BU80R-MDDT3 (1987)

Toyota Dyna 200

Production Aug 1987 - Aug 1988
Engine B
Transmission
Displacement 2500cc
Power 168 HP (125 kW)

(8708- )

Click highlighted areas on diagram

diagram 33621A 35519 74525B 74528 74533 74535E 74537C 74538A 74541 74545A 74546A 74552 74559A 74559A 74559A 74563A 74566B 74566D 74571 74583 75476A 75477A
Part # Description Qty Price
74538A - PLATE, AIR CLEANER INLET OPERATIONAL CAUTION
74538-95405

BU61..GEN;BU60,62,70,80,81..5F

 1
74559A - PLATE, FUEL CAUTION
74559-36020

BU80,81,85..(GEN,GHD,SA)..(CBU,IV3)

W(FUEL TANK=100L & SUB TANK=70L)

 1
74559A - PLATE, FUEL CAUTION
74559-36020

BU80,81,85..(GEN,GHD,SA)..(CBU,IV3)

W(FUEL TANK=100L & SUB TANK=70L)

 1
74559A - PLATE, FUEL CAUTION
74559-36020

BU80,81,85..(GEN,GHD,SA)..(CBU,IV3)

W(FUEL TANK=100L & SUB TANK=70L)

 1
74563A - LABEL, ROOF VENTILATOR INFORMATION
74563-95402

BU85..ARL;BU85..LHD;BU65,85..RHD..CBU;BU60,61,62,70,80,81,82,86..(TR,V)..(CBU,IV3)

 1
74566B - PLATE, POWER TAKE OFF CAUTION
74566-93106

BU60,61,8#..RHD..WT..(ARL,GEN,GHD)..(CBU,IV3)

 1
74571 - PLATE, BRAKE FLUID CAUTION
47287-36010

BU6#,70,8#,93

 1
47287-36010

BU6#,70,8#

 1
75476A - PLATE, TILT OPERATIONAL CAUTION
75476-95419

BU65..GEN..CBU;BU60,61,62,80,81..(T1,T3)..(GEN,GHD)..(CBU,IV3)

W(TILT CAB)

 1
75477A - PLATE, TILT OPERATIONAL CAUTION, NO.2
75477-95408

BU80..LHD..CBU;BU65,80..RHD..(GEN,GHD);BU60,61,62,81..(T1,T3)..(GEN,GHD)..(CBU,IV3)

 1
