YY52L-MDP (1987)
Toyota Dyna150
ILLUST NO. 1 OF 2(8708- )
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 33502 - PLATE SUB-ASSY, SHIFT LEVER | ||||
| 33502-25010 |
LY6#,YY52,61 |
1 | ||
| 33502A - COLLAR (FOR FLOOR SHIFT SETTING) | ||||
| 90387-10081 |
LY6#,YY52,61 OD=13.8 |
4 | ||
| 33502B - GROMMET (FOR SHIFT LEVER PLATE) | ||||
| 90480-17018 |
LY6#,YY52,61 |
4 | ||
| 33502C - BUSH (FOR FLOOR SHIFT SETTING) | ||||
| 90386-13007 |
LY61,YY52,61 |
2 | ||
| 90386-13192 |
LY6#,YY52,61 |
2 | ||
| 33502C - BUSH (FOR FLOOR SHIFT SETTING) | ||||
| 90386-13007 |
LY61,YY52,61 |
2 | ||
| 90386-13192 |
LY6#,YY52,61 |
2 | ||
| 33502D - BOLT, HEXAGON (FOR SHIFT LEVER PLATE) | ||||
| 90101-08107 |
LY6#,YY52,61 |
1 | ||
| 33502E - SPRING, TORSION (FOR SHIFT LEVER PLATE) | ||||
| 90508-23094 |
LY6#,YY52,61 |
1 | ||
| 33502G - COLLAR (FOR SHIFT LEVER PLATE) | ||||
| 90387-08064 |
LY6#,YY52,61 |
1 | ||
| 33503A - COLLAR(FOR SHIFT LEVER) | ||||
| 90387-08063 |
LY6#,YY52,61 UPR |
1 | ||
| 90387-08065 |
LY6#,YY52,61 LWR |
1 | ||
| 33503A - COLLAR(FOR SHIFT LEVER) | ||||
| 90387-08063 |
LY6#,YY52,61 UPR |
1 | ||
| 90387-08065 |
LY6#,YY52,61 LWR |
1 | ||
| 33503F - LEVER SUB-ASSY, SHIFT(FOR FLOOR SHIFT) | ||||
| 33503-25020 |
LY6#,YY52,61..LHD |
1 | ||
| 33503G - BUSH(FOR SHIFT LEVER) | ||||
| 90386-13007 |
LY61,YY52,61 UPR |
2 | ||
| 90386-13192 |
LY6#,YY52,61 UPR |
2 | ||
| 90389-11002 |
LY6#,YY52,61 LWR |
2 | ||
| 33503G - BUSH(FOR SHIFT LEVER) | ||||
| 90386-13007 |
LY61,YY52,61 UPR |
2 | ||
| 90386-13192 |
LY6#,YY52,61 UPR |
2 | ||
| 90389-11002 |
LY6#,YY52,61 LWR |
2 | ||
| 33503G - BUSH(FOR SHIFT LEVER) | ||||
| 90386-13007 |
LY61,YY52,61 UPR |
2 | ||
| 90386-13192 |
LY6#,YY52,61 UPR |
2 | ||
| 90389-11002 |
LY6#,YY52,61 LWR |
2 | ||
| 33503G - BUSH(FOR SHIFT LEVER) | ||||
| 90386-13007 |
LY61,YY52,61 UPR |
2 | ||
| 90386-13192 |
LY6#,YY52,61 UPR |
2 | ||
| 90389-11002 |
LY6#,YY52,61 LWR |
2 | ||
| 33503P - RING, O(FOR SHIFT LEVER) | ||||
| 96711-24018 |
LY6#,YY52,61 |
2 | ||
| 33503P - RING, O(FOR SHIFT LEVER) | ||||
| 96711-24018 |
LY6#,YY52,61 |
2 | ||
| 33504F - KNOB SUB-ASSY, SHIFT LEVER | ||||
| 33504-2401006 |
LY6#,YY52,61 BROWN,TRIM4# |
1 | ||
| 33504-35030B1 |
LY61,YY52,61 BLUISH GRAY,TRIM1# |
1 | ||
| 33504-2401048 |
LY61,YY52,61 GRAY,TRIM1# |
1 | ||
