TRH223R-LETDKQ (2015)
Toyota Hiace
(1501- )2TRFE..TRH201,22#..6FC..ARL
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 15600A - UNION(FOR OIL FILTER) | ||||
| 90404-19022 |
2TRFE..TRH201,22#..ARL LPG CONVERSION PACKAGE |
1 | ||
| 90404-19022 |
2TRFE..TRH201,22#..ARL LPG CONVERSION PACKAGE |
1 | ||
| 90404-19022 |
2TRFE..TRH201,22#..ARL LPG CONVERSION PACKAGE |
1 | ||
| 15601 - FILTER SUB-ASSY, OIL | ||||
| 90915-20003 |
2TRFE..TRH201,22#..ARL LPG CONVERSION PACKAGE |
1 | ||
| 90915-20003 |
2TRFE..TRH201,22#..ARL LPG CONVERSION PACKAGE |
1 | ||
| 90915-20003 |
2TRFE..TRH201,22#..ARL LPG CONVERSION PACKAGE |
1 | ||
| 15609 - BRACKET SUB-ASSY, OIL FILTER | ||||
| 15609-75100 |
2TRFE..TRH201,22#..ARL LPG CONVERSION PACKAGE |
1 | ||
| 15609-75100 |
2TRFE..TRH201,22#..ARL LPG CONVERSION PACKAGE |
1 | ||
| 15609-75100 |
2TRFE..TRH201,22#..ARL LPG CONVERSION PACKAGE |
1 | ||
| 15609-75100 |
2TRFE..TRH201,22#..(02S,05S,06S,12S,14S)..(ARL,GEN,RUS) |
1 | ||
| 15609-75100 |
2TRFE..TRH201,22#..(02S,05S,06S,12S,14S)..(ARL,GEN,RUS) |
1 | ||
| 15609-75100 |
2TRFE..TRH201,22#..(02S,05S,06S,12S,14S)..(ARL,GEN,RUS) |
1 | ||
| 15609-75070 |
2TRFE..TRH201,22#..ARL LPG CONVERSION PACKAGE |
1 | ||
| 15609-75070 |
2TRFE..TRH201,22#..ARL LPG CONVERSION PACKAGE |
1 | ||
| 15609-75070 |
2TRFE..TRH201,22#..ARL LPG CONVERSION PACKAGE |
1 | ||
| 15609B - UNION(FOR OIL FILTER BRACKET) | ||||
| 90404-19017 |
2TRFE..TRH201;2TRFE..TRH221..GCC;2TRFE..TRH203..15S..5F;2TRFE..TRH223..4FC..GL;2TRFE..TRH213..LHD..GEN;2TRFE..TRH223..LHD..STD..GEN;2TRFE..TRH223..STD..(ARL,SA,TH);2TRFE..TRH223..5F..GL..(GCC,RUS);2TRFE..TRH213,221..(02S,06S,11S,16S)..(ARL,GCC,SA,TH) |
1 | ||
| 90404-19017 |
2TRFE..TRH201;2TRFE..TRH221..GCC;2TRFE..TRH203..15S..5F;2TRFE..TRH223..4FC..GL;2TRFE..TRH213..LHD..GEN;2TRFE..TRH223..LHD..STD..GEN;2TRFE..TRH223..STD..(ARL,SA,TH);2TRFE..TRH223..5F..GL..(GCC,RUS);2TRFE..TRH213,221..(02S,06S,11S,16S)..(ARL,GCC,SA,TH) |
1 | ||
| 90404-19017 |
2TRFE..TRH201;2TRFE..TRH221..GCC;2TRFE..TRH203..15S..5F;2TRFE..TRH223..4FC..GL;2TRFE..TRH213..LHD..GEN;2TRFE..TRH223..LHD..STD..GEN;2TRFE..TRH223..STD..(ARL,SA,TH);2TRFE..TRH223..5F..GL..(GCC,RUS);2TRFE..TRH213,221..(02S,06S,11S,16S)..(ARL,GCC,SA,TH) |
1 | ||
| 15609D - PLUG, W/HEAD STRAIGHT SCREW(FOR OIL FILTER BRACKET) | ||||
| 90341-22002 |
2TRFE..TRH201;2TRFE..TRH203..5F;2TRFE..TRH221..GCC;2TRFE..TRH223..4FC..GL;2TRFE..TRH213..LHD..GEN;2TRFE..TRH223..LHD..STD..GEN;2TRFE..TRH223..STD..(ARL,SA,TH);2TRFE..TRH223..5F..GL..(GCC,RUS);2TRFE..TRH213,221..(02S,06S,11S,16S)..(ARL,GCC,SA,TH) |
2 | ||
