KDH202L-REMDYV (2005)
Toyota Hiace
(0501- )KDH200,202,203,LH20#,TRH201,203..LHD..4D
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 51403D - BRACKET SUB-ASSY, ENGINE REAR MOUNTING | ||||
| 51403-26240 |
KDH20#,212,220,221,223;KDH222..ARL,GCC,GEN,SA |
1 | ||
| 51403-26241 |
KDH20#,212,22# |
1 | ||
| 57023 - MEMBER SUB-ASSY, REAR SIDE, RH | ||||
| 57023-26640 |
KDH212,TRH213..GCC;TRH201,213..SG..(03S,09S);KDH212,TRH213..RHD..STD..GEN;KDH202,203,LH202,212,TRH203..SMRF,SRF |
1 | ||
| 57024 - MEMBER SUB-ASSY, REAR SIDE, LH | ||||
| 57024-26640 |
KDH212,TRH213..GCC;TRH201,213..SG..(03S,09S);KDH212,TRH213..RHD..STD..GEN;KDH202,203,LH202,212,TRH203..SMRF,SRF |
1 | ||
| 57066B - MEMBER SUB-ASSY, REAR FLOOR CROSS, NO.6 | ||||
| 57066-26140 |
KDH202,203,LH202,TRH203..LHD |
1 | ||
| 57066-26120 |
KDH202..15S;KDH202..LHD..12S;KDH203,LH202,TRH203..SRF..(12S,15S) AMBURANCE BASE |
1 | ||
| 57066-26121 |
KDH202,203,LH202,TRH203..SRF..(12S,15S)..STD AMBURANCE BASE |
1 | ||
| 57066-26141 |
KDH202,203,LH202,TRH203..LHD |
1 | ||
| 57068 - MEMBER SUB-ASSY, REAR FLOOR REAR CROSS, INNER | ||||
| 57068-26230 |
KDH202,LH202,TRH203..15S AMBURANCE BASE |
1 | ||
| 57068-26260 |
KDH202,LH202,TRH203..LHD..15S |
1 | ||
| 57069 - MEMBER SUB-ASSY, REAR FLOOR REAR CROSS, OUTER | ||||
| 57069-26120 |
KDH200,TRH201..06S..GCC;KDH200,TRH201..03S..(ARL,GCC,GEN,TH);KDH201,202,203,LH20#,TRH203..SRF..(03S,12S,14S,15S) |
1 | ||
| 57254A - REINFORCEMENT, ENGINE REAR MOUNTING MEMBER | ||||
| 57254-26040 |
KDH222..ARL,GCC,GEN,SA;KDH20#,212,220,221,223,LH20#,212,222,TRH20#,213,22# |
1 | ||
| 57312 - OUTRIGGER, NO.1 LH | ||||
| 57302-26040 |
KDH212..GCC;TRH203..LHD..15S..GEN;KDH202,203,LH202,212..LHD..(12S,15S,16S)..5F |
1 | ||
| 57322B - OUTRIGGER, NO.5, LH | ||||
| 57322-26030 |
KDH202..LHD..5F;TRH203,213..LHD..(10S,15S,16S)..(GCC,GEN);KDH200,203,212,222,223,LH20#,212,222,TRH201,22#..LHD..4D..(03S,11S,12S,13S,15S,16S)..(CIS,GCC,GEN,RUS) |
1 | ||
| 57413 - RAIL, FLOOR SIDE, CENTER RH | ||||
| 57413-26A70 |
KDH200..LHD..4D;KDH200..06S..GCC;KDH200,LH200..5D..SP;KDH201..03S..5F..GEN;KDH202,203,212,LH20#,212,TRH201,203,213..LHD..STD |
1 | ||
| 57414 - RAIL, FLOOR SIDE, CENTER LH | ||||
| 57406-26580 |
KDH202,212,LH202,212,TRH203,213..LHD..(15S,16S) |
1 | ||
| 57406-26570 |
KDH202,203,LH202,212,TRH203..LHD..(10S,12S,15S) AMBURANCE BASE |
1 | ||
| 57415 - RAIL, FLOOR SIDE, REAR RH | ||||
| 57415-26210 |
KDH20#,212,220,221,LH20#,212,TRH20#,213,221..03S,06S,14S,15S,16S |
1 | ||
| 57416 - RAIL, FLOOR SIDE, REAR LH | ||||
| 57416-26160 |
KDH20#,212,220,221,LH20#,212,TRH20#,213,221..03S,06S,14S,15S,16S |
