BU83R-MDDT3 (1988)
Toyota Dyna 200
(8808- )BU60,61,65,66,83,84,87..RHD
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 87138S - RESISTOR, BLOWER | ||||
| 87138-95410 |
BU61..CBU;BU60..T3..ST;BU61..ST..IV3;BU61..LHD..IV3;BU91..RHD..CBU;BU96..DSL..GEN;BU66,70,84,87,94..5F;BU60,65,83,88..RHD..(GEN,GHD) |
1 | ||
| 87138-95410 |
BU60,83..RHD;BU60..T3..ST;BU70,84,87,94;BU61..ST..IV3;BU61..LHD..IV3;BU88..RHD..GEN;BU91..RHD..CBU;BU61,65..GEN..CBU;BU66,96..T3..TB..DSL..GEN |
1 | ||
| 87138-95410 |
BU96..GEN;BU61..CBU;BU60..T3..ST;BU61..ST..IV3;BU61..LHD..IV3;BU91..RHD..CBU;BU66,70,84,94..5F;BU60,65,83,88..RHD..(GEN,GHD) |
1 | ||
| 88407 - GLASS SUB-ASSY, SIGHT | ||||
| 88407-95701 |
BU66,84;BU60..T3..ST;BU61..ST..IV3;BU61..LHD..IV3;BU60,83..RHD..WT;BU61,65,70..CBU,IV1 |
1 | ||
| 88407-95701 |
BU60..T3..ST;BU61..ST..IV3;BU61..LHD..IV3;BU66,84..T3..TB;BU60,83,87..RHD;BU61,65,70..CBU,IV1 |
1 | ||
| 88407-95701 |
BU66,84,87;BU60..T3..ST;BU61..ST..IV3;BU61..LHD..IV3;BU60,83..RHD..WT;BU61,65,70..CBU,IV1 |
1 | ||
| 88460 - CONDENSER ASSY, COOLER | ||||
| 88460-95405 |
BU61..ST..IV3;BU61..RHD..CBU;BU60,65,66,83,84..RHD..WT |
1 | ||
| 88460-95405 |
BU61..ST..IV3;BU61..RHD..CBU;BU60,65,66,83,84,87..RHD..WT |
1 | ||
| 88460-37010 |
BU61..RHD..WT..CBU;BU60,65,66,83,84,87..RHD..WT |
1 | ||
| 88460B - BRACKET, COOLER CONDENSER, NO.1 | ||||
| 88688-95416 |
BU70,84,87;BU60,83..RHD;BU60..T3..ST;BU66..T3..TB;BU61..ST..IV3;BU61..CBU,IV1;BU61..LHD..IV3 |
1 | ||
| 88688-95416 |
BU66,70,84;BU60..T3..ST;BU61..CBU,IV1;BU61..ST..IV3;BU61..LHD..IV3;BU60,83..RHD..WT |
1 | ||
| 88688-95416 |
BU60..T3..ST;BU66,70,84,87;BU61..CBU,IV1;BU61..ST..IV3;BU61..LHD..IV3;BU60,83..RHD..WT |
1 | ||
| 88688-95416 |
BU70,84,87;BU60,83..RHD;BU60..T3..ST;BU61..WT..CBU;BU61..LHD..IV3 |
1 | ||
| 88460C - BRACKET, COOLER CONDENSER, NO.2 | ||||
| 88688-95417 |
BU60..T3..ST;BU66,70,84,87;BU61..CBU,IV1;BU61..ST..IV3;BU61..LHD..IV3;BU60,83..RHD..WT |
1 | ||
| 88688-95417 |
BU70,84,87;BU60,83..RHD;BU60..T3..ST;BU61..WT..CBU;BU61..LHD..IV3 |
1 | ||
| 88688-95417 |
BU66,70,84;BU60..T3..ST;BU61..CBU,IV1;BU61..ST..IV3;BU61..LHD..IV3;BU60,83..RHD..WT |
1 | ||
| 88688-95417 |
BU70,84,87;BU60,83..RHD;BU60..T3..ST;BU66..T3..TB;BU61..ST..IV3;BU61..CBU,IV1;BU61..LHD..IV3 |
1 | ||
| 88470 - RECEIVER & DRYER ASSY, COOLER | ||||
| 88471-95400 |
BU91..TD;BU96..GEN;BU88..IV1;BU66,84,87;BU60..T3..ST;BU61..ST..IV3;BU91..RHD..CBU;BU61..LHD..IV3;BU60,83..RHD..WT;BU61,65,70,94..CBU,IV1 |
1 | ||
| 88471-95400 |