| 90341-22002 |
2TRFE..TRH201;2TRFE..TRH203..5F;2TRFE..TRH221..GCC;2TRFE..TRH223..4FC..GL;2TRFE..TRH213..LHD..GEN;2TRFE..TRH223..LHD..STD..GEN;2TRFE..TRH223..STD..(ARL,SA,TH);2TRFE..TRH223..5F..GL..(GCC,RUS);2TRFE..TRH213,221..(02S,06S,11S,16S)..(ARL,GCC,SA,TH) |
2 | ||
| 90341-22002 |
2TRFE..TRH201;2TRFE..TRH203..5F;2TRFE..TRH221..GCC;2TRFE..TRH223..4FC..GL;2TRFE..TRH213..LHD..GEN;2TRFE..TRH223..LHD..STD..GEN;2TRFE..TRH223..STD..(ARL,SA,TH);2TRFE..TRH223..5F..GL..(GCC,RUS);2TRFE..TRH213,221..(02S,06S,11S,16S)..(ARL,GCC,SA,TH) |
2 | ||
| 15609D - PLUG, W/HEAD STRAIGHT SCREW(FOR OIL FILTER BRACKET) | ||||
| 90341-22002 |
2TRFE..TRH201;2TRFE..TRH203..5F;2TRFE..TRH221..GCC;2TRFE..TRH223..4FC..GL;2TRFE..TRH213..LHD..GEN;2TRFE..TRH223..LHD..STD..GEN;2TRFE..TRH223..STD..(ARL,SA,TH);2TRFE..TRH223..5F..GL..(GCC,RUS);2TRFE..TRH213,221..(02S,06S,11S,16S)..(ARL,GCC,SA,TH) |
2 | ||
| 90341-22002 |
2TRFE..TRH201;2TRFE..TRH203..5F;2TRFE..TRH221..GCC;2TRFE..TRH223..4FC..GL;2TRFE..TRH213..LHD..GEN;2TRFE..TRH223..LHD..STD..GEN;2TRFE..TRH223..STD..(ARL,SA,TH);2TRFE..TRH223..5F..GL..(GCC,RUS);2TRFE..TRH213,221..(02S,06S,11S,16S)..(ARL,GCC,SA,TH) |
2 | ||
| 90341-22002 |
2TRFE..TRH201;2TRFE..TRH203..5F;2TRFE..TRH221..GCC;2TRFE..TRH223..4FC..GL;2TRFE..TRH213..LHD..GEN;2TRFE..TRH223..LHD..STD..GEN;2TRFE..TRH223..STD..(ARL,SA,TH);2TRFE..TRH223..5F..GL..(GCC,RUS);2TRFE..TRH213,221..(02S,06S,11S,16S)..(ARL,GCC,SA,TH) |
2 | ||
| 15609E - GASKET, W/HEAD STRAIGHT SCREW PLUG | ||||
| 90430-22011 |
2TRFE..TRH201;2TRFE..TRH203..5F;2TRFE..TRH221..GCC;2TRFE..TRH223..4FC..GL;2TRFE..TRH213..LHD..GEN;2TRFE..TRH223..LHD..STD..GEN;2TRFE..TRH223..STD..(ARL,SA,TH);2TRFE..TRH223..5F..GL..(GCC,RUS);2TRFE..TRH213,221..(02S,06S,11S,16S)..(ARL,GCC,SA,TH) |
2 | ||
| 90430-22011 |
2TRFE..TRH201;2TRFE..TRH203..5F;2TRFE..TRH221..GCC;2TRFE..TRH223..4FC..GL;2TRFE..TRH213..LHD..GEN;2TRFE..TRH223..LHD..STD..GEN;2TRFE..TRH223..STD..(ARL,SA,TH);2TRFE..TRH223..5F..GL..(GCC,RUS);2TRFE..TRH213,221..(02S,06S,11S,16S)..(ARL,GCC,SA,TH) |
2 | ||
| 90430-22011 |
2TRFE..TRH201;2TRFE..TRH203..5F;2TRFE..TRH221..GCC;2TRFE..TRH223..4FC..GL;2TRFE..TRH213..LHD..GEN;2TRFE..TRH223..LHD..STD..GEN;2TRFE..TRH223..STD..(ARL,SA,TH);2TRFE..TRH223..5F..GL..(GCC,RUS);2TRFE..TRH213,221..(02S,06S,11S,16S)..(ARL,GCC,SA,TH) |
2 | ||
| 15609E - GASKET, W/HEAD STRAIGHT SCREW PLUG | ||||
| 90430-22011 |
2TRFE..TRH201;2TRFE..TRH203..5F;2TRFE..TRH221..GCC;2TRFE..TRH223..4FC..GL;2TRFE..TRH213..LHD..GEN;2TRFE..TRH223..LHD..STD..GEN;2TRFE..TRH223..STD..(ARL,SA,TH);2TRFE..TRH223..5F..GL..(GCC,RUS);2TRFE..TRH213,221..(02S,06S,11S,16S)..(ARL,GCC,SA,TH) |
