GUN126R-CTFSHQ3 (2015)
Toyota Hilux
(1506- )SXT,TXT
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 58703C - COVER SUB-ASSY, LUGGAGE COMPARTMENT SIDE, RH | ||||
| 58703-0K010C0 |
GUN125,126,136..TXT..ARL BLACK,TRIM2# |
1 | ||
| 58704D - COVER SUB-ASSY, LUGGAGE COMPARTMENT SIDE, LH | ||||
| 58704-0K010C0 |
GUN125,126,136..TXT..ARL BLACK,TRIM2# |
1 | ||
| 58773A - COVER, LUGGAGE COMPARTMENT SIDE, RH | ||||
| 58773-0K020C0 |
GUN126..TXT..6F..IV3;GUN125,126,136..TXT..6FC BLACK,TRIM2# |
1 | ||
| 58773-0K050C0 |
GUN125,126,136..TXT..ARL BLACK,TRIM2# |
1 | ||
| 58773A - COVER, LUGGAGE COMPARTMENT SIDE, RH | ||||
| 58773-0K020C0 |
GUN126..TXT..6F..IV3;GUN125,126,136..TXT..6FC BLACK,TRIM2# |
1 | ||
| 58773-0K050C0 |
GUN125,126,136..TXT..ARL BLACK,TRIM2# |
1 | ||
| 58774A - COVER, LUGGAGE COMPARTMENT SIDE, LH | ||||
| 58774-0K020C0 |
GUN126..TXT..6F..IV3;GUN125,126,136..TXT..6FC BLACK,TRIM2# |
1 | ||
| 58774-0K050C0 |
GUN125,126,136..TXT..ARL BLACK,TRIM2# |
1 | ||
| 58774A - COVER, LUGGAGE COMPARTMENT SIDE, LH | ||||
| 58774-0K020C0 |
GUN126..TXT..6F..IV3;GUN125,126,136..TXT..6FC BLACK,TRIM2# |
1 | ||
| 58774-0K050C0 |
GUN125,126,136..TXT..ARL BLACK,TRIM2# |
1 | ||
| 62111C - BOARD, COWL SIDE TRIM, RH | ||||
| 62111-0K210C0 |
GUN126..TDC..S..LA;KUN122..(H,L,S,X)..GEN;KUN126..TDC..(S,X)..LA;GUN126,136..ARL,MA,TAIW;GUN125..LHD..(L,X)..GEN;KUN125..TXT..(L,M)..GEN;GUN126..RHD..6F..H..GEN;KUN125..TDC..L..(GEN,IDN);GUN125..TDC..6F..S..(LA,PH);GUN125..TDC..(L,X)..(IDN,LA);GUN125..LHD..(TSC,TXT)..(M,X);GUN120,122..TSC..(ARL,GEN,PH,TH);GUN122,KUN122..(TSC,TXT)..M..GEN;GUN122..TDC..(L,S,X)..(ARL,GEN,PH);GUN125,KUN126..RHD..TDC..ATM..(L,X);GUN126,TGN121..(TDC,TSC)..(L,X)..(ARL,GEN,LA,TH);GUN125,KUN125..RHD..(MDC,TSC,TXT)..(ARL,GEN,IDN,MA);GUN135,TGN126,136..(MDC,TDC,TSC)..(L,S,X)..(ARL,GEN,LA,MA,PH);GGN12#,GUN112,123,KUN112,125,135,TGN110..(TDC,TSC,TXT)..(DCR,HTWC)..(ARL,IDN,LA,TH) BLACK,TRIM2# |
1 | ||
| 62112 - BOARD, COWL SIDE TRIM, LH | ||||
| 62112-0K210C0 |
GUN126..TDC..S..LA;KUN122..(H,L,S,X)..GEN;KUN126..TDC..(S,X)..LA;GUN126,136..ARL,MA,TAIW;GUN125..LHD..(L,X)..GEN;KUN125..TXT..(L,M)..GEN;GUN126..RHD..6F..H..GEN;KUN125..TDC..L..(GEN,IDN);GUN125..TDC..6F..S..(LA,PH);GUN125..TDC..(L,X)..(IDN,LA);GUN125..LHD..(TSC,TXT)..(M,X);GUN120,122..TSC..(ARL,GEN,PH,TH);GUN122,KUN122..(TSC,TXT)..M..GEN;GUN122..TDC..(L,S,X)..(ARL,GEN,PH);GUN125,KUN126..RHD..TDC..ATM..(L,X);GUN126,TGN121..(TDC,TSC)..(L,X)..(ARL,GEN,LA,TH);GUN125,KUN125..RHD..(MDC,TSC,TXT)..(ARL,GEN,IDN,MA);GUN135,TGN126,136..(MDC,TDC,TSC)..(L,S,X)..(ARL,GEN,LA,MA,PH);GGN12#,GUN112,123,KUN112,125,135,TGN110..(TDC,TSC,TXT)..(DCR,HTWC)..(ARL,IDN,LA,TH) BLACK,TRIM2# |
