LN166L-PRMDS (1997)
Toyota Hilux
(9708- )KDN16#,190,KZN165,190,LN16#,19#,RZN16#,19#,VZN167..DCB,SADCB,SRWGN,THDCB
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 47354C - BRACKET, FLEXIBLE HOSE, NO.4 | ||||
| 47354-35110 |
RZN169..SCB..CBR;LN166,171,191,RZN193..LHD |
1 | ||
| 47383F - BRACKET, CONNECTOR | ||||
| 47383-35020 |
LN167..DSL..(ARL,SA);KZN165,RZN194..SR..(ARL,SA);KZN165,RZN168..SCB..DLX..(ARL,GEN);RZN169..(SCB,THSCB)..DLX..(ARL,SA);LN167,RZN169..DCB..SR..(DEFI,EFI)..(SA,TH);KZN165,LN167..DCB..DLX..(DEFI,TDE)..ARL..CBU;LN167,RZN169..(SCB,THDCB,THSCB)..DLX..(CBR,DEFI);KZN190,LN166,17#,19#,RZN174,193..DLX..(ARL,GCC,GEN,SA) |
1 | ||
| 51071 - BRACKET SUB-ASSY, REAR BODY MOUNTING, NO.1 RH | ||||
| 51741-35080 |
LN145..DCB..IV3;RZN149..DCB..GCC;RZN147..DCB..(GCC,GEN);RZN149..DCB..DLX..CBR..GEN;LN145,146,166,191,RZN193..LHD..DCB..(GCC,GEN) |
1 | ||
| 51072 - BRACKET SUB-ASSY, REAR BODY MOUNTING, NO.1 LH | ||||
| 51072-35040 |
LN166,191,RZN193..LHD..DCB |
1 | ||
| 51100F - FRAME SUB-ASSY | ||||
| 51001-3G060 |
LN16#..DCB..DLX |
1 | ||
| 51002-3G410 |
LN166..LHD..DCB |
1 | ||
| 51002-3G410 |
LN166..DCB..GEN |
1 | ||
| 51203 - CROSSMEMBER SUB-ASSY, FRAME, NO.2 | ||||
| 51203-35270 |
LN166,171..LHD;RZN169..SCB..CBR |
1 | ||
| 51203-35270 |
LN166,171,RZN16#..GEN |
1 | ||
| 51204 - CROSSMEMBER SUB-ASSY, FRAME, NO.3 | ||||
| 51202-35400 |
LN166,171..LHD |
1 | ||
| 51202-35400 |
LN166,171..GEN |
1 | ||
| 51205 - CROSSMEMBER SUB-ASSY, FRAME, NO.4 | ||||
| 51204-35560 |
LN16#..ARL,GCC,GEN |
1 | ||
| 51204-35710 |
LN16#..(DCB,SCB,THSCB)..(ARL,GCC,GEN) |
1 | ||
| 51204-35710 |
LN167..(DCB,SCB)..ARL;KZN165,LN166..(DCB,SCB)..(DSL,TDE) |
1 | ||
| 51204-35710 |
LN166..GEN |
1 | ||
| 51205C - CROSSMEMBER SUB-ASSY, FRAME, NO.5 | ||||
| 51205-35260 |
RZN169..SCB..CBR;LN166,171,191,RZN193..LHD |
1 | ||
| 51205-35260 |
LN166,171,191,RZN16#,193..GEN |
1 | ||
| 51207E - BRACKET SUB-ASSY, DIFFERENTIAL SUPPORT, RH | ||||
| 51207-35010 |
LN167..ARL,SA;KZN165..(DCB,SCB)..(ARL,SA);KDN16#,LN166,17#,RZN16#,VZN167,172..DCB,SCB,SRWGN,THXTR,XTR |
1 | ||
| 51207-35010 |
RZN169..DCB..DLX..ARL;LN16#,RZN169..DCB..DLX..(CBR,DSL)..(ARL,GCC,GEN) |
1 | ||
| 51254 - BRACKET, DIFFERENTIAL SUPPORT, LH | ||||
| 51254-35010 |
LN166,171..LHD;RZN169..SCB..CBR |
1 | ||
| 51254-35010 |
LN166,171,RZN16#..GEN |
1 | ||
| 51291 - CROSSMEMBER, FRAME, REAR | ||||
| 51209-35180 |
RZN169..CBR;RZN149..GCC;LN145..DCB..IV3;RZN147..LHD..SCB;RZN149..DLX..CBR..GEN;RZN147..DCB..(GCC,GEN);LN141,145,146,166,171,191,RZN142,144,193..LHD..(GCC,GEN) |
1 | ||
| 51209-35200 |
LN145..LHD..IV3;LN145,166,191,RZN142,147,148,154,16#,193..GEN..CBU |
