GRS182L-DETUKC (2005)

Toyota Crown (China)

Production Feb 2005 - Nov 2009
Engine 3GRFE
Transmission 6FC ATM
Displacement 2500cc
Power 168 HP (125 kW)

(0502- )

Click highlighted areas on diagram

diagram 11296C 69339C 74515A 74571 74579A 74596A 74598A 74751 87528 87529B 88723E 89616
Part # Description Qty Price
11296C - LABEL, ENGINE SERVICE INFORMATION
11296-27020

3GRFE,5GRFE..GRS18#

 1
69339C - LABEL, CHILD PROTECTOR INFORMATION
69339-52020

GRS18#

 2
69339-06030

GRS18#

 2
74515A - PLATE, THEFT WARNING
74515-0N010

GRS18#

 2
74515-30020

GRS18#

 2
74571 - PLATE, BRAKE FLUID CAUTION
47288-60010

GRS18#

 1
74579A - LABEL, UNLEADED FUEL INFORMATION
74579-30030

GRS18#

 1
74596A - LABEL, SIDE AIR BAG CAUTION
74596-12030

GRS182..ROY,ROYG

 2
74598A - LABEL, PASSENGER AIR BAG CAUTION
74598-06040

GRS18#

 1
74751 - LABEL, TIRE PRESSURE INFORMATION
42661-30710

GRS18#

 1
42661-0N010

GRS18#

 1
87528 - LABEL, AIR CONDITIONER INFORMATION
87528-02010

GRS18#

 1
87529B - LABEL, A/C FILTER INFORMATION
87529-0D020

GRS18#

 1
88723E - LABEL, COOLER SERVICE CAUTION
88723-0D020

GRS18#

 1
89616 - LABEL, PUSH START INFORMATION
89616-30020

GRS182..ROY,ROYG

 1
