YY52L-MDP (1987)
Toyota Dyna150
ILLUST NO. 1 OF 2(8708- )LHD
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 58936A - BAND, ENGINE SERVICE HOLE COVER SUPPORT | ||||
| 58930-95700B0 |
LY61,YY52,61 GRAY,TRIM1# |
1 | ||
| 58930-9570006 |
LY6#,YY52,61 DARK BROWN,TRIM4# |
1 | ||
| 71012S - FRAME SUB-ASSY, FRONT SEAT CUSHION, LH | ||||
| 71012-95412 |
LY6#,YY52,61..LHD |
1 | ||
| 71013S - FRAME SUB-ASSY, FRONT SEAT BACK, RH | ||||
| 71013-9541601 |
LY6#,YY52,61..LHD BLACK,TRIM4# |
1 | ||
| 71013-9541601 |
LY61,YY52,61..LHD BLACK,TRIM1# |
1 | ||
| 71014S - FRAME SUB-ASSY, FRONT SEAT BACK, LH | ||||
| 71014-95422 |
LY6#,YY52,61..LHD W(HEADREST) |
1 | ||
| 71014-95423 |
LY6#,YY52,61..LHD |
1 | ||
| 71071S - COVER, FRONT SEAT CUSHION, RH(FOR SEPARATE TYPE) | ||||
| 71071-9548206 |
LY60,YY52,61..LHD W(FLAME RESISTING & HEADREST),BROWN,TRIM4# |
1 | ||
| 71071-9547706 |
LY60,YY52,61..LHD BROWN,TRIM4# |
1 | ||
| 71071-37040B1 |
LY61,YY52,61..LHD GRAY,TRIM1# |
1 | ||
| 71071-37050B1 |
LY61,YY52,61..LHD W(KNIT FABRIC SEAT & HEADREST),GRAY,TRIM1# |
1 | ||
| 71071-95B0406 |
LY6#,YY52,61..LHD BROWN,TRIM4# |
1 | ||
| 71071-95B0506 |
LY6#,YY52,61..LHD W(FLAME RESISTING & HEADREST),BROWN,TRIM4# |
1 | ||
| 71072S - COVER, FRONT SEAT CUSHION, LH(FOR SEPARATE TYPE) | ||||
| 71072-95B0906 |
LY6#,YY52,61..TW..ST..GEN BROWN,TRIM4# |
1 | ||
| 71072-37030B1 |
LY61,YY52,61..TW..ST..GEN GRAY,TRIM1# |
1 | ||
| 71072-95B2006 |
LY6#,YY52,61..TW..ST..GEN W(FLAME RESISTING & HEADREST),BROWN,TRIM4# |
1 | ||
| 71072-37040B1 |
LY61,YY52,61..TW..ST..GEN W(KNIT FABRIC SEAT & HEADREST),GRAY,TRIM1# |
1 | ||
| 71073S - COVER, FRONT SEAT BACK, RH(FOR SEPARATE TYPE) | ||||
| 71073-95B0506 |
LY6#,YY52,61..LHD W(FLAME RESISTING & HEADREST),BROWN,TRIM4# |
1 | ||
| 71073-37040B2 |
LY61,YY52,61..LHD GRAY,TRIM1# |
1 | ||
| 71073-95B0306 |
LY6#,YY52,61..LHD BROWN,TRIM4# |
1 | ||
| 71073-37050B1 |
LY61,YY52,61..LHD W(KNIT FABRIC SEAT & HEADREST),GRAY,TRIM1# |
1 | ||
| 71074S - COVER, FRONT SEAT BACK, LH(FOR SEPARATE TYPE) | ||||
| 71073-9548106 |
LY6#,YY52,61..TW..ST..GEN W(HEADREST),BROWN,TRIM4# |
1 | ||
| 71074-95B6706 |
LY6#,YY52,61..TW..ST..GEN W(FLAME RESISTING & HEADREST),BROWN,TRIM4# |
1 | ||
| 71074-37030B1 |
LY61,YY52,61..TW..ST..GEN W(KNIT FABRIC SEAT & HEADREST),GRAY,TRIM1# |
1 | ||
| 71073-37010B1 |
LY61,YY52,61..TW..ST..GEN W(HEADREST),GRAY,TRIM1# |
1 | ||
| 71074-37020B1 |
