KUN61R-NKPSYT (2008)
Toyota Fortuner
Production
Aug 2008
-
Jul 2011
Engine
1KDFTV
Transmission
Displacement
2500cc
Power
168 HP (125 kW)
(0501- )TGN51,61..RHD
Click highlighted areas on diagram
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 85915S - RELAY, HEATER (FOR AIR FUEL RATIO SENSOR) | ||||
| 90987-T2001 |
GGN50;GGN60,TGN61..(5F,5FC)..(ANCOM,LA);GGN60,TGN51,61..RHD..(4FC,5F)..(SA,TH) |
1 | ||
| 89422 - SENSOR, WATER TEMPERATURE (FOR E.F.I.) | ||||
| 89422-33030 |
TGN51,61;GGN50..LHD;GGN50..5FC..SA;GGN60..SUVW..5FC |
1 | ||
| 89667 - BRACKET, ENGINE CONTROL COMPUTER | ||||
| 89667-0K010 |
GGN50,60,TGN51,61..RHD |
1 | ||
| 89668 - BRACKET, ENGINE CONTROL COMPUTER, NO.2 | ||||
| 89668-0K010 |
GGN50,60,TGN51,61..RHD |
1 | ||
| 89879 - BRACKET, INJECTOR DRIVER | ||||
| 89879-71010 |
TGN51,61..TH |
1 | ||
| Common parts | ||||
| 90105-T0066 | ||||
| 90119-06915 | ||||
| 90159-T0001 | ||||
| 90178-T0018 | ||||
| 90179-06110 | ||||
| 90430-12005 | ||||
| 93319-14008 | ||||
| Linked diagrams | ||||
| 8401 | ||||
(1107- )TGN51,61..RHD
Click highlighted areas on diagram
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| Common parts | ||||
| 90105-T0066 | ||||
| 90119-06915 | ||||
| 90159-T0001 | ||||
| 90178-T0018 | ||||
| 90179-06110 | ||||
| 90430-12005 | ||||
| 93319-14008 | ||||
| Linked diagrams | ||||
| 8401 | ||||
