TRH223R-LEMDKN (2007)
Toyota Hiace
(1204- )KDH222,TRH223..STD..SA
SOUTH AFRICA SPEC
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 04474 - CYLINDER KIT, REAR WHEEL | ||||
| 04474-35100 |
KDH222,TRH223..STD..SA CKD PACKAGE(SOUTH AFRICA) |
2 | ||
| 04474-35100 |
KDH222,223,LH222,TRH223..5F..(GEN,SA,TH) |
2 | ||
| 04474-26070 |
KDH222,LH222,TRH223..5F..(GEN,SA,TH) |
2 | ||
| 04495 - SHOE KIT, REAR BRAKE | ||||
| 04495-26240 |
KDH222,LH222,TRH223..5F..(GEN,SA,TH) MARK NBK D9033 |
1 | ||
| 04495-35230 |
KDH222,223,LH222,TRH223..5F..(GEN,SA,TH) MARK NBK LN508 |
1 | ||
| 04495-35230 |
KDH222,TRH223..STD..SA MARK NBK LN508,CKD PACKAGE(SOUTH AFRICA) |
1 | ||
| 04906 - CUP KIT, REAR WHEEL CYLINDER | ||||
| 04906-35130 |
KDH222,TRH223..STD..SA CKD PACKAGE(SOUTH AFRICA) |
1 | ||
| 04906-26080 |
KDH222,LH222,TRH223..5F..(GEN,SA,TH) |
1 | ||
| 04906-35130 |
KDH222,223,LH222,TRH223..5F..(GEN,SA,TH) |
1 | ||
| 04941 - SPRING KIT, REAR BRAKE SHOE HOLD DOWN | ||||
| 04941-26010 |
KDH222,LH222,TRH223..5F..(GEN,SA,TH) |
1 | ||
| 04941-25040 |
KDH222,TRH223..STD..SA CKD PACKAGE(SOUTH AFRICA) |
1 | ||
| 04941-25040 |
KDH222,223,LH222,TRH223..5F..(GEN,SA,TH) |
1 | ||
| 04942 - SPRING KIT, REAR BRAKE | ||||
| 04942-26010 |
KDH222,LH222,TRH223..5F..(GEN,SA,TH) |
1 | ||
| 04942-25070 |
KDH222,TRH223..STD..SA CKD PACKAGE(SOUTH AFRICA) |
1 | ||
| 04942-25070 |
KDH222,223,LH222,TRH223..5F..(GEN,SA,TH) |
1 | ||
| 04943A - STRUT KIT, REAR BRAKE | ||||
| 04943-25020 |
KDH222,TRH223..STD..SA CKD PACKAGE(SOUTH AFRICA) |
1 | ||
| 04943-08030 |
KDH222,LH222,TRH223..5F..(GEN,SA,TH) |
1 | ||
| 04943-25020 |
KDH222,223,LH222,TRH223..5F..(GEN,SA,TH) |
1 | ||
| 04949 - PLUG KIT, REAR BRAKE | ||||
| 04949-13010 |
KDH20#,212,22#,LH20#,212,222,TRH20#,213,22# |
1 | ||
| 47043 - PLATE SUB-ASSY, BRAKE BACKING, REAR RH | ||||
| 47043-26530 |
KDH222,LH222,TRH223..5F..(GEN,SA,TH) |
1 | ||
| 47043-26150 |
KDH222,223,LH222,TRH223..5F..(GEN,SA,TH) |
1 | ||
| 47043-26150 |
KDH222,TRH223..STD..SA CKD PACKAGE(SOUTH AFRICA) |
1 | ||
| 47043F - NUT(FOR BACKING PLATE TO REAR AXLE HOUSING SETTING) | ||||
| 90179-10088 |
KDH223..RUS,TH;KDH221,223..4FC;KDH20#,212,220,222,LH20#,212,222,TRH20#,213,22# |
8 | ||
| 90179-10041 |
KDH202..15S;KDH202..HRF..MA;KDH221..5D..4FC;TRH213..10S,16S;TRH203..15S..GEN;TRH201,223..4D..SG;KDH202..LHD..12S..5F;KDH202,TRH213..GL..TH;KDH223,TRH201..SG..4FC;TRH20#..4D..(ARL,GCC,MA,SA);KDH220,TRH201..5D..5F..(GCC,GEN,SA);KDH201,203,212,LH200,222,TRH221..03S,06S,10S,11S,12S,14S,16S;KDH200,222,LH202,212..(03S,12S,14S,15S,16S)..5F..(GCC,GEN,MA,SA,TH) |
8 | ||
| 47043H - BOLT, NO.1(FOR REAR BRAKE BACKING PLATE RH) | ||||
| 90114-10002 |
KDH20#,212,22#,LH20#,212,222,TRH20#,213,22# |
4 | ||
| 47044 - PLATE SUB-ASSY, BRAKE BACKING, REAR LH | ||||
| 47044-26150 |
KDH222,223,LH222,TRH223..5F..(GEN,SA,TH) |
1 | ||
| 47044-26530 |