1 | ||
| 62117B - CLIP, NO.1(FOR COWL SIDE TRIM) | ||||
| 90467-11089A0 |
GUN136..H,M;TGN121..M,S,X;GUN125..6F..LA;GUN135..SSC..X;TGN121..L..CBU;GUN135..LHD..SA;GUN135..6F..S..SA;GUN125..TDC..X..GEN;GUN125..TDC..6FC..ARL;GUN136..S..(ARL,BZAGT);GUN135..ADC,ASC,MDC,TDC,TSC,TXT;TGN126,136..(ADC,ASC,SDC,TDC,TSC,TXT)..CBU;GUN125..(SXT,TDC)..(H,L,M,S)..(GCC,GEN,IDN,PH,SA,TH,VN);GUN125..(ADC,ASC,SDC,SSC,TSC,TXT)..(ARL,BZAGT,GCC,GEN,IDN,SA,TH);GGN12#,135,GUN112,120,122,123,126,KUN112,12#,13#,LAN125,TGN11#,120,128,138..ADC,ASC,PDC,PSC,SDC,SSC,SXT,TDC,TSC,TXT IVORY |
4 | ||
| 62117C - CLIP, NO.2(FOR COWL SIDE TRIM) | ||||
| 90467-06147 |
GUN136..H,M;TGN121..M,S,X;GUN125..6F..LA;GUN135..SSC..X;TGN121..L..CBU;GUN135..LHD..SA;GUN135..6F..S..SA;GUN125..TDC..X..GEN;GUN125..TDC..6FC..ARL;GUN136..S..(ARL,BZAGT);GUN135..ADC,ASC,MDC,TDC,TSC,TXT;TGN126,136..(ADC,ASC,SDC,TDC,TSC,TXT)..CBU;GUN125..(SXT,TDC)..(H,L,M,S)..(GCC,GEN,IDN,PH,SA,TH,VN);GUN125..(ADC,ASC,SDC,SSC,TSC,TXT)..(ARL,BZAGT,GCC,GEN,IDN,SA,TH);GGN12#,135,GUN112,120,122,123,126,KUN112,12#,13#,LAN125,TGN11#,120,128,138..ADC,ASC,PDC,PSC,SDC,SSC,SXT,TDC,TSC,TXT |
2 | ||
| 62170A - AIR BAG ASSY, CURTAIN SHIELD, RH | ||||
| 62170-0K090 |
GUN123,125,126,136..TXT..ARL |
1 | ||
| 62170B - BOLT, W/WASHER | ||||
| 91673-80616 |
GUN126..6FC..PH;GUN125..ARL..IV3;GUN136..H..BZAGT;GUN125,126..SDC..M;GUN126..6F..H..BZAGT;GGN12#,135,GUN123..ARL,LA,SA;GUN126..6FC..H..(BZAGT,TH,VN);GUN122,13#,TGN121..(S,X)..ARL;GUN125,KUN126..ATM..(ARL,IDN,VN)..CBU;GUN126..(KDC,SXT,TDC,TSC,TXT)..(ARL,KEN,SA,TAIW);GUN136,KUN125,126..(SDC,SXT,TDC)..M..(ARL,IDN,SA) |
4 | ||
| 62180A - AIR BAG ASSY, CURTAIN SHIELD, LH | ||||
| 62180-0K090 |
GUN123,125,126,136..TXT..ARL |
1 | ||
| 62189A - SPACER, CURTAIN SHIELD AIR BAG CLIP | ||||
| 62189-42010 |
GUN126..6FC..PH;GUN125..ARL..IV3;GUN136..H..BZAGT;GUN125,126..SDC..M;GUN126..6F..H..BZAGT;GGN12#,135,GUN123..ARL,LA,SA;GUN126..6FC..H..(BZAGT,TH,VN);GUN122,13#,TGN121..(S,X)..ARL;GUN125,KUN126..ATM..(ARL,IDN,VN)..CBU;GUN126..(KDC,SXT,TDC,TSC,TXT)..(ARL,KEN,SA,TAIW);GUN136,KUN125,126..(SDC,SXT,TDC)..M..(ARL,IDN,SA) |
4 | ||
| 62211 - GARNISH, FRONT PILLAR, RH | ||||
| 62211-0K190B0 |
GUN136..S..ARL;GUN136..6F..M..ARL;GUN126..TDC..S..ARL;GUN126..(TSC,TXT)..ARL;GGN12#,GUN122,123,125,135,TGN121..ARL LT.GRAY,TRIM2# |
1 | ||
| 62211D - CLIP(FOR FRONT BODY PILLAR GARNISH) | ||||