BU91..TD;BU96..LHD;BU88..IV1;BU66,84,87;BU60..T3..ST;BU61..ST..IV3;BU91..RHD..CBU;BU61..LHD..IV3;BU60,83..RHD..WT;BU61,65,70,94..CBU,IV1 |
1 | ||
| 88471-95400 |
BU91..TD;BU96..LHD;BU88..IV1;BU66,84,87;BU60..T3..ST;BU60,83..RHD;BU61..ST..IV3;BU91..RHD..CBU;BU61..LHD..IV3;BU61,65,70,94..CBU,IV1 |
1 | ||
| 88471-95400 |
BU88..IV1;BU60..T3..ST;BU61..ST..IV3;BU61..LHD..IV3;BU91..RHD..CBU;BU96..LHD..DSL;BU60,83,87..RHD;BU66,84..T3..TB;BU61,65,70,94..CBU,IV1 |
1 | ||
| 88471-95400 |
BU66,84;BU88..IV1;BU96..GEN;BU60..T3..ST;BU61..ST..IV3;BU61..LHD..IV3;BU91..RHD..CBU;BU60,83..RHD..WT;BU61,65,70,94..CBU,IV1 |
1 | ||
| 88472 - BRACKET, RECEIVER TANK, NO.1 | ||||
| 88472-95408 |
BU61..ST..IV3;BU61..RHD..CBU;BU60,65,66,83,84..RHD..WT |
1 | ||
| 88472-37010 |
BU61..RHD..WT..CBU;BU60,65,66,83,84,87..RHD |
1 | ||
| 88472-95408 |
BU61..ST..IV3;BU61..RHD..CBU;BU60,65,83,84,87..RHD |
1 | ||
| 88472-95408 |
BU61..ST..IV3;BU61..RHD..CBU;BU60,65,66,83,84,87..RHD..WT |
1 | ||
| 88479 - FREON GAS, AIR CONDITIONER (DRUM, COOLER REFRIGERANT) | ||||
| 90986-02004 |
BU91..RHD..(ARL,GEN)..IV3;BU65,66,88..RHD..(CBU,IV3);BU60,61,83,84..RHD..WT..GEN..IV3 250G |
2 | ||
| 90986-02001 |
BU61..RHD..WT..GEN..IV3;BU60,66,83,84..RHD..(ARL,GEN)..IV3 400G |
2 | ||
| 90986-02004 |
BU65..CBU;BU66,88,91,96..ARL,GEN;BU60,61,70,83,84,87,94..GEN,GHD,SA 250G |
2 | ||
| 90986-02004 |
BU65..CBU;BU60,61,70,83,84,87,94..GEN,GHD,SA;BU66,88,91,96..(T3,TW1)..TB..DSL..(ARL,GEN) 250G |
2 | ||
| 88550 - MOTOR ASSY, BLOWER (FOR CONDENSER) | ||||
| 87104-95406 |
BU61..CBU;BU60..T3..ST;BU70,84,87,94;BU61..ST..IV3;BU61..LHD..IV3;BU91..RHD..CBU;BU66,96..T3..TB..DSL..GEN;BU60,65,83,88..RHD..(GEN,GHD) |
1 | ||
| 87104-95406 |
BU96..GEN;BU61..CBU;BU60..T3..ST;BU61..ST..IV3;BU61..LHD..IV3;BU91..RHD..CBU;BU66,70,84,94..5F;BU60,65,83,88..RHD..(GEN,GHD) |
1 | ||
| 88648E - WIRING, COOLER | ||||
| 88648-95419 |
BU60..T3..ST;BU61..CBU,IV1;BU61..ST..IV3;BU61..LHD..IV3;BU91..RHD..CBU;BU96..DSL..GEN;BU66,70,84,87,94..5F;BU60,65,83,88..RHD..(GEN,GHD) |
1 | ||
| 88648-95419 |
BU60,83..RHD;BU60..T3..ST;BU70,84,87,94;BU61..ST..IV3;BU61..LHD..IV3;BU88..RHD..GEN;BU91..RHD..CBU;BU61,65..GEN..(CBU,IV1);BU66,96..T3..TB..DSL..GEN |
1 | ||
| 88648-95419 |
BU96..GEN;BU60..T3..ST;BU61..CBU,IV1;BU61..ST..IV3;BU61..LHD..IV3;BU91..RHD..CBU;BU66,70,84,94..5F;BU60,65,83,88..RHD..(GEN,GHD) |
1 | ||
| 88711 - HOSE, COOLER REFRIGERANT DISCHARGE, NO.1 | ||||
| 88711-95429 |
BU60,83,84..RHD..GEN..IV3 |
1 | ||
| 88711-95415 |
