DA110D-Q (1969)
Toyota Heavy Duty Truck
(6903-7704)2D
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 11106 - CHAMBER SUB-ASSY, COMBUSTION | ||||
| 11106-76012 |
2D..DA11#,DB105 |
6 | ||
| 11106-77010 |
2D..DA11# |
6 | ||
| 11106-77011 |
2D..DA11# |
6 | ||
| 11106-76013 |
2D..DA11#,DB105 |
6 | ||
| 11106-76010 |
2D..DA11#,DB10# |
6 | ||
| 11106-76015 |
2D..DA11#,DB105 |
6 | ||
| 11106-76014 |
2D..DA11#,DB105 |
6 | ||
| 11106A - GASKET(FOR COMBUSTION CHAMBER) | ||||
| 90430-32001 |
2D..DA11#,DB105 |
6 | ||
| 90430-32217 |
2D..DA11#,DB10# W/MECHANICAL GOVERNOR |
6 | ||
| 11168-77010 |
2D..DA11# |
6 | ||
| 90430-32217 |
2D..DA11#,DB10# |
6 | ||
| 90430-32050 |
2D..DA11#,DB10# |
6 | ||
| 11167 - CLAMP, COMBUSTION CHAMBER | ||||
| 11167-76010 |
2D..DA11#,DB10# |
6 | ||
| 11167-76011 |
2D..DA11#,DB105 |
6 | ||
| 11171 - FLANGE, COMBUSTION CHAMBER SET | ||||
| 11171-76010 |
2D..DA11#,DB10# |
6 | ||
| 11172 - FLANGE, INJECTION NOZZLE SET | ||||
| 11172-76011 |
2D..DA11#,DB10# |
6 | ||
| 11176 - SEAT, INJECTION NOZZLE | ||||
| 11176-76011 |
2D..DA11#,DB10# |
6 | ||
| 11176-77010 |
2D..DA11# |
6 | ||
| 11176-76013 |
2D..DA11#,DB105 |
6 | ||
| 11176-76012 |
2D..DA11#,DB105 |
6 | ||
| 11176A - GASKET(FOR INJECTION NOZZLE SEAT) | ||||
| 90430-26001 |
2D..DA11#,DB105 |
6 | ||
| 90430-26117 |
2D..DA11#,DB10# |
6 | ||
| 11177 - GASKET, INJECTION NOZZLE SEAT | ||||
| 11177-77013 |
2D..DA11#,DB105 |
6 | ||
| 11177-77012 |
2D..DA11#,DB105 |
6 | ||
| 11177-47010 |
2D..DA11# |
6 | ||
| 11177-76010 |
2D..DA11#,DB10# |
6 | ||
| 11177-77010 |
2D..DA11#,DB10# |
6 | ||
| 11177-77011 |
2D..DA11#,DB105 |
6 | ||
| 11195 - BOLT, NOZZLE SET, STUD | ||||
| 11195-76010 |
2D..DA11#,DB10# |
12 | ||
| 23600 - HOLDER & NOZZLE SET, NOZZLE | ||||
| 23600-76013 |
2D..DA11#,DB105 |
6 | ||
| 23600-76010 |
2D..DA11#,DB10# |
6 | ||
| 23600-76011 |
2D..DA11#,DB10# |
6 | ||
| 23600-76012 |
2D..DA11#,DB105 |
6 | ||
| 23600-77010 |
2D..DA11# |
6 | ||
| 23601 - CONNECTOR SUB-ASSY, NOZZLE HOLDER | ||||
| 23601-76010 |
2D..DA11#,DB10# |
6 | ||
| 23613 - NUT, NOZZLE HOLDER CAP | ||||
| 23613-67010 |
2D..DA11# |
6 | ||
| 23613-76010 |
2D..DA11#,DB10# |
6 | ||
| 23614 - SCREW, NOZZLE HOLDER ADJUSTING | ||||
| 23614-67010 |
2D..DA11# |
6 | ||
| 23614-76010 |
2D..DA11#,DB10# |
6 | ||
| 23615 - NUT, NOZZLE HOLDER ADJUSTING | ||||
| 23615-76010 |
2D..DA11#,DB10# |
6 | ||
| 23616 - SCREW, CAP NOZZLE HOLDER | ||||
| 23616-76010 |
2D..DA11#,DB10# |
6 | ||
| 23616-77021 |
2D..DA11#,DB105 |
6 | ||
| 23617 - SEAT, PRESSURE SPRING | ||||
| 23617-76010 |
2D..DA11#,DB10# |
6 | ||
| 23617-77021 |
2D..DA11#,DB105 |
6 | ||
| 23618 - SPRING, NOZZLE HOLDER PRESSURE | ||||
| 23618-46010 |
2D..DA11# |
6 | ||
| 90501-40134 |
2D..DA11#,DB10# |
6 | ||
| 23619 - PIN, NOZZLE HOLDER PRESSURE | ||||
| 23619-77020 |
2D..DA11#,DB105 |
6 | ||
| 23619-67010 |
2D..DA11# |
6 | ||
| 23619-76010 |
2D..DA11#,DB10# |
6 | ||
| 23620 - NOZZLE ASSY | ||||
| 23620-54010 |
2D..DA11# |
6 | ||
| 23620-76010 |
2D..DA11#,DB10# |
6 | ||