| 33506F - RETAINER SUB-ASSY, CONTROL SHIFT LEVER (FOR FLOOR SHIFT | ||||
| 33506-25020 |
LY6#,YY52,61..LHD |
1 | ||
| 33528 - COVER, CONTROL SHAFT | ||||
| 33528-25010 |
LY6#,YY52,61 |
1 | ||
| 33555 - BOOT, SHIFT LEVER | ||||
| 33555-25010 |
LY6#,YY52,61 |
1 | ||
| 33555-25011 |
LY61,YY52,61 |
1 | ||
| 33710 - ROD ASSY, GEAR SHIFTING, NO.1 | ||||
| 33710-25150 |
LY6#,YY52,61..LHD |
1 | ||
| Common parts | ||||
| 90179-08141 | ||||
| 91121-40855 | ||||
| 91121-50850 | ||||
| 91611-60814 | ||||
| 91665-40825 | ||||
| 94110-40800 | ||||
| 94512-00800 | ||||
ILLUST NO. 2 OF 2(8708- )LHD
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 33607F - SUPPORT SUB-ASSY, CONTROL ROD (FOR FLOOR SHIFT) | ||||
| 33607-25050 |
LY6#,YY52,61 |
1 | ||
| 33642F - LEVER, GEAR SELECTING, NO.2 | ||||
| 33642-25010 |
LY6#,YY52,61..LHD |
1 | ||
| 33642H - BUSH (FOR GEAR SELECTING LEVER) | ||||
| 90386-13007 |
LY61,YY52,61..LHD |
2 | ||
| 90386-13192 |
LY6#,YY52,61..LHD |
2 | ||
| 33642H - BUSH (FOR GEAR SELECTING LEVER) | ||||
| 90386-13007 |
LY61,YY52,61..LHD |
2 | ||
| 90386-13192 |
LY6#,YY52,61..LHD |
2 | ||
| 33642J - RING, E (FOR GEAR SELECTING LEVER) | ||||
| 96160-01000 |
LY6#,YY52,61..LHD |
1 | ||
| 33643F - LEVER, GEAR SELECTING, NO.3 | ||||
| 33643-25010 |
LY6#,YY52,61 |
1 | ||
| 33643G - BUSH (FOR GEAR SELECTING LEVER) | ||||
| 90386-13192 |
LY6#,YY52,61 |
2 | ||
| 33643G - BUSH (FOR GEAR SELECTING LEVER) | ||||
| 90386-13192 |
LY6#,YY52,61 |
2 | ||
| 33705F - SUPPORT SUB-ASSY, CROSS SHAFT, NO.1 (FOR FLOOR SHIFT) | ||||
| 33705-25150 |
LY6#,YY52,61..LHD NO.1 |
1 | ||
| 33705-25140 |
LY6#,YY52,61 NO.2 |
1 | ||
| 33705-25151 |
LY61,YY52,61..LHD NO.1 |
1 | ||
| 33705F - SUPPORT SUB-ASSY, CROSS SHAFT, NO.1 (FOR FLOOR SHIFT) | ||||
| 33705-25150 |
LY6#,YY52,61..LHD NO.1 |
1 | ||
| 33705-25140 |
LY6#,YY52,61 NO.2 |
1 | ||
| 33705-25151 |
LY61,YY52,61..LHD NO.1 |
1 | ||
| 33706F - SUPPORT SUB-ASSY, CROSS SHAFT, NO.2 (FOR FLOOR SHIFT) | ||||
| 33706-25031 |
LY61,YY52,61..LHD |
1 | ||
| 33706-25030 |
LY6#,YY52,61..LHD |
1 | ||
| 33709B - BUSH (FOR CROSS SHAFT) | ||||
| 33772-20010 |
LY6#,YY52,61 |
4 | ||
| 33772-26010 |
LY61,YY52,61 |
2 | ||
| 33709B - BUSH (FOR CROSS SHAFT) | ||||
| 33772-20010 |
LY6#,YY52,61 |
4 | ||
| 33772-26010 |
LY61,YY52,61 |
2 | ||
