RX60L-XEMNCC (1982)

Toyota Cressida

Production Aug 1982 - Aug 1983
Engine 21RC
Transmission 5F MTM
Displacement 2500cc
Power 168 HP (125 kW)

(8009- )

Click highlighted areas on diagram

diagram 11291 11293 11294 11296 11298 11299 17627 17628 17700C 17700C 17700D 17792 23923
Part # Description Qty Price
11291 - PLATE, ENGINE NAME
11291-37020

21R..RX60

21R

 1
11291-37030

21RC..RX60

21R-C

 1
11294 - PLATE, ENGINE CAUTION, NO.2
11294-34020

21RC..RX60

 1
11298 - PLATE, EMISSION CONTROL INFORMATION
11298-37021

21RC..RX60

 1
17627 - PLATE, AIR PUMP CAUTION, NO.1
90917-07066

21RC,5ME..MX62,RX60

 1
17700D - PLATE, ENGINE CAUTION
11293-37020

21R..RX60

 1
11293-37030

21RC..RX60

 1
17792 - PLATE, ENGINE VACUUM HOSE INFORMATION
17792-37060

21RC..RX60

 1
