HU40R-MRDT (1982)
Toyota Dyna
(8204-8408)2H
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 11802 - BEARING SET, CAMSHAFT | ||||
| 11804-68010 |
2H..HU40,50 U/S 0.250 |
1 | ||
| 11803-68010 |
2H..HU40,50 U/S 0.125 |
1 | ||
| 11802-68010 |
2H..HU40,50 STD |
1 | ||
| 13511 - CAMSHAFT | ||||
| 13511-56010 |
B,2B,3B..BU2#,3#,40 |
1 | ||
| 13511-68010 |
2H..HU40,50 |
1 | ||
| 13511B - PLUG, EXPANSION(FOR CAMSHAFT) | ||||
| 90331-51032 |
B,2B,3B..BU2#,3#,40 OD=51 |
1 | ||
| 90331-55001 |
2H..HU40,50 OD=55 |
1 | ||
| 13523 - GEAR OR SPROCKET, CAMSHAFT TIMING | ||||
| 13523-68010 |
2H..HU40,50 |
1 | ||
| 13523B - WASHER, PLATE(FOR TIMING GEAR) | ||||
| 90201-10227 |
B,2B,3B..BU2#,3#,40 OD=40,ID=10.5 |
1 | ||
| 90201-12006 |
2H..HU40,50 |
1 | ||
| 13571 - PLATE, CAMSHAFT THRUST | ||||
| 13571-56010 |
B,2B,3B..BU2#,3#,40 |
1 | ||
| 13571-68010 |
2H..HU40,50 |
1 | ||
| 13711 - VALVE, INTAKE | ||||
| 13711-68010 |
2H..HU40,50 |
6 | ||
| 13711A - SEAL OR RING, O(FOR VALVE STEM OIL) | ||||
| 90913-02050 |
2H..HU40,50 |
12 | ||
| 13711A - SEAL OR RING, O(FOR VALVE STEM OIL) | ||||
| 90913-02050 |
2H..HU40,50 |
12 | ||
| 13711B - SPRING, COMPRESSION(FOR INNER) | ||||
| 90501-26017 |
2H..HU40,50 |
12 | ||
| 13711B - SPRING, COMPRESSION(FOR INNER) | ||||
| 90501-26017 |
2H..HU40,50 |
12 | ||
| 13711C - SPRING, COMPRESSION(FOR OUTER) | ||||
| 90501-42006 |
2H..HU40,50 |
12 | ||
| 90501-47003 |
B,2B,3B..BU2#,3#,40 |
8 | ||
| 13711C - SPRING, COMPRESSION(FOR OUTER) | ||||
| 90501-42006 |
2H..HU40,50 |
12 | ||
| 90501-47003 |
B,2B,3B..BU2#,3#,40 |
8 | ||
| 13715 - VALVE, EXHAUST | ||||
| 13715-68010 |
2H..HU40,50 |
6 | ||
| 13741 - RETAINER, VALVE SPRING | ||||
| 13741-68010 |
2H..HU40,50 |
12 | ||
| 13741 - RETAINER, VALVE SPRING | ||||
| 13741-68010 |
2H..HU40,50 |
12 | ||
| 13741A - LOCK, VALVE SPRING RETAINER | ||||
| 90913-03018 |
2H..HU40,50 |
24 | ||
| 13741A - LOCK, VALVE SPRING RETAINER | ||||
| 90913-03018 |
2H..HU40,50 |
24 | ||
| 13751 - LIFTER, VALVE | ||||
| 13751-47011 |
2H..HU40,50 STD |
12 | ||
| 13755-47011 |
2H..HU40,50 O/S 0.05 |
12 | ||
| 13781 - ROD, VALVE PUSH | ||||
| 13781-68010 |
2H..HU40,50 |
12 | ||
| 13781-31011 |
B,2B,3B..BU2#,3#,40 |
8 | ||
| 13801 - ARM SUB-ASSY, VALVE ROCKER, NO.1 | ||||
| 13811-68010 |
2H..HU40,50 |
12 | ||
| 13811-68011 |
2H..HU40,50 |
12 | ||
| 13801 - ARM SUB-ASSY, VALVE ROCKER, NO.1 | ||||
| 13811-68010 |
2H..HU40,50 |
12 | ||
| 13811-68011 |
2H..HU40,50 |
12 | ||
| 13801 - ARM SUB-ASSY, VALVE ROCKER, NO.1 | ||||
| 13811-68010 |
2H..HU40,50 |
12 | ||
| 13811-68011 |
2H..HU40,50 |
12 | ||
| 13801 - ARM SUB-ASSY, VALVE ROCKER, NO.1 | ||||
| 13811-68010 |
2H..HU40,50 |
12 | ||
| 13811-68011 |
2H..HU40,50 |
12 | ||
| 13801 - ARM SUB-ASSY, VALVE ROCKER, NO.1 | ||||
| 13811-68010 |
2H..HU40,50 |
12 | ||
| 13811-68011 |
2H..HU40,50 |
12 | ||
| 13801 - ARM SUB-ASSY, VALVE ROCKER, NO.1 | ||||
| 13811-68010 |
2H..HU40,50 |
12 | ||
| 13811-68011 |
2H..HU40,50 |
12 | ||
| 13801 - ARM SUB-ASSY, VALVE ROCKER, NO.1 | ||||
| 13811-68010 |
2H..HU40,50 |
12 | ||
| 13811-68011 |
2H..HU40,50 |
12 | ||
| 13801 - ARM SUB-ASSY, VALVE ROCKER, NO.1 | ||||
| 13811-68010 |
2H..HU40,50 |
12 | ||
