AXUH78L-ARXGHV (2020)

Toyota Highlander/Kluger

Production Feb 2020 - Sep 9999
Engine A25AFXS
Transmission CVT
Displacement 2500cc
Power 168 HP (125 kW)

(2002- )LHD..LIMD

Click highlighted areas on diagram

HEAD-UP DISPLAY

diagram 83108 83163 83847 9008011699 9008011699 9009900262
Part # Description Qty Price
83108 - MIRROR SUB-ASSY, METER
83108-0E040

AXUH7#,GSU75..LIMD

 1
83108-0E110

AXUH7#,GSU75..LIMD..(GCC,RUS)

 1
83163 - PLATE, COMBINATION METER MIRROR, NO.1
83163-0E040

AXUH7#,GSU75..LIMD..(GCC,RUS)

 1
83847 - CUSHION, COMBINATION SPEEDOMETER, NO.1
83847-0E040

AXUH7#,GSU7#..LIMD..(ARL,GCC,RUS)

 1
Common parts
90080-11699
90099-00262

(2002- )

Click highlighted areas on diagram

METER

diagram 83100 83100 83138G 83138G 9008015073 9008015073 9008015073 9008015073
Part # Description Qty Price
83100 - METER ASSY, COMBINATION
83800-0ED70

AXUH7#..LIMD

DENSO

 1
83800-0EQ00

AXUH7#..LIMD..GCC

DENSO

 1
83100 - METER ASSY, COMBINATION
83800-0ED70

AXUH7#..LIMD

DENSO

 1
83800-0EQ00

AXUH7#..LIMD..GCC

DENSO

 1
83138G - GLASS, COMBINATION METER
83852-0EC20

AXUH7#..LIMD..GCC;AXUH78..(LIMD,XLE)..(ARL,EUR)

 1
83138G - GLASS, COMBINATION METER
83852-0EC20

AXUH7#..LIMD..GCC;AXUH78..(LIMD,XLE)..(ARL,EUR)

 1
Common parts
90080-15073
