GUN155R-SDTMH (2017)
Toyota Fortuner
(1507- )
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 47749F - CLIP, PIN HOLD | ||||
| 47749-50090 |
TGN156..AGTSU,EPTSU,IDNSU,SASUV,THSUV;GGN155,165,GUN15#,16#,KUN156,165,LAN155,TGN16#..AGTSU,EPTSU,IDNSU,PKNSU,SASUV,THSUV,VNSUV |
2 | ||
| 52021 - REINFORCEMENT SUB-ASSY, FRONT BUMPER | ||||
| 52021-KK010 |
TGN156..AGTSU,EPTSU,IDNSU,SASUV,THSUV;GGN155,165,GUN15#,16#,KUN156,165,LAN155,TGN16#..AGTSU,EPTSU,IDNSU,PKNSU,SASUV,THSUV,VNSUV |
1 | ||
| 52119D - SCREW, NO.1 | ||||
| 90159-60217 |
TGN156..AGTSU,EPTSU,IDNSU,SASUV,THSUV;GGN155,165,GUN15#,16#,KUN156,165,LAN155,TGN16#..AGTSU,EPTSU,IDNSU,PKNSU,SASUV,THSUV,VNSUV |
6 | ||
| 52129B - COVER, FRONT BUMPER, LOWER | ||||
| 52129-KK010 |
LAN155..S;GUN165..IDNSU,SASUV,THSUV,VNSUV;TGN156..AGTSU,EPTSU,IDNSU,SASUV,THSUV;GGN155,165,GUN15#,166,KUN156,165,TGN16#..AGTSU,EPTSU,IDNSU,PKNSU,SASUV,THSUV,VNSUV |
1 | ||
| 52161C - PIECE, FRONT BUMPER | ||||
| 52161-0K050 |
LAN155..S;GUN165..IDNSU,SASUV,THSUV,VNSUV;TGN156..AGTSU,EPTSU,IDNSU,SASUV,THSUV;GGN155,165,GUN15#,166,KUN156,165,TGN16#..AGTSU,EPTSU,IDNSU,PKNSU,SASUV,THSUV,VNSUV |
5 | ||
| 52421A - PAD, FRONT BUMPER | ||||
| 52421-60191 |
GUN165..VNSUV..L;TGN166..AGTSU,EPTSU,IDNSU,PKNSU,SASUV,THSUV;GGN155,165,GUN15#,16#,KUN156,165,LAN155,TGN156,168..AGTSU,EPTSU,IDNSU,SASUV,THSUV |
3 | ||
| 52492 - BOLT, BUMPER PAD, NO.2 | ||||
| 52491-60010 |
GUN165..VNSUV..L;TGN166..AGTSU,EPTSU,IDNSU,PKNSU,SASUV,THSUV;GGN155,165,GUN15#,16#,KUN156,165,LAN155,TGN156,168..AGTSU,EPTSU,IDNSU,SASUV,THSUV |
3 | ||
| 52521A - CLIP(FOR FRONT BUMPER RETAINER) | ||||
| 90467-05114 |
GUN165..VNSUV..L;TGN166..AGTSU,EPTSU,IDNSU,PKNSU,SASUV,THSUV;GGN155,165,GUN15#,16#,KUN156,165,LAN155,TGN156,168..AGTSU,EPTSU,IDNSU,SASUV,THSUV |
6 | ||
| 52526C - RETAINER, FRONT BUMPER, LOWER | ||||
| 52526-60030 |
TGN166..L..GCC;GUN156..H..BZAGT;GUN156..RHD..(L,M,S);TGN156..S..(BZAGT,GEN,KZS,SA);GUN155..(IDNSU,SASUV,THSUV)..6FC;GUN156..(IDNSU,THSUV)..(GCC,LA,PH,VN);GUN156..LHD..(AGTSU,THSUV,VNSUV)..(L,M,S);TGN156..(H,L,M)..(BZAGT,EPT,GCC,GEN,LA,VN);TGN166..BZAGT,EPT,GEN,IDN,LA,PH,PKN,SA,TH,VN;GUN16#,TGN168..AGTSU,IDNSU,SASUV,THSUV,VNSUV |
4 | ||
| 53162A - DEFLECTOR, FRONT BUMPER STONE, RH | ||||
| 53162-KK010 |
