-12018 |
RZN14#,154,16#,174,19#..MTM NSK |
1 | ||
| 90363-12020 |
RZN142,147,148,154,16#,193..GEN..CBU |
1 | ||
| 90363-12002 |
LN145..LHD..IV3;LN145,166,171,191..GEN..CBU |
1 | ||
| Common parts | ||||
| 90119-08079 | ||||
| 90119-T0102 | ||||