LY61,YY52,61..TW..ST..GEN GRAY,TRIM1# |
1 | ||
| 71074-95B3606 |
LY6#,YY52,61..TW..ST..GEN BROWN,TRIM4# |
1 | ||
| 71319A - STRIKER, FRONT SEAT BACK | ||||
| 71319-95404 |
LY6#,YY52,61 |
1 | ||
| 71373B - COVER, FRONT SEAT BACK LOCK | ||||
| 71373-9540006 |
LY6#,YY52,61 BROWN,TRIM4# |
1 | ||
| 71373-95400B0 |
LY61,YY52,61 GRAY,TRIM1# |
1 | ||
| 71410S - CUSHION ASSY, FRONT SEAT, RH(FOR SEPARATE TYPE) | ||||
| 71410-9547306 |
LY60,YY52,61..LHD ***,W(FLAME RESISTING & HEADREST),BROWN,TRIM4# |
1 | ||
| 71410-9546706 |
LY6#,YY52,61..LHD ***,BROWN,TRIM4# |
1 | ||
| 71410-37070B0 |
LY61,YY52,61..LHD ***,W(KNIT FABRIC SEAT & HEADREST),GRAY,TRIM1# |
1 | ||
| 71410-9546606 |
LY60,YY52,61..LHD ***,BROWN,TRIM4# |
1 | ||
| 71410-37060B0 |
LY61,YY52,61..LHD ***,GRAY,TRIM1# |
1 | ||
| 71410-9547106 |
LY6#,YY52,61..LHD ***,W(FLAME RESISTING & HEADREST),BROWN,TRIM4# |
1 | ||
| 71420S - CUSHION ASSY, FRONT SEAT, LH (FOR SEPARATE TYPE) | ||||
| 71420-9548506 |
LY6#,YY52,61..TW..ST..GEN ***,BROWN,TRIM4# |
1 | ||
| 71420-95B1006 |
LY6#,YY52,61..TW..ST..GEN ***,W(FLAME RESISTING & HEADREST),BROWN,TRIM4# |
1 | ||
| 71420-37030B1 |
LY61,YY52,61..TW..ST..GEN ***,GRAY,TRIM1# |
1 | ||
| 71420-37040B0 |
LY61,YY52,61..TW..ST..GEN ***,W(KNIT FABRIC SEAT & HEADREST),GRAY,TRIM1# |
1 | ||
| 71430S - BACK ASSY, FRONT SEAT, RH(FOR SEPARATE TYPE) | ||||
| 71430-9547606 |
LY6#,YY52,61..LHD ***,W(FLAME RESISTING & HEADREST),BROWN,TRIM4# |
1 | ||
| 71430-37050B0 |
LY61,YY52,61..LHD ***,W(KNIT FABRIC SEAT & HEADREST),GRAY,TRIM1# |
1 | ||
| 71430-37040B1 |
LY61,YY52,61..LHD ***,GRAY,TRIM1# |
1 | ||
| 71430-9547406 |
LY6#,YY52,61..LHD ***,BROWN,TRIM4# |
1 | ||
| 71440S - BACK ASSY, FRONT SEAT, LH(FOR SEPARATE TYPE) | ||||
| 71440-95B2806 |
LY6#,YY52,61..TW..ST..GEN ***,W(HEADREST),BROWN,TRIM4# |
1 | ||
| 71440-95B3106 |
LY6#,YY52,61..TW..ST..GEN ***,BROWN,TRIM4# |
1 | ||
| 71440-95B3006 |
LY6#,YY52,61..TW..ST..GEN ***,W(FLAME RESISTING & HEADREST),BROWN,TRIM4# |
1 | ||
| 71440-26130B0 |
LY61,YY52,61..TW..ST..GEN ***,GRAY,TRIM1# |
1 | ||
| 71440-26140B0 |
LY61,YY52,61..TW..ST..GEN ***,W(HEADREST),GRAY,TRIM1# |
1 | ||
| 71440-26150B0 |
LY61,YY52,61..TW..ST..GEN ***,W(KNIT FABRIC SEAT & HEADREST),GRAY,TRIM1# |
1 | ||
| 71511S - PAD, FRONT SEAT CUSHION, RH(FOR SEPARATE TYPE) | ||||
| 71501-95400 |
LY6#,YY52,61..LHD |
1 | ||
| 71512S - PAD, FRONT SEAT CUSHION, LH (FOR SEPARATE TYPE) | ||||
| 71511-95400 |
LY6#,YY52,61..LHD |
