TGN61R-EKPSKD (2006)
Toyota Fortuner
(0501-0611)KUN61,TGN61..SR ; (0501-0611)GGN50,60,KUN5#,60,LAN50,TGN51
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 81210 - LAMP ASSY, FOG | ||||
| 81210-0K050 |
TGN61..SR;KUN61,TGN51..RHD;GGN50,60,KUN5#,60..ANCOM,IDN,LA,MA,PHL,SA,TH |
1 | ||
| 81210B - BULB, FOG LAMP | ||||
| 90981-13047 |
TGN61..IDSUV..IDN;GGN60,TGN51..ANCOM,IDN,MA,TH;GGN50,KUN50,61..(5F,5FC)..(ANCOM,GEN,MA,SA);GGN60,KUN51,60,TGN61..(SUVW,THSUV)..(4FC,5F)..SR..(GEN,IDN,LA,PHL,SA,TH) 12V 51W,HALOGEN |
2 | ||
| 81210B - BULB, FOG LAMP | ||||
| 90981-13047 |
TGN61..IDSUV..IDN;GGN60,TGN51..ANCOM,IDN,MA,TH;GGN50,KUN50,61..(5F,5FC)..(ANCOM,GEN,MA,SA);GGN60,KUN51,60,TGN61..(SUVW,THSUV)..(4FC,5F)..SR..(GEN,IDN,LA,PHL,SA,TH) 12V 51W,HALOGEN |
2 | ||
| 81211C - LAMP UNIT, FOG LAMP, RH | ||||
| 81211-0D070 |
TGN61..IDSUV..IDN;GGN60,TGN51..ANCOM,IDN,MA,TH;GGN50,KUN50,61..(5F,5FC)..(ANCOM,GEN,MA,SA);GGN60,KUN51,60,TGN61..(SUVW,THSUV)..(4FC,5F)..SR..(GEN,IDN,LA,PHL,SA,TH) |
1 | ||
| 81212E - BACK COVER, FOG LAMP | ||||
| 81212-0K050 |
TGN61..SR;KUN61,TGN51..RHD;GGN50,60,KUN5#,60..ANCOM,IDN,LA,MA,PHL,SA,TH |
1 | ||
| 81219A - BRACKET, FOG LAMP, RH | ||||
| 81219-0K051 |
TGN51..IDN;GGN50,KUN51,60,TGN61..GEN,IDN,PHL,TH |
1 | ||
| 81220 - LAMP ASSY, FOG, LH | ||||
| 81220-0K050 |
TGN61..IDSUV..IDN;GGN60,TGN51..ANCOM,IDN,MA,TH;GGN50,KUN50,61..(5F,5FC)..(ANCOM,GEN,MA,SA);GGN60,KUN51,60,TGN61..(SUVW,THSUV)..(4FC,5F)..SR..(GEN,IDN,LA,PHL,SA,TH) |
1 | ||
| 81221C - LAMP UNIT, FOG LAMP, LH | ||||
| 81221-0D070 |
TGN61..IDSUV..IDN;GGN60,TGN51..ANCOM,IDN,MA,TH;GGN50,KUN50,61..(5F,5FC)..(ANCOM,GEN,MA,SA);GGN60,KUN51,60,TGN61..(SUVW,THSUV)..(4FC,5F)..SR..(GEN,IDN,LA,PHL,SA,TH) |
1 | ||
| 81229A - BRACKET, FOG LAMP, LH | ||||
| 81229-0K050 |
TGN51..IDN;GGN50,KUN51,60,TGN61..GEN,IDN,PHL,TH |
1 | ||
| Common parts | ||||
| 90119-T0162 | ||||
| 90119-T0229 | ||||
| 90179-06127 | ||||
(0611- )
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 81210 - LAMP ASSY, FOG | ||||
| 81210-0K050 |
TGN61..SR;KUN61,TGN51..RHD;GGN50,60,KUN5#,60..ANCOM,IDN,LA,MA,PHL,SA,TH |
1 | ||
| 81210B - BULB, FOG LAMP | ||||
| 90981-13047 |
TGN61..IDSUV..IDN;GGN60,TGN51..ANCOM,IDN,MA,TH;GGN50,KUN50,61..(5F,5FC)..(ANCOM,GEN,MA,SA);GGN60,KUN51,60,TGN61..(SUVW,THSUV)..(4FC,5F)..SR..(GEN,IDN,LA,PHL,SA,TH) 12V 51W,HALOGEN |
2 | ||
| 81211C - LAMP UNIT, FOG LAMP, RH | ||||
| 81211-0D070 |
TGN61..IDSUV..IDN;GGN60,TGN51..ANCOM,IDN,MA,TH;GGN50,KUN50,61..(5F,5FC)..(ANCOM,GEN,MA,SA);GGN60,KUN51,60,TGN61..(SUVW,THSUV)..(4FC,5F)..SR..(GEN,IDN,LA,PHL,SA,TH) |
1 | ||
| 81219A - BRACKET, FOG LAMP, RH | ||||
| 81219-0K051 |
TGN51..IDN;GGN50,KUN51,60,TGN61..GEN,IDN,PHL,TH |
1 | ||
| 81220 - LAMP ASSY, FOG, LH | ||||
| 81220-0K050 |
TGN61..IDSUV..IDN;GGN60,TGN51..ANCOM,IDN,MA,TH;GGN50,KUN50,61..(5F,5FC)..(ANCOM,GEN,MA,SA);GGN60,KUN51,60,TGN61..(SUVW,THSUV)..(4FC,5F)..SR..(GEN,IDN,LA,PHL,SA,TH) |
1 | ||
| 81221C - LAMP UNIT, FOG LAMP, LH | ||||
| 81221-0D070 |
TGN61..IDSUV..IDN;GGN60,TGN51..ANCOM,IDN,MA,TH;GGN50,KUN50,61..(5F,5FC)..(ANCOM,GEN,MA,SA);GGN60,KUN51,60,TGN61..(SUVW,THSUV)..(4FC,5F)..SR..(GEN,IDN,LA,PHL,SA,TH) |
1 | ||
| 81229A - BRACKET, FOG LAMP, LH | ||||
| 81229-0K050 |
TGN51..IDN;GGN50,KUN51,60,TGN61..GEN,IDN,PHL,TH |
1 | ||
| Common parts | ||||
| 90119-T0162 | ||||
| 90119-T0229 | ||||
| 90179-06127 | ||||
(1107- )
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| Linked diagrams | ||||
| 5252 | ||||