| 13811-68011 |
2H..HU40,50 |
12 | ||
| 13801 - ARM SUB-ASSY, VALVE ROCKER, NO.1 | ||||
| 13811-68010 |
2H..HU40,50 |
12 | ||
| 13811-68011 |
2H..HU40,50 |
12 | ||
| 13801 - ARM SUB-ASSY, VALVE ROCKER, NO.1 | ||||
| 13811-68010 |
2H..HU40,50 |
12 | ||
| 13811-68011 |
2H..HU40,50 |
12 | ||
| 13801 - ARM SUB-ASSY, VALVE ROCKER, NO.1 | ||||
| 13811-68010 |
2H..HU40,50 |
12 | ||
| 13811-68011 |
2H..HU40,50 |
12 | ||
| 13801 - ARM SUB-ASSY, VALVE ROCKER, NO.1 | ||||
| 13811-68010 |
2H..HU40,50 |
12 | ||
| 13811-68011 |
2H..HU40,50 |
12 | ||
| 13801B - NUT, HEXAGON(FOR VALVE ADJUSTING) | ||||
| 90170-08094 |
2H..HU40,50 |
12 | ||
| 90170-10074 |
H,2H..HU30,40,50 |
12 | ||
| 90170-10074 |
B,2B,3B..BU2#,3#,40 |
12 | ||
| 13801C - SCREW, VALVE ADJUSTING | ||||
| 90913-05007 |
B,2B,3B..BU2#,3#,40 |
12 | ||
| 90913-05020 |
2H..HU40,50 |
12 | ||
| 90913-05007 |
H,2H..HU30,40,50 |
12 | ||
| 13801D - SPRING, COMPRESSION(FOR ROCKER ARM) | ||||
| 90501-16163 |
B,2B,3B..BU2#,3#,40 WD=1.6,CW=7.5 |
6 | ||
| 90501-16163 |
H,2H..HU30,40,50 WD=1.6,CW=7.5 |
6 | ||
| 13801D - SPRING, COMPRESSION(FOR ROCKER ARM) | ||||
| 90501-16163 |
B,2B,3B..BU2#,3#,40 WD=1.6,CW=7.5 |
6 | ||
| 90501-16163 |
H,2H..HU30,40,50 WD=1.6,CW=7.5 |
6 | ||
| 13801D - SPRING, COMPRESSION(FOR ROCKER ARM) | ||||
| 90501-16163 |
B,2B,3B..BU2#,3#,40 WD=1.6,CW=7.5 |
6 | ||
| 90501-16163 |
H,2H..HU30,40,50 WD=1.6,CW=7.5 |
6 | ||
| 13801D - SPRING, COMPRESSION(FOR ROCKER ARM) | ||||
| 90501-16163 |
B,2B,3B..BU2#,3#,40 WD=1.6,CW=7.5 |
6 | ||
| 90501-16163 |
H,2H..HU30,40,50 WD=1.6,CW=7.5 |
6 | ||
| 13801D - SPRING, COMPRESSION(FOR ROCKER ARM) | ||||
| 90501-16163 |
B,2B,3B..BU2#,3#,40 WD=1.6,CW=7.5 |
6 | ||
| 90501-16163 |
H,2H..HU30,40,50 WD=1.6,CW=7.5 |
6 | ||
| 13801D - SPRING, COMPRESSION(FOR ROCKER ARM) | ||||
| 90501-16163 |
B,2B,3B..BU2#,3#,40 WD=1.6,CW=7.5 |
6 | ||
| 90501-16163 |
H,2H..HU30,40,50 WD=1.6,CW=7.5 |
6 | ||
| 13901 - SHAFT SUB-ASSY, VALVE ROCKER, NO.1 | ||||
| 13901-68010 |
2H..HU40,50 |
1 | ||
| 13951 - SUPPORT, VALVE ROCKER, NO.1 | ||||
| 13951-68010 |
2H..HU40,50 |
1 | ||
| 13951-56010 |
B,2B,3B..BU2#,3#,40 |
1 | ||
| 13951A - BOLT(FOR ROCKER SUPPORT SET) | ||||
| 91611-60860 |
2H..HU40,50 *8-1.25PX60-30 |
14 | ||
| 13951B - SCREW OR BOLT(FOR VALVE ROCKER SHAFT LOCK) | ||||
| 91611-40816 |
2H..HU40,50 *8-1.25PX16-16 |
2 | ||
| 13951C - BOLT, STUD(FOR ROCKER SUPPORT) | ||||
| 92112-60828 |
2H..HU40,50 L=38,S=10&16 |
4 | ||
| 13952 - SUPPORT, VALVE ROCKER, NO.2 | ||||
| 13952-56010 |
B,2B,3B..BU2#,3#,40 |
3 | ||
| 13952-68010 |
2H..HU40,50 |
2 | ||
| 13952 - SUPPORT, VALVE ROCKER, NO.2 | ||||
| 13952-56010 |
B,2B,3B..BU2#,3#,40 |
3 | ||
| 13952-68010 |
2H..HU40,50 |
2 | ||
| 13953 - SUPPORT, VALVE ROCKER, NO.3 | ||||
| 13953-68010 |
2H..HU40,50 |
2 | ||
| 13953-56010 |
B,2B,3B..BU2#,3#,40 |
1 | ||
| 13953 - SUPPORT, VALVE ROCKER, NO.3 | ||||
| 13953-68010 |
2H..HU40,50 |
2 | ||
| 13953-56010 |
B,2B,3B..BU2#,3#,40 |
1 | ||
| 13954 - SUPPORT, VALVE ROCKER, NO.4 | ||||
| 13954-68010 |
2H..HU40,50 |
1 | ||
| 13955 - SUPPORT, VALVE ROCKER, NO.5 | ||||
| 13955-68010 |
2H..HU40,50 |
1 | ||
| Common parts | ||||
| 91611-61020 | ||||
| 91619-61250 | ||||
