JZS155L-AEMQF (1995)

Toyota Crown

Production Dec 1995 - Jul 1997
Engine 2JZGE
Transmission 5F MTM
Displacement 2500cc
Power 168 HP (125 kW)

(9512- )5F

Click highlighted areas on diagram

diagram 31126 31204 31210 31230 31232A 31232A 31236B 31250 33311W 9011908026
Part # Description Qty Price
31126 - BOOT, CLUTCH RELEASE FORK
31126-22050

JZS155..5F

 1
31204 - FORK SUB-ASSY, CLUTCH RELEASE
31204-22050

JZS155..5F

 1
31210 - COVER ASSY, CLUTCH
31210-30261

JZS155..5F

 1
31230 - BEARING ASSY, CLUTCH RELEASE
31230-22100

JZS155..5F

 1
31232A - CLIP, RELEASE BEARING HUB
31232-22020

JZS155..5F

TYPE A:REFER TO ILLUSTRATION

 1
31232A - CLIP, RELEASE BEARING HUB
31232-22020

JZS155..5F

TYPE A:REFER TO ILLUSTRATION

 1
31236B - SUPPORT, RELEASE FORK
31236-14010

JZS155..5F

 1
31250 - DISC ASSY, CLUTCH
31250-30390

JZS155..5F

 1
33311W - BEARING (FOR INPUT SHAFT)
90363-12002

JZS155..5F

 1
Common parts
90119-08026
