DB102LC-Q (1969)
Toyota Heavy Duty Truck
(6903- )
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 42601C - NUT, HUB (FOR AXLE) | ||||
| 90942-01003 |
DA11#,DB10#,FA100,11#,FB100,FC100 FR,LH |
8 | ||
| 42633-55021 |
DA11#,DB10#,FA100,11#,FB100,FC100 RR,RH |
8 | ||
| 42634-55020 |
DA11#,DB10#,FA100,11#,FB100,FC100 RR,LH |
8 | ||
| 42633-55020 |
DA11#,DB10#,FA100,11#,FB100,FC100 RR,RH |
8 | ||
| 90942-01019 |
DA11#,DB10#,FA100,11#,FB100 FR,LH |
8 | ||
| 90942-01002 |
DA11#,DB10#,FA100,11#,FB100,FC100 FR,RH |
8 | ||
| 42634-55021 |
DA11#,DB10#,FA100,11#,FB100,FC100 RR,LH |
8 | ||
| 90942-01018 |
DA11#,DB10#,FA100,11#,FB100 FR,RH |
8 | ||
| 42601C - NUT, HUB (FOR AXLE) | ||||
| 90942-01003 |
DA11#,DB10#,FA100,11#,FB100,FC100 FR,LH |
8 | ||
| 42633-55021 |
DA11#,DB10#,FA100,11#,FB100,FC100 RR,RH |
8 | ||
| 42634-55020 |
DA11#,DB10#,FA100,11#,FB100,FC100 RR,LH |
8 | ||
| 42633-55020 |
DA11#,DB10#,FA100,11#,FB100,FC100 RR,RH |
8 | ||
| 90942-01019 |
DA11#,DB10#,FA100,11#,FB100 FR,LH |
8 | ||
| 90942-01002 |
DA11#,DB10#,FA100,11#,FB100,FC100 FR,RH |
8 | ||
| 42634-55021 |
DA11#,DB10#,FA100,11#,FB100,FC100 RR,LH |
8 | ||
| 90942-01018 |
DA11#,DB10#,FA100,11#,FB100 FR,RH |
8 | ||
| 42601D - WEIGHT, BALANCE (FOR DISC WHEEL) | ||||
| 90942-03042 |
DA11#,DB10#,FA100,11#,FB100,FC100 300G |
1 | ||
| 90942-03043 |
DA11#,DB10#,FA100,11#,FB100,FC100 200G |
1 | ||
| 90942-03044 |
DA11#,DB10#,FA100,11#,FB100,FC100 100G |
1 | ||
| 42601F - WHEEL, DISC (FOR FRONT) | ||||
| 42610-55090 |
FA100..RHD;DA11#,DB10#,FA11#,FB100 T=10,W/8.25 OR 9.00-20 TIRE |
2 | ||
| 42610-55090 |
DA11#,DB10#,FA11#,FB100 T=10,W/8.25 OR 9.00-20 TIRE |
2 | ||
| 42601G - RING, DISC WHEEL SIDE (FOR FRONT) | ||||
| 42613-55030 |
DA11#,DB10#,FA100,11#,FB100 W/8.25 OR 9.00-20 TIRE |
2 | ||
| 42601R - WHEEL, DISC (FOR REAR) | ||||
| 42610-55090 |
DA11#,DB10#,FA11#,FB100 T=10,W/8.25 OR 9.00-20 TIRE |
2 | ||
| 42610-55090 |
FA100..RHD;DA11#,DB10#,FA11#,FB100 T=10,W/8.25 OR 9.00-20 TIRE |
2 | ||
| 42601R - WHEEL, DISC (FOR REAR) | ||||
| 42610-55090 |
DA11#,DB10#,FA11#,FB100 T=10,W/8.25 OR 9.00-20 TIRE |
2 | ||
| 42610-55090 |
FA100..RHD;DA11#,DB10#,FA11#,FB100 T=10,W/8.25 OR 9.00-20 TIRE |
2 | ||
| 42601S - RING, DISC WHEEL SIDE (FOR REAR) | ||||
| 42613-55030 |
DA11#,DB10#,FA100,11#,FB100 DISC T=10&11 |
4 | ||
| 42601S - RING, DISC WHEEL SIDE (FOR REAR) | ||||
| 42613-55030 |
DA11#,DB10#,FA100,11#,FB100 DISC T=10&11 |
4 | ||
| 42611A - TIRE TUBE SET OR TUBELESS TIRE | ||||
| 98081-83207 |
DB10# 8.25-20-14 |
6 | ||
| 98081-83207 |
DB10#;DA110..LHD..DMP;DA115,116..LHD..2SR 8.25-20-14 |
6 | ||
| 42621 - CAP, WHEEL | ||||
| 42621-56010 |
DB10#,FB100 |
2 | ||
| Common parts | ||||
| 42621-55010 | ||||
| 42621-56010 | ||||
