RS110R-SEJBS (1979)
Toyota Crown
(7909- )5R
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 16261 - HOSE, WATER BY-PASS | ||||
| 16261-44010 |
5R..RS110 |
1 | ||
| 16261A - CLAMP OR CLIP, HOSE(FOR WATER BY-PASS HOSE) | ||||
| 96112-10240 |
5R..RS110 ID=24 |
2 | ||
| 96112-10250 |
5R..RS110 ID=25 |
2 | ||
| 16261A - CLAMP OR CLIP, HOSE(FOR WATER BY-PASS HOSE) | ||||
| 96112-10240 |
5R..RS110 ID=24 |
2 | ||
| 96112-10250 |
5R..RS110 ID=25 |
2 | ||
| 16331 - OUTLET, WATER | ||||
| 16331-44020 |
5R..RS110 |
1 | ||
| 16331A - THERMOSTAT | ||||
| 90916-03034 |
5R..RS110 *WAX 82-95,*(F) |
1 | ||
| 90916-03037 |
5R..RS110 *WAX 82-95 |
1 | ||
| 16333 - HOUSING, WATER OUTLET | ||||
| 16333-44012 |
5R..RS110 |
1 | ||
| 16341 - GASKET, WATER OUTLET | ||||
| 16341-41010 |
5R..RS110 |
1 | ||
| 16341-38010 |
5R..RS110 |
1 | ||
| 16341-41010 |
5R..RS110 |
1 | ||
| 16343 - GASKET, WATER OUTLET HOUSING | ||||
| 16343-44010 |
5R..RS110 |
1 | ||
| 16361 - FAN | ||||
| 16361-44032 |
5R..RS110 5 BLADES |
1 | ||
| 16361A - BELT, V(FOR FAN & ALTERNATOR) | ||||
| 99322-00930 |
5R..RS110 L=930 |
1 | ||
| 16361A - BELT, V(FOR FAN & ALTERNATOR) | ||||
| 99322-00930 |
5R..RS110 L=930 |
1 | ||
| 16381 - BAR, FAN BELT ADJUSTING | ||||
| 16381-44011 |
5R..RS110 |
1 | ||
| 16400 - RADIATOR ASSY | ||||
| 16400-44210 |
5R..RS110 |
1 | ||
| 16400B - PLUG, RADIATOR DRAIN COCK | ||||
| 90910-09054 |
5R..RS110 |
1 | ||
| 16400F - PACKING(FOR RADIATOR DRAIN COCK) | ||||
| 96710-01007 |
5R..RS110 |
1 | ||
| 16401 - CAP SUB-ASSY, RADIATOR | ||||
| 16401-36011 |
5R..RS110 |
1 | ||
| 16470 - TANK ASSY, RADIATOR RESERVE | ||||
| 16480-41130 |
5R..RS110 |
1 | ||
| 16470B - CLAMP OR CLIP(FOR RADIATOR RESERVE TANK HOSE) | ||||
| 90467-11085 |
5R..RS110 |
2 | ||
| 16470B - CLAMP OR CLIP(FOR RADIATOR RESERVE TANK HOSE) | ||||
| 90467-11085 |
5R..RS110 |
2 | ||
| 16471 - CAP SUB-ASSY, RESERVE TANK | ||||
| 16405-41030 |
5R..RS110 |
1 | ||
| 16571 - HOSE, RADIATOR, INLET | ||||
| 16571-44120 |
5R..RS110 |
1 | ||
| 16571A - CLAMP OR CLIP, HOSE(FOR RADIATOR INLET) | ||||
| 90467-37001 |
5R..RS110 WATER OUTLET SIDE,ID=37 |
1 | ||
| 96111-10430 |
5R..RS110 RADIATOR SIDE,ID=43 |
1 | ||
| 16571A - CLAMP OR CLIP, HOSE(FOR RADIATOR INLET) | ||||
| 90467-37001 |
5R..RS110 WATER OUTLET SIDE,ID=37 |
1 | ||
| 96111-10430 |
5R..RS110 RADIATOR SIDE,ID=43 |
1 | ||
| 16572 - HOSE, RADIATOR, OUTLET | ||||
| 16572-44040 |
5R..RS110 RADIATOR SIDE |
1 | ||
| 16573-44010 |
5R..RS110 PUMP SIDE |
1 | ||
| 16572 - HOSE, RADIATOR, OUTLET | ||||
| 16572-44040 |
5R..RS110 RADIATOR SIDE |
1 | ||
| 16573-44010 |
5R..RS110 PUMP SIDE |
1 | ||
| 16572A - CLAMP OR CLIP, HOSE(FOR RADIATOR OUTLET NO.1) | ||||
| 96111-10460 |
5R..RS110 |
2 | ||
| 16572A - CLAMP OR CLIP, HOSE(FOR RADIATOR OUTLET NO.1) | ||||
| 96111-10460 |
5R..RS110 |
2 | ||
| 16572C - CLAMP OR CLIP, HOSE(FOR RADIATOR OUTLET NO.2) | ||||
| 96111-10460 |
5R..RS110 |
2 | ||
| 16572C - CLAMP OR CLIP, HOSE(FOR RADIATOR OUTLET NO.2) | ||||
| 96111-10460 |
5R..RS110 |
2 | ||
| 16577 - PIPE, RADIATOR, NO.7 | ||||
| 16577-44150 |
5R..RS110 |
1 | ||
| 16701 - SHROUD SUB-ASSY, FAN | ||||
| 16711-44040 |
5R..RS110 |
1 | ||
| 16712 - SHROUD, FAN, NO.2 | ||||
| 16712-44040 |
5R..RS110 |
1 | ||
| 16715 - BRACKET, FAN SHROUD | ||||
| 16715-41010 |
5R..RS110 |
1 | ||
| 88310A - BELT, V (COOLER COMPRESSOR TO CRANKSHAFT PULLEY), NO.1 | ||||
| 99313-51070 |
RS110 |
1 | ||
| Common parts | ||||
| 90119-08051 | ||||
| 90468-06013 | ||||
| 91611-41050 | ||||
| 91611-60620 | ||||
| 91611-60845 | ||||
| 91611-60865 | ||||
| 91655-40820 | ||||
| Linked diagrams | ||||
| 1603 | ||||
| 4503 | ||||
| 8719 | ||||