| 33709F - SHAFT SUB-ASSY, CROSS, NO.1 (FOR FLOOR SHIFT) | ||||
| 33709-25160 |
LY6#,YY52,61 NO.2 |
1 | ||
| 33709-25161 |
LY61,YY52,61 NO.2 |
1 | ||
| 33709-25150 |
LY6#,YY52,61..LHD NO.1 |
1 | ||
| 33709F - SHAFT SUB-ASSY, CROSS, NO.1 (FOR FLOOR SHIFT) | ||||
| 33709-25160 |
LY6#,YY52,61 NO.2 |
1 | ||
| 33709-25161 |
LY61,YY52,61 NO.2 |
1 | ||
| 33709-25150 |
LY6#,YY52,61..LHD NO.1 |
1 | ||
| 33709J - COVER, CROSS SHAFT DUST | ||||
| 33775-20020 |
LY6#,YY52,61..LHD |
2 | ||
| 33709J - COVER, CROSS SHAFT DUST | ||||
| 33775-20020 |
LY6#,YY52,61..LHD |
2 | ||
| 33720E - ROD ASSY, GEAR SELECTING | ||||
| 33720-25160 |
LY6#,YY52,61..LHD |
1 | ||
| 33723F - SWIVEL, CONNECTING ROD (FOR FLOOR SHIFT) | ||||
| 33723-10020 |
LY6#,YY52,61 |
1 | ||
| 33736F - ROD, GEAR SELECTING, NO.2(FOR FLOOR SHIFT) | ||||
| 33790-25200 |
LY6#,YY52,61..LHD |
1 | ||
| 33736P - PIN, W/HOLE(FOR GEAR SELECTING NO.2 ROD) | ||||
| 90240-08028 |
LY6#,YY52,61 |
1 | ||
| 33737F - ROD, GEAR SELECTING, NO.3 (FOR FLOOR SHIFT) | ||||
| 33701-25180 |
LY6#,YY52,61 |
1 | ||
| 33740F - END ASSY, CONNECTING ROD, NO.1(FOR FLOOR SHIFT) | ||||
| 33740-26010 |
LY6#,YY52,61 |
1 | ||
| 33741J - BUSH, NO.2 (FOR SHIFTING OR SELECTING ROD) | ||||
| 90389-08005 |
LY61..T2,T3;LY60,YY52,61;LY61..TW..ST |
2 | ||
| 33741J - BUSH, NO.2 (FOR SHIFTING OR SELECTING ROD) | ||||
| 90389-08005 |
LY61..T2,T3;LY60,YY52,61;LY61..TW..ST |
2 | ||
| 33741J - BUSH, NO.2 (FOR SHIFTING OR SELECTING ROD) | ||||
| 90389-08005 |
LY61..T2,T3;LY60,YY52,61;LY61..TW..ST |
2 | ||
| 33741P - GROMMET, NO.2 (FOR SHIFTING OR SELECTING ROD) | ||||
| 90480-17177 |
LY6#,YY52,61 |
2 | ||
| 33741P - GROMMET, NO.2 (FOR SHIFTING OR SELECTING ROD) | ||||
| 90480-17177 |
LY6#,YY52,61 |
2 | ||
| 33741P - GROMMET, NO.2 (FOR SHIFTING OR SELECTING ROD) | ||||
| 90480-17177 |
LY6#,YY52,61 |
2 | ||
| 33742F - ROD, GEAR SHIFTING, NO.2(FOR FLOOR SHIFT) | ||||
| 33742-25150 |
LY6#,YY52,61..TW |
1 | ||
| 33742F - ROD, GEAR SHIFTING, NO.2(FOR FLOOR SHIFT) | ||||
| 33742-25150 |
LY6#,YY52,61..TW |
1 | ||
| 33742P - PIN, W/HOLE | ||||
| 90240-08068 |
LY61,YY52,61 |
1 | ||
| 90240-08034 |
LY6#,YY52,61 |
1 | ||
| 33742P - PIN, W/HOLE | ||||
| 90240-08068 |
LY61,YY52,61 |
1 | ||
| 90240-08034 |
LY6#,YY52,61 |
1 | ||
| 33743D - ROD, GEAR SHIFTING, NO.3 (FOR FLOOR SHIFT) | ||||
| 33743-25120 |