| 90467-T0021 |
GUN136..H,M;TGN121..M,S,X;GUN125..6F..LA;GUN135..SSC..X;TGN121..L..CBU;GUN135..LHD..SA;GUN135..6F..S..SA;GUN125..TDC..X..GEN;GUN125..TDC..6FC..ARL;GUN136..S..(ARL,BZAGT);GUN135..ADC,ASC,MDC,TDC,TSC,TXT;TGN126,136..(ADC,ASC,SDC,TDC,TSC,TXT)..CBU;GUN125..(SXT,TDC)..(H,L,M,S)..(GCC,GEN,IDN,PH,SA,TH,VN);GUN126,TGN128,138..ADC,ASC,PDC,PSC,SDC,SSC,SXT,TDC,TSC,TXT;GUN125..(ADC,ASC,SDC,SSC,TSC,TXT)..(ARL,BZAGT,GCC,GEN,IDN,SA,TH);GGN12#,135,GUN112,120,122,123,KUN112,12#,13#,LAN125,TGN11#,120..ARL,GCC,GEN,IDN,LA,PH,PKN,SA,TH,VN |
2 | ||
| 62211T - CLIP(FOR FRONT PILLAR GARNISH) | ||||
| 90467-T0021 |
KUN122;GUN136..S..ARL;TGN121..L..CBU;GUN126..6FC..PH;GUN125,126..SDC..M;KUN126..PSC,SDC,SXT;GUN126..6F..H..BZAGT;GUN135..RHD..(SSC,TDC,TSC)..X;GUN126..6FC..H..(BZAGT,TH,VN);TGN121..(SSC,TDC,TSC)..(M,S,X);GGN12#,135,GUN120,123..ARL,LA,SA,TH;GUN125,KUN126..TDC..ATM..(ARL,IDN,VN);GUN136,KUN125..(SDC,SXT,TDC)..M..(ARL,IDN,SA);GUN112,122,KUN112,TGN11#,120..PSC,SSC,TDC,TSC,TXT;GUN125,136,LAN125..(ADC,SSC,TSC,TXT)..(H,X)..(ARL,BZAGT,SA);GUN125,126,KUN125..(PSC,SXT,TDC,TSC,TXT)..(L,M,S)..(ARL,PKN,SA,TAIW) |
2 | ||
| 62212 - GARNISH, FRONT PILLAR, LH | ||||
| 62212-0K190B0 |
GUN136..S..ARL;GUN136..6F..M..ARL;GUN126..TDC..S..ARL;GUN126..(TSC,TXT)..ARL;GGN12#,GUN122,123,125,135,TGN121..ARL LT.GRAY,TRIM2# |
1 | ||
| 62311B - WEATHERSTRIP, FRONT DOOR OPENING TRIM, RH | ||||
| 62311-0K130 |
GUN12#,13#,KUN122,125,TGN121,136..TXT |
1 | ||
| 62312B - WEATHERSTRIP, FRONT DOOR OPENING TRIM, LH | ||||
| 62312-0K130 |
GUN12#,13#,KUN122,125,TGN121,136..TXT |
1 | ||
| 62431C - GARNISH, ROOF SIDE RAIL, FRONT RH | ||||
| 62431-0K020B0 |
GUN125,KUN125..TXT..(L,M,X);GUN122,123,126,136,KUN122..TXT..(ARL,GEN) LT.GRAY,TRIM2# |
1 | ||
| 62432C - GARNISH, ROOF SIDE RAIL, FRONT LH | ||||
| 62432-0K020B0 |
GUN125,KUN125..TXT..(L,M,X);GUN122,123,126,136,KUN122..TXT..(ARL,GEN) LT.GRAY,TRIM2# |
1 | ||
| 62510K - CLIP(FOR QUARTER TRIM FRONT PANEL) | ||||
| 90467-10188 |
GUN136..H,M;TGN121..M,S,X;GUN125..6F..LA;GUN135..SSC..X;TGN121..L..CBU;GUN135..LHD..SA;GUN125..TDC..6FC..ARL;GUN136..S..(ARL,BZAGT);GUN135..(SDC,SSC)..6F..S;GUN135..ADC,ASC,MDC,SXT,TDC,TSC,TXT;GUN125..TDC..(GCC,GEN,IDN,PH,TH,VN);TGN126,136..(ADC,ASC,SDC,TDC,TSC,TXT)..CBU;GUN126,TGN128,138..ADC,ASC,PDC,PSC,SDC,SSC,SXT,TDC,TSC,TXT;GUN125..(ADC,ASC,SDC,SSC,SXT,TSC,TXT)..(ARL,BZAGT,GCC,GEN,IDN,SA,TH);GGN12#,135,GUN112,120,122,123,KUN112,12#,13#,LAN125,TGN11#,120..ARL,GCC,GEN,IDN,LA,PH,PKN,SA,TH,VN |
2 | ||
| 62511 - BOARD, QUARTER INSIDE TRIM, RH | ||||
