DA110L-H (1969)
Toyota Heavy Duty Truck
(6903-8208)FA100,11#,FB100,FC100
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 04315 - LEVER KIT, CLUTCH PRESSURE | ||||
| 04315-55010 |
DA11#,DB105 |
1 | ||
| 04315-55020 |
FA100,11#,FB100,FC100 |
1 | ||
| 04315-55011 |
DA11# |
1 | ||
| 31126 - BOOT, CLUTCH RELEASE FORK | ||||
| 31103-55030 |
DA11#,DB10#,FA100,11#,FB100..5F |
1 | ||
| 31201 - COVER SUB-ASSY, CLUTCH | ||||
| 31211-56010 |
DA11#,DB10# |
1 | ||
| 31211-55011 |
FA100,11#,FB100,FC100 |
1 | ||
| 31210 - COVER ASSY, CLUTCH | ||||
| 31210-55080 |
DA11# |
1 | ||
| 31210-55081 |
DA11# |
1 | ||
| 31210-56010 |
DA11#,DB10# |
1 | ||
| 31210-55070 |
FA100,11#,FB100,FC100 |
1 | ||
| 31221 - PLATE, CLUTCH PRESSURE | ||||
| 31221-55020 |
DA11#,DB10# |
1 | ||
| 31221-55030 |
DA11# |
1 | ||
| 31221-55010 |
FA100,11#,FB100,FC100 |
1 | ||
| 31221-55021 |
DA11#,DB105 |
1 | ||
| 31221-55031 |
DA11# |
1 | ||
| 31221A - SPRING, COMPRESSION(FOR CLUTCH) | ||||
| 90501-50047 |
DA11#,DB10#,FA100,11#,FB100,FC100 |
9 | ||
| 90501-50002 |
DA11# |
12 | ||
| 90501-50003 |
DA11#,DB105,FA100,115 |
9 | ||
| 31222 - LEVER, CLUTCH PRESSURE | ||||
| 31222-55032 |
DA11# |
3 | ||
| 31222-55020 |
FA100,11#,FB100,FC100 |
3 | ||
| 31222-55031 |
DA11#,DB105 |
3 | ||
| 31222-55030 |
DA11#,DB10# |
3 | ||
| 31222A - BOLT, CLUTCH PRESSURE LEVER ADJUST | ||||
| 90106-10004 |
DA11# |
3 | ||
| 90106-08005 |
DA11#,DB10#,FA100,11#,FB100,FC100 |
3 | ||
| 31222B - PIN, W/HOLE(FOR CLUTCH PRESSURE LEVER) | ||||
| 90240-08011 |
FA100,11#,FB100,FC100 |
3 | ||
| 90245-09002 |
DA11#,DB10# |
3 | ||
| 90240-09160 |
DA11#,DB105 |
3 | ||
| 31222C - ROLLER OR BEARING, CLUTCH PRESSURE PLATE PIN | ||||
| 90361-02019 |
FA100,11#,FB100,FC100 |
45 | ||
| 90361-02006 |
DA11#,DB10# |
51 | ||
| 90364-09073 |
DA11#,DB105 |
3 | ||
| 31223 - YOKE, CLUTCH RELEASE LEVER | ||||
| 31223-55032 |
DA11# |
3 | ||
| 31223-55030 |
DA11#,DB10# |
3 | ||
| 31223-55040 |
FA100,11#,FB100,FC100 |
3 | ||
| 31223-55031 |
DA11#,DB10# |
3 | ||
| 31223A - PIN(FOR CLUTCH PRESSURE LEVER) | ||||
| 90249-08105 |
DA11# |
3 | ||
| 90249-06003 |
FA100,11#,FB100,FC100 |
3 | ||
| 90249-08004 |
DA11#,DB10# |
3 | ||
| 31223B - ROLLER, CLUTCH PRESSURE LEVER | ||||
| 90361-06005 |
DA11#,DB10# |
3 | ||
| 90361-06020 |
FA100,11#,FB100,FC100 |
3 | ||
| 31226 - BOLT, CLUTCH PRESSURE PLATE | ||||
| 90101-10077 |
FA100,11#,FB100,FC100 |
3 | ||
| 90101-12092 |
DA11#,DB10# |
3 | ||
| 90101-12286 |
DA11#,DB105 |
3 | ||
| 31226 - BOLT, CLUTCH PRESSURE PLATE | ||||
| 90101-10077 |
FA100,11#,FB100,FC100 |
3 | ||
| 90101-12092 |
DA11#,DB10# |
3 | ||
| 90101-12286 |
DA11#,DB105 |
3 | ||
| 31231 - HUB, CLUTCH RELEASE BEARING | ||||
| 31231-55023 |
DA11#,DB10#,FA100,11#,FB100..5F |
1 | ||
| 31231A - BEARING, BALL(FOR CLUTCH RELEASE HUB) | ||||
| 90363-52018 |
