Toyota Dyna200 BU211 HORN - JDM Part Detective

BU211L-TKMRS3 (1995)

Toyota Dyna200

Production May 1995 - Dec 2002

Engine 14B

Transmission

Displacement 2500cc

Power 168 HP (125 kW)

(9505- )

Click highlighted areas on diagram

Part #	Description	Period	Qty
86510 - HORN ASSY, HIGH PITCHED
86510-95409	BU111,221..LHD..(DM6,T3);BU101,211..LHD..WT..(20T,40T)..IV3	11/2001 - 12/2999	1
86510 - HORN ASSY, HIGH PITCHED
86510-95409	BU111,221..LHD..(DM6,T3);BU101,211..LHD..WT..(20T,40T)..IV3	11/2001 - 12/2999	1
86520 - HORN ASSY, LOW PITCHED
86520-95424	BU100..175T..GEN;BU100,111,140,141,211..LHD..(DM1,T3)..WT..GEN CHINA SPEC	05/1995 - 08/1997	1
86520-95417	BU101..LHD..ST..TS;BU100,111,140,141,211,221..LHD..(DM1,T3,TW1,TW2)..GEN SAUDI ARABIA & GULF SPEC	05/1995 - 11/1999	1
86520-95421	BU212..LHD..40T..TD;BU100,101,111,140,141,211,221..(DM1,T1,T3,TW1,TW2)..GEN..(CBU,IV3) W(AM/FM/SW 1SPEAKER)	05/1995 - 12/2002	1
86520-95424	BU100..175T..GEN;BU100,140,211..LHD..T3..WT CHINA SPEC	08/1997 - 05/1999	1
86520-95422	BU211..IV2;BU212..30T..TD..IV3;BU212..RHD..GEN..IV3;BU101,222..(175T,40T)..GEN;BU102,112,211,212..LHD..(DM7,T2,T3,T4)..DSL COLD SPEC	05/1999 - 12/2002	1
86520-95423	RZU100;BU212..CBU;BU102,212..ARL,TAIW;BU212..LHD..40T..TD;BU142..(20T,25T)..(ARL,GEN);BU100,101,11#,140,141,211,221,222..(DM1,T1,T2,T3,TW1,TW2)..DSL..(ARL,GEN,TAIW)..(CBU,IV3)	05/1995 - 05/2001	1
86520-95417	BU101..LHD..TS;BU111,141,211,221..LHD..(DM1,T3,TW1) SAUDI ARABIA & GULF SPEC	11/1999 - 12/2002	1
86520-95419	BU141,221..LHD;BU101,211..LHD..WT..(20T,40T)..IV3 ALGERIA SPEC	11/2001 - 12/2002	1
86520-95423	BU212..LHD;BU212..TD..CBU;BU142..(20T,25T)..(ARL,GEN);BU101,111,141,211,212,221,222..(DM1,T1,T2,T3,TW1,TW2)..DSL..(ARL,GEN)..(CBU,IV3)	05/2001 - 12/2999	1
86520 - HORN ASSY, LOW PITCHED
86520-95424	BU100..175T..GEN;BU100,111,140,141,211..LHD..(DM1,T3)..WT..GEN CHINA SPEC	05/1995 - 08/1997	1
86520-95417	BU101..LHD..ST..TS;BU100,111,140,141,211,221..LHD..(DM1,T3,TW1,TW2)..GEN SAUDI ARABIA & GULF SPEC	05/1995 - 11/1999	1
86520-95421	BU212..LHD..40T..TD;BU100,101,111,140,141,211,221..(DM1,T1,T3,TW1,TW2)..GEN..(CBU,IV3) W(AM/FM/SW 1SPEAKER)	05/1995 - 12/2002	1