1 | ||
| 57608B - MEMBER SUB-ASSY, REAR FLOOR CROSS, NO.4 | ||||
| 57608-26310 |
KDH202,LH202,TRH203..LHD..15S |
1 | ||
| 57608-26300 |
KDH202..15S;KDH202..LHD..12S;KDH203,LH202,TRH203..SRF..(12S,15S) AMBURANCE BASE |
1 | ||
| 57608-26300 |
KDH202,TRH203..GCC SAUDI ARABIA SPEC&AMBURANCE BASE |
1 | ||
| 57608-26310 |
KDH202,TRH203..GCC SAUDI ARABIA SPEC |
1 | ||
| 57608-26301 |
KDH202,203,LH202,TRH203..SRF..(12S,15S)..STD AMBURANCE BASE |
1 | ||
| 57608-26330 |
KDH202,LH202,TRH203..LHD..15S..5F |
1 | ||
| 57608-26311 |
KDH202,TRH203..GCC SAUDI ARABIA SPEC |
1 | ||
| 57608-26301 |
KDH202,TRH203..GCC SAUDI ARABIA SPEC&AMBURANCE BASE |
1 | ||
| 57608-26331 |
KDH202,LH202,TRH203..LHD..15S |
1 | ||
| 57609C - MEMBER SUB-ASSY, REAR FLOOR CROSS, NO.5 | ||||
| 57609-26181 |
KDH202,203,LH202,TRH203..SRF..(12S,15S)..STD AMBURANCE BASE |
1 | ||
| 57609-26180 |
KDH202..15S;KDH202..LHD..12S;LH202,TRH203..SRF AMBURANCE BASE |
1 | ||
| 57609-26201 |
KDH202,203,LH202,TRH203..LHD |
1 | ||
| 57609-26200 |
KDH202,LH202,TRH203..LHD |
1 | ||
| 57609-26182 |
KDH202,203,LH202,TRH203..SRF..(12S,15S)..STD AMBURANCE BASE |
1 | ||
| 57609-26202 |
KDH202,203,LH202,TRH203..LHD |
1 | ||
| 57652C - MEMBER, REAR FLOOR CROSS, NO.1 | ||||
| 57652-26070 |
KDH20#,LH20#,TRH20# |
1 | ||
| 57653F - MEMBER, REAR FLOOR CROSS, NO.2 | ||||
| 57653-26130 |
KDH201..RHD..03S;KDH201,203..RHD..SG;KDH200,202,LH20#,TRH20# |
1 | ||
| 57654A - MEMBER, REAR FLOOR CROSS, NO.3 | ||||
| 57607-26590 |
KDH202,LH202,TRH203..15S AMBURANCE BASE |
1 | ||
| 57607-26650 |
KDH202,LH202,TRH203..LHD..15S |
1 | ||
| 57607-26590 |
KDH202,TRH203..GCC SAUDI ARABIA SPEC&AMBURANCE BASE |
1 | ||
| 57607-26660 |
KDH202,LH202,TRH203..LHD..15S..5F |
1 | ||
| 57607-26650 |
KDH202,TRH203..GCC SAUDI ARABIA SPEC |
1 | ||
| 57607-26591 |
KDH202,LH202,TRH203..15S AMBURANCE BASE |
1 | ||
| 57607-26591 |
KDH202,TRH203..GCC SAUDI ARABIA SPEC&AMBURANCE BASE |
1 | ||
| 57607-26661 |
KDH202,LH202,TRH203..LHD..15S |
1 | ||
| 57607-26651 |
KDH202,TRH203..GCC SAUDI ARABIA SPEC |
1 | ||
| 57658 - MEMBER, REAR FLOOR CROSS, NO.7 | ||||
| 57067-26100 |
KDH202..15S;KDH202..LHD..12S;KDH203,LH202,TRH203..SRF..(12S,15S) AMBURANCE BASE |
1 | ||
| 57067-26140 |
KDH202,LH202,TRH203..LHD..15S |
1 | ||
| 57067-26101 |
KDH202,203,LH202,TRH203..SRF..(12S,15S)..STD AMBURANCE BASE |
1 | ||
| 57067-26141 |
KDH202,LH202,TRH203..LHD..15S |
1 | ||
| 58218 - PLATE, SEAT FLOOR PANEL | ||||
| 58218-26010 |
KDH222..ARL,GCC,GEN,SA;KDH20#,212,220,221,223,LH20#,212,222,TRH20#,213,22# |
2 | ||
| 58223H - REINFORCEMENT, FLOOR PANEL SIDE, RH | ||||
| 58223-26070 |
