WU90L-MDDT (1987)

Toyota Dyna 200

Production Aug 1987 - Aug 1988
Engine 1W
Transmission LHD 5F
Displacement 2500cc
Power 168 HP (125 kW)

(8708- )

Click highlighted areas on diagram

diagram 11278 11291 11293 11294 11296 11297 11298 11299 17700C 17700C 17700D 23923
Part # Description Qty Price
11293 - PLATE, ENGINE CAUTION & ENGINE NAME
11293-78010

1W..WU9#

 1
11294 - PLATE, ENGINE CAUTION, NO.2
11294-78020

1W..WU90..LHD

CHINA SPEC

 1
17700C - PLATE, AIR CLEANER CAUTION (FOR ENGINE MODEL)
17791-56210

22R,1W,4Y..RU85,WU9#,YU6#,81..(L1,L2,T3)..GEN

SCHNORKEL TYPE & OIL BATH

 1
17791-64020

22R,1W,4Y..RU85,WU9#,YU6#,71,81

 1
17791-56200

1W..WU90..LHD

CHINA SPEC

 1
17700C - PLATE, AIR CLEANER CAUTION (FOR ENGINE MODEL)
17791-56210

22R,1W,4Y..RU85,WU9#,YU6#,81..(L1,L2,T3)..GEN

SCHNORKEL TYPE & OIL BATH

 1
17791-64020

22R,1W,4Y..RU85,WU9#,YU6#,71,81

 1
17791-56200

1W..WU90..LHD

CHINA SPEC

 1
23923 - PLATE, FUEL SEDIMENTER CAUTION
23923-56010

1W..WU9#

 1
23923-56020

1W..WU90..LHD

CHINA SPEC

 1

(8708- )

Click highlighted areas on diagram

diagram 11278 11291 11293 11294 11296 11297 11298 11299 17700C 17700C 17700D 23923
Part # Description Qty Price
11293 - PLATE, ENGINE CAUTION & ENGINE NAME
11293-78010

1W..WU9#

 1
11294 - PLATE, ENGINE CAUTION, NO.2
11294-78020

1W..WU90..LHD

CHINA SPEC

 1
17700C - PLATE, AIR CLEANER CAUTION (FOR ENGINE MODEL)
17791-56210

22R,1W,4Y..RU85,WU9#,YU6#,81..(L1,L2,T3)..GEN

SCHNORKEL TYPE & OIL BATH

 1
17791-64020

22R,1W,4Y..RU85,WU9#,YU6#,71,81

 1
17791-56200

1W..WU90..LHD

CHINA SPEC

 1
17700C - PLATE, AIR CLEANER CAUTION (FOR ENGINE MODEL)
17791-56210

22R,1W,4Y..RU85,WU9#,YU6#,81..(L1,L2,T3)..GEN

SCHNORKEL TYPE & OIL BATH

 1
17791-64020

22R,1W,4Y..RU85,WU9#,YU6#,71,81

 1
17791-56200

1W..WU90..LHD

CHINA SPEC

 1
23923 - PLATE, FUEL SEDIMENTER CAUTION
23923-56010

1W..WU9#

 1
23923-56020

1W..WU90..LHD

CHINA SPEC

 1