86520-95424	BU100..175T..GEN;BU100,140,211..LHD..T3..WT CHINA SPEC	08/1997 - 05/1999	1
86520-95422	BU211..IV2;BU212..30T..TD..IV3;BU212..RHD..GEN..IV3;BU101,222..(175T,40T)..GEN;BU102,112,211,212..LHD..(DM7,T2,T3,T4)..DSL COLD SPEC	05/1999 - 12/2002	1
86520-95423	RZU100;BU212..CBU;BU102,212..ARL,TAIW;BU212..LHD..40T..TD;BU142..(20T,25T)..(ARL,GEN);BU100,101,11#,140,141,211,221,222..(DM1,T1,T2,T3,TW1,TW2)..DSL..(ARL,GEN,TAIW)..(CBU,IV3)	05/1995 - 05/2001	1
86520-95417	BU101..LHD..TS;BU111,141,211,221..LHD..(DM1,T3,TW1) SAUDI ARABIA & GULF SPEC	11/1999 - 12/2002	1
86520-95419	BU141,221..LHD;BU101,211..LHD..WT..(20T,40T)..IV3 ALGERIA SPEC	11/2001 - 12/2002	1
86520-95423	BU212..LHD;BU212..TD..CBU;BU142..(20T,25T)..(ARL,GEN);BU101,111,141,211,212,221,222..(DM1,T1,T2,T3,TW1,TW2)..DSL..(ARL,GEN)..(CBU,IV3)	05/2001 - 12/2999	1
86591 - BRACKET, HORN
86591-37020	BU10#,11#,14#..(DM1,T1,T2,T3,TW2)..(ARL,GEN,TAIW)	05/1995 - 08/1995	1
86591-37030	BU21#,22#..ARL,GEN,TAIW	05/1995 - 12/2999	1
86505-37020	BU211..LHD..T3;BU101..175T..GEN COLD SPEC	05/1999 - 05/2000	1
86591-37050	RZU100;BU10#,11#,14#..(DM1,DM7,T1,T2,T3,T4,TW2)..(ARL,GEN,TAIW)	08/1995 - 12/2999	1
86591-37030	BU221..LHD;BU211..LHD..40T..IV3 ALGERIA SPEC	11/2001 - 12/2999	2
86591 - BRACKET, HORN
86591-37020	BU10#,11#,14#..(DM1,T1,T2,T3,TW2)..(ARL,GEN,TAIW)	05/1995 - 08/1995	1
86591-37030	BU21#,22#..ARL,GEN,TAIW	05/1995 - 12/2999	1
86505-37020	BU211..LHD..T3;BU101..175T..GEN COLD SPEC	05/1999 - 05/2000	1
86591-37050	RZU100;BU10#,11#,14#..(DM1,DM7,T1,T2,T3,T4,TW2)..(ARL,GEN,TAIW)	08/1995 - 12/2999	1
86591-37030	BU221..LHD;BU211..LHD..40T..IV3 ALGERIA SPEC	11/2001 - 12/2999	2
86591 - BRACKET, HORN
86591-37020	BU10#,11#,14#..(DM1,T1,T2,T3,TW2)..(ARL,GEN,TAIW)	05/1995 - 08/1995	1
86591-37030	BU21#,22#..ARL,GEN,TAIW	05/1995 - 12/2999	1
86505-37020	BU211..LHD..T3;BU101..175T..GEN COLD SPEC	05/1999 - 05/2000	1
86591-37050	RZU100;BU10#,11#,14#..(DM1,DM7,T1,T2,T3,T4,TW2)..(ARL,GEN,TAIW)	08/1995 - 12/2999	1
86591-37030	BU221..LHD;BU211..LHD..40T..IV3 ALGERIA SPEC	11/2001 - 12/2999	2
Common parts
90119-08539