LY6#,YY52,61 |
1 | ||
| 33750F - END, CONNECTING ROD, NO.2 (FOR FLOOR SHIFT) | ||||
| 33750-26010 |
LY6#,YY52,61 |
1 | ||
| 33770P - COLLER (FOR CROSS SHAFT) | ||||
| 90387-09021 |
LY6#,YY52,61..LHD |
6 | ||
| 33770P - COLLER (FOR CROSS SHAFT) | ||||
| 90387-09021 |
LY6#,YY52,61..LHD |
6 | ||
| 33772F - BUSH, CROSS SHAFT SUPPORT, NO.1 (FOR FLOOR SHIFT) | ||||
| 33772-25010 |
LY6#,YY52,61 |
1 | ||
| 33772G - RING, SNAP (FOR CROSS SAFT SUPPORT BUSH) | ||||
| 96151-01600 |
LY6#,YY52,61..LHD |
1 | ||
| 33772H - BUSH, CROSS SHAFT SUPPORT, NO.2 (FOR FLOOR SHIFT) | ||||
| 33772-20010 |
LY6#,YY52,61..LHD NO.1 |
4 | ||
| 33772-26010 |
LY61,YY52,61..LHD NO.1 |
2 | ||
| 33772-25020 |
LY6#,YY52,61..LHD NO.2 |
1 | ||
| 33772H - BUSH, CROSS SHAFT SUPPORT, NO.2 (FOR FLOOR SHIFT) | ||||
| 33772-20010 |
LY6#,YY52,61..LHD NO.1 |
4 | ||
| 33772-26010 |
LY61,YY52,61..LHD NO.1 |
2 | ||
| 33772-25020 |
LY6#,YY52,61..LHD NO.2 |
1 | ||
| 33772H - BUSH, CROSS SHAFT SUPPORT, NO.2 (FOR FLOOR SHIFT) | ||||
| 33772-20010 |
LY6#,YY52,61..LHD NO.1 |
4 | ||
| 33772-26010 |
LY61,YY52,61..LHD NO.1 |
2 | ||
| 33772-25020 |
LY6#,YY52,61..LHD NO.2 |
1 | ||
| 33773E - SUPPORT, CROSS SHAFT, NO.1 | ||||
| 33773-20020 |
LY6#,YY52,61 NO.2 |
1 | ||
| 33773H - RING, SNAP (FOR CROSS SHAFT SUPPORT SNAP) | ||||
| 96151-01600 |
LY6#,YY52,61 |
1 | ||
| 33774A - SUPPORT, CROSS SHAFT, NO.2 | ||||
| 33774-25010 |
LY6#,YY52,61 |
1 | ||
| 33775F - COVER, CROSS SHAFT DUST, NO.1 (FOR FLOOR SHIFT) | ||||
| 33775-20020 |
LY6#,YY52,61 RH |
1 | ||
| 33775-20040 |
LY6#,YY52,61 LH |
1 | ||
| 33775F - COVER, CROSS SHAFT DUST, NO.1 (FOR FLOOR SHIFT) | ||||
| 33775-20020 |
LY6#,YY52,61 RH |
1 | ||
| 33775-20040 |
LY6#,YY52,61 LH |
1 | ||
| 33793F - BRACKET, CROSS SHAFT, NO.2(FOR FLOOR SHIFT) | ||||
| 33793-25040 |
LY6#,YY52,61 |
1 | ||
| 33861 - ROD, GEAR SHIFTING, NO.4 | ||||
| 33861-25010 |
LY6#,YY52,61..TW |
1 | ||
| Common parts | ||||
| 90119-08471 | ||||
| 90119-10531 | ||||
| 90170-08052 | ||||
| 90179-08146 | ||||
| 90206-13003 | ||||
| 90468-03011 | ||||
| 90468-14004 | ||||
| 91611-60816 | ||||
| 91611-61025 | ||||
| 91651-40610 | ||||
| 91651-60825 | ||||
| 91661-40830 | ||||
| 94110-41000 | ||||
| 94120-40800 | ||||
| 94130-60800 | ||||
| 94512-01000 | ||||
| 94531-00800 | ||||
| 94611-11400 | ||||
| 94613-10800 | ||||
