TRH203L-REMDK (2005)
Toyota Hiace
(0501- )2TRFE
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 11011 - WASHER SET, CRANKSHAFT THRUST | ||||
| 11011-75020 |
2TRFE..TRH213..RHD;2TRFE..TRH213..GCC;1TRFE,2TRFE..TRH200,201,22#;2TRFE..TRH203,213..(SMRF,SRF)..(09S,10S,12S,15S)..(GCC,GEN) STD |
2 | ||
| 11011 - WASHER SET, CRANKSHAFT THRUST | ||||
| 11011-75020 |
2TRFE..TRH213..RHD;2TRFE..TRH213..GCC;1TRFE,2TRFE..TRH200,201,22#;2TRFE..TRH203,213..(SMRF,SRF)..(09S,10S,12S,15S)..(GCC,GEN) STD |
2 | ||
| 11702 - BEARING SET, CRANKSHAFT | ||||
| 11704-75031 |
1TRFE,2TRFE..TRH20#,213,22# U/S 0.25 |
1 | ||
| 11711 - BEARING, CRANKSHAFT | ||||
| 11701-7503101 |
2TRFE..TRH213..RHD;2TRFE..TRH213..GCC;1TRFE,2TRFE..TRH200,201,22#;2TRFE..TRH203,213..(SMRF,SRF)..(09S,10S,12S,15S)..(GCC,GEN) MARK1,REFER REPAIR MANUAL |
5 | ||
| 11701-7503102 |
2TRFE..TRH213..RHD;2TRFE..TRH213..GCC;1TRFE,2TRFE..TRH200,201,22#;2TRFE..TRH203,213..(SMRF,SRF)..(09S,10S,12S,15S)..(GCC,GEN) MARK2,REFER REPAIR MANUAL |
5 | ||
| 11701-7503103 |
2TRFE..TRH213..RHD;2TRFE..TRH213..GCC;1TRFE,2TRFE..TRH200,201,22#;2TRFE..TRH203,213..(SMRF,SRF)..(09S,10S,12S,15S)..(GCC,GEN) MARK3,REFER REPAIR MANUAL |
5 | ||
| 11711 - BEARING, CRANKSHAFT | ||||
| 11701-7503101 |
2TRFE..TRH213..RHD;2TRFE..TRH213..GCC;1TRFE,2TRFE..TRH200,201,22#;2TRFE..TRH203,213..(SMRF,SRF)..(09S,10S,12S,15S)..(GCC,GEN) MARK1,REFER REPAIR MANUAL |
5 | ||
| 11701-7503102 |
2TRFE..TRH213..RHD;2TRFE..TRH213..GCC;1TRFE,2TRFE..TRH200,201,22#;2TRFE..TRH203,213..(SMRF,SRF)..(09S,10S,12S,15S)..(GCC,GEN) MARK2,REFER REPAIR MANUAL |
5 | ||
| 11701-7503103 |
2TRFE..TRH213..RHD;2TRFE..TRH213..GCC;1TRFE,2TRFE..TRH200,201,22#;2TRFE..TRH203,213..(SMRF,SRF)..(09S,10S,12S,15S)..(GCC,GEN) MARK3,REFER REPAIR MANUAL |
5 | ||
| 11711 - BEARING, CRANKSHAFT | ||||
| 11701-7503101 |
2TRFE..TRH213..RHD;2TRFE..TRH213..GCC;1TRFE,2TRFE..TRH200,201,22#;2TRFE..TRH203,213..(SMRF,SRF)..(09S,10S,12S,15S)..(GCC,GEN) MARK1,REFER REPAIR MANUAL |
5 | ||
| 11701-7503102 |
2TRFE..TRH213..RHD;2TRFE..TRH213..GCC;1TRFE,2TRFE..TRH200,201,22#;2TRFE..TRH203,213..(SMRF,SRF)..(09S,10S,12S,15S)..(GCC,GEN) MARK2,REFER REPAIR MANUAL |
5 | ||
| 11701-7503103 |
2TRFE..TRH213..RHD;2TRFE..TRH213..GCC;1TRFE,2TRFE..TRH200,201,22#;2TRFE..TRH203,213..(SMRF,SRF)..(09S,10S,12S,15S)..(GCC,GEN) MARK3,REFER REPAIR MANUAL |
5 | ||