KDH20#,212,22#,LH20#,212,222,TRH20#,213,22# |
1 | ||
| 58224J - REINFORCEMENT, FLOOR PANEL SIDE, LH | ||||
| 58224-26090 |
KDH20#,212,22#,LH20#,212,222,TRH20#,213,22# |
1 | ||
| 58297J - RETAINER, FLOOR CLAMP | ||||
| 58297-26020 |
TRH223;TRH203..GCC,MA;TRH201..SG..4FC;KDH202..HRF..MA;KDH202..15S..GEN;TRH201..4FC..ARL;TRH203..SRF..GEN;KDH202..LHD..12S..5F;KDH220..SP..(GEN,SA);TRH201,213..(03S,06S,10S,16S)..5F;KDH202,TRH213..(11S,12S,15S)..(GCC,TH);KDH200,222,LH202,212..(03S,12S,14S,15S,16S)..(GCC,GEN,MA,SA,TH);KDH201,203,212,221,223,LH200,222,TRH221..03S,06S,10S,11S,14S,16S |
1 | ||
| 58303B - STEP SUB-ASSY, REAR FLOOR, RH | ||||
| 58303-26160 |
KDH20#..SG..GCC BATTERY-80D26R X 2(55AH X 2) |
1 | ||
| 58303-26150 |
KDH20#,TRH20#..SG..GCC |
1 | ||
| 58303-26250 |
KDH202,TRH203..GCC AMBURANCE BASE |
1 | ||
| 58303-26260 |
KDH202..GCC AMBURANCE BASE&BATTERY-80D26R X 2(55AH X 2) |
1 | ||
| 58303-26160 |
KDH200,202,212,TRH201,203,213..SG..GCC |
1 | ||
| 58303-26260 |
KDH202,TRH203..GCC AMBURANCE BASE |
1 | ||
| 58311 - PAN, REAR FLOOR | ||||
| 58311-26C50 |
KDH202,LH202,TRH203..LHD..15S |
1 | ||
| 58311-26C10 |
KDH202,LH202,TRH203..LHD AMBURANCE BASE |
1 | ||
| 58311-26C50 |
KDH202,TRH203..GCC SAUDI ARABIA SPEC |
1 | ||
| 58311-26C10 |
KDH202,TRH203..GCC SAUDI ARABIA SPEC&AMBURANCE BASE |
1 | ||
| 58311-26D20 |
KDH202,LH202,TRH203..LHD..15S |
1 | ||
| 58335A - SEAL, REAR FLOOR SIDE SERVICE HOLE COVER | ||||
| 58335-26030 |
TRH213..GCC,GEN,SA,TH;KDH222..ARL,GCC,GEN,SA;KDH20#,212,220,221,223,LH20#,212,222,TRH20#,22# |
1 | ||
| 58474 - COVER, INSPECTION HOLE | ||||
| 58474-26010 |
KDH20#,212,22#,LH20#,212,222,TRH20#,213,22# |
2 | ||
| 58656C - PLATE, REAR FLOOR, CENTER LOWER NO.2 RH | ||||
| 58656-26020 |
TRH213..GL..(GEN,TH);KDH200,201,LH200,TRH200,201..5D;KDH202,203,212,LH20#,212,TRH203..LHD;KDH200,TRH201,213..LHD..4D..STD..(GCC,GEN) |
1 | ||
| 58759A - COVER, FUEL TANK INSPECTION HOLE | ||||
| 58759-26010 |
KDH222..ARL,GCC,GEN,SA;KDH20#,212,220,221,223,LH20#,212,222,TRH20#,213,22# |
1 | ||
| 59324 - BASE, SUB FLOOR LEG, NO.2 | ||||
| 59324-26020 |
KDH202,LH202,TRH203..15S |
1 | ||
| Common parts | ||||
| 90159-50322 | ||||
| 90189-05055 | ||||
| 91553-80612 | ||||
| 91553-80818 | ||||
| 91553-81230 | ||||
| Linked diagrams | ||||
| 5752 | ||||
| 5851 | ||||
| 5854 | ||||
(1312- )KDH20#,LH20#,TRH203..LHD..4D
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| Common parts | ||||
| 90159-50322 | ||||
| 90189-05055 | ||||
| 91553-80612 | ||||
| 91553-80818 | ||||
| 91553-81230 | ||||
| Linked diagrams | ||||
| 5752 | ||||
| 5851 | ||||
| 5854 | ||||
