MS135R-AESQF (1987)
Toyota Crown
Production
Sep 1987
-
Oct 1991
Engine
7MGE
Transmission
4HC ATM
Displacement
2500cc
Power
168 HP (125 kW)
(8709- )MS135
Click highlighted areas on diagram
ECT
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 35517 - PLATE, TRANSMISSION WIRE LOCK | ||||
| 35517-30010 |
MS135 |
1 | ||
| 82125B - WIRE, TRANSMISSION | ||||
| 82125-30070 |
MS135 |
1 | ||
| 84720 - SWITCH ASSY, PATTERN SELECT | ||||
| 84720-30110 |
MS135..4HC |
1 | ||
| 84720 - SWITCH ASSY, PATTERN SELECT | ||||
| 84720-30110 |
MS135..4HC |
1 | ||
| 85420 - SOLENOID ASSY, TRANSMISSION | ||||
| 85420-22080 |
MS135 NO.1 & NO.2 |
2 | ||
| 85420-30110 |
MS135 NO.3,AISIN |
1 | ||
| 85420-30120 |
MS135 NO.3,NIPPNDENSO |
1 | ||
| 85420-30120 |
MS135 NO.3,NIPPONDENSO |
1 | ||
| 85420-12020 |
MS135 NO.1 & NO.2 |
2 | ||
| 85420 - SOLENOID ASSY, TRANSMISSION | ||||
| 85420-22080 |
MS135 NO.1 & NO.2 |
2 | ||
| 85420-30110 |
MS135 NO.3,AISIN |
1 | ||
| 85420-30120 |
MS135 NO.3,NIPPNDENSO |
1 | ||
| 85420-30120 |
MS135 NO.3,NIPPONDENSO |
1 | ||
| 85420-12020 |
MS135 NO.1 & NO.2 |
2 | ||
| 85420 - SOLENOID ASSY, TRANSMISSION | ||||
| 85420-22080 |
MS135 NO.1 & NO.2 |
2 | ||
| 85420-30110 |
MS135 NO.3,AISIN |
1 | ||
| 85420-30120 |
MS135 NO.3,NIPPNDENSO |
1 | ||
| 85420-30120 |
MS135 NO.3,NIPPONDENSO |
1 | ||
| 85420-12020 |
MS135 NO.1 & NO.2 |
2 | ||
| 85420D - RING, O (FOR TRANSMISSION SOLENOID) | ||||
| 90301-06004 |
MS135 |
3 | ||
| 85420D - RING, O (FOR TRANSMISSION SOLENOID) | ||||
| 90301-06004 |
MS135 |
3 | ||
| 85420D - RING, O (FOR TRANSMISSION SOLENOID) | ||||
| 90301-06004 |
MS135 |
3 | ||
| 89411C - SENSOR, SPEED | ||||
| 89411-22061 |
MS135 |
1 | ||
| 89411-22060 |
MS135 |
1 | ||
| 89414 - ROTOR, SENSOR | ||||
| 89414-30020 |
MS135 |
1 | ||
| 89414-30021 |
MS135 |
1 | ||
| 89530 - COMPUTER ASSY, TRANSMISSION CONTROL | ||||
| 89530-30470 |
MS135..RHD |
1 | ||
| Common parts | ||||
| 82711-12200 | ||||
| 90105-06049 | ||||
| 90159-40159 | ||||
| 90280-03005 | ||||
| 90520-30002 | ||||
| 91611-60616 | ||||
| 91611-60816 | ||||
| 93567-55016 | ||||
| 96721-24011 | ||||
| 96721-24018 | ||||
