BU40R-MRDT3 (1982)
Toyota Dyna
(8204-8408)BU40,HU40,50,WU40,50
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 45046 - END SUB-ASSY, TIE ROD, RH | ||||
| 45046-39145 |
BU40,HU40,50,WU40,50 |
1 | ||
| 45046-39095 |
BU2#,3#,HU30,JU20,RU2#,30 |
1 | ||
| 45046A - NUT, CASTLE(FOR TIE ROD END) | ||||
| 90171-18001 |
BU40,HU40,50,WU40,50 |
2 | ||
| 90171-14041 |
BU2#,3#,HU30,JU20,RU2#,30 |
2 | ||
| 45046C - SEAL, DUST(FOR TIE ROD END) | ||||
| 45479-36040 |
BU40,HU40,50,WU40,50 |
2 | ||
| 45479-36020 |
BU2#,3#,HU30,JU20,RU2#,30 |
2 | ||
| 45047 - END SUB-ASSY, TIE ROD, LH | ||||
| 45047-39105 |
BU40,HU40,50,WU40,50 |
1 | ||
| 45047-39065 |
BU2#,3#,HU30,JU20,RU2#,30 |
1 | ||
| 45440 - LINK ASSY, STEERING DRAG | ||||
| 45441-39095 |
BU40,HU40,50,WU40..RHD |
1 | ||
| 45447 - SEAL, DRAG LINK DUST | ||||
| 45447-36050 |
BU40,HU40,50,WU40..RHD |
2 | ||
| 45447 - SEAL, DRAG LINK DUST | ||||
| 45447-36050 |
BU40,HU40,50,WU40..RHD |
2 | ||
| 45460 - ROD ASSY, TIE, RH | ||||
| 45460-39185 |
BU40,HU40,50,WU40,50 |
1 | ||
| 45473 - SEAT, BALL STUD | ||||
| 45473-56010 |
BU40,HU40,50,WU40,50 |
4 | ||
| 45473-55010 |
BU2#,3#,HU30,JU20,RU2#,30 |
4 | ||
| 45473 - SEAT, BALL STUD | ||||
| 45473-56010 |
BU40,HU40,50,WU40,50 |
4 | ||
| 45473-55010 |
BU2#,3#,HU30,JU20,RU2#,30 |
4 | ||
| 45473 - SEAT, BALL STUD | ||||
| 45473-56010 |
BU40,HU40,50,WU40,50 |
4 | ||
| 45473-55010 |
BU2#,3#,HU30,JU20,RU2#,30 |
4 | ||
| 45473 - SEAT, BALL STUD | ||||
| 45473-56010 |
BU40,HU40,50,WU40,50 |
4 | ||
| 45473-55010 |
BU2#,3#,HU30,JU20,RU2#,30 |
4 | ||
| 45475 - SEAT, STEERING LINK JOINT SPRING | ||||
| 45475-55030 |
BU40,HU40,50,WU40,50 |
2 | ||
| 45475 - SEAT, STEERING LINK JOINT SPRING | ||||
| 45475-55030 |
BU40,HU40,50,WU40,50 |
2 | ||
| 45475B - PLUG, STRAIGHT SCREW(FOR STEERING LINK JOINT) | ||||
| 90340-33001 |
BU40,HU40,50,WU40,50 |
2 | ||
| 45475B - PLUG, STRAIGHT SCREW(FOR STEERING LINK JOINT) | ||||
| 90340-33001 |
BU40,HU40,50,WU40,50 |
2 | ||
| 45476 - PLATE, TURNING STOPPER | ||||
| 45476-56010 |
BU40,HU40,50,WU40,50 |
2 | ||
| 45476 - PLATE, TURNING STOPPER | ||||
| 45476-56010 |
BU40,HU40,50,WU40,50 |
2 | ||
| 45477 - PLATE, STOPPER | ||||
| 45477-56010 |
BU40,HU40,50,WU40,50 |
2 | ||
| 45477 - PLATE, STOPPER | ||||
| 45477-56010 |
BU40,HU40,50,WU40,50 |
2 | ||
| 45611 - ARM, STEERING KNUCKLE, RH | ||||
| 45601-39095 |
BU40,HU40,50,WU40..RHD |
1 | ||
| 45611D - NUT(FOR STEERING KNUCKLE ARM) | ||||
| 90171-27001 |
BU40,HU40,50,WU40,50 |
2 | ||
| 90171-22038 |
BU2#,3#,HU30,JU20,RU2#,30 |
2 | ||
| 45611D - NUT(FOR STEERING KNUCKLE ARM) | ||||
| 90171-27001 |
BU40,HU40,50,WU40,50 |
2 | ||
| 90171-22038 |
BU2#,3#,HU30,JU20,RU2#,30 |
2 | ||
| 45612 - ARM, STEERING KNUCKLE, LH | ||||
| 45612-39065 |
BU40,HU40,50,WU40..RHD |
1 | ||
| Common parts | ||||
| 90101-12073 | ||||
| 94115-71200 | ||||
| 94512-01200 | ||||
| 95381-04035 | ||||
| 95381-05040 | ||||
| 96456-00609 | ||||
ILLUST NO. 2 OF 3(0110-0610)RHD ; (0610-0801)SA ; (0801- )WU410,XZU420,430..75T,85T..SA
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| Common parts | ||||
| 90029-01001 | ||||
| 90029-34002 | ||||
| 94115-51200 | ||||
| 94531-01200 | ||||
| 96711-35042 | ||||
ILLUST NO. 1 OF 3(0110-0610)RHD ; (0610-0801)SA ; (0801- )WU410,XZU420,430..75T,85T..SA
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| Common parts | ||||
| 90031-16061 | ||||
| 90105-14002 | ||||
| 90170-30001 | ||||
| 90204-30040 | ||||
| 90901-01004 | ||||
| 94130-01401 | ||||
| 94130-01601 | ||||
| 94531-01400 | ||||
| 94531-01600 | ||||