| 23621 - GASKET, NOZZLE HOLDER CAP NUT | ||||
| 23621-76010 |
2D..DA11#,DB10# |
6 | ||
| 23621-77020 |
2D..DA11#,DB105 |
6 | ||
| 23622 - GASKET, NOZZLE HOLDER CONNECT | ||||
| 23622-76010 |
2D..DA11#,DB10# |
6 | ||
| 23622-77020 |
2D..DA11#,DB105 |
6 | ||
| 23624 - NUT, NOZZLE RETAINING | ||||
| 23624-76010 |
2D..DA11#,DB10# |
6 | ||
| 23624-77020 |
2D..DA11#,DB10# |
6 | ||
| 23624-77010 |
2D..DA11# |
6 | ||
| Common parts | ||||
| 90201-08106 | ||||
| 90401-08009 | ||||
| 94110-41000 | ||||
| 94512-01000 | ||||
(7704- )2D
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 11106 - CHAMBER SUB-ASSY, COMBUSTION | ||||
| 11106-76012 |
2D..DA11#,DB105 |
6 | ||
| 11106-77010 |
2D..DA11# |
6 | ||
| 11106-77011 |
2D..DA11# |
6 | ||
| 11106-76013 |
2D..DA11#,DB105 |
6 | ||
| 11106-76010 |
2D..DA11#,DB10# |
6 | ||
| 11106-76015 |
2D..DA11#,DB105 |
6 | ||
| 11106-76014 |
2D..DA11#,DB105 |
6 | ||
| 11176 - SEAT, INJECTION NOZZLE | ||||
| 11176-76011 |
2D..DA11#,DB10# |
6 | ||
| 11176-77010 |
2D..DA11# |
6 | ||
| 11176-76013 |
2D..DA11#,DB105 |
6 | ||
| 11176-76012 |
2D..DA11#,DB105 |
6 | ||
| 11177 - GASKET, INJECTION NOZZLE SEAT | ||||
| 11177-77013 |
2D..DA11#,DB105 |
6 | ||
| 11177-77012 |
2D..DA11#,DB105 |
6 | ||
| 11177-47010 |
2D..DA11# |
6 | ||
| 11177-76010 |
2D..DA11#,DB10# |
6 | ||
| 11177-77010 |
2D..DA11#,DB10# |
6 | ||
| 11177-77011 |
2D..DA11#,DB105 |
6 | ||
| 23600 - HOLDER & NOZZLE SET, NOZZLE | ||||
| 23600-76013 |
2D..DA11#,DB105 |
6 | ||
| 23600-76010 |
2D..DA11#,DB10# |
6 | ||
| 23600-76011 |
2D..DA11#,DB10# |
6 | ||
| 23600-76012 |
2D..DA11#,DB105 |
6 | ||
| 23600-77010 |
2D..DA11# |
6 | ||
| 23600 - HOLDER & NOZZLE SET, NOZZLE | ||||
| 23600-76013 |
2D..DA11#,DB105 |
6 | ||
| 23600-76010 |
2D..DA11#,DB10# |
6 | ||
| 23600-76011 |
2D..DA11#,DB10# |
6 | ||
| 23600-76012 |
2D..DA11#,DB105 |
6 | ||
| 23600-77010 |
2D..DA11# |
6 | ||
| 23612 - WASHER, COPPER PLATE | ||||
| 23612-77020 |
2D..DA11# |
12 | ||
| 23612 - WASHER, COPPER PLATE | ||||
| 23612-77020 |
2D..DA11# |
12 | ||
| 23613 - NUT, NOZZLE HOLDER CAP | ||||
| 23613-67010 |
2D..DA11# |
6 | ||
| 23613-76010 |
2D..DA11#,DB10# |
6 | ||
| 23614 - SCREW, NOZZLE HOLDER ADJUSTING | ||||
| 23614-67010 |
2D..DA11# |
6 | ||
| 23614-76010 |
2D..DA11#,DB10# |
6 | ||
| 23618 - SPRING, NOZZLE HOLDER PRESSURE | ||||
| 23618-46010 |
2D..DA11# |
6 | ||
| 90501-40134 |
2D..DA11#,DB10# |
6 | ||
| 23619 - PIN, NOZZLE HOLDER PRESSURE | ||||
| 23619-77020 |
2D..DA11#,DB105 |
6 | ||
| 23619-67010 |
2D..DA11# |
6 | ||
| 23619-76010 |
2D..DA11#,DB10# |
6 | ||
| 23620 - NOZZLE ASSY | ||||
| 23620-54010 |
2D..DA11# |
6 | ||
| 23620-76010 |
2D..DA11#,DB10# |
6 | ||
| 23624 - NUT, NOZZLE RETAINING | ||||
| 23624-76010 |
2D..DA11#,DB10# |
6 | ||
| 23624-77020 |
2D..DA11#,DB10# |
6 | ||
| 23624-77010 |
2D..DA11# |
6 | ||
| 23627A - SCREW, FOLLOW(FOR NOZZLE) | ||||
| 90099-18017 |
2D..DA11# |
6 | ||
| 23654 - WASHER(FOR RING PACKING) | ||||
| 23654-67010 |
2D..DA11# |
6 | ||
| 23655 - SCREW, CYLINDER | ||||
| 23655-77010 |
2D..DA11# |
6 | ||
