GUN135L-BGFXHG (2015)
Toyota Hilux
(0408- )CBU
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| Common parts | ||||
| 90069-46025 | ||||
| 90119-06754 | ||||
| 90119-T0147 | ||||
| 90467-T0005 | ||||
| 90467-T0006 | ||||
(1107- )CBU
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| Common parts | ||||
| 90119-T0147 | ||||
| 90467-T0005 | ||||
| 90467-T0006 | ||||
(1505- )CBU
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 81496 - GUIDE, REAR COMBINATION LAMP | ||||
| 81496-52020 |
GUN122..RHD..SA;GUN122..(TDC,TSC,TXT)..CBU;GGN12#,135,GUN112,123,125,126,13#,KUN112,12#,13#,LAN125,TGN11#,12#,13#..CBU |
2 | ||
| 81496-52020 |
GUN125..6FC..ARL..CBU;TGN136..ADC,ASC,SDC,TDC,TSC,TXT;GUN125,KUN126..(BZAGT,GCC,GEN,IDN,LA,PH,SA,TH,VN)..CBU;GGN12#,135,GUN112,120,122,135..(ADC,ASC,MDC,PSC,SDC,SSC,SXT,TDC,TSC,TXT)..CBU;GUN123,126,136,KUN112,122,125,13#,LAN125,TGN11#,120,121,126,128,138..(ADC,ASC,PDC,PSC,SDC,SSC,SXT,TDC,TSC,TXT)..CBU (J) |
2 | ||
| 81550 - LAMP ASSY, REAR COMBINATION, RH | ||||
| 81550-0K260 |
GUN125,126,13#,KUN125,126,13#,TGN126,128,13#..(ADC,ASC)..CBU KOITO |
1 | ||
| 81550-0K261 |
GGN125,GUN125,126,13#,KUN125,126,13#,TGN126,128,13#..(ADC,ASC)..CBU KOITO |
1 | ||
| 81550-0K300 |
GGN125,GUN125,126,13#,KUN125,126,13#,TGN126,128,13#..(ADC,ASC)..CBU VALEO |
1 | ||
| 81550H - BULB, TAIL & STOP LAMP | ||||
| 90981-13094 |
GGN125,GUN125,126,13#,KUN125,126,13#,TGN126,128,13#..(ADC,ASC)..CBU 12V 21/5W,PNC 81560 = KOITO |
2 | ||
| 90981-13096 |
GGN125,GUN125,126,13#,KUN125,126,13#,TGN126,128,13#..(ADC,ASC)..CBU 12V 21/5W,PNC 81560 = VALEO |
2 | ||
| 81550L - BULB, REAR TURN SIGNAL LAMP | ||||
| 90981-15028 |
GGN125,GUN125,126,13#,KUN125,126,13#,TGN126,128,13#..(ADC,ASC)..CBU 12V 21W,AMBER,PNC 81560 = KOITO |
2 | ||
| 90981-15020 |
GGN125,GUN125,126,13#,KUN125,126,13#,TGN126,128,13#..(ADC,ASC)..CBU 12V 21W,AMBER,PNC 81560 = VALEO |
2 | ||
| 81550N - BULB, BACK UP LAMP | ||||
| 90981-13095 |
GGN125,TGN128,138..ADC;GUN125,126,13#,TGN126,136..BZAGT..CBU 12V 21W,PNC 81550 = VALEO |
1 | ||
| 90981-13093 |
GGN125,TGN128,138..ADC;GUN125,126,13#,TGN126,136..BZAGT..CBU 12V 21W,PNC 81550 = KOITO |
1 | ||
| 81550Q - BULB, REAR FOG LAMP, NO.1 | ||||
| 90981-13095 |
GGN125,TGN128,138..ADC;GUN125,126,13#,TGN126,136..BZAGT..CBU 12V 21W |
1 | ||
| 90981-13093 |
GGN125,TGN128,138..ADC;GUN125,126,13#,TGN126,136..BZAGT..CBU 12V 21W,PNC 81560 = KOITO |
1 | ||
| 81551D - LENS & BODY, REAR COMBINATION LAMP, RH | ||||
| 81551-0K260 |
GUN125,126,13#,KUN125,126,13#,TGN126,128,13#..(ADC,ASC)..CBU KOITO |
1 | ||
| 81551-0K300 |
GGN125,GUN125,126,13#,KUN125,126,13#,TGN126,128,13#..(ADC,ASC)..CBU VALEO |
1 | ||
| 81551-0K261 |
GGN125,GUN125,126,13#,KUN125,126,13#,TGN126,128,13#..(ADC,ASC)..CBU KOITO |
1 | ||
| 81555 - SOCKET & WIRE SUB-ASSY, REAR COMBINATION LAMP, RH | ||||
| 81555-0K260 |
GGN125,GUN125,126,13#,KUN125,126,13#,TGN126,128,13#..(ADC,ASC)..CBU KOITO |
1 | ||
| 81555-0K300 |
GGN125,GUN125,126,13#,KUN125,126,13#,TGN126,128,13#..(ADC,ASC)..CBU VALEO |
1 | ||
| 81560 - LAMP ASSY, REAR COMBINATION, LH | ||||
| 81560-0K270 |
GUN125,126,13#,TGN126,128,13#..BZAGT..CBU KOITO |
1 | ||
| 81560-0K271 |
GGN125,TGN128,138..ADC;GUN125,126,13#,TGN126,136..BZAGT..CBU KOITO |
1 | ||
| 81560-0K310 |
GGN125,TGN128,138..ADC;GUN125,126,13#,TGN126,136..BZAGT..CBU VALEO |
1 | ||
| 81561D - LENS & BODY, REAR COMBINATION LAMP, LH | ||||
| 81561-0K270 |
GUN125,126,13#,TGN126,128,13#..BZAGT..CBU KOITO |
1 | ||
| 81561-0K310 |
GGN125,TGN128,138..ADC;GUN125,126,13#,TGN126,136..BZAGT..CBU VALEO |
1 | ||
| 81561-0K271 |
GGN125,TGN128,138..ADC;GUN125,126,13#,TGN126,136..BZAGT..CBU KOITO |
1 | ||
| 81565 - SOCKET & WIRE SUB-ASSY, REAR COMBINATION LAMP, LH | ||||
| 81555-0K270 |
GGN125,TGN128,138..ADC;GUN125,126,13#,TGN126,136..BZAGT..CBU KOITO |
1 | ||
| 81565-0K310 |
GGN125,TGN128,138..ADC;GUN125,126,13#,TGN126,136..BZAGT..CBU VALEO |
1 | ||
| Common parts | ||||
| 76817-26040 | ||||
| 90105-T0151 | ||||
(2005- )ARL,BZAG,GCC,GEN,IDN,KEN,LA,MA,MMR,PH,PKN,SA,TH,TWN,VN..CBU
REAR TAIL & STOP LAMP = BLUB TYPE
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| Common parts | ||||
| 76817-26040 | ||||
| 90105-T0151 | ||||
(2005- )AS,KD,KS,MD,MMD,MS,PD,PS,SD,SS,SX,TD,TS,TX..CBU
REAR TAIL & STOP LAMP = LED TYPE
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| Common parts | ||||
| 76817-26040 | ||||
| 90105-T0151 | ||||