DA11#,DB10#,FA100,11#,FB100,FC100 |
1 | ||
| 31236 - BALL, RELEASE FORK | ||||
| 31236-55902 |
DA11#,DB10#,FA100,11#,FB100,FC100 |
1 | ||
| 31236-55902 |
DA11#,DB10# |
1 | ||
| 31238 - HANGER, RELEASE FORK RETRACTING SPRING | ||||
| 31238-55010 |
FA100,11#,FB100,FC100 |
1 | ||
| 31240 - FORK ASSY, CLUTCH RELEASE | ||||
| 31204-55041 |
DA11#,DB10#,FA100,11#,FB100,FC100 |
1 | ||
| 31240A - SPRING, TENSION(FOR CLUTCH RELEASE FORK RETURN) | ||||
| 90506-18101 |
DA11#,DB10#,FA100,11#,FB100,FC100 |
1 | ||
| 90506-18189 |
DA11#,DB10#,FA100,11#,FB100,FC100 |
1 | ||
| 31250 - DISC ASSY, CLUTCH | ||||
| 31250-55044 |
DA11#,DB10# |
1 | ||
| 31250-55032 |
FA100,11#,FC100 |
1 | ||
| 31250-55031 |
FA100,11#,FB100,FC100 |
1 | ||
| 31250-55045 |
DA11#,DB10# |
1 | ||
| 31250-55046 |
DA11#,DB105 |
1 | ||
| 31250-55090 |
DA11# |
1 | ||
| 31250-55100 |
DA11# |
1 | ||
| 31250-55101 |
DA11# |
1 | ||
| 33311W - BEARING (FOR INPUT SHAFT) | ||||
| 97110-06202 |
DA11#,DB10#,FA100,11#,FB100,FC100 6202ZC3 |
1 | ||
| 97110-06202 |
FA100,11#,FC100 6202ZC3 |
1 | ||
| 97120-06202 |
DA11#,DB10# 6202ZZ |
1 | ||
| 90363-15004 |
DA11# |
1 | ||
| 90363-15004 |
DA11#,FA100,115 |
1 | ||
| Common parts | ||||
| 90119-08134 | ||||
| 91611-40612 | ||||
| 91611-40820 | ||||
| 94120-40800 | ||||
| 94523-01000 | ||||
| 95381-02012 | ||||
(6903- )DA11#,DB10#
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 04315 - LEVER KIT, CLUTCH PRESSURE | ||||
| 04315-55010 |
DA11#,DB105 |
1 | ||
| 04315-55020 |
FA100,11#,FB100,FC100 |
1 | ||
| 04315-55011 |
DA11# |
1 | ||
| 31126 - BOOT, CLUTCH RELEASE FORK | ||||
| 31103-55030 |
DA11#,DB10#,FA100,11#,FB100..5F |
1 | ||
| 31126 - BOOT, CLUTCH RELEASE FORK | ||||
| 31103-55030 |
DA11#,DB10#,FA100,11#,FB100..5F |
1 | ||
| 31201 - COVER SUB-ASSY, CLUTCH | ||||
| 31211-56010 |
DA11#,DB10# |
1 | ||
| 31211-55011 |
FA100,11#,FB100,FC100 |
1 | ||
| 31210 - COVER ASSY, CLUTCH | ||||
| 31210-55080 |
DA11# |
1 | ||
| 31210-55081 |
DA11# |
1 | ||
| 31210-56010 |
DA11#,DB10# |
1 | ||
| 31210-55070 |
FA100,11#,FB100,FC100 |
1 | ||
| 31221 - PLATE, CLUTCH PRESSURE | ||||
| 31221-55020 |
DA11#,DB10# |
1 | ||
| 31221-55030 |
DA11# |
1 | ||
| 31221-55010 |
FA100,11#,FB100,FC100 |
1 | ||
| 31221-55021 |
DA11#,DB105 |
1 | ||
| 31221-55031 |
DA11# |
1 | ||
| 31221A - SPRING, COMPRESSION(FOR CLUTCH) | ||||
| 90501-50047 |
DA11#,DB10#,FA100,11#,FB100,FC100 |
9 | ||
| 90501-50002 |
DA11# |
12 | ||
| 90501-50003 |
DA11#,DB105,FA100,115 |
9 | ||
| 31222 - LEVER, CLUTCH PRESSURE | ||||
| 31222-55032 |
DA11# |
3 | ||
| 31222-55020 |
FA100,11#,FB100,FC100 |
3 | ||
| 31222-55031 |
DA11#,DB105 |
3 | ||
| 31222-55030 |
DA11#,DB10# |
3 | ||
| 31222A - BOLT, CLUTCH PRESSURE LEVER ADJUST | ||||
| 90106-10004 |
DA11# |
3 | ||
| 90106-08005 |
DA11#,DB10#,FA100,11#,FB100,FC100 |
3 | ||
