YH80R-MDB3 (1985)
Toyota Dyna100
(8508- )
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 04412 - GASKET KIT, REAR DIFFERENTIAL CARRIER | ||||
| 04412-35010 |
LH80,YH8# |
1 | ||
| 41101 - CARRIER SUB-ASSY, DIFFERENTIAL, REAR | ||||
| 41101-35040 |
YH8#..ARL,GEN;LH80..5F..ARL |
1 | ||
| 41110 - CARRIER ASSY, DIFFERENTIAL, REAR | ||||
| 41110-35044 |
YH80 *FGR=37:7=5.285,*AXC=G162,*FGR=37:7 |
1 | ||
| 41110A - BOLT, NO.1 (FOR REAR DIFFERENTIAL CARRIER SET) | ||||
| 90116-08180 |
LH80,YH8# L=44 |
2 | ||
| 41110A - BOLT, NO.1 (FOR REAR DIFFERENTIAL CARRIER SET) | ||||
| 90116-08180 |
LH80,YH8# L=44 |
2 | ||
| 41114 - BOLT, REAR DIFFERENTIAL BEARING CAP | ||||
| 90105-12053 |
LH80,YH8# |
4 | ||
| 41201 - FINAL GEAR KIT, DIFFERENTIAL, REAR | ||||
| 41201-29326 |
YH80 *FGR=37:7 |
1 | ||
| 41201A - BEARING (FOR REAR DRIVE PINION REAR) | ||||
| 90366-35044 |
LH80,YH8# |
1 | ||
| 41201B - BEARING (FOR REAR DRIVE PINION FRONT) | ||||
| 90366-30022 |
LH80,YH8# |
1 | ||
| 41201C - SEAL, OIL (FOR REAR DIFFERENTIAL CARRIER) | ||||
| 90311-38133 |
LH80,YH8# |
1 | ||
| 41201D - WASHER, PLATE (FOR REAR DIFFERENTIAL DRIVE PINION) | ||||
| 90201-35502 |
LH80,YH8# OD=47,T=1.85,T=1,84-1,86 |
1 | ||
| 90201-35498 |
LH80,YH8# OD=47,T=1.73,T=1,72-1,74 |
1 | ||
| 90201-35506 |
LH80,YH8# OD=47,T=1.97,T=1,96-1,98 |
1 | ||
| 90201-35501 |
LH80,YH8# OD=47,T=1.82,T=1,81-1,83 |
1 | ||
| 90201-35509 |
LH80,YH8# OD=47,T=2.06,T=2,05-2,07 |
1 | ||
| 90201-35503 |
LH80,YH8# OD=47,T=1.88,T=1,87-1,89 |
1 | ||
| 90201-35512 |
LH80,YH8# OD=47,T=2.15,T=2,14-2,16 |
1 | ||
| 90201-35497 |
LH80,YH8# OD=47,T=1.70,T=1,69-1,71 |
1 | ||
| 90201-35511 |
LH80,YH8# OD=47,T=2.12,T=2,11-2,13 |
1 | ||
| 90201-35500 |
LH80,YH8# OD=47,T=1.79,T=1,78-1,80 |
1 | ||
| 90201-35499 |
LH80,YH8# OD=47,T=1.76,T=1,75-1,77 |
1 | ||
| 90201-35504 |
LH80,YH8# OD=47,T=1.91,T=1,90-1,92 |
1 | ||
| 90201-35515 |
LH80,YH8# OD=47,T=2.24,MARK 01,T=2,23-2,25 |
1 | ||
| 90201-35517 |
LH80,YH8# OD=47,T=2.30,MARK 03,T=2,29-2,31 |
1 | ||
| 90201-35508 |
LH80,YH8# OD=47,T=2.03,T=2,02-2,04 |
1 | ||
| 90201-35518 |
LH80,YH8# OD=47,T=2.33,MARK 04,T=2.32-2.34 |
1 | ||
| 90201-35514 |
LH80,YH8# OD=47,T=2.21,T=2,20-2,22 |
1 | ||
| 90201-35510 |
LH80,YH8# OD=47,T=2.09,T=2,08-2,10 |
1 | ||
| 90201-35516 |
LH80,YH8# OD=47,T=2.27,MARK 02,T=2,26-2,28 |
1 | ||
| 90201-35513 |
LH80,YH8# OD=47,T=2.18,T=2,17-2,19 |
1 | ||
| 90201-35507 |
LH80,YH8# OD=47,T=2.00,T=1,99-2,01 |
1 | ||
| 90201-35505 |
LH80,YH8# OD=47,T=1.94,T=1,93-1,95 |
1 | ||
| 41204 - FLANGE SUB-ASSY, REAR DRIVE PINION COMPANION, REAR | ||||
| 41204-35040 |
LH80,YH8# |
1 | ||
| 41204A - WASHER, PLATE (FOR REAR DRIVE PINION) | ||||
| 90201-20005 |
LH80,YH8# |
1 | ||
| 41204B - NUT (FOR REAR DRIVE PINION) | ||||
| 90179-20001 |
LH80,YH8# |
1 | ||
| 41214 - SLINGER, REAR DIFFERENTIAL DRIVE PINION OIL | ||||