BU60,61,83,84..RHD..WT..GEN..IV3 A/C=DEALER OPT |
1 | ||
| 88711-37090 |
BU60,61,83,84..RHD..WT..GEN..IV3 A/C=DEALER OPT |
1 | ||
| 88711-37030 |
BU65..GEN..CBU;BU60,83,84..RHD..GEN..IV3 |
1 | ||
| 88711A - HOSE, COOLER REFRIGERANT DISCHARGE, NO.2 | ||||
| 88711-95417 |
BU60..T3..ST;BU61..ST..IV3;BU61..LHD..IV3;BU66,84..T3..TB;BU60,83,87..RHD;BU61,65,70..CBU,IV1 |
1 | ||
| 88711-37020 |
BU67,70,84;BU60..T3..ST;BU61..WT..CBU;BU61..LHD..IV3;BU60,65,66,83,87..RHD |
1 | ||
| 88711-95417 |
BU66,84;BU60..T3..ST;BU61..ST..IV3;BU61..LHD..IV3;BU60,83..RHD..WT;BU61,65,70..CBU,IV1 |
1 | ||
| 88711-95417 |
BU66,84,87;BU60..T3..ST;BU61..ST..IV3;BU61..LHD..IV3;BU60,83..RHD..WT;BU61,65,70..CBU,IV1 |
1 | ||
| 88712 - HOSE, COOLER REFRIGERANT SUCTION, NO.1 | ||||
| 88712-95437 |
BU60,83,84..RHD..GEN..IV3 |
1 | ||
| 88712-37010 |
BU61..ST;BU65..GEN..CBU;BU60,83,84..RHD..GEN..IV3 |
1 | ||
| 88712-37120 |
BU65..GEN..CBU;BU60,61,83,84..RHD..WT..GEN..IV3 A/C=DEALER OPT |
1 | ||
| 88712-95420 |
BU60,61,83,84..RHD..WT..GEN..IV3 A/C=DEALER OPT |
1 | ||
| 88713 - HOSE, COOLER REFRIGERANT SUCTION, NO.2 | ||||
| 88712-95421 |
BU60..ARL;BU60,61,83,84..RHD..WT..GEN..IV3 |
1 | ||
| 88712-95421 |
BU61..RHD..WT..GEN..IV3;BU60,66,83,84..RHD..(ARL,GEN)..IV3 |
1 | ||
| 88712-37050 |
BU65..GEN..CBU;BU60,83,84..RHD..GEN..IV3 |
1 | ||
| 88712-37130 |
BU60,61,83,84..RHD..WT..GEN..IV3 A/C=DEALER OPT |
1 | ||
| 88714 - HOSE, COOLER REFRIGERANT LIQUID, NO.1 | ||||
| 88721-95413 |
BU61..ST..IV3;BU61..RHD..CBU;BU60,83,84..RHD..(GEN,GHD) |
1 | ||
| 88721-95405 |
BU61..ST..IV3;BU61..RHD..CBU;BU60,83,84..RHD..(GEN,GHD) |
1 | ||
| 88721-95407 |
BU60,61,83,84..RHD..WT..GEN..IV3 A/C=DEALER OPT |
1 | ||
| 88721-95413 |
BU61..ST..IV3;BU61..RHD..CBU;BU60,83,84,87..RHD..(GEN,GHD) |
1 | ||
| 88721-95405 |
BU60,83,84,87..RHD..(GEN,GHD) |
1 | ||
| 88721-36090 |
BU61..ST..IV3;BU61..RHD..CBU;BU60,83,84,87..RHD..(GEN,GHD) |
1 | ||
| 88721-37030 |
BU61..ST..IV3;BU61..RHD..CBU;BU60,65,83,84,87..RHD..(GEN,GHD) |
1 | ||
| 88721-37050 |
BU65..GEN..CBU;BU60,61,83,84..RHD..WT..GEN..IV3 A/C=DEALER OPT |
1 | ||
| 88714A - HOSE, COOLER REFRIGERANT LIQUID, NO.2 | ||||
| 88721-95405 |
BU61..ST..IV3;BU61..RHD..CBU;BU60,65,66,83,84,87..RHD..WT |
1 | ||
| 88721-37010 |
BU61..RHD..WT..CBU;BU60,65,66,83,84,87..RHD |
1 | ||
| 88721-95405 |
BU61..ST..IV3;BU61..RHD..CBU;BU60,65,66,83,84..RHD..WT |
1 | ||
| 88721-95405 |
BU61..ST..IV3;BU61..RHD..CBU;BU60,65,83,84,87..RHD |
1 | ||
| 88715A - PIPE, COOLER REFRIGERANT DISCHARGE, A | ||||