(9905- )175T..GEN ; (9905- )BU211..LHD..T3

Click highlighted areas on diagram

COLD SPEC

Part #	Description	Period	Qty
86520 - HORN ASSY, LOW PITCHED
86520-95424	BU100..175T..GEN;BU100,111,140,141,211..LHD..(DM1,T3)..WT..GEN CHINA SPEC	05/1995 - 08/1997	1
86520-95417	BU101..LHD..ST..TS;BU100,111,140,141,211,221..LHD..(DM1,T3,TW1,TW2)..GEN SAUDI ARABIA & GULF SPEC	05/1995 - 11/1999	1
86520-95421	BU212..LHD..40T..TD;BU100,101,111,140,141,211,221..(DM1,T1,T3,TW1,TW2)..GEN..(CBU,IV3) W(AM/FM/SW 1SPEAKER)	05/1995 - 12/2002	1
86520-95424	BU100..175T..GEN;BU100,140,211..LHD..T3..WT CHINA SPEC	08/1997 - 05/1999	1
86520-95422	BU211..IV2;BU212..30T..TD..IV3;BU212..RHD..GEN..IV3;BU101,222..(175T,40T)..GEN;BU102,112,211,212..LHD..(DM7,T2,T3,T4)..DSL COLD SPEC	05/1999 - 12/2002	1
86520-95423	RZU100;BU212..CBU;BU102,212..ARL,TAIW;BU212..LHD..40T..TD;BU142..(20T,25T)..(ARL,GEN);BU100,101,11#,140,141,211,221,222..(DM1,T1,T2,T3,TW1,TW2)..DSL..(ARL,GEN,TAIW)..(CBU,IV3)	05/1995 - 05/2001	1
86520-95417	BU101..LHD..TS;BU111,141,211,221..LHD..(DM1,T3,TW1) SAUDI ARABIA & GULF SPEC	11/1999 - 12/2002	1
86520-95419	BU141,221..LHD;BU101,211..LHD..WT..(20T,40T)..IV3 ALGERIA SPEC	11/2001 - 12/2002	1
86520-95423	BU212..LHD;BU212..TD..CBU;BU142..(20T,25T)..(ARL,GEN);BU101,111,141,211,212,221,222..(DM1,T1,T2,T3,TW1,TW2)..DSL..(ARL,GEN)..(CBU,IV3)	05/2001 - 12/2999	1
86520 - HORN ASSY, LOW PITCHED
86520-95424	BU100..175T..GEN;BU100,111,140,141,211..LHD..(DM1,T3)..WT..GEN CHINA SPEC	05/1995 - 08/1997	1
86520-95417	BU101..LHD..ST..TS;BU100,111,140,141,211,221..LHD..(DM1,T3,TW1,TW2)..GEN SAUDI ARABIA & GULF SPEC	05/1995 - 11/1999	1
86520-95421	BU212..LHD..40T..TD;BU100,101,111,140,141,211,221..(DM1,T1,T3,TW1,TW2)..GEN..(CBU,IV3) W(AM/FM/SW 1SPEAKER)	05/1995 - 12/2002	1
86520-95424	BU100..175T..GEN;BU100,140,211..LHD..T3..WT CHINA SPEC	08/1997 - 05/1999	1
86520-95422	BU211..IV2;BU212..30T..TD..IV3;BU212..RHD..GEN..IV3;BU101,222..(175T,40T)..GEN;BU102,112,211,212..LHD..(DM7,T2,T3,T4)..DSL COLD SPEC	05/1999 - 12/2002	1
86520-95423	RZU100;BU212..CBU;BU102,212..ARL,TAIW;BU212..LHD..40T..TD;BU142..(20T,25T)..(ARL,GEN);BU100,101,11#,140,141,211,221,222..(DM1,T1,T2,T3,TW1,TW2)..DSL..(ARL,GEN,TAIW)..(CBU,IV3)	05/1995 - 05/2001	1
86520-95417	BU101..LHD..TS;BU111,141,211,221..LHD..(DM1,T3,TW1) SAUDI ARABIA & GULF SPEC	11/1999 - 12/2002	1
86520-95419	BU141,221..LHD;BU101,211..LHD..WT..(20T,40T)..IV3 ALGERIA SPEC	11/2001 - 12/2002	1
86520-95423	BU212..LHD;BU212..TD..CBU;BU142..(20T,25T)..(ARL,GEN);BU101,111,141,211,212,221,222..(DM1,T1,T2,T3,TW1,TW2)..DSL..(ARL,GEN)..(CBU,IV3)	05/2001 - 12/2999	1
86522 - PROTECTOR, HORN
86522-37020	BU211..LHD..T3	05/2000 - 12/2002	1
86591 - BRACKET, HORN
86591-37020	BU10#,11#,14#..(DM1,T1,T2,T3,TW2)..(ARL,GEN,TAIW)	05/1995 - 08/1995	1
86591-37030	BU21#,22#..ARL,GEN,TAIW	05/1995 - 12/2999	1
86505-37020	BU211..LHD..T3;BU101..175T..GEN COLD SPEC	05/1999 - 05/2000	1
86591-37050	RZU100;BU10#,11#,14#..(DM1,DM7,T1,T2,T3,T4,TW2)..(ARL,GEN,TAIW)	08/1995 - 12/2999	1
86591-37030	BU221..LHD;BU211..LHD..40T..IV3 ALGERIA SPEC	11/2001 - 12/2999	2
Common parts
90119-08539
91651-61020

BU211L-TKMRS3 (1995)

(9505- )

(9905- )175T..GEN ; (9905- )BU211..LHD..T3