1 | ||
| 51209-35180 |
LN147..IV3;KZN165..XTR;LN145..LHD..IV3;LN150,152..DLX..CBU;LN145,RZN148..GEN..CBU;LN145,147..(DCB,THDCB)..(ARL,TH);KZN165,RZN169..(DCB,SCB)..(ARL,GCC,GEN);LN167,172,RZN149..(DCB,SCB,THDCB,THSCB,THXTR)..(ARL,GCC);KDN145,15#,165,LN141,146,155,166,191,RZN142,144,147,154,168,193..ARL,GCC,GEN,TH |
1 | ||
| 51296B - REINFORCEMENT, DIFFERENTIAL BRACKET, LH | ||||
| 51296-35010 |
LN166,171..LHD;RZN169..SCB..CBR |
1 | ||
| 51296-35010 |
LN166,171,RZN16#..GEN |
1 | ||
| 51321 - GUSSET, CROSSMEMBER, NO.2 RH | ||||
| 51321-35050 |
LN166,171,191,RZN193..LHD..(DCB,XTR) |
2 | ||
| 51321-35050 |
KZN190..SR;LN167..ARL,SA;KZN165,LN192..DCB,SCB,THDCB,THSCB;KDN16#,190,LN166,17#,191,RZN16#,174,19#,VZN167,172..DCB,SCB,THXTR,XTR |
2 | ||
| 51321 - GUSSET, CROSSMEMBER, NO.2 RH | ||||
| 51321-35050 |
LN166,171,191,RZN193..LHD..(DCB,XTR) |
2 | ||
| 51321-35050 |
KZN190..SR;LN167..ARL,SA;KZN165,LN192..DCB,SCB,THDCB,THSCB;KDN16#,190,LN166,17#,191,RZN16#,174,19#,VZN167,172..DCB,SCB,THXTR,XTR |
2 | ||
| 51401 - BRACKET SUB-ASSY, ENGINE FRONT MOUNTING, RH | ||||
| 51047-35070 |
LN166,171,191..LHD |
1 | ||
| 51047-35070 |
LN166,171,191..GEN |
1 | ||
| 51402 - BRACKET SUB-ASSY, ENGINE FRONT MOUNTING, LH | ||||
| 51048-35070 |
LN166,171,191..LHD |
1 | ||
| 51048-35070 |
LN166,171,191..GEN |
1 | ||
| 51501 - SUPPORT SUB-ASSY, SUSPENSION ARM, RH | ||||
| 51501-35130 |
RZN169..SCB..CBR;LN166,171,191,RZN193..LHD |
1 | ||
| 51501-35130 |
LN166,171,191,RZN16#,193..GEN |
1 | ||
| 51502 - SUPPORT SUB-ASSY, SUSPENSION ARM, LH | ||||
| 51502-35130 |
RZN169..SCB..CBR;LN166,171,191,RZN193..LHD |
1 | ||
| 51502-35130 |
KDN190..IV1;LN167..ARL,SA;KZN165..(DCB,SCB)..(ARL,SA);KDN16#,LN166,17#,RZN16#,VZN167,172..DCB,SCB,SRWGN,THXTR,XTR |
1 | ||
| 51505C - SUPPORT SUB-ASSY, ANCHOR ARM, RH | ||||
| 51505-35100 |
RZN169..SCB..CBR;LN166,171,191,RZN193..LHD |
1 | ||
| 51505-35100 |
LN166,171,191,RZN16#,193..GEN |
1 | ||
| 51506C - SUPPORT SUB-ASSY, ANCHOR ARM, LH | ||||
| 51506-35020 |
RZN169..SCB..CBR;LN166,171,191,RZN193..LHD |
1 | ||
| 51506-35020 |
LN166,171,191,RZN16#,193..GEN |
1 | ||
| 51631 - STOPPER, FRONT SUSPENSION REBOUND, RH | ||||
| 51061-35010 |
RZN169..SCB..CBR;LN166,171,191,RZN193..LHD |
1 | ||
| 51061-35010 |
LN166,171,191,RZN16#,193..GEN |
1 | ||
| 51632 - STOPPER, FRONT SUSPENSION REBOUND, LH | ||||
| 51061-35010 |
LN16#..DCB..DLX |
1 | ||
| 51061-35010 |
KDN165,190,LN166,171,191,RZN16#,193..GEN,MA |
1 | ||
| 51701 - BRACKET SUB-ASSY, CAB MOUNTING, NO.1 RH | ||||
| 51701-35170 |
RZN169..SCB..CBR;LN166,171,191,RZN193..LHD |
1 | ||
| 51701-35170 |
LN166,171,191,RZN16#,193..GEN |
1 | ||