2 | ||
| 90430-22011 |
2TRFE..TRH201;2TRFE..TRH203..5F;2TRFE..TRH221..GCC;2TRFE..TRH223..4FC..GL;2TRFE..TRH213..LHD..GEN;2TRFE..TRH223..LHD..STD..GEN;2TRFE..TRH223..STD..(ARL,SA,TH);2TRFE..TRH223..5F..GL..(GCC,RUS);2TRFE..TRH213,221..(02S,06S,11S,16S)..(ARL,GCC,SA,TH) |
2 | ||
| 90430-22011 |
2TRFE..TRH201;2TRFE..TRH203..5F;2TRFE..TRH221..GCC;2TRFE..TRH223..4FC..GL;2TRFE..TRH213..LHD..GEN;2TRFE..TRH223..LHD..STD..GEN;2TRFE..TRH223..STD..(ARL,SA,TH);2TRFE..TRH223..5F..GL..(GCC,RUS);2TRFE..TRH213,221..(02S,06S,11S,16S)..(ARL,GCC,SA,TH) |
2 | ||
| 15692 - GASKET, OIL FILTER BRACKET | ||||
| 15692-75011 |
2TRFE..TRH201;2TRFE..TRH221..GCC;2TRFE..TRH203..15S..5F;2TRFE..TRH223..4FC..GL;2TRFE..TRH213..LHD..GEN;2TRFE..TRH223..LHD..STD..GEN;2TRFE..TRH223..STD..(ARL,SA,TH);2TRFE..TRH223..5F..GL..(GCC,RUS);2TRFE..TRH213,221..(02S,06S,11S,16S)..(ARL,GCC,SA,TH) |
1 | ||
| 15692-75011 |
2TRFE..TRH201;2TRFE..TRH221..GCC;2TRFE..TRH203..15S..5F;2TRFE..TRH223..4FC..GL;2TRFE..TRH213..LHD..GEN;2TRFE..TRH223..LHD..STD..GEN;2TRFE..TRH223..STD..(ARL,SA,TH);2TRFE..TRH223..5F..GL..(GCC,RUS);2TRFE..TRH213,221..(02S,06S,11S,16S)..(ARL,GCC,SA,TH) |
1 | ||
| 15692-75011 |
2TRFE..TRH201;2TRFE..TRH221..GCC;2TRFE..TRH203..15S..5F;2TRFE..TRH223..4FC..GL;2TRFE..TRH213..LHD..GEN;2TRFE..TRH223..LHD..STD..GEN;2TRFE..TRH223..STD..(ARL,SA,TH);2TRFE..TRH223..5F..GL..(GCC,RUS);2TRFE..TRH213,221..(02S,06S,11S,16S)..(ARL,GCC,SA,TH) |
1 | ||
| Common parts | ||||
| 90126-08054 | ||||
| 90126-T0011 | ||||
| 90178-T0019 | ||||
| 90301-17017 | ||||
| 90301-T0028 | ||||
| 91551-80845 | ||||
| 91551-80875 | ||||
| 94151-80800 | ||||
| Linked diagrams | ||||
| 1105 | ||||
(1501- )2TRFE..TRH201,22#..02S,05S,06S,12S,14S..ARL,GEN,RUS
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 04152 - ELEMENT KIT, OIL FILTER | ||||
| 04152-38010 |
1TRFE..TRH200;2TRFE..TRH201,22#..6FC |
1 | ||
| 04152-38010 |
2TRFE..TRH201,22#..ARL LPG CONVERSION PACKAGE |
1 | ||
| 15609 - BRACKET SUB-ASSY, OIL FILTER | ||||
| 15609-75100 |
2TRFE..TRH201,22#..ARL LPG CONVERSION PACKAGE |
1 | ||
| 15609-75100 |
2TRFE..TRH201,22#..(02S,05S,06S,12S,14S)..(ARL,GEN,RUS) |
1 | ||
| 15609-75070 |
2TRFE..TRH201,22#..ARL LPG CONVERSION PACKAGE |
1 | ||
| 15609B - UNION(FOR OIL FILTER BRACKET) | ||||
| 90404-19017 |
2TRFE..TRH201;2TRFE..TRH221..GCC;2TRFE..TRH203..15S..5F;2TRFE..TRH223..4FC..GL;2TRFE..TRH213..LHD..GEN;2TRFE..TRH223..LHD..STD..GEN;2TRFE..TRH223..STD..(ARL,SA,TH);2TRFE..TRH223..5F..GL..(GCC,RUS);2TRFE..TRH213,221..(02S,06S,11S,16S)..(ARL,GCC,SA,TH) |