1 | ||
| 71551S - PAD, FRONT SEAT BACK, RH(FOR SEPARATE TYPE) | ||||
| 71552-95403 |
LY6#,YY52,61..LHD |
1 | ||
| 71552S - PAD, FRONT SEAT BACK, LH(FOR SEPARATE TYPE) | ||||
| 71551-95405 |
LY6#,YY52,61..LHD |
1 | ||
| 71551-95404 |
LY6#,YY52,61..LHD W(HEADREST) |
1 | ||
| 71812C - COVER, RECLINING ADJUSTER, LH | ||||
| 71812-95J00B0 |
LY61,YY52,61..LHD GRAY,TRIM1# |
1 | ||
| 71812-95J0016 |
LY6#,YY52,61..LHD BROWN,TRIM4# |
1 | ||
| 71816A - COVER, FRONT SEAT CUSHION HINGE, LH | ||||
| 71816-95J0016 |
LY6#,YY52,61..LHD BROWN,TRIM4# |
1 | ||
| 71816-95J00B0 |
LY61,YY52,61..LHD GRAY,TRIM1# |
1 | ||
| 71910A - HEADREST ASSY, FRONT SEAT | ||||
| 71910-9260306 |
LY6#,YY52,61..TW BROWN,TRIM4# |
1 | ||
| 71910-92603B0 |
LY61,YY52,61..TW GRAY,TRIM1# |
1 | ||
| 71910A - HEADREST ASSY, FRONT SEAT | ||||
| 71910-9260306 |
LY6#,YY52,61..TW BROWN,TRIM4# |
1 | ||
| 71910-92603B0 |
LY61,YY52,61..TW GRAY,TRIM1# |
1 | ||
| 72090 - LOCK ASSY, FRONT SEAT BACK | ||||
| 72090-9540006 |
LY6#,YY52,61 BROWN,TRIM4# |
1 | ||
| 72090-95400B0 |
LY61,YY52,61 GRAY,TRIM1# |
1 | ||
| 72120 - TRACK ASSY, FRONT SEAT, OUTER LH | ||||
| 72120-95A00 |
LY6#,YY52,61..LHD |
1 | ||
| 72520 - ADJUSTER ASSY, RECLINING SEAT BACK, LH | ||||
| 72520-95A0506 |
LY6#,YY52,61..LHD BROWN,TRIM4# |
1 | ||
| 72520-95A05B0 |
LY61,YY52,61..LHD GRAY,TRIM1# |
1 | ||
| Common parts | ||||
| 90119-06214 | ||||
| 90119-08079 | ||||
| 90119-08086 | ||||
| 90119-08469 | ||||
| 90119-10116 | ||||
| 90149-50039 | ||||
| 90168-40043 | ||||
| 90179-08039 | ||||
| 90386-12018 | ||||
| 90468-18071 | ||||
| 90523-08001 | ||||
| 90530-06001 | ||||
| 90530-18003 | ||||
| 90540-06006 | ||||
| 91611-61020 | ||||
| 93560-55016 | ||||
ILLUST NO. 2 OF 2(8708- )
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 71075B - COVER, REAR SEAT CUSHION (FOR BENCH TYPE) | ||||
| 71075-37020B1 |
YY52 W(KNIT FABRIC SEAT),GRAY,TRIM1# |
1 | ||
| 71075-37010B1 |
LY61,YY52,61..TW..GEN GRAY,TRIM1# |
1 | ||
| 71065-9540006 |
LY6#,YY52,61..TW..GEN BROWN,TRIM4# |
1 | ||
| 71065-9501206 |
LY6#,YY52,61..TW..ST..GEN W(FLAME RESISTING),BROWN,TRIM4# |
1 | ||
| 71077B - COVER, REAR SEAT BACK (FOR BENCH TYPE) | ||||
| 71077-9540906 |
LY6#,YY52,61..TW..ST..GEN W(FLAME RESISTING),BROWN,TRIM4# |
1 | ||
| 71077-9540706 |
LY6#,YY52,61..TW..GEN BROWN,TRIM4# |
1 | ||
| 71077-37010B2 |
LY61,YY52,61..TW..GEN GRAY,TRIM1# |
1 | ||
| 71077-37020B2 |