TGN156..AGTSU,EPTSU,IDNSU,SASUV,THSUV;GUN15#,165,TGN166..AGTSU,EPTSU,IDNSU,PKNSU,SASUV,THSUV,VNSUV;GGN155,GUN166,KUN156,165,LAN155,TGN168..BZAGT,EPT,GEN,LA,SA,TH |
1 | ||
| 53163A - DEFLECTOR, FRONT BUMPER STONE, LH | ||||
| 53163-KK010 |
TGN156..AGTSU,EPTSU,IDNSU,SASUV,THSUV;GUN15#,165,TGN166..AGTSU,EPTSU,IDNSU,PKNSU,SASUV,THSUV,VNSUV;GGN155,GUN166,KUN156,165,LAN155,TGN168..BZAGT,EPT,GEN,LA,SA,TH |
1 | ||
| 53879M - RETAINER, FRONT FENDER LINER | ||||
| 53879-50020 |
GUN165..VNSUV..L;TGN166..AGTSU,EPTSU,IDNSU,PKNSU,SASUV,THSUV;GGN155,165,GUN15#,16#,KUN156,165,LAN155,TGN156,168..AGTSU,EPTSU,IDNSU,SASUV,THSUV |
2 | ||
| 75392 - RETAINER, OUTSIDE MOULDING | ||||
| 75392-0K010 |
GUN165..VNSUV..L;TGN166..AGTSU,IDNSU,PKNSU,SASUV,THSUV;GGN155,165,GUN15#,16#,KUN156,165,LAN155,TGN156,168..AGTSU,IDNSU,SASUV,THSUV |
8 | ||
| 75392 - RETAINER, OUTSIDE MOULDING | ||||
| 75392-0K010 |
GUN165..VNSUV..L;TGN166..AGTSU,IDNSU,PKNSU,SASUV,THSUV;GGN155,165,GUN15#,16#,KUN156,165,LAN155,TGN156,168..AGTSU,IDNSU,SASUV,THSUV |
8 | ||
| Common parts | ||||
| 90105-T0144 | ||||
| 90109-06272 | ||||
| 90119-T0209 | ||||
| 90159-50353 | ||||
| 90159-T0033 | ||||
| 90167-40057 | ||||
| 90179-06349 | ||||
| 90183-06030 | ||||
| 90189-T0019 | ||||
| 90467-09232 | ||||
| 90467-09237 | ||||
| Linked diagrams | ||||
| 8101 | ||||
(2005- )
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| Common parts | ||||
| 52161-0K050 | ||||
| 90105-T0144 | ||||
| 90109-06272 | ||||
| 90119-T0209 | ||||
| 90159-50353 | ||||
| 90159-60217 | ||||
| 90159-T0033 | ||||
| 90167-50063 | ||||
| 90179-06349 | ||||
| 90183-06030 | ||||
| 90189-T0019 | ||||
| 90467-09232 | ||||
| 90467-09237 | ||||
| Linked diagrams | ||||
| 8101 | ||||
(2005- )
MLM PACKAGE
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| Common parts | ||||
| 52161-0K050 | ||||
| 90105-T0144 | ||||
| 90109-06272 | ||||
| 90119-T0209 | ||||
| 90159-50353 | ||||
| 90159-T0033 | ||||
| 90159-T0034 | ||||
| 90167-50063 | ||||
| 90179-06349 | ||||
| 90183-06030 | ||||
| 90189-T0019 | ||||
| 90467-05114 | ||||
| 90467-05170 | ||||
| 90467-07215 | ||||
| 90467-09232 | ||||
| 90467-09237 | ||||
| 90467-T0047 | ||||
| 90467-T0050 | ||||
| Linked diagrams | ||||
| 8606 | ||||