| 11711 - BEARING, CRANKSHAFT | ||||
| 11701-7503101 |
2TRFE..TRH213..RHD;2TRFE..TRH213..GCC;1TRFE,2TRFE..TRH200,201,22#;2TRFE..TRH203,213..(SMRF,SRF)..(09S,10S,12S,15S)..(GCC,GEN) MARK1,REFER REPAIR MANUAL |
5 | ||
| 11701-7503102 |
2TRFE..TRH213..RHD;2TRFE..TRH213..GCC;1TRFE,2TRFE..TRH200,201,22#;2TRFE..TRH203,213..(SMRF,SRF)..(09S,10S,12S,15S)..(GCC,GEN) MARK2,REFER REPAIR MANUAL |
5 | ||
| 11701-7503103 |
2TRFE..TRH213..RHD;2TRFE..TRH213..GCC;1TRFE,2TRFE..TRH200,201,22#;2TRFE..TRH203,213..(SMRF,SRF)..(09S,10S,12S,15S)..(GCC,GEN) MARK3,REFER REPAIR MANUAL |
5 | ||
| 11711 - BEARING, CRANKSHAFT | ||||
| 11701-7503101 |
2TRFE..TRH213..RHD;2TRFE..TRH213..GCC;1TRFE,2TRFE..TRH200,201,22#;2TRFE..TRH203,213..(SMRF,SRF)..(09S,10S,12S,15S)..(GCC,GEN) MARK1,REFER REPAIR MANUAL |
5 | ||
| 11701-7503102 |
2TRFE..TRH213..RHD;2TRFE..TRH213..GCC;1TRFE,2TRFE..TRH200,201,22#;2TRFE..TRH203,213..(SMRF,SRF)..(09S,10S,12S,15S)..(GCC,GEN) MARK2,REFER REPAIR MANUAL |
5 | ||
| 11701-7503103 |
2TRFE..TRH213..RHD;2TRFE..TRH213..GCC;1TRFE,2TRFE..TRH200,201,22#;2TRFE..TRH203,213..(SMRF,SRF)..(09S,10S,12S,15S)..(GCC,GEN) MARK3,REFER REPAIR MANUAL |
5 | ||
| 11991 - WASHER, BALANCESHAFT THRUST | ||||
| 11991-75010 |
2TRFE..TRH201,22#;2TRFE..TRH213..RHD;2TRFE..TRH213..GCC;2TRFE..TRH203,213..(SMRF,SRF)..(09S,10S,12S,15S)..(GCC,GEN) |
1 | ||
| 11992 - WASHER, BALANCESHAFT THRUST, NO.2 | ||||
| 11992-75010 |
2TRFE..TRH201,22#;2TRFE..TRH213..RHD;2TRFE..TRH213..GCC;2TRFE..TRH203,213..(SMRF,SRF)..(09S,10S,12S,15S)..(GCC,GEN) |
1 | ||
| 13011 - RING SET, PISTON | ||||
| 13011-75110 |
2TRFE..TRH20#..LHD..SRF..GEN;2TRFE..TRH223..LHD..STD..GEN STD,EL SALVADOR SPEC |
1 | ||
| 13011-75110 |
2TRFE..TRH203..LHD..15S..GEN STD,PERU SPEC |
1 | ||
| 13013-75110 |
2TRFE..TRH20#..LHD..SRF..GEN;2TRFE..TRH223..LHD..STD..GEN O/S 0.50,EL SALVADOR SPEC |
1 | ||
| 13011-75110 |
2TRFE..TRH20#..LHD..SRF..GEN;2TRFE..TRH223..LHD..STD..GEN STD,COSTA RICA SPEC |
1 | ||
| 13013-75110 |
2TRFE..TRH20#..LHD..SRF..GEN;2TRFE..TRH223..LHD..STD..GEN O/S 0.50,COSTA RICA SPEC |
1 | ||
| 13011-75110 |
2TRFE..TRH20#..LHD..SRF..GEN;2TRFE..TRH223..LHD..STD..GEN STD,ECUADOR SPEC |
1 | ||
| 13013-75110 |
2TRFE..TRH203..LHD..15S..GEN O/S 0.50,PERU SPEC |
1 | ||
| 13013-75110 |
2TRFE..TRH20#..LHD..SRF..GEN;2TRFE..TRH223..LHD..STD..GEN O/S 0.50,ECUADOR SPEC |