| 62511-0K330B0 |
GUN123,125,126,136..TXT..ARL LT.GRAY,TRIM2# |
1 | ||
| 62511B - CLIP (FOR QUARTER INSIDE TRIM BOARD) | ||||
| 90467-T0021 |
GUN136..H,M;TGN121..M,S,X;GUN125..6F..LA;GUN135..SSC..X;TGN121..L..CBU;GUN135..LHD..SA;GUN125..TDC..6FC..ARL;GUN136..S..(ARL,BZAGT);GUN135..(SDC,SSC)..6F..S;GUN135..ADC,ASC,MDC,SXT,TDC,TSC,TXT;GUN125..TDC..(GCC,GEN,IDN,PH,TH,VN);TGN126,136..(ADC,ASC,SDC,TDC,TSC,TXT)..CBU;GUN126,TGN128,138..ADC,ASC,PDC,PSC,SDC,SSC,SXT,TDC,TSC,TXT;GUN125..(ADC,ASC,SDC,SSC,SXT,TSC,TXT)..(ARL,BZAGT,GCC,GEN,IDN,SA,TH);GGN12#,135,GUN112,120,122,123,KUN112,12#,13#,LAN125,TGN11#,120..ARL,GCC,GEN,IDN,LA,PH,PKN,SA,TH,VN |
4 | ||
| 62511G - CLIP (FOR QUARTER INSIDE TRIM BOARD) | ||||
| 90467-T0021 |
GUN135..LHD..SA;GUN135..SDC..6F..S;GGN12#..ARL,GCC,LA,SA;GUN125..TDC..6FC..ARL;GUN125..(ADC,TDC)..6F..LA;GUN135..ADC,MDC,SXT,TDC,TXT;GUN136..S..(ARL,BZAGT)..CBU;GUN125..TDC..(GCC,GEN,IDN,PH,TH,VN);GUN136..(ADC,SDC,SXT,TDC,TXT)..(H,M);GUN125..(ADC,SDC,SXT,TXT)..(ARL,BZAGT,GEN,IDN,SA,TH);GGN135,GUN120,122,123,126,KUN12#,13#,LAN125,TGN120,121,126,128,13#..ADC,PDC,SDC,SXT,TDC,TXT |
4 | ||
| 62512 - BOARD, QUARTER INSIDE TRIM, LH | ||||
| 62512-0K330B0 |
GUN123,125,126,136..TXT..ARL LT.GRAY,TRIM2# |
1 | ||
| 62513A - PANEL, QUARTER TRIM, LOWER RH | ||||
| 62513-0K250C0 |
GUN123,125,126,136..TXT..ARL BLACK,TRIM2# |
1 | ||
| 62514A - PANEL, QUARTER TRIM, LOWER LH | ||||
| 62514-0K250C0 |
GUN123,125,126,136..TXT..ARL BLACK,TRIM2# |
1 | ||
| 64271C - TRIM, BACK PANEL | ||||
| 64271-0K110C0 |
GUN123,125,126,136..TXT..ARL BLACK,TRIM2# |
1 | ||
| 64271-0K440C0 |
GUN125,126,136..TXT..ARL BLACK,TRIM2# |
1 | ||
| 64271D - CLIP(FOR BACK PANEL TRIM) | ||||
| 90467-10188 |
GUN126..TXT..6F..IV3;GUN125,126,136..TXT..6FC NO.1 |
7 | ||
| 90467-T0021 |
GUN126..TXT..6F..IV3;GUN125,126,136..TXT..6FC NO.2 |
8 | ||
| 64271D - CLIP(FOR BACK PANEL TRIM) | ||||
| 90467-10188 |
GUN126..TXT..6F..IV3;GUN125,126,136..TXT..6FC NO.1 |
7 | ||
| 90467-T0021 |
GUN126..TXT..6F..IV3;GUN125,126,136..TXT..6FC NO.2 |
8 | ||
| 67913B - PLATE, FRONT DOOR SCUFF, RH | ||||
| 67913-0K140C0 |
GUN125,KUN125..TXT..(L,M,X);GUN122,123,126,136,KUN122..TXT..(ARL,GEN) BLACK,TRIM2# |
1 | ||
| 67914B - PLATE, FRONT DOOR SCUFF, LH | ||||
| 67914-0K140C0 |
GUN125,KUN125..TXT..(L,M,X);GUN122,123,126,136,KUN122..TXT..(ARL,GEN) BLACK,TRIM2# |
1 | ||
| Common parts | ||||
| 90167-T0028 | ||||
| 90189-05141 | ||||
| 90467-18017 | ||||
| 90467-T0021 | ||||
| 93560-55018 | ||||
| 93567-55020 | ||||