YY52 W(KNIT FABRIC SEAT),GRAY,TRIM1# |
1 | ||
| 71301D - HINGE SUB-ASSY, REAR SEAT, RH | ||||
| 71301-95401 |
LY6#,YY52,61..TW |
1 | ||
| 71302D - HINGE SUB-ASSY, REAR SEAT, LH | ||||
| 71302-95401 |
LY6#,YY52,61..TW |
1 | ||
| 71308C - LEG SUB-ASSY, REAR SEAT, FRONT | ||||
| 71308-95400 |
LY6#,YY52,61..TW..GEN |
1 | ||
| 71315B - PIN, REAR SEAT HINGE | ||||
| 71315-95011 |
LY61,YY52,61..TW |
2 | ||
| 71334A - STOPPER, REAR SEAT LEG | ||||
| 71334-95400 |
LY6#,YY52,61..TW |
1 | ||
| 71409 - STOPPER SUB-ASSY, REAR SEAT BACK | ||||
| 71409-95A31 |
LY6#,YY52,61..TW |
1 | ||
| 71460B - CUSHION ASSY, REAR SEAT (FOR BENCH TYPE) | ||||
| 71460-37010B1 |
LY61,YY52,61..TW..GEN ***,GRAY,TRIM1# |
1 | ||
| 71460-9541306 |
LY6#,YY52,61..TW..GEN ***,BROWN,TRIM4# |
1 | ||
| 71460-9501706 |
LY6#,YY52,61..TW..ST..GEN ***,W(FLAME RESISTING),BROWN,TRIM4# |
1 | ||
| 71460-37030B1 |
YY52 ***,W(KNIT FABRIC SEAT),GRAY,TRIM1# |
1 | ||
| 71480B - BACK ASSY, REAR SEAT (FOR BENCH TYPE) | ||||
| 71480-37020B1 |
YY52 ***,W(KNIT FABRIC SEAT),GRAY,TRIM1# |
1 | ||
| 71480-9540706 |
LY6#,YY52,61..TW..GEN ***,BROWN,TRIM4# |
1 | ||
| 71480-9540906 |
LY6#,YY52,61..TW..ST..GEN ***,W(FLAME RESISTING),BROWN,TRIM4# |
1 | ||
| 71480-37010B1 |
LY61,YY52,61..TW..GEN ***,GRAY,TRIM1# |
1 | ||
| 71611 - PAD, REAR SEAT CUSHION | ||||
| 71611-95401 |
LY6#,YY52,61..TW |
1 | ||
| 71621A - PAD, REAR SEAT CUSHION SILENCER, A | ||||
| 71621-95701 |
LY6#,YY52,61..TW |
6 | ||
| 71650 - SPRING ASSY, REAR SEAT CUSHION | ||||
| 71650-95404 |
LY6#,YY52,61..TW |
1 | ||
| 71651B - PAD, REAR SEAT BACK(FOR BENCH TYPE) | ||||
| 71651-95400 |
LY6#,YY52,61..TW |
1 | ||
| 71670 - SPRING ASSY, REAR SEAT BACK(FOR BENCH SEAT) | ||||
| 71670-95402 |
LY6#,YY52,61..TW |
1 | ||
| 71777A - PLATE, REAR SIDE SEAT HINGE, LOWER RH | ||||
| 71777-95400 |
LY6#,YY52,61..TW |
1 | ||
| 71778A - PLATE, REAR SIDE SEAT HINGE, LOWER LH | ||||
| 71778-95400 |
LY6#,YY52,61..TW |
1 | ||
| 79189 - STOPPER, NO.1 SEAT LEG | ||||
| 79189-95J00 |
LY61,YY52,61..TW |
2 | ||
| 79199 - HOLDER, NO.1 SEAT LEG STOPPER | ||||
| 79199-95J00 |
LY61,YY52,61..TW |
2 | ||
| Common parts | ||||
| 90109-08137 | ||||
| 90109-08157 | ||||
| 90109-10084 | ||||
| 90119-10185 | ||||
| 90119-10395 | ||||
| 90206-12035 | ||||
| 90386-12007 | ||||
| 90468-18071 | ||||
| 90506-23037 | ||||
| 90523-06017 | ||||
| 91611-60610 | ||||
| 91611-60614 | ||||
| 91611-60816 | ||||
| 93568-55018 | ||||