1 | ||
| 13011-75110 |
2TRFE..TRH223..LHD..STD..GEN;2TRFE..TRH201,203..LHD..SRF..GEN STD,CENTRAL AMERICA(4COUNTRY) SPEC |
1 | ||
| 13011-75130 |
2TRFE..TRH221..SP..GEN;2TRFE..TRH223..5F..GEN;2TRFE..TRH213..RHD..STD..GEN;2TRFE..TRH201,203..SRF..(03S,12S,15S)..GEN STD |
1 | ||
| 13013-75130 |
2TRFE..TRH221..SP..GEN;2TRFE..TRH223..5F..GEN;2TRFE..TRH213..RHD..STD..GEN;2TRFE..TRH201,203..SRF..(03S,12S,15S)..GEN O/S 0.50 |
1 | ||
| 13013-75110 |
2TRFE..TRH223..LHD..STD..GEN;2TRFE..TRH201,203..LHD..SRF..GEN O/S 0.50,CENTRAL AMERICA(4COUNTRY) SPEC |
1 | ||
| 13013-75110 |
2TRFE..TRH221..SP..GEN;2TRFE..TRH223..LHD..STD..GEN;2TRFE..TRH201,203,213..LHD..(SMRF,SRF)..STD..GEN O/S 0.50,NIGERIA SPEC |
1 | ||
| 13011-75110 |
2TRFE..TRH221..SP..GEN;2TRFE..TRH223..LHD..STD..GEN;2TRFE..TRH201,203,213..LHD..(SMRF,SRF)..STD..GEN STD,NIGERIA SPEC |
1 | ||
| 13041 - BEARING, CONNECTING ROD | ||||
| 13041-7504005 |
2TRFE..TRH20#,213,22# MARK5,REFER REPAIR MANUAL |
4 | ||
| 13041-7504004 |
2TRFE..TRH20#,213,22# MARK4,REFER REPAIR MANUAL |
4 | ||
| 13041-7503004 |
2TRFE..TRH201,22#;2TRFE..TRH213..RHD;2TRFE..TRH213..GCC;2TRFE..TRH203,213..(SMRF,SRF)..(09S,10S,12S,15S) MARK 4,REFER REPAIR MANUAL |
4 | ||
| 13041-7503005 |
2TRFE..TRH201,22#;2TRFE..TRH213..RHD;2TRFE..TRH213..GCC;2TRFE..TRH203,213..(SMRF,SRF)..(09S,10S,12S,15S) MARK 5,REFER REPAIR MANUAL |
4 | ||
| 13041-7504006 |
2TRFE..TRH20#,213,22# MARK6,REFER REPAIR MANUAL |
4 | ||
| 13041-7503006 |
2TRFE..TRH201,22#;2TRFE..TRH213..RHD;2TRFE..TRH213..GCC;2TRFE..TRH203,213..(SMRF,SRF)..(09S,10S,12S,15S) MARK 6,REFER REPAIR MANUAL |
4 | ||
| 13041 - BEARING, CONNECTING ROD | ||||
| 13041-7504005 |
2TRFE..TRH20#,213,22# MARK5,REFER REPAIR MANUAL |
4 | ||
| 13041-7504004 |
2TRFE..TRH20#,213,22# MARK4,REFER REPAIR MANUAL |
4 | ||
| 13041-7503004 |
2TRFE..TRH201,22#;2TRFE..TRH213..RHD;2TRFE..TRH213..GCC;2TRFE..TRH203,213..(SMRF,SRF)..(09S,10S,12S,15S) MARK 4,REFER REPAIR MANUAL |
4 | ||
| 13041-7503005 |
2TRFE..TRH201,22#;2TRFE..TRH213..RHD;2TRFE..TRH213..GCC;2TRFE..TRH203,213..(SMRF,SRF)..(09S,10S,12S,15S) MARK 5,REFER REPAIR MANUAL |
4 | ||
| 13041-7504006 |
2TRFE..TRH20#,213,22# MARK6,REFER REPAIR MANUAL |
4 | ||
| 13041-7503006 |
2TRFE..TRH201,22#;2TRFE..TRH213..RHD;2TRFE..TRH213..GCC;2TRFE..TRH203,213..(SMRF,SRF)..(09S,10S,12S,15S) MARK 6,REFER REPAIR MANUAL |