| 41214-26010 |
LH80,YH8# |
1 | ||
| 41222 - PLATE, REAR DIFFERENTIAL RING GEAR SET BOLT LOCK | ||||
| 41222-35020 |
LH80,YH8# |
5 | ||
| 41222A - BOLT (FOR REAR DIFFERENTIAL RING GEAR SET) | ||||
| 90101-11353 |
LH80,YH8# |
10 | ||
| 41231 - SPACER, REAR DIFFERENTIAL DRIVE PINION BEARING | ||||
| 41231-40011 |
LH80,YH8# |
1 | ||
| 41252 - DEFLECTOR, DUST (FOR REAR DIFFERENTIAL) | ||||
| 41252-35010 |
LH80,YH8# |
1 | ||
| 41301A - BEARING(FOR REAR DIFFERENTIAL CASE) | ||||
| 90368-45066 |
LH80,YH8# |
2 | ||
| 41301A - BEARING(FOR REAR DIFFERENTIAL CASE) | ||||
| 90368-45066 |
LH80,YH8# |
2 | ||
| 41302 - CASE SUB-ASSY, REAR DIFFERENTIAL | ||||
| 41311-40020 |
LH80,YH8# |
1 | ||
| 41315 - NUT, REAR DIFFERENTIAL BEARING ADJUSTING | ||||
| 41315-35010 |
LH80,YH8# |
2 | ||
| 41315 - NUT, REAR DIFFERENTIAL BEARING ADJUSTING | ||||
| 41315-35010 |
LH80,YH8# |
2 | ||
| 41316 - LOCK, REAR DIFFERENTIAL BEARING ADJUSTING NUT | ||||
| 41316-30010 |
LH80,YH8# |
2 | ||
| 41331 - GEAR, REAR DIFFERENTIAL SIDE | ||||
| 41331-35011 |
LH80,YH8# |
2 | ||
| 41331 - GEAR, REAR DIFFERENTIAL SIDE | ||||
| 41331-35011 |
LH80,YH8# |
2 | ||
| 41341 - PINION, REAR DIFFERENTIAL | ||||
| 41341-35020 |
LH80,YH8# |
2 | ||
| 41341 - PINION, REAR DIFFERENTIAL | ||||
| 41341-35020 |
LH80,YH8# |
2 | ||
| 41342 - SHAFT, REAR DIFFERENTIAL PINION | ||||
| 41342-39610 |
LH80,YH8# |
1 | ||
| 41343 - PIN, REAR DIFFERENTIAL PINION SHAFT | ||||
| 90250-06085 |
LH80,YH8# |
1 | ||
| 41351 - WASHER, REAR DIFFERENTIAL PINION THRUST | ||||
| 41351-30052 |
LH80,YH8# |
2 | ||
| 41351 - WASHER, REAR DIFFERENTIAL PINION THRUST | ||||
| 41351-30052 |
LH80,YH8# |
2 | ||
| 41361 - WASHER, REAR DIFFERENTIAL SIDE GEAR THRUST, NO.1 | ||||
| 41363-40021 |
LH80,YH8# T=1.8,T=1.77-1,83 |
2 | ||
| 41362-40021 |
LH80,YH8# T=1.7,T=1,67-1,73 |
2 | ||
| 41361-40021 |
LH80,YH8# T=1.6,T=1,57-1,63 |
2 | ||
| 41361 - WASHER, REAR DIFFERENTIAL SIDE GEAR THRUST, NO.1 | ||||
| 41363-40021 |
LH80,YH8# T=1.8,T=1.77-1,83 |
2 | ||
| 41362-40021 |
LH80,YH8# T=1.7,T=1,67-1,73 |
2 | ||
| 41361-40021 |
LH80,YH8# T=1.6,T=1,57-1,63 |
2 | ||
| 42110 - HOUSING ASSY, REAR AXLE | ||||
| 42110-26190 |
LH80,YH8# |
1 | ||
| 42110A - PLUG (FOR REAR AXLE HOUSING FILLER) | ||||
| 90341-18006 |
LH80,YH8# |
1 | ||
| 42110B - GASKET (FOR REAR AXLE HOUSING FILLER PLUG) | ||||
| 12157-10010 |
LH80,YH8# |
1 | ||
| 42110C - PLUG, BREATHER (FOR REAR AXLE HOUSING) | ||||
| 90930-03031 |
LH80,YH8# |
1 | ||
| 42110D - GASKET (FOR REAR AXLE HOUSING DRAIN PLUG) | ||||
| 12157-10010 |
LH80,YH8# |
1 | ||
| 42110E - PLUG (FOR REAR AXLE HOUSING DRAIN) | ||||
| 90341-18057 |
LH80,YH8# |
1 | ||
| 42181 - GASKET, REAR DIFFERENTIAL CARRIER | ||||
| 42181-60020 |
LH80,YH8# |
1 | ||
| Common parts | ||||
| 90170-08204 | ||||
| 91611-60814 | ||||
| 94110-50800 | ||||
| 94512-00800 | ||||
