Toyota Dyna XZU330 REAR DISC BRAKE CALIPER & DUST COVER

Part #	Description	Period	Qty
04466 - PAD KIT, DISC BRAKE, REAR
04465-37090	XZU330,340..80T MARK NS174	10/2004 - 10/2006	1
04479A - CYLINDER KIT, DISC BRAKE, REAR
04478-37090	XZU330,340..80T	10/2004 - 10/2006	1
04946 - SHIM KIT, ANTI SQUEAL(FOR REAR DISC BRAKE)
04945-37050	XZU330,340..80T	10/2004 - 10/2006	1
04948 - FITTING KIT, DISC BRAKE, REAR
04948-37010	XZU330,340..80T	10/2004 - 10/2006	1
31478C - CAP, BLEEDER PLUG(FOR REAR DISC BRAKE)
31478-37030	XZU330,340..80T	10/2004 - 10/2006	2
47547C - PLUG, BLEEDER(FOR REAR DISC BRAKE)
47847-37030	XZU330,340..80T	10/2004 - 10/2006	2
47715C - PIN, CYLINDER SLIDE(FOR REAR DISC BRAKE)
47715-37120	XZU330,340..80T NO.2	10/2004 - 10/2006	2
47714-37120	XZU330,340..80T NO.1	10/2004 - 10/2006	2
47715C - PIN, CYLINDER SLIDE(FOR REAR DISC BRAKE)
47715-37120	XZU330,340..80T NO.2	10/2004 - 10/2006	2
47714-37120	XZU330,340..80T NO.1	10/2004 - 10/2006	2
47716A - PLATE, PAD SUPPORT, NO.1(FOR REAR DISC BRAKE)
47716-37120	XZU330,340..80T	10/2004 - 10/2006	4
47716A - PLATE, PAD SUPPORT, NO.1(FOR REAR DISC BRAKE)
47716-37120	XZU330,340..80T	10/2004 - 10/2006	4
47717A - PLATE, PAD SUPPORT, NO.2(FOR REAR DISC BRAKE)
47717-37120	XZU330,340..80T	10/2004 - 10/2006	4
47717A - PLATE, PAD SUPPORT, NO.2(FOR REAR DISC BRAKE)
47717-37120	XZU330,340..80T	10/2004 - 10/2006	4
47721C - MOUNTING, REAR DISC BRAKE CYLINDER, RH
47821-37010	XZU330,340..80T	10/2004 - 10/2006	1
47721D - BOLT(FOR REAR DISC BRAKE CYLINDER MOUTING)
90105-37120	XZU330,340..80T	10/2004 - 10/2006	4
47721D - BOLT(FOR REAR DISC BRAKE CYLINDER MOUTING)
90105-37120	XZU330,340..80T	10/2004 - 10/2006	4
47722A - MOUNTING, REAR DISC BRAKE CYLINDER, LH
47821-37010	XZU330,340..80T	10/2004 - 10/2006	1
47731B - PISTON, REAR DISC BRAKE
47731-37120	XZU330,340..80T	10/2004 - 10/2006	4
47731B - PISTON, REAR DISC BRAKE
47731-37120	XZU330,340..80T	10/2004 - 10/2006	4
47775D - BOOT, BUSH DUST(FOR REAR DISC BRAKE)
47775-37120	XZU330,340..80T	10/2004 - 10/2006	4
47775D - BOOT, BUSH DUST(FOR REAR DISC BRAKE)
47775-37120	XZU330,340..80T	10/2004 - 10/2006	4
47803 - COVER SUB-ASSY, DISC BRAKE DUST, REAR RH
47803-37010	XZU330,340..80T	10/2004 - 10/2006	1
47804 - COVER SUB-ASSY, DISC BRAKE DUST, REAR LH
47804-37010	XZU330,340..80T	10/2004 - 10/2006	1
47830 - CYLINDER ASSY, DISC BRAKE, REAR RH
47830-37010	XZU330,340..80T	10/2004 - 10/2006	1
47850 - CYLINDER ASSY, DISC BRAKE, REAR LH
47850-37010	XZU330,340..80T	10/2004 - 10/2006	1
Common parts
90105-16071
91611-B0812

XZU330L-TKMSWR3 (2002)

(0410- )80T
