KUN50R-NKPDHE (2008)
Toyota Fortuner
(0501- )GGN50,KUN5#,LAN50,TGN51
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 33368B - RING, SYNCHRONIZER (FOR TRANSFER FRONT DRIVE CLUTCH) | ||||
| 33367-60130 |
KUN50 |
1 | ||
| 33371B - SPRING, SYNCHROMESH SHIFTING KEY (FOR TRANSFER) | ||||
| 33371-36030 |
KUN50 |
2 | ||
| 33371B - SPRING, SYNCHROMESH SHIFTING KEY (FOR TRANSFER) | ||||
| 33371-36030 |
KUN50 |
2 | ||
| 33481P - GEAR, SPEEDOMETER DRIVE (FOR TRANSFER) | ||||
| 33481-60130 |
KUN50 N=11 |
1 | ||
| 36205 - SPROCKET SUB-ASSY, TRANSFER DRIVE | ||||
| 36205-60020 |
KUN50,TGN51..MA |
1 | ||
| 36210A - BEARING (FOR TRANSFER INPUT SHAFT) | ||||
| 90363-75001 |
KUN50,TGN51..MA |
1 | ||
| 36211 - SHAFT, TRANSFER INPUT | ||||
| 36201-60030 |
KUN50 |
1 | ||
| 36212A - BEARING, RADIAL BALL (FOR TRANSFER INPUT GEAR) | ||||
| 90363-28013 |
KUN50,TGN51..MA |
1 | ||
| 36212D - RING, SHAFT SNAP (FOR TRANSFER INPUT BEARING) | ||||
| 90520-72004 |
KUN50,TGN51..MA T=1.60,MARK 4 |
1 | ||
| 90520-72002 |
KUN50,TGN51..MA T=1.50,MARK 2 |
1 | ||
| 90520-72001 |
KUN50,TGN51..MA T=1.45,MARK 1 |
1 | ||
| 90520-72005 |
KUN50,TGN51..MA T=1.65,MARK 5 |
1 | ||
| 90520-72003 |
KUN50,TGN51..MA T=1.55,MARK 3 |
1 | ||
| 36213 - STOPPER, TRANSFER INPUT GEAR | ||||
| 36213-35020 |
KUN50,TGN51..MA |
1 | ||
| 36213A - BALL (FOR TRANSFER INPUT GEAR STOPPER) | ||||
| 90360-05012 |
KUN50,TGN51..MA |
1 | ||
| 36213B - RING, SHAFT SNAP (FOR TRANSFER INPUT GEAR STOPPER) | ||||
| 90520-44003 |
KUN50,TGN51..MA T=2.10-2.15 |
1 | ||
| 90520-44005 |
KUN50,TGN51..MA T=2.20-2.25 |
1 | ||
| 90520-44008 |
KUN50,TGN51..MA T=2.35-2.40 |
1 | ||
| 90520-44004 |
KUN50,TGN51..MA T=2.15-2.20 |
1 | ||
| 90520-44009 |
KUN50,TGN51..MA T=2.40-2.45 |
1 | ||
| 90520-44014 |
KUN50,TGN51..MA T=2.65-2.70 |
1 | ||
| 90520-44010 |
KUN50,TGN51..MA T=2.45-2.50 |
1 | ||
| 90520-44007 |
KUN50,TGN51..MA T=2.30-2.35 |
1 | ||
| 90520-44012 |
KUN50,TGN51..MA T=2.55-2.60 |
1 | ||
| 90520-44006 |
KUN50,TGN51..MA T=2.25-2.30 |
1 | ||
| 90520-44011 |
KUN50,TGN51..MA T=2.50-2.55 |
1 | ||
| 90520-44015 |
KUN50,TGN51..MA T=2.70-2.75 |
1 | ||
| 90520-44013 |
KUN50,TGN51..MA T=2.60-2.65 |
1 | ||
| 90520-44016 |
KUN50,TGN51..MA T=2.75-2.80 |
1 | ||
| 90520-44018 |
KUN50,TGN51..MA T=2.85-2.90 |
1 | ||
| 90520-44020 |
KUN50,TGN51..MA T=2.95-3.00 |
1 | ||
| 90520-44017 |
KUN50,TGN51..MA T=2.80-2.85 |
1 | ||
| 90520-44021 |
KUN50,TGN51..MA T=3.00-3.05 |
1 | ||
| 90520-44019 |
KUN50,TGN51..MA T=2.90-2.95 |
1 | ||
| 36216A - RING, TRANSFER INPUT SHAFT SEAL, NO.1 | ||||
| 36216-35011 |
KUN50,TGN51..MA |
2 | ||
| 36216A - RING, TRANSFER INPUT SHAFT SEAL, NO.1 | ||||
| 36216-35011 |
KUN50,TGN51..MA |
2 | ||
| 36231 - SHAFT, TRANSFER OUTPUT, REAR | ||||
| 36231-35050 |
KUN50,TGN51..MA |
1 | ||
| 36231A - SPACER (FOR TRANSFER OUTPUT SHAFT) | ||||
| 90560-28004 |
KUN50,TGN51..MA T=4.0 |
1 | ||
| 36231D - WASHER, PLATE (FOR TRANSFER OUTPUT SHAFT) | ||||
| 36275-35020 |
KUN50,TGN51..MA |
2 | ||
| 36231D - WASHER, PLATE (FOR TRANSFER OUTPUT SHAFT) | ||||