| 31222B - PIN, W/HOLE(FOR CLUTCH PRESSURE LEVER) | ||||
| 90240-08011 |
FA100,11#,FB100,FC100 |
3 | ||
| 90245-09002 |
DA11#,DB10# |
3 | ||
| 90240-09160 |
DA11#,DB105 |
3 | ||
| 31222B - PIN, W/HOLE(FOR CLUTCH PRESSURE LEVER) | ||||
| 90240-08011 |
FA100,11#,FB100,FC100 |
3 | ||
| 90245-09002 |
DA11#,DB10# |
3 | ||
| 90240-09160 |
DA11#,DB105 |
3 | ||
| 31222C - ROLLER OR BEARING, CLUTCH PRESSURE PLATE PIN | ||||
| 90361-02019 |
FA100,11#,FB100,FC100 |
45 | ||
| 90361-02006 |
DA11#,DB10# |
51 | ||
| 90364-09073 |
DA11#,DB105 |
3 | ||
| 31222C - ROLLER OR BEARING, CLUTCH PRESSURE PLATE PIN | ||||
| 90361-02019 |
FA100,11#,FB100,FC100 |
45 | ||
| 90361-02006 |
DA11#,DB10# |
51 | ||
| 90364-09073 |
DA11#,DB105 |
3 | ||
| 31223 - YOKE, CLUTCH RELEASE LEVER | ||||
| 31223-55032 |
DA11# |
3 | ||
| 31223-55030 |
DA11#,DB10# |
3 | ||
| 31223-55040 |
FA100,11#,FB100,FC100 |
3 | ||
| 31223-55031 |
DA11#,DB10# |
3 | ||
| 31223A - PIN(FOR CLUTCH PRESSURE LEVER) | ||||
| 90249-08105 |
DA11# |
3 | ||
| 90249-06003 |
FA100,11#,FB100,FC100 |
3 | ||
| 90249-08004 |
DA11#,DB10# |
3 | ||
| 31223B - ROLLER, CLUTCH PRESSURE LEVER | ||||
| 90361-06005 |
DA11#,DB10# |
3 | ||
| 90361-06020 |
FA100,11#,FB100,FC100 |
3 | ||
| 31226 - BOLT, CLUTCH PRESSURE PLATE | ||||
| 90101-10077 |
FA100,11#,FB100,FC100 |
3 | ||
| 90101-12092 |
DA11#,DB10# |
3 | ||
| 90101-12286 |
DA11#,DB105 |
3 | ||
| 31231 - HUB, CLUTCH RELEASE BEARING | ||||
| 31231-55023 |
DA11#,DB10#,FA100,11#,FB100..5F |
1 | ||
| 31231A - BEARING, BALL(FOR CLUTCH RELEASE HUB) | ||||
| 90363-52018 |
DA11#,DB10#,FA100,11#,FB100,FC100 |
1 | ||
| 31236 - BALL, RELEASE FORK | ||||
| 31236-55902 |
DA11#,DB10#,FA100,11#,FB100,FC100 |
1 | ||
| 31236-55902 |
DA11#,DB10# |
1 | ||
| 31240 - FORK ASSY, CLUTCH RELEASE | ||||
| 31204-55041 |
DA11#,DB10#,FA100,11#,FB100,FC100 |
1 | ||
| 31240A - SPRING, TENSION(FOR CLUTCH RELEASE FORK RETURN) | ||||
| 90506-18101 |
DA11#,DB10#,FA100,11#,FB100,FC100 |
1 | ||
| 90506-18189 |
DA11#,DB10#,FA100,11#,FB100,FC100 |
1 | ||
| 31250 - DISC ASSY, CLUTCH | ||||
| 31250-55044 |
DA11#,DB10# |
1 | ||
| 31250-55032 |
FA100,11#,FC100 |
1 | ||
| 31250-55031 |
FA100,11#,FB100,FC100 |
1 | ||
| 31250-55045 |
DA11#,DB10# |
1 | ||
| 31250-55046 |
DA11#,DB105 |
1 | ||
| 31250-55090 |
DA11# |
1 | ||
| 31250-55100 |
DA11# |
1 | ||
| 31250-55101 |
DA11# |
1 | ||
| 33311W - BEARING (FOR INPUT SHAFT) | ||||
| 97110-06202 |
DA11#,DB10#,FA100,11#,FB100,FC100 6202ZC3 |
1 | ||
| 97110-06202 |
FA100,11#,FC100 6202ZC3 |
1 | ||
| 97120-06202 |
DA11#,DB10# 6202ZZ |
1 | ||
| 90363-15004 |
DA11# |
1 | ||
| 90363-15004 |
DA11#,FA100,115 |
1 | ||
| Common parts | ||||
| 90170-10018 | ||||
| 91611-40612 | ||||
| 91611-40820 | ||||
| 91611-61020 | ||||
| 91651-40612 | ||||
| 94120-40800 | ||||
| 94523-01200 | ||||
| 95381-02015 | ||||