| 88715-95407 |
BU66,84;BU60..T3..ST;BU61..ST..IV3;BU61..LHD..IV3;BU60,83..RHD..WT;BU61,65,70..CBU,IV1 |
1 | ||
| 88715-95407 |
BU60..T3..ST;BU61..ST..IV3;BU61..LHD..IV3;BU66,84..T3..TB;BU60,83,87..RHD;BU61,65,70..CBU,IV1 |
1 | ||
| 88715-37020 |
BU67,70,84;BU60..T3..ST;BU61..WT..CBU;BU61..LHD..IV3;BU60,65,66,83,87..RHD |
1 | ||
| 88715-95407 |
BU66,84,87;BU60..T3..ST;BU61..ST..IV3;BU61..LHD..IV3;BU60,83..RHD..WT;BU61,65,70..CBU,IV1 |
1 | ||
| 88716A - PIPE, COOLER REFRIGERANT LIQUID, A | ||||
| 88716-95412 |
BU61..ST..IV3;BU61..RHD..CBU;BU60,65,66,83,84..RHD..WT |
1 | ||
| 88716-95412 |
BU61..ST..IV3;BU61..RHD..CBU;BU60,65,66,83,84,87..RHD..WT |
1 | ||
| 88716-95412 |
BU61..ST..IV3;BU61..RHD..CBU;BU60,65,83,84,87..RHD |
1 | ||
| 88716-37030 |
BU61..RHD..WT..CBU;BU60,65,66,83,84,87..RHD |
1 | ||
| 88716B - PIPE, COOLER REFRIGERANT LIQUID, B | ||||
| 88716-95413 |
BU61..ST..IV3;BU61..RHD..CBU;BU60,65,66,83,84..RHD..WT |
1 | ||
| 88716-95413 |
BU61..ST..IV3;BU61..RHD..CBU;BU60,65,83,84,87..RHD |
1 | ||
| 88716-95413 |
BU61..ST..IV3;BU61..RHD..CBU;BU60,65,66,83,84,87..RHD..WT |
1 | ||
| 88716-37020 |
BU61..RHD..WT..CBU;BU60,65,66,83,84,87..RHD |
1 | ||
| 88717J - PIPE, COOLER REFRIGERANT SUCTION, J | ||||
| 88717-95404 |
BU66;BU61,65..CBU;BU61..ST..IV3;BU61..LHD..IV3;BU60,70,83,84..GEN,GHD,SA |
1 | ||
| 88717-95404 |
BU66;BU61,65..CBU;BU61..ST..IV3;BU61..LHD..IV3;BU60,70,83,84,87..GEN,GHD,SA |
1 | ||
| 88717-95404 |
BU61,65..CBU;BU66..T3..TB;BU61..ST..IV3;BU61..LHD..IV3;BU60,70,83,84,87 |
1 | ||
| 88717-37020 |
BU67,70,84;BU60..T3..ST;BU61..WT..CBU;BU61..LHD..IV3;BU60,65,66,83,87..RHD |
1 | ||
| 88896C - COVER, COOLER REFRIGERANT PIPE, NO.1 | ||||
| 88896-95705 |
BU65..GEN..CBU;BU60,61,83,84..RHD..WT..GEN..IV3 A/C=DEALER OPT |
1 | ||
| 88896-95704 |
BU65..GEN..CBU;BU60,83,84..RHD..GEN..IV3 |
1 | ||
| Common parts | ||||
| 87241-95400 | ||||
| 88467-22010 | ||||
| 88688-95418 | ||||
| 88688-95419 | ||||
| 88688-95430 | ||||
| 88688-95434 | ||||
| 88718-12790 | ||||
| 88718-30720 | ||||
| 88718-95015 | ||||
| 88718-95023 | ||||
| 88718-95419 | ||||
| 88718-95420 | ||||
| 88718-95426 | ||||
| 88718-95429 | ||||
| 88718-95A06 | ||||
| 90099-32073 | ||||
| 90179-08065 | ||||
| 90179-08146 | ||||
| 90461-08205 | ||||
| 91611-60616 | ||||
| 91611-60812 | ||||
| 91611-60814 | ||||
| 91611-60816 | ||||
| 91611-60835 | ||||
| 91611-61016 | ||||
| 91651-40825 | ||||
| 91651-60620 | ||||
| 91651-60835 | ||||
| 91655-40816 | ||||
| 91661-60825 | ||||