| 36275-35020 |
KUN50,TGN51..MA |
2 | ||
| 36231E - BEARING, NEEDLE ROLLER (FOR TRANSFER OUTPUT SHAFT FRONT | ||||
| 90364-35009 |
KUN50,TGN51..MA NO.2 |
1 | ||
| 90364-28004 |
KUN50,TGN51..MA NO.1 |
1 | ||
| 36231E - BEARING, NEEDLE ROLLER (FOR TRANSFER OUTPUT SHAFT FRONT | ||||
| 90364-35009 |
KUN50,TGN51..MA NO.2 |
1 | ||
| 90364-28004 |
KUN50,TGN51..MA NO.1 |
1 | ||
| 36231F - RING, SHAFT SNAP (FOR TRANSFER OUTPUT SHAFT) | ||||
| 90520-82001 |
KUN50,TGN51..MA T=1.65 |
1 | ||
| 36231J - BEARING, RADIAL BALL (FOR TRANSFER OUTPUT SHAFT REAR) | ||||
| 90363-32040 |
KUN50,TGN51..MA |
1 | ||
| 36235 - SLEEVE, TRANSFER HIGH & LOW CLUTCH | ||||
| 36235-35030 |
KUN50,TGN51..MA |
1 | ||
| 36236 - SLEEVE, FRONT DRIVE CLUTCH | ||||
| 36236-60080 |
KUN50,TGN51..MA |
1 | ||
| 36237 - HUB, TRANSFER CLUTCH | ||||
| 36237-60060 |
KUN50,TGN51..MA |
1 | ||
| 36249 - KEY, SYNCHROMESH SHIFTING, TRANSFER DRIVE, NO.2 | ||||
| 36249-60030 |
KUN50 |
3 | ||
| 36255 - SPACER, TRANSFER OUTPUT SHAFT, NO.1 | ||||
| 36255-35030 |
KUN50,TGN51..MA |
1 | ||
| 36255A - BALL (FOR TRANSFER OUTPUT SHAFT SPACER) | ||||
| 90360-05012 |
KUN50,TGN51..MA |
1 | ||
| 36256 - SPACER, TRANSFER OUTPUT SHAFT, NO.2 | ||||
| 36256-35030 |
KUN50,TGN51..MA |
1 | ||
| 36270 - GEAR ASSY, TRANSFER LOW PLANETARY | ||||
| 36270-35040 |
KUN50,TGN51..MA |
1 | ||
| 36270A - BEARING (FOR TRANSFER LOW PLANETARY GEAR) | ||||
| 90364-47001 |
KUN50,TGN51..MA NO.1 |
1 | ||
| 90374-49001 |
KUN50,TGN51..MA NO.2 |
1 | ||
| 36270A - BEARING (FOR TRANSFER LOW PLANETARY GEAR) | ||||
| 90364-47001 |
KUN50,TGN51..MA NO.1 |
1 | ||
| 90374-49001 |
KUN50,TGN51..MA NO.2 |
1 | ||
| 36270B - RING, SHAFT SNAP (FOR TRANSFER LOW PLANETARY GEAR) | ||||
| 90520-99078 |
KUN50,TGN51..MA T=6.0 |
1 | ||
| 36270C - RING, SHAFT SNAP(FOR TRANSFER LOW PLANETARY GEAR BEARIN | ||||
| 90520-99072 |
KUN50,TGN51..MA |
1 | ||
| 36273 - GEAR, TRANSFER LOW PLANETARY RING | ||||
| 36273-35030 |
KUN50,TGN51..MA |
1 | ||
| 36273A - RING, HOLE SNAP (FOR TRANSFER LOW PLANETARY RING GEAR) | ||||
| 90520-29052 |
KUN50,TGN51..MA |
1 | ||
| 36278 - WASHER, MANUAL TRANSFER PLANETARY CARRIER | ||||
| 36278-35020 |
KUN50,TGN51..MA T=0.95-1.05 |
1 | ||
| 36284 - PIECE, TRANSFER LOW PLANETARY GEAR SPLINE | ||||
| 36284-35030 |
KUN50,TGN51..MA |
1 | ||
| 36288 - RACE, TRANSFER THRUST BEARING, NO.1 | ||||
| 36288-28010 |
KUN50,TGN51..MA |
1 | ||
| 36291A - BEARING (FOR TRANSFER DRIVE SPROCKET) | ||||
| 90364-37013 |
KUN50,TGN51..MA |
1 | ||
| 36292 - SPROCKET, TRANSFER DRIVEN | ||||
| 36292-35050 |
KUN50,TGN51..MA |
1 | ||
| 36292A - BEARING (FOR TRANSFER DRIVEN SPROCKET) | ||||
| 90363-32037 |
KUN50,TGN51..MA |
1 | ||
| 36293 - CHAIN, TRANSFER FRONT DRIVE | ||||
| 36293-35040 |
KUN50,TGN51..MA |
1 | ||
| 41311M - CASE, CENTER DIFFERENTIAL | ||||
| 41301-60140 |
KUN50 |
1 | ||
| 41331M - RING, HOLE SNAP(FOR CENTER DIFFERENTIAL PLANETARY RING | ||||
| 90520-99079 |
KUN50,TGN51..MA |
1 | ||
(1107- )GGN50,KUN5#,LAN50,TGN51