4 | ||
| 13101 - PISTON SUB-ASSY, W/PIN | ||||
| 13103-75130 |
2TRFE..TRH201,203,213,22# O/S 0.50 |
4 | ||
| 13101-75130 |
2TRFE..TRH201,22#;2TRFE..TRH213..RHD;2TRFE..TRH213..GCC;2TRFE..TRH203,213..(SMRF,SRF)..(09S,10S,12S,15S)..(GCC,GEN) STD |
4 | ||
| 13101A - RING, HOLE SNAP(FOR PISTON PIN) | ||||
| 90520-22025 |
1TRFE,2TRFE..TRH20#,213,22# |
8 | ||
| 13101A - RING, HOLE SNAP(FOR PISTON PIN) | ||||
| 90520-22025 |
1TRFE,2TRFE..TRH20#,213,22# |
8 | ||
| 13201 - ROD SUB-ASSY, CONNECTING | ||||
| 13201-79575 |
2TRFE..TRH201,22#;2TRFE..TRH213..RHD;2TRFE..TRH213..GCC;2TRFE..TRH203,213..(SMRF,SRF)..(09S,10S,12S,15S) |
4 | ||
| 13201-79576 |
2TRFE..TRH201..5F;2TRFE..TRH201..SG..4FC;2TRFE..TRH201..4FC..ARL;2TRFE..TRH22#..ARL,CIS,GCC,GEN,SA;2TRFE..TRH203,213..(SMRF,SRF)..(10S,12S,15S,16S) |
4 | ||
| 13201A - BUSH(FOR CONNECTING ROD SMALL END) | ||||
| 90999-73144 |
1TRFE,2TRFE..TRH20#,213,22# |
4 | ||
| 13202 - BEARING SET, CONNECTING ROD | ||||
| 13204-75040 |
2TRFE..TRH223;2TRFE..TRH221..SP;2TRFE..TRH20#,213..(SMRF,SRF)..(03S,06S,10S,11S,15S) U/S 0.25 |
1 | ||
| 13204-75030 |
2TRFE..TRH223;2TRFE..TRH221..SP;2TRFE..TRH20#,213..(SMRF,SRF)..(03S,06S,10S,11S,12S,15S) U/S 0.25 |
1 | ||
| 13265 - BOLT, CONNECTING ROD | ||||
| 13265-28010 |
1TRFE,2TRFE..TRH20#,213,22# |
8 | ||
| 13405 - FLYWHEEL SUB-ASSY | ||||
| 13405-75060 |
2TRFE..TRH201,22#..5F;2TRFE..TRH213..RHD..5F;2TRFE..TRH213..5F..GCC;2TRFE..TRH203,213..(SMRF,SRF)..(09S,10S,12S,15S)..5F..(GCC,GEN) |
1 | ||
| 13405A - PIN, STRAIGHT(FOR FLYWHEEL) | ||||
| 90250-08054 |
2TRFE..TRH201,22#..5F;2TRFE..TRH213..RHD..5F;2TRFE..TRH213..5F..GCC;2TRFE..TRH203,213..(SMRF,SRF)..(09S,10S,12S,15S)..5F..(GCC,GEN) L=23,OD=8 |
3 | ||
| 13405B - BOLT, FLYWHEEL SETTING | ||||
| 90910-02116 |
2TRFE..TRH201,22#..5F;2TRFE..TRH213..RHD..5F;2TRFE..TRH213..5F..GCC;2TRFE..TRH203,213..(SMRF,SRF)..(09S,10S,12S,15S)..5F..(GCC,GEN) |
10 | ||
| 13411 - CRANKSHAFT | ||||
| 13401-75020 |
2TRFE..TRH201..5F;2TRFE..TRH213..GCC;2TRFE..TRH201..SG..4FC;2TRFE..TRH201..4FC..ARL;2TRFE..TRH213..RHD..(10S,16S);2TRFE..TRH22#..ARL,CIS,GCC,GEN,SA;2TRFE..TRH203,213..(SMRF,SRF)..(10S,12S,15S)..(GCC,GEN) |
1 | ||
| 13453 - GEAR, FLYWHEEL RING | ||||
| 13453-20010 |
2TRFE..TRH201,22#..5F;2TRFE..TRH213..RHD..5F;2TRFE..TRH213..5F..GCC;2TRFE..TRH203,213..(SMRF,SRF)..(09S,10S,12S,15S)..5F..(GCC,GEN) |
