GUN126L-DGTSJG (2015)
Toyota Hilux
(1511- )ADC,ASC,VDC
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 04474 - CYLINDER KIT, REAR WHEEL | ||||
| 04474-0K010 |
GGN125,GUN125,126,13#,KUN125,126,13#,TGN126,128,13#..ADC,ASC |
2 | ||
| 04495 - SHOE KIT, REAR BRAKE | ||||
| 04495-0K050 |
GGN125,GUN125,126,13#,KUN125,126,13#,TGN126,128,13#..ADC,ASC MARK NSA LN508 |
1 | ||
| 04906 - CUP KIT, REAR WHEEL CYLINDER | ||||
| 04906-0K060 |
GGN125,GUN125,126,13#,KUN125,126,13#,TGN126,128,13#..ADC,ASC |
1 | ||
| 04941 - SPRING KIT, REAR BRAKE SHOE HOLD DOWN | ||||
| 04941-0K060 |
GGN125,GUN125,126,13#,KUN125,126,13#,TGN126,128,13#..ADC,ASC |
1 | ||
| 04942 - SPRING KIT, REAR BRAKE | ||||
| 04942-0K160 |
GGN125,GUN125,126,13#,KUN125,126,13#,TGN126,128,13#..ADC,ASC |
1 | ||
| 04943A - STRUT KIT, REAR BRAKE | ||||
| 04943-0K040 |
GGN125,GUN125,126,13#,KUN125,126,13#,TGN126,128,13#..ADC,ASC |
1 | ||
| 04949 - PLUG KIT, REAR BRAKE | ||||
| 04949-0K070 |
GGN125,GUN125,126,13#,KUN125,126,13#,TGN126,128,13#..ADC,ASC |
1 | ||
| 47043 - PLATE SUB-ASSY, BRAKE BACKING, REAR RH | ||||
| 47043-0K140 |
GGN125,GUN125,126,13#,KUN125,126,13#,TGN126,128,13#..ADC,ASC |
1 | ||
| 47043C - BOLT(FOR BACKING PLATE TO REAR AXLE HOUSING SETTING) | ||||
| 90114-T0011 |
KUN126..PDC..L;TGN136..ADC,ASC,SDC,TDC,TSC,TXT;GUN125..ADC,ASC,SDC,SSC,SXT,TSC,TXT;GUN125..TDC..(GCC,GEN,IDN,LA,PH,TH,VN);GUN125,KUN126..(PDC,TDC)..ATM..(ARL,PKN);GGN12#,135,GUN112,120,135,KUN126..ADC,ASC,MDC,PSC,SDC,SSC,SXT,TDC,TSC,TXT;GUN122,123,126,136,KUN112,122,125,13#,LAN125,TGN11#,120,121,126,128,138..ADC,ASC,PDC,PSC,SDC,SSC,SXT,TDC,TSC,TXT *10-1.25PX54.5-30 |
8 | ||
| 47043F - NUT(FOR BACKING PLATE TO REAR AXLE HOUSING SETTING) | ||||
| 90178-T0077 |
KUN126..PDC..L;TGN136..ADC,ASC,SDC,TDC,TSC,TXT;GUN125..ADC,ASC,SDC,SSC,SXT,TSC,TXT;GUN125..TDC..(GCC,GEN,IDN,LA,PH,TH,VN);GUN125,KUN126..(PDC,TDC)..ATM..(ARL,PKN);GGN12#,135,GUN112,120,135,KUN126..ADC,ASC,MDC,PSC,SDC,SSC,SXT,TDC,TSC,TXT;GUN122,123,126,136,KUN112,122,125,13#,LAN125,TGN11#,120,121,126,128,138..ADC,ASC,PDC,PSC,SDC,SSC,SXT,TDC,TSC,TXT |
8 | ||
| 47044 - PLATE SUB-ASSY, BRAKE BACKING, REAR LH | ||||
| 47044-0K140 |
GGN125,GUN125,126,13#,KUN125,126,13#,TGN126,128,13#..ADC,ASC |
1 | ||
| 47547R - PLUG, BLEEDER(FOR DRUM BRAKE, REAR) | ||||
| 90069-0K072 |
GGN125,GUN125,126,13#,KUN125,126,13#,TGN126,128,13#..ADC,ASC |
2 | ||
| 47548R - CAP, BLEEDER PLUG(FOR DRUM BRAKE, REAR) | ||||
| 31478-0K030 |
GUN135..6F..H;GUN125..TDC..6FC..ARL;GUN125..ADC,ASC,TSC,TXT;GUN135..(MDC,TDC,TXT)..6FC;GUN135..6F..(ARL,BZAGT,LA,PH,TH,VN);GUN125..TDC..(GCC,GEN,IDN,LA,PH,TH,VN);GGN125,GUN126,136,KUN125,126,13#,TGN126,128,13#..ADC,ASC,PDC,PSC,TDC,TSC,TXT |
2 | ||
| 47550 - CYLINDER ASSY, REAR WHEEL BRAKE(FOR RH, FRONT OR UPPER) | ||||
| 47550-09080 |
GGN125,GUN125,126,13#,KUN125,126,13#,TGN126,128,13#..ADC,ASC |
1 | ||
| 47550C - SPRING, COMPRESSION(FOR REAR WHEEL BRAKE CYLINDER) | ||||
| 90069-51002 |
GGN125,GUN125,126,13#,KUN125,126,13#,TGN126,128,13#..ADC,ASC |
2 | ||
| 47570 - CYLINDER ASSY, REAR WHEEL BRAKE(FOR LH, FRONT OR UPPER) | ||||
| 47550-09080 |
GGN125,GUN125,126,13#,KUN125,126,13#,TGN126,128,13#..ADC,ASC |
1 | ||
| 47601 - LEVER SUB-ASSY, PARKING BRAKE SHOE, RH(FOR REAR BRAKE) | ||||
| 47611-0K070 |
GGN125,GUN125,126,13#,KUN125,126,13#,TGN126,128,13#..ADC,ASC |
1 | ||
| 47601C - WASHER, C(FOR REAR BRAKE) | ||||
| 90069-52023 |
GGN125,GUN125,126,13#,KUN125,126,13#,TGN126,128,13#..ADC,ASC |
2 | ||
| 47602 - LEVER SUB-ASSY, PARKING BRAKE SHOE, LH (FOR REAR BRAKE) | ||||
| 47612-0K070 |
GGN125,GUN125,126,13#,KUN125,126,13#,TGN126,128,13#..ADC,ASC |
1 | ||
| Common parts | ||||
| 90069-31011 | ||||
(2005- )GGN125,GUN125,126,13#,TGN126,136..MD,MMD,MS,PD,PS,TD,TS,TX
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| Common parts | ||||
| 90016-AA602 | ||||
(2005- )AD,AS
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| Common parts | ||||
| 90069-31011 | ||||