1 | ||
| 15609D - PLUG, W/HEAD STRAIGHT SCREW(FOR OIL FILTER BRACKET) | ||||
| 90341-22002 |
2TRFE..TRH201;2TRFE..TRH203..5F;2TRFE..TRH221..GCC;2TRFE..TRH223..4FC..GL;2TRFE..TRH213..LHD..GEN;2TRFE..TRH223..LHD..STD..GEN;2TRFE..TRH223..STD..(ARL,SA,TH);2TRFE..TRH223..5F..GL..(GCC,RUS);2TRFE..TRH213,221..(02S,06S,11S,16S)..(ARL,GCC,SA,TH) |
2 | ||
| 15609D - PLUG, W/HEAD STRAIGHT SCREW(FOR OIL FILTER BRACKET) | ||||
| 90341-22002 |
2TRFE..TRH201;2TRFE..TRH203..5F;2TRFE..TRH221..GCC;2TRFE..TRH223..4FC..GL;2TRFE..TRH213..LHD..GEN;2TRFE..TRH223..LHD..STD..GEN;2TRFE..TRH223..STD..(ARL,SA,TH);2TRFE..TRH223..5F..GL..(GCC,RUS);2TRFE..TRH213,221..(02S,06S,11S,16S)..(ARL,GCC,SA,TH) |
2 | ||
| 15609E - GASKET, W/HEAD STRAIGHT SCREW PLUG | ||||
| 90430-22011 |
2TRFE..TRH201;2TRFE..TRH203..5F;2TRFE..TRH221..GCC;2TRFE..TRH223..4FC..GL;2TRFE..TRH213..LHD..GEN;2TRFE..TRH223..LHD..STD..GEN;2TRFE..TRH223..STD..(ARL,SA,TH);2TRFE..TRH223..5F..GL..(GCC,RUS);2TRFE..TRH213,221..(02S,06S,11S,16S)..(ARL,GCC,SA,TH) |
2 | ||
| 15609E - GASKET, W/HEAD STRAIGHT SCREW PLUG | ||||
| 90430-22011 |
2TRFE..TRH201;2TRFE..TRH203..5F;2TRFE..TRH221..GCC;2TRFE..TRH223..4FC..GL;2TRFE..TRH213..LHD..GEN;2TRFE..TRH223..LHD..STD..GEN;2TRFE..TRH223..STD..(ARL,SA,TH);2TRFE..TRH223..5F..GL..(GCC,RUS);2TRFE..TRH213,221..(02S,06S,11S,16S)..(ARL,GCC,SA,TH) |
2 | ||
| 15620 - CAP ASSY, OIL FILTER | ||||
| 15620-31050 |
2TRFE..TRH201,22#..ARL LPG CONVERSION PACKAGE |
1 | ||
| 15620-31050 |
1TRFE..TRH200;2TRFE..TRH201,22#..6FC |
1 | ||
| 15620C - GASKET(FOR OIL FILTER CAP) | ||||
| 90301-79006 |
1TRFE..TRH200;2TRFE..TRH201,22#..6FC |
1 | ||
| 90301-79006 |
2TRFE..TRH201,22#..ARL LPG CONVERSION PACKAGE |
1 | ||
| 15643 - PLUG, OIL FILTER DRAIN | ||||
| 15643-31050 |
1TRFE..TRH200;2TRFE..TRH201,22#..6FC |
1 | ||
| 15643-31050 |
2TRFE..TRH201,22#..ARL LPG CONVERSION PACKAGE |
1 | ||
| 15643A - RING, O(FOR OIL FILTER DRAIN PLUG) | ||||
| 96723-35028 |
2TRFE..TRH201,22#..ARL LPG CONVERSION PACKAGE |
1 | ||
| 96723-35028 |
1TRFE..TRH200;2TRFE..TRH201,22#..6FC |
1 | ||
| 15692 - GASKET, OIL FILTER BRACKET | ||||
| 15692-75011 |
2TRFE..TRH201;2TRFE..TRH221..GCC;2TRFE..TRH203..15S..5F;2TRFE..TRH223..4FC..GL;2TRFE..TRH213..LHD..GEN;2TRFE..TRH223..LHD..STD..GEN;2TRFE..TRH223..STD..(ARL,SA,TH);2TRFE..TRH223..5F..GL..(GCC,RUS);2TRFE..TRH213,221..(02S,06S,11S,16S)..(ARL,GCC,SA,TH) |
1 | ||
| Common parts | ||||
| 90105-T0126 | ||||
| 90105-T0253 | ||||
| 90126-08054 | ||||
| 90301-17017 | ||||
| 91551-80845 | ||||
| 94151-80800 | ||||
| Linked diagrams | ||||
| 1105 | ||||