KDH222,LH222,TRH223..5F..(GEN,SA,TH) |
1 | ||
| 47044-26150 |
KDH222,TRH223..STD..SA CKD PACKAGE(SOUTH AFRICA) |
1 | ||
| 47044A - BOLT, NO.1(FOR REAR BRAKE BACKING PLATE LH) | ||||
| 90114-10002 |
KDH20#,212,22#,LH20#,212,222,TRH20#,213,22# |
4 | ||
| 47547R - PLUG, BLEEDER(FOR DRUM BRAKE, REAR) | ||||
| 47547-12010 |
KDH20#,212,22#,LH20#,212,222,TRH20#,213,22# |
2 | ||
| 47548R - CAP, BLEEDER PLUG(FOR DRUM BRAKE, REAR) | ||||
| 31478-30010 |
KDH20#,212,22#,LH20#,212,222,TRH20#,213,22# |
2 | ||
| 47550 - CYLINDER ASSY, REAR WHEEL BRAKE(FOR RH, FRONT OR UPPER) | ||||
| 47550-26140 |
KDH222,LH222,TRH223..5F..(GEN,SA,TH) |
1 | ||
| 47550-26150 |
KDH222,223,LH222,TRH223..5F..(GEN,SA,TH) |
1 | ||
| 47550-26150 |
KDH222,TRH223..STD..SA CKD PACKAGE(SOUTH AFRICA) |
1 | ||
| 47550C - SPRING, COMPRESSION(FOR REAR WHEEL BRAKE CYLINDER) | ||||
| 90029-60009 |
KDH222,TRH223..STD..SA CKD PACKAGE(SOUTH AFRICA) |
2 | ||
| 90029-60011 |
KDH222,LH222,TRH223..5F..(GEN,SA,TH) |
2 | ||
| 90029-60009 |
KDH222,223,LH222,TRH223..5F..(GEN,SA,TH) |
2 | ||
| 47570 - CYLINDER ASSY, REAR WHEEL BRAKE(FOR LH, FRONT OR UPPER) | ||||
| 47550-26150 |
KDH222,TRH223..STD..SA CKD PACKAGE(SOUTH AFRICA) |
1 | ||
| 47550-26150 |
KDH222,223,LH222,TRH223..5F..(GEN,SA,TH) |
1 | ||
| 47550-26140 |
KDH222,LH222,TRH223..5F..(GEN,SA,TH) |
1 | ||
| 47601 - LEVER SUB-ASSY, PARKING BRAKE SHOE, RH(FOR REAR BRAKE) | ||||
| 47612-35040 |
KDH222,223,LH222,TRH223..5F..(GEN,SA,TH) |
1 | ||
| 47612-35040 |
KDH222,TRH223..STD..SA CKD PACKAGE(SOUTH AFRICA) |
1 | ||
| 47601-26530 |
KDH222,LH222,TRH223..5F..(GEN,SA,TH) |
1 | ||
| 47602 - LEVER SUB-ASSY, PARKING BRAKE SHOE, LH (FOR REAR BRAKE) | ||||
| 47602-26530 |
KDH222,LH222,TRH223..5F..(GEN,SA,TH) |
1 | ||
| 47611-35040 |
KDH222,TRH223..STD..SA CKD PACKAGE(SOUTH AFRICA) |
1 | ||
| 47611-35040 |
KDH222,223,LH222,TRH223..5F..(GEN,SA,TH) |
1 | ||
| 47643A - LEVER, REAR BRAKE AUTOMATIC ADJUST, RH | ||||
| 47643-45010 |
KDH222,LH222,TRH223..5F..(GEN,SA,TH) |
1 | ||
| 47644-60010 |
KDH222,TRH223..STD..SA CKD PACKAGE(SOUTH AFRICA) |
1 | ||
| 47644-60010 |
KDH222,223,LH222,TRH223..5F..(GEN,SA,TH) |
1 | ||
| 47644A - LEVER, REAR BRAKE AUTOMATIC ADJUST, LH | ||||
| 47644-45010 |
KDH222,LH222,TRH223..5F..(GEN,SA,TH) |
1 | ||
| 47643-60010 |
KDH222,TRH223..STD..SA CKD PACKAGE(SOUTH AFRICA) |
1 | ||
| 47643-60010 |
KDH222,223,LH222,TRH223..5F..(GEN,SA,TH) |
1 | ||
| Common parts | ||||
| 90119-06084 | ||||
| 90119-06315 | ||||
(1312- )TRH223..4FC..GEN ; (1312- )KDH222,223,TRH223..ARL,GCC,RUS ; (1312-
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| Common parts | ||||
| 90119-06084 | ||||
| 90119-06315 | ||||
(1312- )KDH222,223,LH222,TRH223..03S,12S,14S,16S..GEN,KEN,SA,TH,VN
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| Common parts | ||||
| 90119-06084 | ||||
| 90119-06315 | ||||