1 | ||
| 13471 - PULLEY, CRANKSHAFT | ||||
| 13408-75040 |
2TRFE..TRH201,22#;2TRFE..TRH213..RHD;2TRFE..TRH213..GCC;2TRFE..TRH203,213..(SMRF,SRF)..(09S,10S,12S,15S)..(GCC,GEN) |
1 | ||
| 13471A - KEY, CRANKSHAFT(FOR CRANKSHAFT PULLEY SET) | ||||
| 90280-05005 |
2TRFE..TRH213..RHD;2TRFE..TRH213..GCC;1TRFE,2TRFE..TRH200,201,22#;2TRFE..TRH203,213..(SMRF,SRF)..(09S,10S,12S,15S)..(GCC,GEN) |
2 | ||
| 13471A - KEY, CRANKSHAFT(FOR CRANKSHAFT PULLEY SET) | ||||
| 90280-05005 |
2TRFE..TRH213..RHD;2TRFE..TRH213..GCC;1TRFE,2TRFE..TRH200,201,22#;2TRFE..TRH203,213..(SMRF,SRF)..(09S,10S,12S,15S)..(GCC,GEN) |
2 | ||
| 13471C - BOLT(FOR CRANKSHAFT PULLEY SET) | ||||
| 90105-16041 |
2TRFE..TRH213..RHD;2TRFE..TRH213..GCC;1TRFE,2TRFE..TRH200,201,22#;2TRFE..TRH203,213..(SMRF,SRF)..(09S,10S,12S,15S)..(GCC,GEN) |
1 | ||
| 13521 - GEAR OR SPROCKET, CRANKSHAFT TIMING | ||||
| 13521-75020 |
2TRFE..TRH213..RHD;2TRFE..TRH213..GCC;1TRFE,2TRFE..TRH200,201,22#;2TRFE..TRH203,213..(SMRF,SRF)..(09S,10S,12S,15S)..(GCC,GEN) |
1 | ||
| 13621 - BALANCESHAFT, NO.1 | ||||
| 13621-75020 |
2TRFE..TRH201,22#;2TRFE..TRH213..RHD;2TRFE..TRH213..GCC;2TRFE..TRH203,213..(SMRF,SRF)..(09S,10S,12S,15S)..(GCC,GEN) |
1 | ||
| 13622 - BALANCESHAFT, NO.2 | ||||
| 13622-75020 |
2TRFE..TRH201,22#;2TRFE..TRH213..RHD;2TRFE..TRH213..GCC;2TRFE..TRH203,213..(SMRF,SRF)..(09S,10S,12S,15S)..(GCC,GEN) |
1 | ||
| 13632 - GEAR, BALANCESHAFT DRIVEN, NO.1 | ||||
| 13632-75010 |
2TRFE..TRH201,22#;2TRFE..TRH213..RHD;2TRFE..TRH213..GCC;2TRFE..TRH203,213..(SMRF,SRF)..(09S,10S,12S,15S)..(GCC,GEN) |
1 | ||
| 13633 - GEAR, BALANCESHAFT DRIVEN, NO.2 | ||||
| 13633-75010 |
2TRFE..TRH201,203,213,22# |
1 | ||
| 13635 - SPACER, BALANCESHAFT THRUST | ||||
| 13635-75010 |
2TRFE..TRH201,22#;2TRFE..TRH213..RHD;2TRFE..TRH213..GCC;2TRFE..TRH203,213..(SMRF,SRF)..(09S,10S,12S,15S)..(GCC,GEN) |
1 | ||
| Common parts | ||||
| 90105-08323 | ||||
| 90105-T0238 | ||||
| 90281-03001 | ||||
| 91641-80818 | ||||
| 91641-H0820 | ||||
| Linked diagrams | ||||
| 1302 | ||||
(1312- )2TRFE..ARL,GCC,GEN,RUS,SA,TH ; (1401-1412)2TRFE..TRH203..MA
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| Common parts | ||||
| 90105-08323 | ||||
| 90105-T0118 | ||||
| 90105-T0238 | ||||
| 90281-03001 | ||||
| 91551-80814 | ||||
| 91641-80818 | ||||
| Linked diagrams | ||||
| 1302 | ||||