| 51702 - BRACKET SUB-ASSY, CAB MOUNTING, NO.1 LH | ||||
| 51702-35140 |
RZN169..SCB..CBR;LN166,171,191,RZN193..LHD |
1 | ||
| 51702-35140 |
LN166,171,191,RZN16#,193..GEN |
1 | ||
| 51703 - BRACKET SUB-ASSY, CAB MOUNTING, NO.2, RH | ||||
| 51703-35150 |
LN166,191,RZN193..LHD..DCB |
1 | ||
| 51703-35150 |
LN166,191,RZN16#,193..DCB..GEN |
1 | ||
| 51704 - BRACKET SUB-ASSY, CAB MOUNTING, NO.2 LH | ||||
| 51704-35140 |
LN166,191,RZN193..LHD..DCB |
1 | ||
| 51704-35140 |
LN166,191,RZN16#,193..DCB..GEN |
1 | ||
| 51707C - BRACKET SUB-ASSY, CAB MOUNTING, NO.4 RH | ||||
| 51707-35080 |
LN145..DCB..IV3;RZN149..DCB..GCC;RZN147..DCB..(GCC,GEN);RZN149..DCB..DLX..CBR..GEN;LN145,146,166,191,RZN193..LHD..DCB..(GCC,GEN) |
1 | ||
| 51707-35080 |
LN145,166,191,RZN147,148,16#,193..DCB..GEN |
1 | ||
| 51708A - BRACKET SUB-ASSY, CAB MOUNTING, NO.4 LH | ||||
| 51708-35080 |
LN145..DCB..IV3;RZN149..DCB..GCC;RZN147..DCB..(GCC,GEN);RZN149..DCB..DLX..CBR..GEN;LN145,146,166,191,RZN193..LHD..DCB..(GCC,GEN) |
1 | ||
| 51708-35080 |
LN145,166,191,RZN147,148,16#,193..DCB..GEN |
1 | ||
| 51755 - BRACKET, BODY SUPPORT, NO.3 RH | ||||
| 51755-35010 |
RZN149..GCC;LN145..DCB..IV3;RZN147..LHD..SCB;RZN169..SCB..CBR;RZN149..DLX..CBR..GEN;RZN147..DCB..(GCC,GEN);LN141,145,146,166,171,191,RZN142,144,193..LHD..(GCC,GEN) |
1 | ||
| 51755-35010 |
LN145..LHD..IV3;LN145,166,171,191,RZN142,147,148,154,16#,193..GEN..CBU |
1 | ||
| 51756 - BRACKET, BODY SUPPORT, NO.3 LH | ||||
| 51755-35010 |
LN16#..DCB..DLX |
1 | ||
| 51755-35010 |
LN145..LHD..IV3;KDN165,190,LN145,166,171,191,RZN142,147,148,154,16#,193..(GEN,MA)..CBU |
1 | ||
| 51963A - HOOK, TRANSPORT, FRONT RH | ||||
| 51963-35070 |
RZN149..GCC;LN145..DCB..IV3;RZN147..LHD..SCB;RZN169..SCB..CBR;RZN149..DLX..CBR..GEN;RZN147..DCB..(GCC,GEN);LN141,145,146,166,171,191,RZN142,144,193..LHD..(GCC,GEN) |
1 | ||
| 51963-35070 |
LN145..LHD..IV3;LN145,166,171,191,RZN142,147,148,154,16#,193..GEN..CBU |
1 | ||
| 51964A - HOOK, TRANSPORT, FRONT LH | ||||
| 51964-35050 |
RZN149..GCC;LN145..DCB..IV3;RZN147..LHD..SCB;RZN169..SCB..CBR;RZN149..DLX..CBR..GEN;RZN147..DCB..(GCC,GEN);LN141,145,146,166,171,191,RZN142,144,193..LHD..(GCC,GEN) |
1 | ||
| 51964-35050 |
LN145..LHD..IV3;LN145,166,171,191,RZN142,147,148,154,16#,193..GEN..CBU |
1 | ||
| 77512A - BRACKET, FUEL TANK, REAR | ||||
| 77512-35090 |
LN145..LHD..IV3;LN145,166,171,191,RZN147,148,154,16#,193..GEN..CBU |
1 | ||
| Common parts | ||||
| 90101-12176 | ||||
| 90105-12016 | ||||
| 90105-12160 | ||||
| 90105-12259 | ||||
| 90119-10536 | ||||
| 90119-10566 | ||||
| 90170-12014 | ||||
| 91362-81240 | ||||
| 91611-B0825 | ||||
| 94622-11200 | ||||
